SERVICE MANUAL
MODEL
KDF-E42A11E
All manuals and user guides at all-guides.com
COMMANDER
DEST
RM-ED002
AEP
KDF-E42/50A11E
MODEL
KDF-E50A11E
LCD PROJECTION TV
- 1 -
KDF-E42/50A11E
RM-ED002
LE-4B
CHASSIS
COMMANDER
DEST
RM-ED002
AEP
RM-ED002

Advertisement

Table of Contents
loading

Related Manuals for Sony KDF-E42A11E

Summary of Contents for Sony KDF-E42A11E

  • Page 1 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 SERVICE MANUAL LE-4B CHASSIS MODEL MODEL COMMANDER DEST COMMANDER DEST KDF-E42A11E KDF-E50A11E RM-ED002 RM-ED002 KDF-E42/50A11E RM-ED002 LCD PROJECTION TV - 1 -...

  • Page 2: Table Of Contents

    DUE TO LIVE CHASSIS, THE CHASSIS OF THIS RECEIVER IS PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE DIRECTLY CONNECTED TO THE POWER LINE. THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.

  • Page 3: Caution

    Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com - 3 -...

  • Page 4: Specifications

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 . s l . s l . s l n i l e i l . s l l a i a j i . o i n i l i n i y t i - 4 -...

  • Page 5: Connectors

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 21 pin connector Pin No Signal Signal level Audio output B Standard level : 0.5V rms (right) Output impedence : Less than 1kohm* Audio input B Standard level : 0.5V rms (right) Output impedence : More than 10kohm* Audio output A...

  • Page 6: Self Diagnosis Function

    All manuals and user guides at all-guides.com KDF-E42/50A12U RM-ED002 SECTION 1 SELF DIAGNOSIS FUNCTION LE-4B Self Diagnostic Software LE-4B chassis TV’s contain a self diagnosis function. In the event of an error occurring, the STANDBY LED indicator will automatically begin to flash.
  • Page 7 All manuals and user guides at all-guides.com KDF-E42/50A12U RM-ED002 3. STOPPING THE STANDBY INDICATOR FLASH Turn off the power switch on the TV to stop the STANDBY indicator from flashing. 4. SELF-DIAGNOSTIC SCREEN DISPLAY For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes off” that cannot be confirmed, it is possible to bring up past occurrences of failure on the screen for confirmation.

  • Page 8: General

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 SECTION 2 GENERAL Using the Menu Getting Started – 8 –...
  • Page 9 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Using the Menu – 9 –...
  • Page 10 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Using the Menu – 10 –...
  • Page 11 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 – 11 –...
  • Page 12 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Using the Menu Using the Menu – 12 –...
  • Page 13 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Using the Menu – 13 –...
  • Page 14 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Using the Menu – 14 –...
  • Page 15 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Using the Menu – 15 –...
  • Page 16 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Using Optional Equipment – 16 –...
  • Page 17 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Using Optional Equipment – 17 –...
  • Page 18 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Additional Information – 18 –...
  • Page 19 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Additional Information – 19 –...
  • Page 20 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Additional Information – 20 –...
  • Page 21 All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 Additional Information – 21 –...

  • Page 22: Disassembly

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 SECTION 3 DISASSEMBLY 3-1. REAR COVER REMOVAL 3-2. PILLAR REMOVAL 3-3. MAIN BRACKET COVER REMOVAL 3-4. MAIN BRACKET REMOVAL – 22 –...

  • Page 23: Service Position

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 3-5. SERVICE POSITION 3-6. N, JB, AG BOARDS 3-7. POWER BLOCK REMOVAL 3-8. OPTICAL UNIT – 23 –...

  • Page 24: C Board Removal

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 3-9. C BOARD REMOVAL 3-10. SCREEN, MIRROR BLOCK ASSEMBLY REMOVAL – 24 –...

  • Page 25: Mirror Cover Block Assembly Removal

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 3-11. MIRROR COVER BLOCK ASSEMBLY REMOVAL 3-12. CONTRAST SCREEN, DIFFUSION PLATE REMOVAL – 25 –...

  • Page 26: Mirror Removal

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 3-13. MIRROR REMOVAL 3-14. H3 REMOVAL 3-15. SPEAKER REMOVAL – 26 –...

  • Page 27: Set-Up Adjustments

    All manuals and user guides at all-guides.com KF-E42/50A11E RM-ED002 SECTION 4 SET-UP ADJUSTMENTS 4-1-3. SECAM auto adjustment (CVBS) 4-1. Signal Adjustment 1. Select AV1 and input SECAM signal. (SECAM CVBS: CB 75%Y/ Service adjustments to this model can be performed using the 75%C from signal generator).

  • Page 28: White Balance Adjustment (C/O)

    All manuals and user guides at all-guides.com KF-E42/50A11E RM-ED002 4-2-2. White Balance adjustment (C/O) 4-2-3. SECAM White Balance adjustment (H/L) 1. Select AV0. 1. Select AV0. 2. Change the TV to Custom Mode and set the following registers by 2. Change the TV to Custom Mode and set the following registers by sending “TT54”.

  • Page 29: Secam White Balance Adjustment (C/O)

    All manuals and user guides at all-guides.com KF-E42/50A11E RM-ED002 4-2-4. SECAM White Balance adjustment (C/O) 4-3. TEST TEST MODE 1. Select AV0. Test Test Mode is available in Service Mode, OSD ‘TT’ appears. The 2. Change the TV to Custom Mode and set the following registers by functions described below are available by selecting the two numbers.

