IC206 VHITK11131C-1R (TK11131C): REGULATOR
IC209 VHITK11130C-1R (TK11130C): REGULATOR
Pin No. Terminal name
1 CONT
(IC209: VCONT)
2 GND
3 NP
4 VOUT
5 VIN
IC208 VHIXC620925-1L (XC6209B252MR): HIGH SPEED LDO REGULATOR
Pin No. Terminal name
1 VIN
2 VSS
3 CE
4* NC
5 VOUT
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
