Make Cuisine TOPCHEF 2-IN-1 User Manual

Electric multi-cooker pressure cooker & air fryer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Electric Multi-Cooker Pressure Cooker & Air Fryer
UsEr's MAnUAl
1

Advertisement

Table of Contents
loading

Related Manuals for Make Cuisine TOPCHEF 2-IN-1

Summary of Contents for Make Cuisine TOPCHEF 2-IN-1

  • Page 1 Electric Multi-Cooker Pressure Cooker & Air Fryer UsEr’s MAnUAl...
  • Page 2 caution BEFORE THE FIRST USE preheat the appliance for at least 10 minutes without putting food inside. 1. Throw around 200 ml of water in the pot (one glass) and activate the “Keep warm” program with the pressure valve in “Venting” position (open). 2.
  • Page 3 caution BE VERY CAREFUL with hot steam coming out of the valve pressure. Do not put your hands or any object that could cover the upper part of the appliance.
  • Page 4 noticE Please save these instructions for future reference. • To avoid damage or injury, be sure to follow all instructions and safety warnings. • Do not allow children to use this appliance. Keep the appliance out of the reach of children. •...

  • Page 5: Main Diagram

    WaRninG • Do not use any accessory or element that is not original from the same manufacturer and compatible with your model. • Do not use this unit with an external timer or remote control system. • Do not put flammable materials such as paper or plastic inside or in contact with the appliance to avoid the risk of fire.
  • Page 6 Main DiaGRaM PREssuRE cookER LID PREssuRE cookER LID (toP vIEw) (bottom vIEw) SAFETY BUTTON TO OPEN THE LID Press this button while turning the lid counterclockwise. If there is still pressure inside the pot, the security system will block the button, therefore the pot lid cannot be opened until there is pressure inside and the safety button is unlocked.
  • Page 7 contRoL PanEL - aiRFRYER • ON / OFF: Press to turn on/off, defaults to 180°C and 15 minutes. • PROGRAM: Press to select the different cooking programs. • DIGITAL DISPLAY: Displays temperature and time. DIGITAL DISPLAY PROGRAM SELECTION TEMPERATURE SET TIME START/PAUSE COOKING PRESETS...

  • Page 8: Meat And Poultry

    SuGGEStionS FoR REciPES QUANTITIES TIME TEMPERATURE RECIPE INFORMATION MIN-MAX (grs.) (min.) (ºC) POTATOES 15-18 Hash Brown Add ½ tablespoon of oil 285-680 10-24 Spicy potatoes Add ½ tablespoon of oil Diced potatoes 285-680 10-24 Add ½ tablespoon of oil 285-680 10-16 Baked Potatoes Frozen Fries potatoes (thin)
  • Page 9 SuGGEStionS FoR REciPES QUANTITIES TEMPERATURE TIME RECIPE INFORMATION MIN-MAX (grs.) (min.) (ºC) TO BAKE Sweet Appetizers 15-18 Muffins Quiche 20-22 20-25 Cake contRoL PanEL - PRESSuRE cooKER • CONTROL KNOB: Turn to cycle through recipes or adjust cook time. - Press to adjust the time of the selected recipe. •...
  • Page 10 contRoL PanEL - PRESSuRE cooKER QUANTITY OF COOKING TIME MANUAL TIME RECIPE INGREDIENTS (MIN.) SETTING Less Normal RiCe - ARRoz 1 to 99 min. More Less Normal SoUP - SoPAS 1to 99 min. More Less Normal eggS - HUeVoS 1 to 99 min. More Less MeAt/Stew -...
  • Page 11 contRoL PanEL - PRESSuRE cooKER QUANTITY OF COOKING TIME MANUAL TIME RECIPE INGREDIENTS (MIN.) SETTING Less Normal RiSotto 1 to 99 min. More Less VegetABleS - Normal 1 to 99 min. VeRDURAS More Less 24 hours Normal yogURt 8 hours 6 to 24 hours More Boil...
  • Page 12 PREPaRation Place the appliance on a stable and level surface, plug it into a power outlet. - Leave at least 15 cm. free space around the appliance during operation. - Make sure the power cord is long enough to reach the plug comfortably, without straining or forced kinks.
  • Page 13 cooKinG Select the appropriate lid to use the appliance as an Airfryer or as a pressure cooker. • Attach the Airfryer lid and the controls on the • Put the lid on the pot and turn it clockwise. lid will light up automatically. When properly closed, the controls on the frypot will light up.
  • Page 14 cooKinG Press the power button or turn the control knob to turn on the appliance. Select a program and / or manually set the desired temperature and time settings.
  • Page 15 cooKinG Press the start button to start cooking. If necessary, the Airfryer lid can be lifted while the selected program is running to monitor, add, remove or turn the ingredients being cooked. Simply lift the Airfryer lid and put it back in its housing. The selected program will continue to run at the same point it was at before lifting the Airfryer lid.
  • Page 16 cooKinG Cooking is finished when the timer hits 0. The appliance will emit a sound and turn off or keep food warm. Use oven mitts to remove the pan from the pot and remove the food. NOTE: Be sure to place the pot on a stable surface, away from anything that is combustible or can melt from the heat.