  • Page 30: Diagrams 5-1. Block Diagram (1)

    All manuals and user guides at all-guides.com 5-1. BLOCK DIAGRAMS (1) IC6210 CN3001 Q6201 FAN B PW Q6202 FAN B PROT FAN LAMP POW AG ( FAN LAMP PROT MAIN POWER SUPPLY, TUNER, AUDIO AMPLIFIER CN3000 LAMP COV IC1602 D3001 PH1601 11V voltage sensor LAMP CONV...

  • Page 31: Block Diagram (2)

    All manuals and user guides at all-guides.com 5-1. BLOCK DIAGRAMS (2) IC2501 R DRIVE CN2551 IC2614 PAWN SID OUT P SIG-OB Q2502 D-A 0 SID OUT IC3200 B OUT-0 Q2504 SIG B6 BIN 0 B OUT 2 LVDS Receiver B-SIG 01 D-A 1 SH OUT 1 SIG B5...

  • Page 32: Block Diagram (3)

    All manuals and user guides at all-guides.com 5-1. BLOCK DIAGRAMS (3) IC5500 IC1002 Video Processor Memory OTP (Software) IC5000 Video Processor MVREF N13 VREF CN9511 B-PC PB_B2 G_PC JB 1/2 ( Audio Processor, AV Switch, Chroma Y_G2 M5 BA1 R_PC Decoder, Video Processor, Main Micro PR_P2 CLKE...

  • Page 33: Block Diagram (4)

    All manuals and user guides at all-guides.com 5-1. BLOCK DIAGRAMS (4) CN9501 CN8551 (Digital Only) IC9500 AV Switch SCL_TV Q9607 (Digital Only) SDA_TV Q9606 (Digital Only) JB 2/2 ( N_RST Audio Processor, AV Switch, Chroma To Sheet 1 DIGITAL_R Decoder, Video Processor, Main Micro S2-1 S2-1 Q9500...

  • Page 34: Block Diagram (5)

    All manuals and user guides at all-guides.com 5-1. BLOCK DIAGRAMS (5) IC3100 IC3314 MULTIMEDIA PROCESSOR OCTAL BUFFER DADD4 N 1/3 ( EMMA RDATA (9) RDATA (9) nBYPASS-EN nBYPASS-EN DADD4 RDATAA9/HSD1 Digital I/F !OE1! !OE2! DADD5 EMMA RDATA (2) RDATA (2) DADD5 RDATAA2 IN-TS-BCLK...

  • Page 35: Block Diagram (6)

    All manuals and user guides at all-guides.com 5-1. BLOCK DIAGRAMS (6) CN3607 FWEB FWEB FOEB FOEB N 2/3 ( GCB0 GCSB Digital I/F FCSB0 FCSB nRDY-DAMON nRDY DAMON-INTB nINTA nDAMON-RST nRST JIG-MODE TDX3B 48 TX2 CN3608 RDX3B RDATA [11] RDATA [11] RADD [0] 52 ADD [0] nMASTER_RESET...

  • Page 36: Block Diagram (7)

    All manuals and user guides at all-guides.com 5-1. BLOCK DIAGRAMS (7) N 3/3 ( Digital I/F IC3801 IC3815 IC3303 GP OUTPUT ???? NAND GATES CI-PWR-EN GCSB3 GCSB3 H1 ( nPCARD-EN CI-EN Front Buttons RDATA (15) nCIPC-EN CI-EN nPCARD-EN nRESET RDATA (14) nCIPC-DATA-EN !CL! nPC-EN...

  • Page 37: Block Diagram (8)

    All manuals and user guides at all-guides.com 5-1. BLOCK DIAGRAMS (8) 5-2. CIRCUIT BOARD LOCATION Reference Information RESISTOR : METAL FILM : SOLID FPRD : NON FLAMMABLE CARBON CN4302 B_PC Q4301 FUSE : NON FLAMMABLE FUSIBLE G_PC R_PC CN4300 : NON FLAMMABLE METAL OXIDE Q4302 V_PC R_PC...

  • Page 38: Ag Board Schematic Diagram

    All manuals and user guides at all-guides.com 0.01 0.01 10UH UDZS-33B 0.01 TO H3 BOARD CN4305 TO N BOARD CN3403 R2026 D2005 MMDL914T1 C2511 120K R2027 470K C2003 TO N BOARD CN3503 AGC DEFEAT DAN202K 0.22 BTP-DC411 TO N BOARD CN3404 20PF 0.22...
  • Page 39 All manuals and user guides at all-guides.com FSS BTP-AC431 PQ1CG2032FZ 2.5V REGULATOR 3.3V REGULATOR 1.3K 1.2K 1000 10UH TO OPTICS BLOCK 100UH 1000 6.3V C3004 0.01 D2S4MF PTZ-TE25-3.9B 68PF 68PF C3000 0.01 STBY +7V C3001 0.01 TO LAMP DRIVER C3002 0.01 JR6224 C3003...
  • Page 40 All manuals and user guides at all-guides.com 1.1UH 1.1UH 0.0047 500V POWER SUPPLY PS1600 FCH10A06 FCH10A06 11V VOLTAGE SENSOR DTA144EK COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL ~ AG Board Schematic Diagram [ Main Power Supply, Tuner, Audio Amplifier ] Page 3/3 ~ - 40 -...

