Sony CFD-E10 Service Manual

SERVICE MANUAL
Ver 1.2 2003. 11
Sony Corporation
9-873-683-03
2003K16-1 Personal Audio Company
© 2003.11 Published by Sony Engineering Corporation
SPECIFICATIONS
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a
distance of about 200 mm from the
objective lens surface on the optical
pick-up block with 7 mm aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm)
(CLV)
Number of channels
2
Frequency response
20 - 20,000 Hz +1/–2 dB
Wow and flutter
Below measurable limit
Radio section
US model:
Frequency range
FM: 87.5 - 108 MHz
AM:530 - 1,710 kHz
Except US model:
Frequency range
FM: Italy: 87.5 - 108 MHz/Other
countries: 87.5 - 107 MHz
AM: Italy: 526.5 - 1 606.5 kHz/Other
countries: 530 - 1 611 kHz
IF
FM: 10.7 MHz
AM: 455 kHz
Antennas
FM: Telescopic antenna
AM: Built-in ferrite bar antenna
CFD-E10
Model Name Using Similar Mechanism NEW
CD Mechanism Type
Optical Pick-up Name
General
Speaker
Full range: 5.7 cm dia., 2.7 Ω, cone
type (2)
Outputs
Headphones jack (stereo minijack)
For 8 - 32 ohms impedance
headphones
Power output
1 W + 1 W (at 2.7 Ω , 10 % harmonic
distortion in AC operation)
Power requirements
DC IN 6 V accepts:
Supplied AC power adaptor for use
with 110-120 V, 220-240 V AC
selectable, 50/60 Hz (Tourist model),
with 120 V AC, 60 Hz (US model),
with 230 V AC, 50 Hz (Other models),
6 V DC, 4 size AA (R6) batteries
Power consumption
DC 11.5 W (US model)
DC 13 W (except US model)
Battery life
When playing a CD:
Sony R6P: approx. 2 hours
Sony alkaline LR6: approx 4 hours
Dimensions
Approx. 315 × 131 × 70 mm (w/h/d)
× 5 × 2
5 1 7 inches) (incl.
(12 ⁄ ⁄ ⁄
8
4 8
projecting parts)
Mass
Approx. 920 g (2 lb.) (incl. batteries)
Supplied accessory
AC power adaptor (1)
Design and specifications are subject to
change without notice.
PERSONAL AUDIO SYSTEM
US Model
AEP Model
UK Model
E Model
Tourist Model
KSM-900AMA
KSS-900A
