Aerial Connections
• To enjoy a clearer picture, we recommend that you use an outdoor aerial. The following is a brief
explanation of the types of connection that are used for coaxial:
Aerial Lead: Connect the cable from the aerial to a
standard DIN45325 plug (IEC169-2) and plug it
into the aerial terminal at the back of the TV set.
Rear of TV
SCART-terminal
Aerial terminal
Typical Connections
Enjoy the stunning visuals of a VCR or DECODER by connecting them to this TV set through its Euro-
SCART 21-Pin terminal.
Please refer to the Operation Manual of your VCR for details.
Typical connection (VCR and TV)
through the RF terminal
Web-site: www.sharp.co.uk/support
75-ohm coaxial cable (round cable)
Aerial Lead
(not supplied)
Rear of TV
Aerial Lead
(not supplied)
SCART Lead
(not supplied)
RF Out
Aerial IN
Scart Terminal
Antenna in
Help Line (office hours only): 0990-274277
Outdoor aerial
(not supplied)
Aerial Lead
(not supplied)
Back of VCR