  • Page 41: Ag Printed Wiring Board

    All manuals and user guides at all-guides.com ~ AG Printed Wiring Board Conductor Side A ~ - 41 -...
  • Page 42 All manuals and user guides at all-guides.com ~ AG Printed Wiring Board Conductor Side B ~ - 42 -...

  • Page 43: C Board Schematic Diagram

    All manuals and user guides at all-guides.com COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL LVDS RECEIVER TO JB BOARD CN9510 TO JB BOARD CN9506 TO AG BOARD CN6208 LCD PANEL DRIVER BOARD ~ C Board Schematic Diagram [ LCD Panel Driver Board ] Page 1/4 ~ - 43 -...
  • Page 44 All manuals and user guides at all-guides.com COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL TEMPERATURE SENSOR TC74VHCT541AFT OCTAL BUS BUFFER TC74VHCT541AFT OCTAL BUS BUFFER ~ C Board Schematic Diagram [ LCD Panel Driver Board ] Page 2/4 ~ - 44 -...
  • Page 45 All manuals and user guides at all-guides.com COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL HN1B01FU-TE85R HN1B01FU-TE85R 3.3K PQ20VZ1UJ00H 13.5V REGULATOR ~ C Board Schematic Diagram [ LCD Panel Driver Board ] Page 3/4 ~ - 45 -...
  • Page 46 All manuals and user guides at all-guides.com UDZS-5.6B DUAL OPERATIONAL AMP DUAL OPERATIONAL AMP DUAL OPERATIONAL AMP ~ C Board Schematic Diagram [ LCD Panel Driver Board ] Page 4/4 ~ - 46 -...

  • Page 47: C Printed Wiring Board

    All manuals and user guides at all-guides.com ~ C Printed Wiring Board Conductor Side A ~ ~ C Printed Wiring Board Conductor Side B ~ - 47 -...

  • Page 48: Jb Board Schematic Diagram

    All manuals and user guides at all-guides.com JB.-LE4B 1/9 AUDIO PROCESSOR, AV SWITCH, CHROMA DECODER, VIDEO PROCESSOR, MAIN MICRO Q7810 R7854 MSD601-RST1 HP_DET C7832 R7841 R7855 L7805 R7864 R7865 CN9513 8.2uH D9602 R7840 C7834 R7856 UDZSTE-179.1B C7824 C7849 100p R7858 120p HP_DET HP_DET...
  • Page 49 All manuals and user guides at all-guides.com JB.-LE4B A5V_1 A5V_1 R2511 1/10W B_SCART2 R2513 C2550 R2512 0.47 1/10W B_SCART1 1/10W C2551 R2558 C2540 0.47 R2565 CHIP A5V_1 1/10W R2559 CHIP R_IN L2500 A5V_1 R2560 CHIP 10uH B_IN R2576 CHIP G_IN R2580 R2561 CHIP...
  • Page 50 All manuals and user guides at all-guides.com JB.-LE4B VDR004 R_OUT1 R9507 C9512 C9500 R9503 R9505 C9539 D9522 0.022 470k 470p 1/10W 1/10W 1/10W RIN1 R9504 C9513 R9516 VDR005 C9501 R9506 C9654 R9744 R9745 R9749 470k 0.001 D9523 1/10W 1/10W CHIP Q9603 1/10W 1/10W...
  • Page 51 All manuals and user guides at all-guides.com JB.-LE4B COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL R8000 R8001 C8500 CHIP FAN_PROT R8538 R8531 COINCIDENCE SCL_5V R8539 R8532 AGC_DEFEAT DAC4 SDA_5V R8597 SP_MUTE DAC3 SDA2 STBY5V R9770 FAN_CTL DAC2 SDA1 R9773 R8003...
  • Page 52 All manuals and user guides at all-guides.com TO C BOARD CN3004 CN9506 JB.-LE4B R1127 0 STBY5V CN5402 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL RD_RAM R1130 WR_RAM RD/ECS_5V RST_O WR/ESC_RX RST_O/ECS_NC R1115 RST_I RST_I/ECS_NC R7580 ALE_M ALE_M/ECS_TX R1131 1/16W R7504...
  • Page 53 All manuals and user guides at all-guides.com JB.-LE4B VD3_3 R5010 1/10W R5011 VDDMQ C5058 C5094 C5093 C5092 C5049 C5060 C5096 C5095 C5061 C5112 C5091 C5090 C5089 0.001 C5114 R5033 R5032 C5113 0.001 C5097 0.001 1/16W 1/16W SENSE R9769 VD1_8 FL5005 1/16W VDDL MPUGPIO0...
  • Page 54 All manuals and user guides at all-guides.com JB.-LE4B C5516 C5503 MD[16] MD[18] VDDMQ MD[17] MD[19] RB5507 VDDMQ R5501 R5500 VDDM 1/10W 1/10W MD[20] MD[21] MD[22] MD[23] RB5506 MD[0] MD[1] VDDMQ MD[3] MD[2] RB5505 B8 DQ31 C3 VDDQ C5 VDDQ C9 DQ30 C7 VDDQ B9 DQ229 MD[4]...
  • Page 55 All manuals and user guides at all-guides.com JB.-LE4B COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL INPUT TO Trident R9736 MAIN_DIN D9609 1/10W UDZSTE-175.6B PC_B CN9511 R9775 R9776 1/10W 1/10W B_PC PC_G R9737 R9777 R9778 G_PC 1/10W 1/10W 1/10W D9610 UDZSTE-175.6B...
  • Page 56 All manuals and user guides at all-guides.com JB.-LE4B R9743 IC5740 L88M05T-FA-TL 5V STBY VOLTAGE REG STBY STBY5V C5740 C5741 C5742 C5743 IC1000 S-1111B33MC-NYSTFG 3.3V STBY VOLTAGE REG STBY3.3V VOUT ON/OFF NC C1004 C1000 C1002 IC1001 BH25FB1WG-TR 2.5V STBY VOLTAGE REG VOUT STBY2.5V ON/OFF...