  • Page 17: Cleaning And Storage

    cooKinG tiPS: PRESSuRE cooKER • This appliance cooks under pressure. Incorrect use can cause damage and / or injury to people. • Be very careful with the hot steam that will come out of the pressure valve. • Do not place your hands or objects that could cover the pressure cooker. •...
  • Page 18 coMPLEtE PRoGRaMMinG taBLE - aiRFRYER PRESET PRESET SELECTABLE PROGRAM DESCRIPTION TIME TEMPERATURE TEMPERATURE Frozen Chips 15 min. 200ºC 80-200ºC Fish 15 min. 160ºC 80-200ºC Burger 13 min. 185ºC 80-200ºC Pizza 15 min. 185ºC 80-200ºC Beef Steak 25 min. 175ºC 80-200ºC Chicken Leg 22 min.
  • Page 19 coMPLEt PRESEt taBLE - PRESSuRE cooKER PRESET PROGRAM MANUAL SETTING PROGRAM TEMPERATURE FOOD QUANTITY/MINUTES (MINUTES) ºC Less RiCe - ARRoz 1-99 min. Normal More Less Normal SoUP - SoPAS 1-99 min. More Less Normal 1-99 min. eggS - HUeVoS More Less Normal 1-99 min.
  • Page 20 coMPLEt PRESEt taBLE - PRESSuRE cooKER PRESET PROGRAM MANUAL SETTING PROGRAM TEMPERATURE FOOD QUANTITY/MINUTES (MINUTES) ºC Less PORRIDGE 1-99 min. Normal More Less PORK&RIBS - 1-99 min. Normal CARNE More Less DeSSeRt - 1-99 min. Normal PoStRe More Less RiSotto 1-99 min.
  • Page 21 coMPLEt PRESEt taBLE - PRESSuRE cooKER PRESET PRESSURE LEVELS AND TIME PRESSURE PROGRAM KEEP TIMER TEMPERATURe PRESET HIGH LOw PRESSURE ºC wARM PRESSURE 50-60 kpa 30-45 kpa 0.5-24 h. 24 h. 60-80 RiCe - ARRoz 50-60 kpa 30-45 kpa 0.5-24 h. 24 h.

  • Page 22: Problem Solving

    PRoBLEM SoLVinG PROBLEM PROBABLE CAUSE SOLUTION The appliance is not plugged in Plug the appliance into the mains. correctly. The timer is not set. Set the timer The lid is not closed properly. Make sure the lid is completely closed. It does not work.

  • Page 23: After Sales Support

    aFtER SaLES SuPPoRt Do you need help with any matter related to your product Send an email customerservice@makecuisine.com Product Orders in our Online technical Service and Performance Store warranty extension WaRRantY • The appliance for domestic use covered by this guarantee has been manufactured in accordance with standard quality standards, having passed the corresponding approval tests.
  • Page 24 sales@makecuisine.com www.makecuisine.com...
