Getting Your WiFi capable
imageCLASS Product
Back On Your Network After A
Router Or Network Change
imageCLASS MF8080Cw/MF8380Cdw
Windows OS
1

Advertisement

Table of Contents
loading

Related Manuals for Canon imageCLASS MF8080Cw

Summary of Contents for Canon imageCLASS MF8080Cw

  • Page 1 Next >> << Previous Getting Your WiFi capable imageCLASS Product Back On Your Network After A Router Or Network Change imageCLASS MF8080Cw/MF8380Cdw Windows OS...

  • Page 2: Table Of Contents

    Before adding the machine to a wireless LAN Switching the connection method to wireless LAN Selecting a method for setting the wireless LAN Configuring using WPS Configuring Manually Required Information Using the Wireless Setup Assistant Change imageCLASS MF8080Cw/MF8380Cdw Windows OS << Previous Next >>...
  • Page 3 << Previous Next >> If any of the following situations exist • You have replaced your Router or Access Point • You want to use a different wireless network • Router settings have been changed. Please complete the following steps to apply the new configuration settings to your multifunction.

  • Page 4: Before Adding The Machine To A Wireless Lan

    Before adding the machine to a wireless LAN Check to make sure that the setup of the computer and wireless LAN or access point are complete. If they are not set up, you will not be able to use the machine on the wireless LAN network even if you perform the steps outlined in this document: The structure of your computer or networked device, the existence of •...

  • Page 5: Switching The Connection Method To Wireless Lan

    Switching the connection Method to Wireless LAN 1. Press [ ] (Menu). 2. Select <Network Settings> with [ ] and [ ], and then press [OK]. << Previous Next >>...

  • Page 6: Wireless Lan

    Switching the connection Method to Wireless LAN The screen below is displayed for approximately 5 seconds. (You do not need to turn the machine OFF/ON in this step.) 3. Select <Select Wired/Wireless LAN> using [ ] or [ ], and then press [OK]. 4.
  • Page 7 5. Turn the machine OFF/ON when the following screen disappears. It is necessary to turn the machine OFF/ON to activate the settings. Turn OFF the machine and wait for at least 10 seconds before turning it back ON. MF8380Cdw MF8080Cw << Previous Next >>...

  • Page 8: Configuring Manually

    Selecting a method for connecting to the wireless LAN Two methods are provided for connecting to the wireless LAN or access point, connecting using WPS (Wi-Fi Protected Setup) function or connecting manually. Select the appropriate setting method after checking the following function on the wireless LAN or access point you are using.
  • Page 9 Configuring with WPS Features Is there a WPS button? Connect using “WPS Push Button Mode.” Click Here Set the machine’s PIN code using “WPS PIN Code Mode” that is entered manually from the computer to the wireless LAN router or access point.
  • Page 10 Configuring with WPS Features (Push Button Mode) 1. Press [ ] (Menu). 2. Select <Network Settings> with [ ] or [ ] , and then press [OK]. The screen below is displayed for approximately 5 seconds. (You do not need to turn the machine OFF/ON in this step.
  • Page 11 Configuring with WPS Features (Push Button Mode) 4. Press [OK]. 5. Select <WPS Push Button Mode> using [ ] or [ ], and press [OK]. 6. Press [ ] to select <Yes>, and press [OK] << Previous Next >>...
  • Page 12 Configuring with WPS Features (Push Button Mode) 7. Within 2 minutes, press and hold the WPS button on the wireless LAN router or access point. *The amount of time you must hold down the WPS button will depend on the wireless LAN router or access point you are using.
  • Page 13 Configuring with WPS Features (Push Button Mode) 8. Make sure the WiFi indicator blinks. When the wireless LAN router or access point is detected, the Wi-Fi indicator blinks. The screen below is displayed for approximately 2 seconds, and then the Wi-Fi indicator will remain solidly lit. *If an error message appears, press [OK] to close the screen and follow the procedure again from Step 5 <<...
  • Page 14 Configuring with WPS Features (Push Button Mode) 9. Wait until the machine sets the IP address automatically (approx. 2 min). The imageCLASS device sets the IP address automatically and connects to the network. When the next screen is displayed, click [OK]. If you want to set the IP address manually, see the following.
  • Page 15 Configuring with WPS Features (Pin Code Mode) << Previous Next >> Enter the PIN code generated by the imageCLASS device to wireless LAN routers and/or access points for connection. 1. Press [ ] (Menu). 2. Select <Network Settings> using [ ] or [ ], and then press [OK]. 3.
  • Page 16 Configuring with WPS Features (Pin Code Mode) << Previous Next >> 4. Press [OK]. 5. Select <WPS PIN Code Mode> using [ ] or [ ] and press [OK]. 6. Select <Yes> using [ ] and press [OK].
  • Page 17 Configuring with WPS Features (Pin Code Mode) << Previous Next >> 7. Within 10 minutes, use your computer to enter the PIN code displayed on the screen into the wireless LAN router or access point. *For PIN code entry methods, see the instruction manual provided with the wireless LAN router or access point you are using.
  • Page 18 Configuring with WPS Features (Pin Code Mode) << Previous Next >> 8. Make sure the WiFi indicator blinks. When the wireless LAN router or access point is detected, the Wi-Fi indicator blinks. The screen below is displayed for approximately 2 seconds, and then the Wi-Fi indicator will remain solidly lit. *If an error message appears, press [OK] to close the screen and follow the procedure again from Step 5...
  • Page 19 Configuring with WPS Features (Pin Code Mode) << Previous Next >> 9. Wait until the machine sets the IP address automatically (approx. 2 min). The machine sets the IP address automatically and connects to the network. If you want to set the IP address manually, see the following. •e-Manual “Setting the IP Address (IPv4) •e-Manual “Setting the IP Address (IPv6) Automatic obtaining of the IP address (Auto IP)