  • Page 57: Jb Printed Wiring Board

    All manuals and user guides at all-guides.com ~ JB Printed Wiring Board Conductor Side A ~ - 57 -...
  • Page 58 All manuals and user guides at all-guides.com ~ JB Printed Wiring Board Conductor Side B ~ - 58 -...

  • Page 59: H1 Schematic Diagram

    All manuals and user guides at all-guides.com ~ H1 Board Schematic Diagram [ Front Buttons ] ~ ~ H2 Board Schematic Diagram [ Front LED ] ~ FRONT LED FRONT BUTTONS R6323 TO H1 BOARD 1/10W CN9509 SLR-325VCT31 SPR-325MVW TO JB BOARD CN9507 GP1UE26SXK0F SIRCS...

  • Page 60: H1 Printed Wiring Board

    All manuals and user guides at all-guides.com ~ H1 Printed Wiring Board Conductor Side A ~ ~ H3 Printed Wiring Board Conductor Side A ~ ~ H1 Printed Wiring Board Conductor Side B ~ ~ H3 Printed Wiring Board Conductor Side B ~ ~ H2 Printed Wiring Board Conductor Side A ~ ~ T2 Printed Wiring Board Conductor Side ~ ~ H2 Printed Wiring Board Conductor Side B ~...

  • Page 61: N Board Schematic Diagram

    All manuals and user guides at all-guides.com N..-LE4B NAND_ALE,NAND_CLE,NAND_RBB +3V3D +3V3D_STRAPS FB3100 THESE CAPACITORS TO BE PLACED UNDERNEATH BGA C3103 C3100 C3106 C3109 C3112 C3115 C3119 +2V5D_DDR +2V5D FB3101 THESE CAPACITORS TO BE PLACED UNDERNEATH BGA C3116 C3120 C3107 C3110 C3113 C3104 151 150...
  • Page 62 All manuals and user guides at all-guides.com N..-LE4B +3V3D FB3201 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL C3205 C3206 C3208 NAND FLASH C3209 +3V3D R3251 R3238 RDATA[7] IO/8 RDATA[6] IO/7 NAND_RBB RDATA[5] IO/6 C3230 0.001 RDATA[4] FOEB IO/5 +2V5D_DDR FCSB1...
  • Page 63 All manuals and user guides at all-guides.com EXTERNAL CONNECTOR CN3300 +3V3D_31 N..-LE4B Mount Mecha A3300 181564021 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL IC3311 74LVT245PW C3315 OCTAL TRANSCEIVER +3V3D_31 +3V3D FB3300 C3300 C3301 R3308 C3324 C3320 CHIP D[15:8] +5VD_CI R3303...
  • Page 64 All manuals and user guides at all-guides.com N..-LE4B +5VA FB3402 +3V3D D3400 +3V3D RB706F-40 R3442 Q3412 C3403 C3404 GAIN = R3482 + (R3470 + R3471) 2SC5658T2LQ/R ----------------------- 0.01 CN3401 (R3470 + R3471) R3493 VIDEO CIRCUIT C3402 R3438 R3469 R3492 SPDIF Q3405 2SA2029T2LQ/R D3401...
  • Page 65 All manuals and user guides at all-guides.com N..-LE4B +3V3D +3V3D_MODEM +3V3D R3537 FB3557 2.2k CHIP SMC/MODEM Connector nMODEM_EN CN3500 MODEM PIN 1 : GND C3504 C3570 MODEM_EN PIN 2 : nSMC_INT PIN 3 : DTE-CTS Q3504 PIN 4 : DTE-RTS DTC114EKA-T146 PIN 5 : nSMC_RST PIN 6 : SMC_RXD...
  • Page 66 All manuals and user guides at all-guides.com N..-LE4B COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL +3V3D_STRAPS +3V3D_STRAPS +5VD +3V3D R3630 FIT FOR JTAG FIT FOR FWEB EJTAG R3632 FWEB R3634 R3636 TESTPIN FOEB FOEB CN3603 TMODE2 TMODE0 GCSB1 GCSB TMODE1...
  • Page 67 All manuals and user guides at all-guides.com N..-LE4B +3V3D COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL RESET SIGNAL GENERATION FB3801 +3V3D IC3805 74LVC08APW QUAD AND GATE C3810 R3839 R3827 C3809 R3800 1/16W nDAMON_RST D3800 1PS184-115 1/16W R3832 nMASTER_RESET nCI_EN C3801...

  • Page 68: N Printed Wiring Board

    All manuals and user guides at all-guides.com ~ N Printed Wiring Board Conductor Side A ~ ~ N Board Semiconductor Location Table Side A ~ ~ N Printed Wiring Board Conductor Side B ~ ~ N Board Semiconductor Location Table Side B ~ - 68 -...

