- Page 1 XSLi8/XSLi12 Manual 1.1 en...
- Page 2 General information XSLi8/XSLi12 Manual Version: 1.1 en, 09/2021, D2754.EN .01 Copyright © 2021 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this document to the new owner.
-
Page 3: Table Of Contents
Contents Safety precautions.............. 4 1.1 d&b ArrayCalc................5 XSLi8/XSLi12 loudspeaker..........6 2.1 Intended use................6 2.2 Connections................7 2.3 Operation..................7 2.3.1 Controller settings..............8 2.4 Dispersion characteristics............9 2.5 Technical specifications............10 Manufacturer's declarations......... 12 3.1 Conformity of loudspeakers............. 12 3.2 WEEE Declaration (Disposal).......... -
Page 4: Safety Precautions
Safety precautions Potential risk of personal injury Never stand in the immediate vicinity of loudspeakers driven at a high level. Professional loudspeaker systems are capable of causing a sound pressure level detrimental to human health. Seemingly non-critical sound levels (from approx. 95 dB SPL) can cause hearing damage if people are exposed to it over a long period. -
Page 5: D&B Arraycalc
1.1 d&b ArrayCalc For both safety and acoustic reasons, d&b line arrays must be designed using the d&b ArrayCalc simulation software. The software is available as a native stand-alone application for both Microsoft Windows and Mac OS X operating systems and can be downloaded at www.dbaudio.com. -
Page 6: Xsli8/Xsli12 Loudspeaker
XSLi8/XSLi12 loudspeaker 2.1 Intended use NOTICE! Only operate d&b SL-Series loudspeakers with the specified and correctly configured d&b amplifiers, otherwise there is a risk of damaging the loudspeaker components and the directional characteristics of the system cannot be achieved. Applicable d&b amplifiers: 40D Product description The XSLi8 is an installation-specific line array loudspeaker for small to medium-scale sound reinforcement applications. -
Page 7: Connections
Rigging components and arrays The cabinets are mechanically connected using the rigging strands on both sides of the cabinet front and a central strand at the rear of the cabinet. All necessary rigging components are mounted on the cabinet and fold out or slide out when needed. A detailed description of the rigging components is given in the respective rigging manuals. -
Page 8: Controller Settings
Line and Arc setups The selection of "Line" or "Arc" depends on the curvature of the array. Both setups may be used within one array. The "Line" setup is used for long throw array sections with three or more consecutive splay settings of 0°, 1° or 2°. Compared to the "Arc"... -
Page 9: Dispersion Characteristics
HFC function (Line/Arc setups only) Selecting the HFC (High Frequency Compensation) function compensates for the loss of high frequency energy due to air absorption when loudspeakers are used to cover far field listening positions. The HFC function has two settings (HFC1 and HFC2) for different distances the cabinets need to cover. -
Page 10: Technical Specifications
2.5 Technical specifications System data Frequency response (–5 dB standard) 60 Hz - 18 kHz Frequency response (–5 dB CUT mode) 90 Hz - 18 kHz Max. sound pressure (1 m, free field) XSLi8 141 dB XSLi12 140 dB (SPLmax: Broadband signal IEC 60268) XSLi8: Frequency response*, Standard and CUT modes *single cabinet within array Loudspeaker data... - Page 11 XSLi8/XSLi12 cabinet dimensions in mm [inch] d&b XSLi8/XSLi12 Manual 1.1 en...
-
Page 12: Manufacturer's Declarations
Manufacturer's declarations 3.1 Conformity of loudspeakers This declaration applies to: d&b Z0776 XSLi8 loudspeaker d&b Z0777 XSLi12 loudspeaker manufactured by d&b audiotechnik GmbH & Co. KG. All product variants are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications. - Page 13 www.dbaudio.com...