  • Page 20: Configuring Manually

    Configuring Manually << Previous Next >> If your wireless LAN routers and/or access points do not support WPS, enter the wireless LAN router and/or access point information to the machine for connection. Select Access Point From the list of access points searched by the machine, select a wireless LAN router or an access point to be connected and enter a network key for connection.
  • Page 21 Configuring Manually << Previous Next >> Preparing The following information is required. Check your wireless LAN routers and/or access points, and make a note of the information labeled on the bottom. * See the manual provided with your wireless LAN routers and/or access points, or contact the manufacturer for where the information is displayed or how to check it.

  • Page 22: Required Information

    Configuring Manually (Required Information) Access Point Name/Network Name * It may be labeled as “SSID.” It is the distinguished name for specifying a particular access point. It is used for selecting an access point. Network Key *It is also called encryption key, WEP key, WPA/WPA2 passphrase, PSK or pre-shared key. It is a password that must be set in order to prevent communications from being intercepted.

  • Page 23: Using The Wireless Setup Assistant

    If the SSID and network key are not indicated on the body of the wireless LAN router or access point or if you are not sure because they are changed, you can check using Canon MF/LBP Wireless Setup Assistant. * Canon MF/LBP Wireless Setup Assistant is included in the supplied User Software CD-ROM.
  • Page 24 Configuring Manually (Using the Wireless Setup << Previous Next >> Assistant) 3. Click [Additional Software Programs].
  • Page 25 Configuring Manually (Using the Wireless Setup << Previous Next >> Assistant) 4. Click [Start] for [Canon MF/LBP Wireless Setup Assistant].
  • Page 26 Configuring Manually (Using the Wireless Setup Assistant) 5. Read the License Agreement. If you agree, click [Yes]. 6. The information for the wireless LAN router or access point is displayed. Write down the information outlined in orange. << Previous Next >>...
  • Page 27 Configuring Manually (Using the Wireless Setup Assistant) If multiple access points are displayed Write down all of the displayed SSIDs When wireless LAN routers or access points are not displayed Click [Refresh] When information is not displayed even after clicking [Refresh], check that the settings for the computer and wireless LAN or access point are complete.
  • Page 28 Configuring Manually (Selecting Access Points) << Previous Next >> From the list of access points searched by the imageCLASS device, select a wireless LAN router or an access point to be connected and enter a network key for connection. Selecting Access Point For selecting access points, WEP 802.11 authentication system is set to <Open System>, while WPA/WPA2 is set to Auto>...
  • Page 29 Configuring Manually (Selecting Access Points) << Previous Next >> 3. Select <Wireless LAN Settings> using [ ] or [ ] and press [OK]. 4. Press [OK]. 5. Select <SSID Settings> using [ ] or [ ] and press [OK].
  • Page 30 Configuring Manually (Selecting Access Points) << Previous Next >> 6. Select <Select Access Point> using [ ] or [ ] and press [OK].
  • Page 31 Configuring Manually (Selecting Access Points) << Previous Next >> 7. Select the matched SSID that you have written down earlier using [ ] or [ ], and then press [OK]. If multiple matched SSID are displayed, select the one that is displayed at the top (a stronger signal).
  • Page 32 Configuring Manually (Selecting Access Points) << Previous Next >> 8. Enter the network entry format that matches the number of network key characters (digits) that you have written down earlier using [ ] or [ ], and then press [OK]. Either of the following screens is displayed.
  • Page 33 Configuring Manually (Selecting Access Points) << Previous Next >> 9. Enter the network key that you have written down. ASCII text 1. Press [ ] (Tone), and the select <Entry Mode>. 2. Enter the network key. Enter it using the numeric keys. 3.