  • Page 69: Semiconductors

    All manuals and user guides at all-guides.com 5-4. SEMICONDUCTORS 24LC21AT LM3526MX NJM2904M 74LVC32A-PW 74LVC00-PW NJM3404AM-T1 74LVC08A-PW 74LVC541A-PW 74LVC273-PW LM75C1MX-3 LM75C1MX-5 M24128 BWMN6T A NJM4556AM NJM4556AD 74LVC541APW 74LVC08APW 74LVC14APW 74LVC273PW 74LVC32A-PW 74LVT245PW-T M24128-BWMN6T M24128-BWMN6T(A) BA09ST_V5 PCF8593/T118 M24C32-WMN6T(B) MC14053 BDR2 PQ070XZ01ZPH BA18BC0FP-E MCZ3001D CXAB070AP PQ1CG2032FZ...
  • Page 70 All manuals and user guides at all-guides.com TDA2822D PQ20VZ-U TDA7269A PQ30RV11 TDA7482 PQ30RV21 UPC1093J-1-T PST3629UL TC7SH08FU(T5RSOYJF) TC7SH08F-TE85R - 70 -...

  • Page 71: Exploded Views

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 SECTION 6 SECTION 6 EXPLODED VIEWS EXPLODED VIEWS NOTE : NOTE : Items with no part number and no description are not Items with no part number and no description are not Items marked “*” are not stocked Items marked “*” are not stocked since they are seldom required for since they are seldom required for stocked because they are seldom required for routine stocked because they are seldom required for routine service. service. routine service. Some delay should routine service. Some delay should The construction parts of an assembled part are indicated The construction parts of an assembled part are indicated be anticipated when ordering these be anticipated when ordering these items. items. with a collation number in the remarks column. with a collation number in the remarks column.

  • Page 72: Chassis/Bottom Block Assembly

    All manuals and user guides at all-guides.com KDF-E42/50A11E RM-ED002 6-2. CHASSIS / BOTTOM BLOCK ASSEMBLY The components identified by shading £  : 7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3 and mark are critical for safety. Replace only with part number specified. : 7-685-663-79 SCREW +BVTP 4X16 TYPE2 IT-3      REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK £ 1-823-715-21 CORD, POWER *A-1151-409-B N COMPLETE LE4B (ZAPPING) 3-701-810-72 SCREW, TERMINAL *2-593-078-21 BRACKET, G...

  • Page 73: Lamp Duct Assembly, Optics Unit Block

    All manuals and user guides at all-guides.com KDF-E42/50A12U RM-ED002 6-3. LAMP DUCT ASSEMBLY, OPTICS UNIT BLOCK The components identified by shading £  : 7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3 and mark are critical for safety. Replace only with part number specified. : 7-685-663-79 SCREW +BVTP 4X16 TYPE2 IT-3    Revision 2.0 (Click inside red box to see related change) REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK *A-1122-463-A T1 MOUNT 53 £ 1-468-936-11 POWER SUPPLY BLOCK *2-590-723-21 COVER, SIROCCO FAN...

