U-Line H-995 Quick Start Manual

H-995
VINYL DUNNAGE
INFLATOR GUN
1. Twist cap off to open valve. (See Figure 1)
Figure 1
2. Make sure inner valve is closed. Valve is closed when
the center pin is in the upright position. If open, turn
cross clockwise until the spring pops up, closing the
valve. (See Figure 2)
Figure 2
3. Press and hold the trigger to inflate the bag. Do not
release the trigger; the bag cannot over-inflate.
(See Figure 3)
Figure 3
PAGE 1 OF 3
1-800-295-5510
uline.com
INFLATION
4. When air can be felt exiting the back of the gun,
the Dunnage Bag is inflated and the gun may be
removed. (See FIgure 4)
Figure 4
5. Wait until the gun is completely removed before
releasing the trigger. (See Figure 5)
Figure 5
6. Close the cap on the valve. (See FIgure 6)
Figure 6
Para Español, vea página 2.
Pour le français, consulter la page 3.
0421 IH-995
