Grizzly H8175 Instruction Sheet

EYE/SKIN BURN HAZARD!
Wear safety glasses and
protective clothing when
using this tool!
Always disconnect tool from
air to prevent unexpected
operation during service!
DO NOT EXCEED 100 PSI!
Personal
occur.
ELECTRICITY
Electrocution or fire could
result if this tool is not
properly grounded. Do not
remove the ground pin.
Specifications
Air Regulator Inlet Size ............................
Operating Temperature ................... 284°F–428°F
Maximum Temperature ...............................446°F
Operating Air Pressure .............................. 90 PSI
Glue Stick Diameter .........................................
Cord Length .................................................... 2 ft.
Weight ...........................................................3 lbs
Operation
1. Connect the glue gun to the air regulator and
connect the air regulator to the air supply.
2. Plug the glue gun into a grounded outlet and
turn it ON with the power switch located at the
base of the glue gun.
3.
Allow the gun to heat up for approximately 3–5
minutes.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROvAL OF GRIZZLY INDUSTRIAL, INC.
INJURY HAZARD!
injury could
HAZARD!
⁄ " NPT
1
4
COPyRIGHT © MAy, 2008 By GRIzzLy INDuSTRIAL, INC.
#JM10780 PRINTED IN TAIWAN
MODEL H8175
PROFESSIONAL
PNEUMATIC GLUE GUN
INSTRUCTION SHEET
Case
Air
Regulator
Screwdriver
4. Insert a
of the gun.
5.
Once the gun has fully heated, slowly squeeze
the trigger until the melted material begins to
flow from the nozzle.
Note: When hot, rest the gun with the tip fac-
ing down, as shown in Figure 1, to prevent
⁄ "
1
2
melted glue from escaping the chamber and
increasing the risk of fire or personal injury.
6. After the gluing operation is complete, allow
the glue gun to fully cool before storing it.
Glue sticks may remain in the glue gun when
it is not in use and be re-melted when the
glue gun is used again.
Note: Never pull the glue stick out through
the back of the gun or it may damage the
feed mechanism. Cut off the extra portion of
the glue and feed the remainder through the
glue gun.
Extra Nozzles
Figure 1. Model H8175.
⁄ " diameter glue stick into the back
1
2
Gun