  • Page 74: Electrical Parts List

    All manuals and user guides at all-guides.com SECTION 7 ELECTRICAL PARTS LIST PARTS LISTING TABLE OF CONTENTS Page T1BOARD COMPLETE Parts List : ............................75 C BOARD COMPLETE Parts List : ............................75 T2 BOARD COMPLETE Parts List : ............................80 H3 BOARD COMPLETE Parts List :............................
  • Page 75 All manuals and user guides at all-guides.com T1 C REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C2519 1-164-505-11 CERAMIC CHIP 2.2UF 16V * A-1122-463-A T1 BOARD COMPLETE C2520 1-128-992-21 ELECT CHIP 47UF 20% 25V C2521 1-164-156-11 CERAMIC CHIP 0.1UF 25V < CONNECTOR > C2522 1-164-156-11 CERAMIC CHIP 0.1UF 25V C2523 1-164-156-11 CERAMIC CHIP 0.1UF 25V CN4306 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P C2524 1-164-156-11...
  • Page 76 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C2655 1-164-156-11 CERAMIC CHIP 0.1UF 25V C2801 1-164-156-11 CERAMIC CHIP 0.1UF 25V C2656 1-164-156-11 CERAMIC CHIP 0.1UF 25V C2802 1-128-992-21 ELECT CHIP 47UF 20% 25V C2657 1-164-156-11 CERAMIC CHIP 0.1UF 25V C2804 1-128-992-21 ELECT CHIP 47UF 20% 25V C2658 1-128-992-21 ELECT CHIP 47UF 20% 25V C2836 1-162-926-11 CERAMIC CHIP 82PF 5.00% 50V C2659 1-164-156-11 CERAMIC CHIP 0.1UF 25V C2837...
  • Page 77 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK CN3200 * 1-819-817-11 CONNECTOR (RECEPTACLE) 14P IC3200 6-701-870-01 IC THC63LVDF84B-T CN3201 1-694-981-21 EARTH TERMINAL (SMD) CN3202 1-694-981-21 EARTH TERMINAL (SMD) < JUMPER RESISTOR > < DIODE > JR3000 1-216-864-11 SHORT CHIP 0 JR3001 1-216-864-11 SHORT CHIP 0 D1320 8-719-069-55 DIODE UDZSTE-175.6B JR3002 1-216-864-11 SHORT CHIP 0 D1321 6-500-697-01...
  • Page 78 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK L3204 1-456-583-11 INDUCTOR 0UH R1398 1-216-864-11 SHORT CHIP 0 L3205 1-456-583-11 INDUCTOR 0UH R1399 1-216-864-11 SHORT CHIP 0 R2059 1-216-864-11 SHORT CHIP 0 < TRANSISTOR > R2060 1-216-809-11 METAL CHIP 100 5% 1/10W R2061 1-216-809-11 METAL CHIP 100 5% 1/10W Q1300 8-729-010-29 TRANSISTOR MSD601-RST1 Q2502 8-729-013-28 TRANSISTOR HN1B01FU-TE85R...
  • Page 79 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R2602 1-216-864-11 SHORT CHIP 0 R2713 1-218-845-11 METAL CHIP 820 0.5% 1/10W R2603 1-216-833-11 METAL CHIP 10K 5% 1/10W R2715 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W R2604 1-216-813-11 METAL CHIP 220 5% 1/10W R2716 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W R2605 1-216-864-11 SHORT CHIP 0 R2717 1-216-823-11 METAL CHIP 1.5K 5% 1/10W R2606 1-216-805-11 METAL CHIP 47 5% 1/10W R2718...
  • Page 80 All manuals and user guides at all-guides.com C T2 H3 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R3110 1-216-833-11 METAL CHIP 10K 5% 1/10W * A-1127-037-A T2 BOARD COMPLETE R3111 1-216-805-11 METAL CHIP 47 5% 1/10W R3113 1-216-833-11 METAL CHIP 10K 5% 1/10W < CONNECTOR > R3176 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3200 1-218-668-11 METAL CHIP 100 0.5% 1/10W CN4340 * 1-564-518-11 PLUG, CONNECTOR 3P R3201...
  • Page 81 All manuals and user guides at all-guides.com H3 JB REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK < FILTER > < VARISTOR > FL4300 1-239-897-22 FERRITE 0UH VDR4300 1-803-974-21 VARISTOR, CHIP (1608) FL4301 1-239-897-22 FERRITE 0UH VDR4301 1-803-974-21 VARISTOR, CHIP (1608) FL4302 1-239-897-22 FERRITE 0UH * A-1129-435-A JB_WAX COMPLETE DIG < IC > * 2-109-150-01 SHEET, RADIATION 4-087-203-01...
  • Page 82 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C2516 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C5021 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C2517 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V C5022 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C2518 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V C5024 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C2519 1-126-394-11 ELECT CHIP 10UF 20.00% 16V C5026 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C2520 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C5027...
  • Page 83 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C5078 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V C5513 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C5079 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V C5514 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V C5080 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V C5515 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V C5081 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C5516 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C5082 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C5700...
  • Page 84 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C7826 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V C9563 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V C7827 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V C9565 1-127-861-11 CERAMIC CHIP 2.2UF 10% 16V C7828 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V C9567 1-127-861-11 CERAMIC CHIP 2.2UF 10% 16V C7830 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V C9568 1-127-861-11 CERAMIC CHIP 2.2UF 10% 16V C7831 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V C9569...