  • Page 34 Configuring Manually (Selecting Access Points) << Previous Next >> 10. Select <Yes> using [ ] and press [OK].
  • Page 35 Configuring Manually (Selecting Access Points) << Previous Next >> 11. Make sure the Wi-Fi indicator blinks. When the wireless LAN router or access point is detected, the Wi-Fi indicator blinks. The screen below is displayed for approximately 2 seconds, and then the Wi-Fi indicator will remain solidly lit. If an error message appears, press [OK] to close the screen, check to make sure that the network key is correct, and follow the procedure from step 4.
  • Page 36 Configuring Manually (Selecting Access Points) 12. Wait until the machine sets the IP address automatically (approx. 2 min). The machine sets the IP address automatically and connects to the network. If you want to set the IP address manually, see the following. •e-Manual “Setting the IP Address (IPv4) •e-Manual “Setting the IP Address (IPv6) Automatic obtaining of the IP address (Auto IP)
  • Page 37 Configuring Manually (Manually Entering SSID) << Previous Next >> 1. Press [ ] (Menu). 2. Select <Network Settings> using [ ] or [ ], and then press [OK]. 3. Select <Wireless LAN Settings> using [ ] or [ ], and then press [OK]. 4.
  • Page 38 Configuring Manually (Manually Entering SSID) << Previous Next >> 5. Select <SSID Settings> using [ ] or [ ], and then press [OK]. 6. Select <Manual Settings> using [ ] or [ ], and then press [OK]. 7. Enter the SSID that you have written down. After entering it using the numeric keys, select <Apply>...
  • Page 39 Configuring Manually (Manually Entering SSID) 8. Select encryption types that you have written down using [ ] or [ ], and then press [OK]. In case of <None>, go to step 12. 9. Select the authentication method or encryption type that you have written down using [ ] or [ ], and then press [OK].
  • Page 40 Configuring Manually (Manually Entering SSID) 2. Select <Edit WEP Key> using [ 3. Select the WEP key using [ * Select the key number to be used for encryption which you wrote down earlier. When the type of encryption is WPA/WPA2-PSK Auto (AES-CCMP or TKIP) •...
  • Page 41 Configuring Manually (Manually Entering SSID) 10. Select the entry format that matches the number of network key characters (digits) that you have written down, using [ ] or [ ]then press [OK]. Either of the following screens is displayed. << Previous Next >>...
  • Page 42 Configuring Manually (Manually Entering SSID) 11. Enter the network key that you have written down earlier ASCII text 1. Press [ ](Tone), and then select <Entry Mode>. 2. Enter the network key, using the numeric keys. 3. After entering, select <Apply> using [ When WEP is the encryption type •...
  • Page 43 Configuring Manually (Manually Entering SSID) Hexadecimal 1. Enter the network key. *Select the characters using [ 2. Select <Apply> using [ 12. Select <Yes> using [ ], and then press [OK]. ] or [ ], and then press [OK] to enter. ] or [ ], and then press [OK].
  • Page 44 Configuring Manually (Manually Entering SSID) << Previous Next >> 13. Make sure the Wi-Fi indicator blinks. When the wireless LAN router or access point is detected, the Wi-Fi indicator blinks. The screen below is displayed for approximately 2 seconds, and then the Wi-Fi indicator will remain solidly lit. *If an error message appears, press [OK] to close the screen and check to make sure that the type of encryption, method, the network key are correctly entered.
  • Page 45 Configuring Manually (Manually Entering SSID) 14. Wait until the machine sets the IP address automatically (approx. 2 min). The machine sets the IP address automatically and connects to the network. If you want to set the IP address manually, see the following. •e-Manual “Setting the IP Address (IPv4) •e-Manual “Setting the IP Address (IPv6) Automatic obtaining of the IP address (Auto IP)
  • Page 46 Congratulations! << Previous Next >> You have successfully added your Canon imageCLASS device to your wireless network.
