GENERAL PURPOSE UNDERCOUNTER FREEZERS
This manual describes how to operate and care for your appliance to get the best, most efficient, performance.
Note to Customer:
This merchandise was carefully packed and thoroughly inspected before leaving our plant. Responsibility for its
safe delivery was assumed by the carrier upon acceptance of the shipment. As directed on the side of your
packing carton, claims for loss or damage sustained in transit must be made on the carrier as follows:
A.) Visible Loss, Damage, Shortage External Evidence of Loss or Damage: This type of damage must be noted on
the freight bill and acknowledged by the carrier's agent (driver) at time of delivery. Make sure you get a signed
copy. Send a written request for an inspection to the carrier.
B.) Concealed Damage: This type of damage may not be discovered until the unit is being unpacked. When
concealed damage is discovered, stop unpacking immediately and contact the carrier immediately to report
the claim and request an inspection. This should be done as soon as possible and, in any case, must be done
within 15 days or receiving the merchandise. If at all possible, do not move the item and save all packaging
material for carrier's inspection.
C.) FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN THE CARRIER REFUSING TO HONOR YOUR
COMPANY'S CLAIM. UNDER NO CIRCUMSTANCES SHOULD THE MERCHANDISE BE RETURNED TO THE
MANUFACTURER. NO RETURNS WILL BE ACCEPTED WITHOUT PRIOR AUTHORIZATION.
Horizon Scientific
125 Varnfield Drive
Summerville, SC 29483
Phone: 800-648-4041
Fax:
843-821-8051
LABH-2-FM
OWNER'S INSTRUCTIONS
READ THIS BOOK!
Warranty:
Two-Year Parts and Labor
5 Years Compressor Parts
Revision Date
11/27/2012
Advertisement
Related Manuals for LabRepCo LABH-2-FM
Summary of Contents for LabRepCo LABH-2-FM
- Page 1 GENERAL PURPOSE UNDERCOUNTER FREEZERS LABH-2-FM OWNER’S INSTRUCTIONS This manual describes how to operate and care for your appliance to get the best, most efficient, performance. READ THIS BOOK! Note to Customer: This merchandise was carefully packed and thoroughly inspected before leaving our plant. Responsibility for its safe delivery was assumed by the carrier upon acceptance of the shipment.
-
Page 2: Table Of Contents
TABLE OF CONTENTS RECEIVING ..................3 INSTALLATION ................... 4 NORMAL OPERATION ................ 6 QUICK TROUBLESHOOTING GUIDE ............. 7 MAINTENANCE AND CLEANING ............9 PRODUCT WARRANTY INFORMATION ..........10 BEFORE CALLING THE MANUFACTURER’S TECHNICAL SUPPORT DEPARTMENT, please have the unit’s model and serial number ready as well as the problem description. The model and serial number is located on the serial tag which can be found on the interior left upper wall of the unit. -
Page 3: Receiving
RECEIVING Your unit was built, packaged, and inspected with extreme care. We shipped it to you using carriers we trust with a proven track record of careful handling, good customer service, and on time delivery. Unfortunately, regardless of all of these efforts sometimes accidents happen and occasionally those accidents result in shipping damage. -
Page 4: Installation
INSTALLATION UNCRATING Move the unit as close to the final location as possible before unpacking. Remove from the box and the styrofoam base. The location should be as close as possible to the power outlet so an extension cord is not needed. This unit requires a minimum of 4 inches of air flow space in back and 3 inches on the sides and top. - Page 5 STARTING There are no compressor shipping bolts to loosen or valves to open. All that is necessary after the unit has been properly leveled is to plug the service cord into an electrical outlet When starting this new appliance, allow the cabinet to operate a minimum of eight hours or until it has started cycling normally before placing product in the cabinet.
-
Page 6: Normal Operation
NORMAL OPERATION After the unit is properly installed and power is applied, it will take some time before the system is cooled down to temperature and cycling normally. You should wait 8 hours on the first startup before beginning to add product to the unit. This ensures that the unit is installed and operating properly before being put into service. -
Page 7: Quick Troubleshooting Guide
QUICK TROUBLESHOOTING GUIDE Check these items before calling for service PROBLEM: POSSIBLE CAUSE / SOULTIONS: Electrical circuit is not 110-120V 60Hz. The power cord is not plugged in. No power at electrical outlet. Check to make sure Unit does not run breaker is not tripped or fuse is not blown. - Page 8 PROBLEM: POSSIBLE CAUSE / SOULTIONS: Compressor may be overheated. Please check the room Compressor noises temp and ensure the range is within 65°F to 85°F. If the problem still exists, call for service. Door gasket is not sealing properly. Check for debris, cracks, and items passing through door at the gasket.
-
Page 9: Maintenance And Cleaning
MAINTENANCE AND CLEANING These units require very little maintenance. They should be cleaned periodically to keep them running efficiently. Use the cleaning agents and suggestions in the table below for best results. The freezers should be defrosted and cleaned whenever ¼ to ½ inch of frost has accumulated inside the unit or if the unit will not maintain proper temperature. -
Page 10: Product Warranty Information
PRODUCT WARRANTY INFORMATION HORIZON SCIENTIFIC, INC. PRODUCT WARRANTY Horizon Scientific, Inc. warrants to the original purchaser every new Horizon Scientific, Inc. refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, when such unit is installed, used, and maintained in accordance with provided instructions, for a period of two (2) years. - Page 11 OR NOT INSURED, SHALL NOT EXCEED THE COST OF THE PRODUCT(S) GIVING RISE TO THE CLAIM OR LIABILITY. WARRANTY IS NOT TRANSFERABLE. This warranty is not assignable and applies only in favor of the original purchaser/user to whom delivered. Any such assignment or transfer shall void the warranties herein made and shall void all warranties, express or implied, including any warranty of merchantability or fitness for a particular purpose.
