VB-AUD-201
Conference Speakerphone
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website.
Model No. VS19004
P/N: VB-AUD-201
Advertisement
Table of Contents
Related Manuals for ViewSonic VB-AUD-201
Summary of Contents for ViewSonic VB-AUD-201
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
- Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
-
Page 3: Table Of Contents
Contents Product Overview ............4 Package Contents ....................4 Overview.........................5 Making Connections ............ 6 USB Connection ......................6 Bluetooth Connection ....................6 Audio Output ......................7 Using the Speakerphone ..........8 Powering On/Off ....................8 Button Control ......................9 Status LED Indicator....................9 Charging ........................10 Charging the Speakerphone .................. 10 Charging External Equipment ................ -
Page 4: Product Overview
Product Overview Package Contents Please take a moment to check if all the necessary items are included in Overview VB-AUD-201 Converse 1 2 3 4 5 the package. If anything is missing or damaged, please contact your dealer Conference Speakerphone immediately. -
Page 5: Overview
Overview 1 2 3 4 5 11 12 Bluetooth LED indicator Volume up button Bluetooth button Call button Mute button Status indicator USB port for charging output (Type-A) Multi-function button Volume down button Audio output port Power button USB port for charging input (Type-C) Power LED indicator Warning •... -
Page 6: Making Connections
Making Connections USB Connection Warning: Do not connect the USB cable to a cellphone. Bluetooth Connection When the speakerphone is powered on for the first time, it will automatically enter Bluetooth pairing mode. Press once Enter pairing mode Blue indicator is flashing Bluetooth pairing Blue indicator is always on Bluetooth connected... -
Page 7: Audio Output
Audio Output Connect an external speaker to the AUX jack of the speakerphone with an AUX cable (not provided). The audio will be played through the external speaker. -
Page 8: Using The Speakerphone
Using the Speakerphone Powering On/Off 1. Press and hold the power button for two (2) seconds to turn on the power; the Status Indicator will light up from top to bottom then turn off. 2. Press and hold the power button for two (2) seconds to turn off the power; the Status Indicator will light up from bottom to top then turn off. -
Page 9: Button Control
Button Control Press or hold Volume up/down Press Answer/end calls Press and hold for 2 seconds Refuse calls Press Turn the microphone off/on Press Play/pause music Status LED Indicator The USB cable has been connected to a White indicator is on for 2 seconds computer Green indicator is flashing Calling... -
Page 10: Charging
Charging Charging the Speakerphone Power Indicator Status Red indicator is always on Currently charging White indicator is always on Fully charged Red indicator is flashing Low battery Charging External Equipment NOTE: • If the speakerphone is powered off or charging, charging output is not available. -
Page 11: Troubleshooting
The maximum range for VB-AUD-201 is 20 feet/6 meters. Try moving closer to the device you are connected to. And check the specifications on your connected device to see how close you need to be... -
Page 12: Specifications
(1) Input: USB Type-C interface; External power supply supplies power to VB-AUD-201 device through USB Type-C interface. Power (2) Output: USB Type-A interface. VB-AUD-201 can reverse charge peripherals such as mobile phones through USB Type-A interface. Button Touch button (mute button with light indicator) - Page 13 Item Category Specifications Environment Battery specification: 6500mAh; Rechargeable Full charge time: 4 hours (5V/2A); Condition Battery Maximum charging current: 2.1A; Duration: 24 hours; 4.88 x 4.88 x 1.26(inch) Dimensions 124 x 124 x 32(mm) (without packaging) Weight 0.71 lbs/0.32 kg (Net) Temperature: 0°C ~ 40°C (working state), -20°C ~ 60°C (non-working state) Working...
-
Page 14: Regulatory And Service Information
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 15: Fcc Radiation Exposure Statement
FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. -
Page 16: Ic Radiation Exposure Statement
IC Radiation Exposure Statement This equipment complied with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. The device for the band 5150-5825 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems. -
Page 17: Declaration Of Rohs2 Compliance
Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Actual Concentration... -
Page 18: Copyright Information
VESA is a registered trademark of the Video Electronics Standards Association. DPMS, DisplayPort, and DDC are trademarks of VESA. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 19: Customer Service
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn www.viewsonic.com/hk/ 香港 (繁體中文) Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/... -
Page 20: Limited Warranty
ViewSonic® Conference Speakerphone What the warranty covers: ViewSonic® warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, and as your sole remedy, repair or replace the product with a similar product. - Page 21 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
- Page 22 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
-
Page 23: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &... - Page 24 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
- Page 25 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
- Page 26 C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...
