FAVORIT 40660
Dishwasher
User information

Advertisement

Table of Contents
loading

Related Manuals for AEG Favorit 40660

Summary of Contents for AEG Favorit 40660

  • Page 1 FAVORIT 40660 Dishwasher User information...
  • Page 2 Dear Customer, Please read this user information carefully and keep it to refer to later. Please pass the user information on to any future owner of the appli- ance. The following symbols are used in the text: Safety instructions Warning! Information that affects your personal safety. Important! Information that prevents damage to the appliance.

  • Page 3: Table Of Contents

    Contents Operating Instructions Safety ............Diagram of Appliance .

  • Page 4: Operating Instructions

    Operating Instructions 1 Safety Prior to using for the first time • Follow the ”Instructions for installation and connection”. Correct Use • The dishwasher is only intended for washing domestic dishes. • Additions or modifications to the dishwasher are not permitted. •...

  • Page 5: Diagram Of Appliance

    Diagram of Appliance Top Spray Nozzle Upper basket spray arm and lower spray arm Water softener unit. Salt Container Detergent Dispenser Rinse aid dispenser Rating plate Filters Control Panel ON/OFF button The ON/OFF button is used to turn the dishwasher on and off.
  • Page 6 The Programme buttons are used to select the desired dishwashing cy- cle. Function buttons: In addition to the pre-set dishwashing cycle, the following functions can also be set using these buttons: Function button 1 Function button 2 Function button 3 The rinse aid inflow is only affected, if the 3in1 function is selected.

  • Page 7: Prior To Using For The First Time

    Prior to Using for the First Time If you wish to use 3 in 1 detergent: – First read the section “Using 3in1 detergents”. – Do not fill up with special salt or rinse aid. If you do not use 3in1 detergent, before using for the first time 1.
  • Page 8 3. Press function button 1. The LED indicator for function button 1 will flash. The LED indicator for the end of the dishwashing cycle will flash simul- taneously: – The number of times that the LED indicator for the end of the dish- washing cycle flashes corresponds to the hardness setting.

  • Page 9: Adding Dishwasher Salt

    Adding dishwasher Salt To decalcify the water softener, it must be filled up with dishwasher salt. Use only special salt suitable for domestic dishwashers. If you do not use 3 in1 detergent, fill up with dishwasher salt: – Before using the dishwasher for the first time. –...

  • Page 10: Filling Up With Rinse Aid

    Filling Up with Rinse Aid Rinse aid causes the rinse water to flow easily from the crockery leav- ing gleaming dishes and glassware. If you do not use 3in1 detergent, fill up with rinse aid: – Before using the dishwasher for the first time. –...

  • Page 11: Setting The Amount Of Rinse Aid Required

    Setting the Amount of Rinse Aid Required Only change the amount dispensed, if smears, milky spots (reduce the amount) or dried on water spots (increase the amount) can be seen on glasses and dishes. (See section “If dishwashing results are not satisfac- tory”.) The dosage can be set from 1-6.
  • Page 12 Activating rinse aid inflow when 3in1 function is se- lected If the 3in1 function is not selected, the rinse aid inflow is always acti- vated. If the 3in1 function is selected due to the use of 3in1 detergent, the rinse aid inflow is deactivated. If the dishes then do not dry sufficiently, you should re-activate the rinse aid inflow (see also section “Using 3in1 detergents”).

  • Page 13: In Daily Use

    In daily use Loading cutlery and dishes Sponges, cleaning cloths and any other objects that can absorb water must not be washed in the dishwasher. Plastic and Teflon-coated dishes and pans tend to retain water droplets. These dishes and pans therefore do not dry as well as those made of china and stainless steel.

  • Page 14: Loading Cutlery

    Loading cutlery Warning: Sharp knives and other items of cutlery with sharp edges must be laid in the cutlery rack or in the upper basket to avoid the risk of injury. To ensure that all items of cutlery in the cutlery basket can be reached by the water, you should: 1.Place the grid insert on the cut- lery basket...
  • Page 15 To make it easier to load larger dish- es, the two plate racks on the right in the lower basket can be folded down. Cups, Glasses, Coffee Service Load smaller, fragile crockery and long, sharp cutlery in the upper bas- ket.

