Wireless
Speaker System
Operating Instructions
AIR-SA15R
© 2008 Sony Corporation
Printed in China
10) Protect the power cord from being walked on
WARNING
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
To reduce the risk of fire or electric shock,
11) Only use attachments/accessories specified by the
do not expose this apparatus to rain or
manufacturer.
moisture.
12) Use only with the cart, stand,
tripod, bracket, or table specified
To reduce the risk of fire, do not cover the ventilation
by the manufacturer, or sold with
opening of the apparatus with newspapers, tablecloths,
the apparatus. When a cart is used,
curtains, etc. Do not place the naked flame sources such
use caution when moving the
as lighted candles on the apparatus.
cart/apparatus combination to avoid
To reduce the risk of fire or electric shock, do not injury from tip-over.
expose this apparatus to dripping or splashing, and do 13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
not place objects filled with liquids, such as vases, on the
apparatus. 14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
As the main plug is used to disconnect the unit from
damaged in any way, such as power-supply cord or
the mains, connect the unit to an easily accessible
plug is damaged, liquid has been spilled or objects
AC outlet. Should you notice an abnormality in the
have fallen into the apparatus, the apparatus has
unit, disconnect the main plug from the AC outlet
been exposed to rain or moisture, does not operate
immediately.
normally, or has been dropped.
The unit is not disconnected from the mains as long as it
is connected to the AC outlet, even if the unit itself has The following FCC statement
been turned off.
applies only to the version of this
Do not install the appliance in a confined space, such as model manufactured for sale in
a bookcase or built-in cabinet.
the U.S.A. Other versions may
Do not expose batteries or apparatus with battery-
not comply with FCC technical
installed to excessive heat such as sunshine, fire or the
regulations.
like.
The nameplate is located on the bottom exterior.
NOTE:
Notice for the customers in the
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
U.S.A.
to Part 15 of the FCC Rules. These limits are designed
The following indications are located on the bottom
to provide reasonable protection against harmful
exterior.
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
This symbol is intended to alert the
interference will not occur in a particular installation.
user to the presence of uninsulated
If this equipment does cause harmful interference to
"dangerous voltage" within the
radio or television reception, which can be determined
product's enclosure that may be of
by turning the equipment off and on, the user is
sufficient magnitude to constitute a
encouraged to try to correct the interference by one or
risk of electric shock to persons.
more of the following measures:
 Reorient or relocate the receiving antenna.
This symbol is intended to alert the
user to the presence of important  Increase the separation between the equipment and
operating and maintenance (servicing) receiver.
instructions in the literature
 Connect the equipment into an outlet on a
accompanying the appliance.
circuit different from that to which the receiver is
connected.
 Consult the dealer or an experienced radio/TV
Owner's Record
technician for help.
The model and serial numbers are located on the
CAUTION
bottom of the unit. Record these numbers in the space
provided below. Refer to them whenever you call upon
You are cautioned that any changes or modifications
your Sony dealer regarding this product.
not expressly approved in this manual could void your
authority to operate this equipment.
Model No.
Serial No.
For the wireless transceiver (EZW-RT10)
Important Safety Instructions This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) Read these instructions.
(1) this device may not cause harmful interference, and
2) Keep these instructions.
(2) this device must accept any interference received,
3) Heed all warnings.
including interference that may cause undesired
4) Follow all instructions.
operation.
5) Do not use this apparatus near water.
6) Clean only with dry cloth. This equipment must not be co-located or operated in
conjunction with any other antenna or transmitter.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
This equipment complies with FCC radiation exposure
8) Do not install near any heat sources such as
limits set forth for uncontrolled equipment and meets
radiators, heat registers, stoves, or other apparatus
the FCC radio frequency (RF) Exposure Guidelines in
(including amplifiers) that produce heat.
Supplement C to OET65.
9) Do not defeat the safety purpose of the polarized
This equipment should be installed and operated with at
or grounding-type plug. A polarized plug has two
least 20cm and more between the radiator and person's
blades with one wider than the other. A grounding
body (excluding extremities: hands, wrists, feet and
type plug has two blades and a third grounding
ankles).
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
Notice for the customers in Canada
4-117-794-12(1)
For the wireless transceiver (EZW-RT10)
This device complies with RSS-Gen of IC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device.
This equipment complies with IC radiation exposure
limits set forth for uncontrolled equipment and meets
the RSS-102 of the IC radio frequency (RF) Exposure
rules.
This equipment should be installed and operated with at
least 20cm and more between the radiator and person's
body (excluding extremities: hands, wrists, feet and
ankles).
 "S-AIR" and its logo are trademarks of Sony
Corporation.
 The Bluetooth word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such
marks by Sony Corporation is under license. Other
trademarks and trade names are those of their
respective owners.
Features Getting Started
The AIR-SA15R is an "S-AIR" compatible product. It is
Connect the unit and S-AIR main unit to listen to sound from the S-AIR main unit.
also called the "S-AIR sub unit. " Connecting this unit
with an S-AIR main unit using "S-AIR" technology, you
can use each unit in a remote location.
