- Page 1 Installation Manual of DS-7600NI-H2/P Series DS-7600NI-H2/P Series Installation Manual UD.7L0202D1761B01...
- Page 2 Installation Manual of DS-7600NI-H2/P Series Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. Before you start, read the following statement first: This manual, as well as the software described in it, is furnished under license and may be used or copied only in accordance with the terms of such license.
- Page 3 Installation Manual of DS-7600NI-H2/P Series Preventive and Cautionary Tips Before connecting and operating your NVR, please be advised of the following tips: It is not recommended to replace the batteries by the user, since improper use or replacement of the battery may result in hazard of explosion.
-
Page 4: Table Of Contents
Installation Manual of DS-7600NI-H2/P Series Table of Contents Chapter 1 Overview ............................. 3 Chapter 2 Chipset Features ..........................4 Chapter 3 Interface Description ......................... 5 Front Panel Introduction ......................5 Rear Panel Introduction ......................5 Motherboard Introduction ......................6 Chapter 4 Operating System Installation ...................... -
Page 5: Chapter 1 Overview
Installation Manual of DS-7600NI-H2/P Series Chapter 1 Overview DS-7600NI-H2/P series is an embedded development platform. It is designed for professional digital surveillance. It is featured with well performance in CPU processing, encoding and decoding, and storage capability. Due to the openness of IA structure, various PC application software can be applied to the product, and providing a flexible NVR solution for the software developers or system integrators. -
Page 6: Chapter 2 Chipset Features
Installation Manual of DS-7600NI-H2/P Series Chapter 2 Chipset Features Intel® Celeron® Processor J1900 (2M Cache, 2.00GHz) with low power consumption and high performance. Flexible development due to IA structure. 1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface. ... -
Page 7: Chapter 3 Interface Description
Installation Manual of DS-7600NI-H2/P Series Chapter 3 Interface Description 3.1 Front Panel Introduction Figure 3. 1 View of Front Panel Table 3. 1 Description of Front Panel Name Description When the device is off and the power switch in rear panel is on, press the power button to start the device. -
Page 8: Motherboard Introduction
Installation Manual of DS-7600NI-H2/P Series Name Description Line in Audio input for two-way audio function. Network interface for the cameras and to provide power over Ethernet. 4 PoE interfaces for DS-7600NI-H2/4P and 8 for DS-7600NI-H2/8P. Universal Serial Bus (USB) 3.0 port for additional device such as USB USB 3.0 mouse and USB Hard Disk Drive (HDD). - Page 9 Installation Manual of DS-7600NI-H2/P Series Description Front panel interface, with 6 pins. FAN interface. USB 2.0 interface for front panel, with 9 pins. PoE card interface, with 24 pins.
-
Page 10: Operating System Installation
Installation Manual of DS-7600NI-H2/P Series Chapter 4 Operating System Installation 4.1 Installing a HDD Before you start: Before installing a hard disk drive (HDD), please make sure the power is disconnected from the NVR. A factory recommended HDD should be used for this installation. Steps: 1. -
Page 11: Setting Boot Sequence
Installation Manual of DS-7600NI-H2/P Series Figure 4. 3 Placing the HDD and Fastening the Screws 5. Re-install the cover of the NVR and fasten screws. 4.2 Setting Boot Sequence Purpose: When installing the operating system, you need to manually set the CD/DVD-ROM Drive as the first boot type. Steps: Enter BIOS interface when starting process by pressing F2 on keyboard. -
Page 12: Installing Operating System
Installation Manual of DS-7600NI-H2/P Series Figure 4. 5 Setting the Boot Type 4.3 Installing Operating System Before you start: If you use a SATA CD/DVD-ROM drive, connect it to the interface of SATA. If you use a USB CD/DVD-ROM drive, connect it to any of the USB interfaces. Step: Insert the Windows installation CD and install the operating system. - Page 13 Installation Manual of DS-7600NI-H2/P Series Graphics Driver Network Driver Audio Driver Figure 4. 6 Computer Management Interface...
-
Page 14: Chapter 5 Specification
Installation Manual of DS-7600NI-H2/P Series Chapter 5 Specification Model DS-7600N-H2/4P DS-7600N-H2/8P Type Intel® Celeron® Processor J1900 (2M Cache, 2.00GHz) Processor Memory size Memory Network Incoming bandwidth 300Mb HDMI output 1-ch, resolution: 1920 × 1080/60Hz Video/Audio VGA output 1-ch, resolution: 2560 × 1600/30Hz output 1 RCA (2.0Vp-p, 1kΩ) Audio output...