  • Page 16: Adding Detergent

    Adding Detergent Detergents remove the dirt from dishes and cutlery. The detergent must be added before the cycle starts. Only use detergent intended for do- mestic dishwashers. The detergent compartment is lo- cated on the inside of the door. 1. If the lid is closed: Press the release button.

  • Page 17: Concentrated Detergents

    Concentrated detergents Today’s detergents for dishwashers are almost exclusively low-alkaline concentrated detergents with natural enzymes in tablet or powder form. Using 50°C dishwashing cycles in conjunction with these concentrated detergents reduces pollution and is good for your dishes, as these dish- washing cycles are specially matched to the dirt-dissolving properties of the enzymes in concentrated detergents.

  • Page 18: Using 3In1 Detergents

    Using 3in1 detergents These products are detergents with a combined cleaning, rinsing and salt function. When the 3in1 function is activated, – the addition of special salt and rinse aid from the respective dispenser is prevented. – If the salt and rinse aid dispensers are empty, this is not indicated. –...

  • Page 19: Selecting The Dishwashing Cycle (Cycle Table)

    Selecting the dishwashing cycle (Cycle Table) Dishwashing- Suitable cycle for: INTENSIV Dinner service CARE 70° and cookware 30 MIN Dishes, excluding (60°) saucepans NORMAL Dinner service 65° and cookware Dinner service and cookware, 50° temperature-sen- sitive crockery 1) The consumption values were obtained under standardised conditions. They depend on how full the baskets for the dishes are.

  • Page 20: Selecting A Programme

    Selecting a programme When your dishes look like this, select: an intensive programme. a normal or energy-saving pro- gramme. a short programme (e.g. 30 minute programme).

  • Page 21: Starting A Dishwashing Cycle

    Starting a Dishwashing Cycle 1. Check that the spray arms can turn freely. 2. Turn the water tap on fully. 3. Close the door. 4. Press the ON/OFF button. 5. Select the desired cycle. The programme display lights up. The selected cycle will begin after ap- proximately 3 seconds.

  • Page 22: Switching Off The Dishwasher

    3. Select dishwashing cycle. The LED indicator for the programme selected and the indicator next to the number of hours will light up. The dishwashing cycle will start automatically following a countdown of the hours set. To change the time delay: As long as the cycle has not yet started, you can still change the setting by pressing the DELAY TIMER button.

  • Page 23: Care And Cleaning

    Care and cleaning Do not use furniture care products or aggressive cleaners. • When necessary, clean the dishwasher’s controls with a soft cloth. • Occasionally check the internal dispensers, door seal and water inlet filter (if fitted) for dirt and clean them, if necessary. Cleaning the filters The filters must be regularly checked and cleaned.
  • Page 24 5. Remove the flat filter (3) from the base of the washing compartment and clean both surfaces thoroughly. 6. Re-insert the flat filter. 7. Place the fine filter in the micro-fil- ter and fit the two together. 8. Insert the filter system in place and lock it by turning the handle clock- wise as far as it will go.
  • Page 25 3. Place cleaned upper basket spray arm back in position against the connect- ing piece: press the two together firmly, until you feel them snap into place. Bottom spray arm 1. To remove bottom spray arm, pull it upwards out of its catch. 2.

  • Page 26: What To Do If

    What to do if... Remedying small malfunctions If while the appliance is operating indicators on the control panel flash or are lit up as described in the following table, please consult this to find out how to remedy the fault. After remedying the fault that is flashing in the first or second rhythm in the programme progress display, press the button for the dishwashing cycle that had already started.
  • Page 27 Malfunction the indicator for the end of the dishwashing cycle is flashing in sequence 3 short light signals one after anoth- The cycle is not starting. Rust spots are visible in the dishwashing compartment. A whistling noise can be heard when washing dishes. Possible cause The anti-flood system has been triggered.

