Garmin GMX 200 Reference Manual

Nomenclature:
Type/Model/Part Number:
GMX 200 Standard
GMX 200 I/O Traffic
GMX 200 I/O Radar/TAWS
GMX 200 I/O Radar/Traffic
TSO Number: TSO-C63c
TSO-C110a
TSO-C113
TSO-C118
TSO-C147
Manufacturer's Specification And/Or Other Applicable Specification:
Manufacturer:
Address:
Date Tested:
The GMX 200 has been tested to the following environmental categories per procedures defined in RTCA/DO-
160D. Tests were conducted from February 2006 to June 2006 using the original 1997 revision of DO-160D,
(except where credit was claimed for previous testing to equivalent levels, refer to Garmin document 005-00315-19
for details).
RTCA D O - 1 6 0 D Conditions
Temperature and Altitude
Low Temperature
High Temperature
In-Flight Loss of Cooling
Altitude
Decompression
Overpressure
Temperature Variation
Humidity
GMX 200 Environmental Qualification Form
Page 1 of 2
G M X 2 0 0 M u l t i - F u n c t i o n D i s p l a y
E n v i r o n m e n t a l Q u a l i f i c a t i o n F o r m
GMX 200 Multi-Function Display
Garmin Part Number 010-00483-(), which includes 011-01271-()
Garmin Part Number 010-00571-(), which includes 011-01465-()
Garmin Part Number 010-00486-(), which includes 011-01466-()
Garmin Part Number 010-00487-(), which includes 011-01467-()
Airborne Weather and Ground Mapping Pulsed Radar
Airborne Passive Thunderstorm Equipment
Multipurpose Electronic Displays
Traffic Alert and Collision Avoidance System (TCAS 1)
Traffic Advisory System (TAS) Airborne Equipment
004-00221-00
Garmin Ltd. or its subsidiaries
1200 East 151
Olathe, Kansas 66062
U.S.A.
D O - 1 6 0 D
Section
4.0
4.5.1
4.5.2 & 4.5.3
4.5.4
4.6.1
4.6.2
4.6.3
5.0
6.0
st
Street
D e s c r i p t i o n o f C o n d u c t e d T e s t s
Equipment tested to Categories A1F1
Equipment Tested to Category Y
Equipment was operating during test.
Equipment tested to Category C
Equipment tested to Category A
005-00315-20
Rev 1
