- Page 1 FILE NO. LED-19XR11 SERVICE MANUAL PRODUCT CODE No. PRODUCT CODE No. 1 682 351 00: PAL-B/G (CCIR) NTSC(AV) LED-LCD TV INPUT REFERENCE No.:SM0915201...
-
Page 2: Table Of Contents
CONTENTS Safety precautions………………………………………………………………………..… Alignment instructions …………………………….…….………………………………… Software upgrade instructions .................. Working principle analysis……………………………….………….…………....Block diagram…………………………………..………………………………….………… IC block diagram………………………………………………………………………..…… Wiring diagram ……………………………………………………………………………. Troubleshooting flow chart ………………………………………………………………..…… Schematic diagram………………………………………………………………………… APPENDIX-A: Assembly list APPENDIX-B: Exploded View Assembling the Stand WALL MOUNTING INSTRUCTIONS... -
Page 3: Safety Precautions
Attention: This service manual is only for service personnel to take reference with. Before servicing please read the following points carefully. Safety precautions 1. Instructions Be sure to switch off the power supply before replacing or welding any components or inserting/plugging in connection wire. - Page 4 would be unable to work and no way to get it repaired. If the connection wires, connections or components fixed by the thermotropic glue need to disengage when service, please soak the thermotropic glue into the alcohol and then pull them out in case of dagmage.
-
Page 5: Alignment Instructions
Adjustment Instruction Safety Instructions 1.1 Power supply must be cut off when replacing or welding any component or inserting / pulling out connective lines; 1.2 Anti-electrostatic measures must be carried out during the whole producing processes! Do not touch IC by hands at will; Use anti-electrostatic iron;... - Page 6 3.2 Adjustment flow as Fig. 1: Check if EDID、 HDCP KEY、 FLASH has been written? General assembly and combined adjustment White balance adjustment Input central signal, check TV function (omitted channel, analog parameters control, etc. ), check earphone, speakers output. Check accessory and packing Check AV input, output and relevant functions.
- Page 7 Adjustment Instruction 4.1 The unit adjustment 4.1.1 According to the wiring diagram specified by “Product Specification”, connect power/backlight board assembly, data processing assembly, IR/Key board assembly correctly, supply with power, turn on the TV set. Check display. 4.1.2 Factory menu instruction Press key “INPUT”, then press digital keys “2、5、8、0”...
- Page 8 4.1.4 ADC calibration for Component channel a) Switch to Component channel; b) Press key “INPUT”, then press digital keys “2、5、8、0” in turn to enter into primary factory menu; c) Move cursor to item “ADC ADJUST” and press key “OK” to enter into the inferior submenu; d) Input Component signal (VG-849 Timing:972(1080i), Pattern:918 100% color bar);...
- Page 9 Gain/Offset upward, coordinates of Y will increase, adjust G Gain/Offset downward, coordinates of Y will decrease; Note: Sanyo customer requires that default color temperature is Normal, adjust white balance of color temperature Normal and Cool in Dynamic picture mode; for other customers, please adjust white balance of color temperature Cool in Dynamic picture mode.
- Page 10 5.4 D-SUB port Input D-SUB signal from VG-849 with formats listed as Table 3 separately, check picture and sound; if H./V. of picture displays abnormally, enter into main menu Picture->Screen->Auto Adjust to perform auto calibration. Table 3 D-SUB signal formats H.- Freq.
- Page 11 Table 5 Video & audio signal formats of digital HDMI Item Unit Parameter Note Deep color：RGB 4:4:4（24 bit/pixel，30 bit/pixel，36 bit/pixel）、 YUV 4:4:4 （24 bit/pixel，30 bit/pixel，36 bit/pixel）、 Video 对于1080p，deep color只支持到30 bit/pixel。 YUV 4:2:2(16 bit)、YUV 4:2:2(20 bit)、YUV 4:2:2(24 bit) Audio sample 32、44.1、48 freqence Audio data...
