MICRO COMPONENT SYSTEM
MODEL
XL-S15H
OPERATION MANUAL
If you require any advice or assistance regarding
your Sharp product, please visit our web-site
www.sharp.co.uk/customersupport.
Customers without Internet access may telephone
08705 274277 during office hours (or (01) 676 0648
if telephoning from Ireland).
Thank you for purchasing this SHARP product.
To obtain the best performance from this product,
please read this manual carefully. It will guide you in
operating your SHARP product.
XL-S15H Micro Component System consisting of XL-
S15H (main unit) and CP-S15H (speaker system).
1
XL-S15H(UK) TINSEA028SJZZ
Advertisement
Table of Contents
Related Manuals for Sharp XL-S15H
Summary of Contents for Sharp XL-S15H
- Page 1 To obtain the best performance from this product, MICRO COMPONENT SYSTEM please read this manual carefully. It will guide you in operating your SHARP product. XL-S15H Micro Component System consisting of XL- MODEL S15H (main unit) and CP-S15H (speaker system). XL-S15H...
- Page 2 Where plug destroyed immediately and disposed of in a safe manner. this is not possible, please visit our web-site www. sharp.co.uk/ customersupport. Under no circumstances should the cut-off plug be inserted else-...
- Page 3 NOTES ! Recording and playback of any material may require consent, which SHARP is unable to give. Please refer particularly to the provisions of the Copyright Act 1956, the Dramatic and Musical Performers Protection Act 1958, the Performs Protection Acts 1963 and 1972 and to any subsequent statutory enactments and orders.
-
Page 4: Table Of Contents
Accessories Contents XL-S15H Please confirm that the following accessories are included. Page " General Information Precautions ......... . 5 Controls and indicators . -
Page 5: Precautions
SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other ! Do not place anything on top of the unit. -
Page 6: Controls And Indicators
Controls and indicators XL-S15H Reference page 1. CD Compartment ....... . . 12 2. - Page 7 XL-S15H(UK) TINSEA028SJZZ XL-S15H 1. Full-Range Speaker 2. Speaker Wire Note: The speaker grilles are not removable. Reference page 3. Remote Control Transmitter ......9 4.
-
Page 8: System Connections
System connections XL-S15H Make sure to unplug the AC power lead before making any connections. FM aerial AM loop aerial " Aerial connection Connect the FM/AM loop aerial to the ANTENNA socket. Position the FM aerial wire and rotate the AM loop aerial for opti- mum reception. -
Page 9: Remote Control
XL-S15H " Connecting the AC power lead " To turn the power on After checking all the connections have been made correctly, plug Press the ON/STAND-BY button to turn the power on. the AC power lead of this unit into the wall socket. -
Page 10: Sound Control
Sound control XL-S15H " Adjusting the volume Main unit operation: When the VOLUME control is turned clockwise, the volume will increase. When it is turned anti-clockwise, the volume will decrease. Remote control operation: Press the VOLUME + button to increase the volume and the VOL- UME - button to decrease the volume. -
Page 11: Setting The Clock
Setting the clock XL-S15H Within 1 minute, press the PRESET ( ) button to ad- just the hour and then press the MEMORY button. When the 12-hour display is selected, "AM" will change auto- matically to "PM". Within 1 minute, press the PRESET ( ) button to ad- This may be operated only with the remote control. -
Page 12: Listening To A Cd
Listening to a CD XL-S15H This system can play audio CD-R and CD-RW discs just like CD Press the ON/STAND-BY button to turn the power on. discs, but cannot perform recording. Playback of audio CD-R or CD-RW may not be performed depend- Press the FUNCTION button until "Cd dISC"... - Page 13 XL-S15H " To locate the beginning of a track To interrupt playback: Main unit operation: To move to the beginning of the next track: Press the button. To resume playback from the same point, press Press the button for less than 0.5 seconds during playback.
- Page 14 XL-S15H Listening to a CD (continued) " Repeat or Random play Notes: ! The random play will stop automatically when all tracks are You can select one of the CD playback mode; "Repeat play", "Ran- played once. (The same track will not be played back twice.) dom play"...
-
Page 15: Programmed Play
Programmed play XL-S15H You can choose up to 32 selections for playback in the order you Whilst in the stop mode, press the button to se- like. lect the desired track. Selected track number Press the MEMORY (MEMORY/SET) button to save the track number. -
Page 16: Listening To The Radio
Listening to the radio XL-S15H Press the ON/STAND-BY button to turn the power on. Press the FUNCTION button until "FM" or "AM" appears on the display. When operating with the remote control, press the TUNER (BAND) button to select "FM" or "AM". -
Page 17: Listening To The Memorised Station
Listening to the memorised station XL-S15H " Memorising a station " To recall a memorised station You can store 40 AM and FM stations in memory and recall them at Press the PRESET ( ) button for less than 0.5 seconds to the push of a button. -
Page 18: Listening To A Cassette Tape
Listening to a cassette tape XL-S15H Before playback: Press the ON/STAND-BY button to turn the power on. ! For playback, use normal or low-noise tapes for the best sound. (Metal or CrO tapes are not rec- Press the FUNCTION button until "TAPE" appears on the ommended.) -
Page 19: Recording To A Cassette Tape
Press the ON/STAND-BY button to turn the power on. ! SHARP is not liable for damage or loss of your recording arising from malfunction of this unit. Press the FUNCTION button until "Cd dISC" appears on the ! The volume and sound controls can be adjusted with no effect on display. - Page 20 XL-S15H Recording to a cassette tape (continued) " Recording from the radio " Erasing a recorded tape 1. Load the tape to be erased into the cassette compartment with Tune in to the desired station (see page 16). the side to be erased facing toward you.
-
Page 21: Timer And Sleep Operation
Timer and sleep operation XL-S15H This may be operated only with the remote control. " Timer playback Timer playback: Press the ON/STAND-BY button to turn the power on. The unit turns on and plays the desired source (CD, tuner) at the Press the CD or TUNER (BAND) button to select the de- preset time. - Page 22 XL-S15H Timer and sleep operation (continued) To cancel the sleep operation: When the preset time is reached, playback will start. Press the ON/STAND-BY button whilst "SLEEP" is indicated. To cancel the sleep operation without setting the system to the The volume will increase gradually until it reaches the volume stand-by mode, press the SLEEP button until "OFF"...
-
Page 23: Troubleshooting Chart
! Is the unit placed near the TV or comput- If something is wrong with this product, check the following before usual noises contin- calling your authorised SHARP dealer or service centre. uously. ! Is the FM or AM aerial placed properly? "... - Page 24 XL-S15H Troubleshooting chart (continued) " If trouble occurs " Condensation When this product is subjected to strong external interference Sudden temperature changes, storage or operation in an extremely (mechanical shock, excessive static electricity, abnormal supply humid environment may cause condensation inside the cabinet (CD voltage due to lightning, etc.) or if it is operated incorrectly, it may...
-
Page 25: Maintenance
Maintenance XL-S15H " Cleaning the CD pickup lens " Care of compact discs Compact discs are fairly resistant to damage, however mistracking Do not touch the laser pickup lens. If fin- can occur due to an accumulation of dirt on the disc surface. Follow... -
Page 26: Specifications
Specifications XL-S15H As part of our policy of continuous improvement, SHARP reserves " CD player the right to make design and specification changes for product Type Compact disc player improvement without prior notice. The performance specification fig- ures indicated are nominal values of production units. There may be... - Page 27 Downloaded from: http://www.usersmanualguide.com/...
-
Page 28: Terms Of Guarantee