  • Page 85 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK CN9508 * 1-573-768-21 PIN, CONNECTOR (1.5MM) (SMD)5P D9620 8-719-069-55 DIODE UDZSTE-175.6B CN9509 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD)4P D9621 8-719-069-55 DIODE UDZSTE-175.6B CN9510 * 1-819-817-11 CONNECTOR (RECEPTACLE) 14P D9622 8-719-069-55 DIODE UDZSTE-175.6B CN9511 * 1-695-210-21 PIN, CONNECTOR (PC BOARD) 15P CN9512 * 1-793-497-11 CONNECTOR, BOARD TO BOARD 40P < FUSE > CN9513 1-573-806-21 PIN, CONNECTOR (1.5MM) (SMD)6P...
  • Page 86 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK IC5740 8-759-533-85 IC L88M05T-FA-TL L9502 1-412-030-11 INDUCTOR 22UH IC6309 8-759-576-76 IC TDA2822D013TR L9510 1-412-030-11 INDUCTOR 22UH IC7402 8-752-072-94 IC CXA1875AM-T4 IC7403 6-706-137-01 IC K6F2008V2E-LF70T00 < TRANSISTOR > IC7804 6-701-031-11 IC MSP3411G-QA-B11 Q2501 8-729-010-05 TRANSISTOR MSB709-RT1 IC8500 8-752-072-94 IC CXA1875AM-T4...
  • Page 87 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R1010 1-218-990-81 SHORT CHIP 0 R2503 1-216-821-11 METAL CHIP 1K 5% 1/10W R1011 1-218-990-81 SHORT CHIP 0 R2506 1-216-838-11 METAL CHIP 27K 5% 1/10W R1012 1-218-990-81 SHORT CHIP 0 R2507 1-216-864-11 SHORT CHIP 0 R1014 1-218-990-81 SHORT CHIP 0 R2508 1-216-828-11 METAL CHIP 3.9K 5% 1/10W R1016 1-218-990-81 SHORT CHIP 0 R2511...
  • Page 88 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R2576 1-216-864-11 SHORT CHIP 0 R5007 1-216-864-11 SHORT CHIP 0 R2577 1-216-864-11 SHORT CHIP 0 R5008 1-216-864-11 SHORT CHIP 0 R2578 1-216-833-11 METAL CHIP 10K 5% 1/10W R5009 1-216-864-11 SHORT CHIP 0 R2579 1-216-833-11 METAL CHIP 10K 5% 1/10W R5010 1-216-821-11 METAL CHIP 1K 5% 1/10W R2580 1-216-833-11 METAL CHIP 10K 5% 1/10W R5012...
  • Page 89 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R6531 1-216-837-11 METAL CHIP 22K 5% 1/10W R7560 1-216-841-11 METAL CHIP 47K 5% 1/10W R6532 1-216-837-11 METAL CHIP 22K 5% 1/10W R7561 1-216-841-11 METAL CHIP 47K 5% 1/10W R6533 1-220-234-11 METAL CHIP 4.7 10% 1/4W R7563 1-216-864-11 SHORT CHIP 0 R6534 1-220-234-11 METAL CHIP 4.7 10% 1/4W R7564 1-216-864-11 SHORT CHIP 0 R6535 1-216-813-11 METAL CHIP 220 5% 1/10W R7565...
  • Page 90 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R8498 1-216-833-11 METAL CHIP 10K 5% 1/10W R9537 1-216-813-11 METAL CHIP 220 5% 1/10W R8499 1-216-833-11 METAL CHIP 10K 5% 1/10W R9538 1-216-853-11 METAL CHIP 470K 5% 1/10W R8529 1-216-864-11 SHORT CHIP 0 R9539 1-216-853-11 METAL CHIP 470K 5% 1/10W R8530 1-216-864-11 SHORT CHIP 0 R9540 1-216-049-11 RES-CHIP 1K 5% 1/10W R8531 1-216-864-11 SHORT CHIP 0 R9541...
  • Page 91 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R9632 1-216-864-11 SHORT CHIP 0 R9708 1-216-029-00 RES-CHIP 150 5% 1/10W R9633 1-216-864-11 SHORT CHIP 0 R9709 1-216-029-00 RES-CHIP 150 5% 1/10W R9634 1-216-864-11 SHORT CHIP 0 R9713 1-216-864-11 SHORT CHIP 0 R9638 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R9722 1-218-875-11 METAL CHIP 15K 0.5% 1/10W R9639 1-216-809-11 METAL CHIP 100 5% 1/10W R9723...
  • Page 92 All manuals and user guides at all-guides.com JB N REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R9779 1-218-827-11 METAL CHIP 150 0.5% 1/10W VDR010 1-803-974-21 VARISTOR, CHIP (1608) R9780 1-218-827-11 METAL CHIP 150 0.5% 1/10W VDR011 1-803-974-21 VARISTOR, CHIP (1608) R9781 1-216-833-11 METAL CHIP 10K 5% 1/10W R9782 1-216-833-11 METAL CHIP 10K 5% 1/10W < CRYSTAL > < RESISTOR CHIP > X1000 1-795-537-21 VIBRATOR, CRYSTAL X2500 1-781-730-11 VIBRATOR, CRYSTAL...
  • Page 93 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C3134 1-100-597-91 CERAMIC CHIP 0.1UF 10% 25V C3400 1-100-611-91 CERAMIC CHIP 22UF 20% 6.3V C3135 1-100-597-91 CERAMIC CHIP 0.1UF 10% 25V C3402 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3136 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3403 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3137 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3404 1-164-943-81 CERAMIC CHIP 0.01UF 10.00% 16V C3138 1-165-908-11 CERAMIC CHIP 1UF 10% 10V C3405...
  • Page 94 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C3452 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 50V C3809 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3504 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3810 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3509 1-117-720-11 CERAMIC CHIP 4.7UF 10V C3811 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C3513 1-126-206-11 ELECT CHIP 100UF 20.00% 6.3V C3812 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3514 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3813...
  • Page 95 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK FB3403 1-469-458-91 FERRITE 0UH IC3200 6-707-809-01 IC EDD1216AATA-6B-E FB3404 1-469-869-21 FERRITE 0UH IC3201 6-705-271-01 IC KA5SDKASO1TSL FB3405 1-469-869-21 FERRITE 0UH IC3206 6-704-621-01 IC TC58DVM72A1TG00 FB3406 1-469-869-21 FERRITE 0UH IC3301 8-759-644-48 IC 74LVC541APW FB3407 1-469-869-21 FERRITE 0UH IC3302...