-
Page 12: Software Upgrade Instructions
Software Upgrading Instruction Software Upgrading Instruction as Table 6 Table 6 Software Upgrading Instruction Software SMT before Location Part No. Part model Upgrading method function upgrading Upgrade with ALL100, etc., N103 5272532006 EN25Q32A-100HIP FLASH need write protection, refer to Note1; HDCP KEY N105 5272404005... - Page 13 Fig. 3 Device MX25L64 successful connection If connection is failed, press the first menu “Device” and choose “MX25L64” manually, then press “Connect”; 4） Press “Read”, choose upgrading file, such as “MERGE.bin”; please refer to Fig. 4; Fig. 4 Choosing upgrading file 5）...
- Page 14 6） Press “Run” shown as Fig. 4 to perform upgrading in two steps, “Erase” and “Program”; Normal upgrading process: The first step “Erasing…， Flash Status: 03” will last for some time, or erasing is failed if the step passes over immediately; please confirm procedure 2) to perform upgrading again; The second step is “Programming…，Flash Status:00”;...
-
Page 15: Working Principle Analysis
Working Principle of the Unit 1、 ATV PAL signal flow Receive RF PAL analog signal and sent it to XC5200C (D/A silicon Tuner controlled by main chip MSD309PX through I C bus) to be demodulated, then differential IF signal is send out to main chip MSD309PX analog demodulation to be demodulated to get analog CVBS video signal and SIF sound signal. - Page 16 sent to main chip MSD309PX to be processed by acoustic effect processor and volume controller. Finally, the sound is sent to earphone amplifier BH3547F to be amplified and then outputted to earphone jack and an audio amplifier TDA7266SA to drive speakers. 5、...
-
Page 17: Block Diagram
Block Diagram LVDS PANEL SILICON TUNER XC5200C HP AMP MAX9820 MSD309 HDMI1.4 HDMI1 TDA7266SA FLASH VIDEO SIGNALS YPbPr DDR2 512MbitX2 AUDIO SIGNALS USB2.0... -
Page 18: Ic Block Diagram
IC Block Diagram 1、 TUNER IC XC5200C The Single-Chip Multi-Standard Tuner XC5200C supports all analog TV formats transmitted worldwide in the 42-1000 MHz band on either cable or terrestrial broadcast channels. It implements on-chip tuning, and channel filtering without external (SAW) filters and has no manually tunable parts. The broadband tuner converts the selected channel into an Intermediate Frequency (IF), which is then sampled by an internal high-resolution analog-to-digital converter (A/D) for further processing. - Page 19 2、 AMP IC TDA7266SA DESCRIPTION The TDA7266SA is a dual bridge amplifier specially designed for LCD Monitor, PC Motherboard, TV and Portable Radio applications. WIDE SUPPLY VOLTAGE RANGE (3.5-18V) MINIMUM EXTERNAL COMPONENTS – NO SWR CAPACITOR – NO BOOTSTRAP – NO BOUCHEROT CELLS –...
- Page 20 3、 AUDIO IC MAX9820 The MAX9820 Windows Vista®-compliant stereo headphone amplifier is designed for portable Equipment where board space is at a premium. It features Maxim’s DirectDrive® architecture to produce a ground-referenced output from a single supply, eliminating the large output-coupling capacitors required by conventional single-supply headphone amplifiers.
-
Page 21: Wiring Diagram
Wiring Diagram LVDS SPEAKERS PANEL X101 INVERTER MAIN BOARD POWER BOARD X501 TITLE: DWG NO. 9219KI7701JL LE-19KI77 H KEY BOARD IR BOARD V1.0 REV. DRAWN BY Sheet XOCECO APPROVED BY XIAMEN OVERSEAS CHINESE ELECTRONIC CO., LTD. -
Page 22: Troubleshooting Flow Chart
Troubleshooting Block Diagram 1．Panel doesn’t light up. Supply with power, check if red indicator lights up in STANDBY state? Press key POWER on remote control or unit, check indicator. Check if 5V is supplied Blue to X601-PIN10 ? Check if level of X601-PIN13 on main Check STANDBY... - Page 23 No picture, but backlight is normal: 2． Can control the TV set Press key MENU, by keys on remote can OSD display control or the unit? normally? Do no channel have picture at all? Enter into factory menu to initialize EEPROM, then cut off main power and then turn on the TV set again, check if there is picture?
