Page 11
WARNING This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the To prevent fire or shock hazard, do not literature accompanying the appliance. expose the unit to rain or moisture. WARNING: THIS WARNING IS APPLICABLE FOR USA To avoid electrical shock, do not open the ONLY.
Page 12
For the customers in Europe Attention – when the product is installed in rack: WARNING 1. Prevention against overloading of branch circuit This is a Class A product. In a domestic environment, this When this product is installed in a rack and is supplied product may cause radio interference in which case the power from an outlet on the rack, please make sure user may be required to take adequate measures.
Table of Contents Precautions ................... 4(E) Overview ....................5(E) Location and Function of Parts ............6(E) Front Panel ..................6(E) Rear Panel..................7(E) Specifictations ..................9(E) 3(E)
Do not damage the power cord Failure to ground the unit can result in electrical shock. A damaged power cord can cause a fire or electrical If the unit cannot be grounded safely, contact a Sony shock. representative or the dealer where you purchased the •...
Overview The SIU-80 is a system interface unit in which you can install various signal processing boards needed to configure an A/V server system. The unit has the following features. Eight slots for installing optional boards The units has eight slots for installing optional boards. They allow you to install an appropriate combination of the following boards for controlling disk drive units or for processing various signals.
Front Panel 3 Status indicator A 4 Status indicator B 1 POWER A switch 2 POWER B switch a) Provided only for the SIU-80 with the optional BKSI-PS80 installed. 1 POWER A (main power) switch Indication Fault Press the side of the switch marked “1” to turn the unit...
1 REF IN (reference video signal input) 4 ADDRESS switch (4-switch DIP) connectors (BNC type) When the system incorporates more than one SIU-80 Connect a reference video signal to one of these unit, use this switch to set the unit’s ID address (0 to connectors.
Page 18
5 RS232C (data communication) connector (D-sub 25-pin) Use this connector for data communications. When a personal computer in which Sony ISR software is installed is connected to this connector, you can use the software to monitor the state of the unit as well as the boards (excluding the BKSI-2070/2080) installed in the unit.
Specifications General Optional accessory Power requirements BKSI-PS80 Backup Power Supply 100 to 240 V AC, 50/60 Hz Current consumption BKSI-PS80 Backup Power Supply 5 A to 2 A (at maximum load) specifications Supplied current 1. +5 V DC: 47A 2. –5.2 V DC: 20A Power requirements The sum of 1 and 2 must not 100 to 240 V AC, 50/60 Hz...
Page 21
The material contained in this manual consists of information that is the property of Sony Corporation and is intended solely for use by the purchasers of the equipment described in this manual. Sony Corporation expressly prohibits the duplication of any...