  • Page 96 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK Q3405 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R R3135 1-218-937-11 RES-CHIP 47 5% 1/16W Q3406 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R R3136 1-218-937-11 RES-CHIP 47 5% 1/16W Q3407 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R R3137 1-218-937-11 RES-CHIP 47 5% 1/16W Q3408 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R R3141 1-218-937-11 RES-CHIP 47 5% 1/16W Q3409 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R R3145...
  • Page 97 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R3321 1-218-941-81 RES-CHIP 100 5% 1/16W R3468 1-218-967-11 RES-CHIP 15K 5% 1/16W R3324 1-218-941-81 RES-CHIP 100 5% 1/16W R3469 1-218-949-11 RES-CHIP 470 5% 1/16W R3325 1-218-937-11 RES-CHIP 47 5% 1/16W R3470 1-208-675-11 METAL CHIP 470 0.5% 1/16W R3400 1-218-966-11 RES-CHIP 12K 5% 1/16W R3471 1-208-885-11 METAL CHIP 820 0.5% 1/16W R3401 1-218-967-11 RES-CHIP 15K 5% 1/16W R3472...
  • Page 98 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R3560 1-218-937-11 RES-CHIP 47 5% 1/16W R3822 1-218-965-11 RES-CHIP 10K 5% 1/16W R3561 1-218-941-81 RES-CHIP 100 5% 1/16W R3824 1-218-965-11 RES-CHIP 10K 5% 1/16W R3562 1-218-941-81 RES-CHIP 100 5% 1/16W R3825 1-218-965-11 RES-CHIP 10K 5% 1/16W R3563 1-218-941-81 RES-CHIP 100 5% 1/16W R3826 1-218-941-81 RES-CHIP 100 5% 1/16W R3564 1-218-941-81 RES-CHIP 100 5% 1/16W R3827...
  • Page 99 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK RB3110 1-234-370-21 RES, NETWORK 22 (1005X4) C1039 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V RB3200 1-234-372-21 RES, NETWORK 100 (1005X4) C1040 1-135-372-31 ELECT 470UF 20% 10V RB3201 1-234-372-21 RES, NETWORK 100 (1005X4) C1103 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V RB3202 1-234-372-21 RES, NETWORK 100 (1005X4) C1104 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V RB3203 1-234-702-11 RES, NETWORK 68 (1005X4) C1106...
  • Page 100 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C1655 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V C6226 1-128-942-31 ELECT 1000UF 20% 6.3V C1656 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V C6227 1-128-942-31 ELECT 1000UF 20% 6.3V C1659 1-137-194-81 FILM 0.47UF 5.00% 50V C6229 1-128-528-11 ELECT 470UF 20% 25V C1660 £ 1-165-530-11 MYLAR 0.47UF 10 275V C6230 1-126-935-11 ELECT 470UF 20.00% 16V C1661 £ 1-119-887-51 CERAMIC 1000PF 20.00% 250V C6235 1-164-156-11 CERAMIC CHIP 0.1UF 25V...
  • Page 101 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK CN6208 * 1-564-512-11 PLUG, CONNECTOR 9P FB1230 1-469-869-21 FERRITE 0UH FB1231 1-469-869-21 FERRITE 0UH < DIODE > < CLIP FUSE > D1002 8-719-050-38 DIODE M1MA152WK-T1 D1005 8-719-081-97 DIODE MMDL914T1 FH1601 £ 1-533-725-11 FUSE HOLDER 0A 0V D1007 8-719-081-67 DIODE M1FM3 D1008 8-719-073-69 DIODE PTZ-TE25-6.2A < FILTER >...
  • Page 102 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK Q2500 8-729-010-29 TRANSISTOR MSD601-RST1 < COIL > Q2501 8-729-010-29 TRANSISTOR MSD601-RST1 Q2502 8-729-010-29 TRANSISTOR MSD601-RST1 L1001 1-414-934-21 INDUCTOR 10UH Q2503 8-729-010-29 TRANSISTOR MSD601-RST1 L1002 1-414-934-21 INDUCTOR 10UH Q2504 8-729-027-38 TRANSISTOR DTA144EKA-T146 L1003 1-406-663-21 INDUCTOR 47UH L1004 1-216-864-11 SHORT CHIP 0...
  • Page 103 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R1237 1-216-821-11 METAL CHIP 1K 5% 1/10W R2501 1-216-821-11 METAL CHIP 1K 5% 1/10W R1238 1-216-821-11 METAL CHIP 1K 5% 1/10W R2502 1-216-818-11 METAL CHIP 560 5% 1/10W R1239 1-216-841-11 METAL CHIP 47K 5% 1/10W R2503 1-216-818-11 METAL CHIP 560 5% 1/10W R1601 1-245-494-21 METAL 2.2M 2% 1/4W R2504 1-216-841-11 METAL CHIP 47K 5% 1/10W R1602 1-245-494-21 METAL 2.2M 2% 1/4W R2505...
  • Page 104 All manuals and user guides at all-guides.com AG H2 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R6256 1-216-841-11 METAL CHIP 47K 5% 1/10W < IC > R6262 1-216-834-11 METAL CHIP 12K 5% 1/10W R6263 1-216-833-11 METAL CHIP 10K 5% 1/10W IC1000 6-703-744-01 IC GP1UE26SXKOF R6264 1-216-833-11 METAL CHIP 10K 5% 1/10W R6267 1-216-833-11 METAL CHIP 10K 5% 1/10W < TRANSISTOR > R6303 1-216-821-11 METAL CHIP 1K 5% 1/10W Q1010 8-729-010-29 TRANSISTOR MSD601-RST1...
  • Page 105 All manuals and user guides at all-guides.com REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK S4403 1-692-431-21 SWITCH, TACTILE MISCELLANEOUS S4404 1-692-431-21 SWITCH, TACTILE S4405 1-692-431-21 SWITCH, TACTILE 1-826-219-11 LOUD SPEAKER (5.5x15CM) S4406 1-692-431-21 SWITCH, TACTILE £ 1-823-715-21 CORD, POWER £ 1-787-373-11 D.C. FAN 1-576-912-11 THERMOSTAT £ 1-468-936-13 POWER SUPPLY BLOCK £ 1-787-231-11 D.C. FAN (SIROCCO) ACCESSORIES AND CONNECTORS 1-900-277-08 CONNECTOR ASSY 2P 1-910-017-08 CONNECTOR ASSY, 9P EHR-ZHR 1-910-017-09 CONNECTOR ASSY, 10P DF13-ZHR...
  • Page 106 All manuals and user guides at all-guides.com English Sony Corporation 06KP7100-1 Sony UK Printed in U.K. 9-927-530-02 Service Promotions Dept. © 2006.11...