- Page 24 No sound, but picture is normal: 3． No sound Check if levels Check if there Check if levels of Replace is sound from N607-PIN3&13 N607-PIN6&7are X607 speakers? are 12V? all high? Check 12V of Check if levels Touch CV04 Check power board of V615-b# and...
-
Page 25: Schematic Diagram
N101 MSD309PX-LF-V1 N 1 0 7 N 1 0 8 N T 5 T U 3 2 M 1 6 D G - A C N T 5T U 3 2 M 1 6 DG - A C MIUA MIUB Close to 309 Close to 309 MIUB_ODT... - Page 26 +3.3V_TUNER N101 MSD309PX-LF-V1 +1.8V_TUNER +3.3V_TUNER R240 +3.3V_T +3.3V_T +1.8V_TUNER PCMCIA C217 R231 100p JUMPER C210 100n +3.3V_TUNER C274 IF_N PAD_PCM_D[0] PAD_TS1_D[0] DIF_M AD14 R237 R238 L201 C216 R251 R271 PAD_PCM_D[1] PAD_TS1_D[1] 4.7K 4.7K C255 C256 C257 C259 AD15 STLI1608_R12KT 150p 100n 100n 100n...
- Page 27 X309 JY-3541L-01-030 C339 R384 VGA-LIN 001:F4 C312 C340 R385 100n VGA-RIN 001:F4 C302 R323 C341 R381 C342 R386 GND-D SPDIF V305 R340 C304 001:F5;003:G5 BC847AW GND-D +3.3V 3 4 5 +3.3V-S N316 PESD5V0L4UG GND-D R379 UART-RX R387 GND-D R382 R322 001:B4;003:G5;004:D1 C355 X301...
- Page 28 X605 +12V FI-X30SSL-HF +12V-AMP +5V-S +3.3V-S X604 +5V-S X603 TJC10S-03A +3.3V +3.3V TJC10-04A BLSW +3.3V-S R605 R614 C604 C605 C640 R612 R630 220u 220u 100n 100K R640 BL_SW- V602 5.6K C602 R603 R638 R639 BC847AW 001:D6 R634 BLSW 100n 2.2K 4.7K 4.7K UART-RX...
- Page 29 N902 HRM138BB5117 Vout R913 VCC_5V R914 X903 LED901 HFT5037MBR-1 R911 1.1K R915 V901 BC847AW X901 POWER SOURCE MENU VOL+ VOL- S907 S906 S905 S903 S904 S901 S902 R906 R905 R904 R903 R902 R901 1.5K 2.4K 4.3K...
- Page 30 Power board...
- Page 31 APPENDIX-A: Main assembly 9219KI7711 LED-19XR11 NAME MAIN COMPONENT AND IT'S NO. N101 MSD309PX-LF-SV 5270309003 N107,N108 NT5TU32M16DG_AC 5273216001 Main XI6KI0160110 N312 MAX9820 5279820001 board N205 XC5200C 5275200002 X607 TDA7266SA 5267266001 IR board XI635KI01801 XI635KI01800 board Power XI6KI0162010 board Remote XI6010900802 RC-908-0A...
-
Page 32: Appendix-B: Exploded View
APPENDIX-B: Exploded view (LED-19XR11) - Page 33 PART LIST OF EXPLODED VIEW REF.No. DESCRIPION Front cabinet assembly Speaker assembly IR assembly Main board connector (up) Main board connector (down) Interface baffle (side) Power / Backlight assembly Bracket for power cord clip Data processing assembly Back cover assembly Interface baffle Standing pole Pedestal assembly...
- Page 34 PART LIST LED-19XR11 ver. REF.No. PARTS No. DESCRIPION Q'TY REMARK XI661977002A Front cabinet assembly XI6170915000 Speaker assembly IR assembly XI635KI01801 XI58A0D92900 Main board connector (up) Main board connector (down) XI58A0E92900 XI5810B77810 Interface baffle (side) XI6KI0162010 Power / Backlight assembly Bracket for power cord clip...
- Page 35 Appendix: Installing the Stand If the stand is provided, please read these instructions thoroughly before attempting this installation. You must install your TV into the stand in order for it to stand upright on a cabinet or other flat surface. If you intend to mount your TV on a wall or other vertical surface, you must remove the stand column.