  • Page 28: If The Dishwashing Results Are Not Satisfactory

    If the Dishwashing Results are not Satisfactory The dishes are still dirty. • The wrong dishwashing cycle was selected. • The dishes were loaded is such a way that the dishwashing water did not reach all items. The baskets for the dishes must not be overload- •...

  • Page 29: Disposal

    Disposal Packaging material The packaging materials are environmentally friendly and can be recy- cled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at your local waste disposal facilities. Old appliance The symbol on the product or on its packaging indicates that this...

  • Page 30: Technical Data

    Technical data Capacity: Permitted water pres- sure: Electrical connection: Total output Dishwasher: Free-standing appliances Dimensions: Max. weight: This appliance conforms with the following EU Directives: – 73/23/EEC dated 19.02.1973 Low Voltage Directive – 89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Directive 92/31/EEC –...

  • Page 31: Notes For Test Institutes

    Notes for Test Institutes Testing in accordance with EN 60704 must be carried out with the appliance fully loaded and using the test cycle (see “Cycle Table”). Tests in accordance with EN 50242 must be carried out when the salt dispenser in the water softener and the rinse aid dispenser have been filled with salt and rinse aid respectively, and using the test cycle (see “Cycle Table”).
  • Page 32 Lower basket with cutlery basket Cutlery basket *) If there are cup racks in place on the lefthand side or if beer glass holders are in place, remove them.

  • Page 33: Installation And Connection Instructions

    Installation and connection instructions 1 Safety Information for the Installation • Only transport the dishwasher in an upright position, otherwise salt water may run out. • Before using the dishwasher for the first time, check for any damage caused in transport. Do not under any circumstances connect an ap- pliance that is damaged.

  • Page 34: Installing The Dishwasher

    Installing the Dishwasher • The dishwasher must be installed on a firm floor and adjusted to en- sure that it is stable and level in all directions. • To compensate for unevenness in the floor and to match the height of the appliance to that of sur- rounding units, extend the thread- ed feet using a screwdriver.
  • Page 35 Free-standing appliances If the dishwasher is installed directly next to a cooker, a heat-insulat- ing, non-flammable panel (laminated with aluminium foil on the side next to the cooker) must be fitted flush with the top edge of the work surface (depth 57.5 cm). If the appliance is built-in under a kitchen work surface, the worktop supplied with the dishwasher can be...

  • Page 36: Connecting The Dishwasher

    Connecting the dishwasher Connecting to the water supply • The dishwasher can be connected to cold and hot water supplies up to max. 60°C. • The dishwasher must not be connected to open hot water appliances or instantaneous water heaters. Permitted water pressure Lowest permitted water pressure: 1 bar (=10 N/cm2 =100 kPa)

  • Page 37: Water Drainage

    Water drainage Drain hose The drain hose must not be kinked, crushed or entangled. Connecting the drain hose: – Maximum permitted height: 1 metre. – Minimum required height: 40 cm above the bottom edge of the ap- pliance. Extension hoses •...

  • Page 38: Electrical Connection

    2. Secure the drain hose so that it cannot slide off the edge of the sink. Pass a piece of cord through the hose elbow and fix it to the wall or the tap. Anti-flood system For protection from water damage, the dishwasher is equipped with a anti-flood system.

  • Page 39: Connecting Systems

    • The wire coloured green and yellow must be connected to the termi- nal marked with the letter “E“ or by the earth symbol E or coloured green and yellow. • The wire coloured blue must be connected to the terminal “N“ or col- oured black.

  • Page 40: Warranty Conditions

    Great Britain Standard guarantee conditions We, AEG, undertake that if within 12 months of the date of the purchase this AEG appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we...

  • Page 43: Service And Spare Parts

    Customer Care For general enquiries concerning your AEG-Electrolux appliance, or for further information on AEG- Electrolux products please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.aeg.co.uk.
  • Page 44 USD 14 billion in more than 150 countries around the world. AEG Hausgeräte GmbH Postfach 1036 D-90327 Nürnberg http://www.aeg-electrolux.de © Copyright by AEG 822 612 648-00-300605-02 Subject to change without notice...
