Product

M300 / M350

G-sharp

IMPORTANT:

Modification should only be carried out by authorized technicians.

Standard procedure:

1. Always reset and download the latest software to the unit you can find and download

the latest version online from the

2. Reset the unit: Press and hold the (3) TAP button and power on the unit. Then the

letter r should blink in the display(5) to confirm the reset press the load button(4) fig.2.

3. Download software: Connect the MIDI cable to the unit and start the M300

application software fig.4. Press the preset+arrow(up) (2) buttons and power on the

unit for getting into the download mode notice that the 3 green leds should be moving

rapidly(1) see fig.3.

Filename: m300 service

Date: 29-11-2006

Servicenote nr. 760100001

Description:

Service guide M300/M350/G-sharp

software download

TC support site

Fig.2

Fig.3

TC Electronic

Ref. / date

Thsig / 20.12.04

Page 1 of 2

Page 1 Press the preset+arrow(up) (2) buttons and power on the unit for getting into the download mode notice that the 3 green leds should be moving rapidly(1) see fig.3. Fig.3 Filename: m300 service Page 1 of 2 TC Electronic Date: 29-11-2006 Servicenote nr. 760100001...
Page 2 6. Test off all effects: try to listen for digital noise or crackling sound at the output. Filename: m300 service Page 2 of 2 TC Electronic Date: 29-11-2006 Servicenote nr. 760100001...