For example, you can install this unit in the bedroom,
and then install an S-AIR main unit in the living room.
You can then listen to the music from the S-AIR main
unit located in the living room by controlling this unit.
Precautions
Notes on use of the S-AIR product
 As the S-AIR product transmits sound by radio waves,
sound may skip when radio waves are obstructed.
This is a characteristic of radio waves and is not a
malfunction.
 As the S-AIR product transmits sound by radio waves,
equipment that generates electromagnetic energy,
such as a microwave oven, may interfere with sound
transmission.
 Wireless transceiver
 As the S-AIR product uses the radio waves that share
Insert the supplied wireless transceiver (EZW-RT10)
the same frequency as other wireless systems, such
as wireless LAN or Bluetooth devices, interference or securely into the EZW-RT10 slot on the rear panel of
poor transmission may result. In this case, take the the unit.
following steps: Check the orientation of the  mark when inserting the
 Do not install the S-AIR product near other wireless supplied wireless transceiver (EZW-RT10). Failure to do
systems. so may result in damage to the unit.
 Do not use the S-AIR product and the other wireless
Notes
systems at the same time.
 Make sure to turn off the unit when inserting or removing the
 The transmission distance differs depending on
supplied wireless transceiver (EZW-RT10). Failure to do so may
result in damage to the unit.
the usage environment. Find a location where
 Do not touch the terminals of the supplied wireless transceiver
transmission between the unit and the S-AIR main
(EZW-RT10).
unit is most effective, and install the unit and the S-
 Do not insert any device other than the supplied wireless
AIR main unit there.
transceiver (EZW-RT10) into the EZW-RT10 slot.
On safety

S-AIR ID selector
 Completely disconnect the power cord from the wall
Set the same S-AIR ID for this unit and the S-AIR main
socket (mains) if it is not going to be used for an
unit to be connected. For details on setting the S-AIR
extended period of time. When unplugging the unit,
ID, see "Establishing the connection with an S-AIR
always grip the plug. Never pull the cord itself.
main unit. "
 Should any solid object or liquid get into the unit,
unplug the unit, and have it checked by qualified
 Power
personnel before operating it again.
Connect the power cord to a wall socket.
 The power cord can be changed only by a qualified
service facility.
On placement
Establishing the connection with an
 Do not place the unit in an inclined position or in
S-AIR main unit
locations that are extremely hot, cold, dusty, dirty, or
humid or lacking adequate ventilation, or subject to
You can easily establish the connection by setting the
vibration, direct sunlight or a bright light.
same S-AIR ID for this unit and S-AIR main unit.
 Be careful when placing the unit on surfaces that have
1
been specially treated (for example, with wax, oil,
Turn on the unit.
polish) as staining or discoloration of the surface may
Press 
result.
2
Set the S-AIR ID of the unit to the same S-AIR ID as
On heat buildup the S-AIR main unit to be connected.
 Heat buildup on the unit during operation is normal For details on setting the S-AIR ID of the S-AIR
and is not cause for alarm.
main unit, refer to the Operating Instructions
 Do not touch the cabinet if it has been used supplied with the S-AIR main unit.
continuously at a high volume because the cabinet
3
Operate the S-AIR main unit to turn on the S-AIR
may have become hot.
function.
 Do not obstruct the ventilation holes.
For details on turning on the S-AIR function, refer to
the Operating Instructions supplied with the S-AIR
On the speaker system
main unit.
This speaker system is not magnetically shielded, and
Once the connection is established, the S-AIR
the picture on nearby TV sets may become magnetically
indicator
distorted. In this situation, turn off the TV, wait about
15 to 30 minutes, and turn it back on. appears in the display for about 2 seconds.
If there is no improvement, move the unit far away from
Identifying the unit with a specific S-AIR
the TV.
main unit (Pairing operation)
Cleaning the cabinet
It is easy to set the same S-AIR ID for the unit and S-
Clean the cabinet with a soft dry cloth. Do not use any
AIR main unit to establish the connection.
type of abrasive pad, scouring powder, or solvent, such
However, if a neighbor has an S-AIR main unit with the
as thinner, benzine, or alcohol.
same S-AIR ID as your S-AIR main unit, you may be
able to hear the audio transmitted from your neighbor's
S-AIR main unit on your system. To prevent this, you
S-AIR (Sony Audio Interactive Radio
can identify the unit with a specific S-AIR main unit by
frequency)
performing the pairing operation.
Recent times have seen the rapid spread of DVD
Before pairing
media, Digital Broadcasting, and other high-quality
The connection is established by the S-AIR ID
media.
(example).
To ensure that the subtle nuances of these high-
quality media are transmitted with no deterioration,
Your system
Sony has developed a technology called "S-AIR" for
the radio transmission of digital audio signals with no
compression, and has incorporated this technology
into the EZW-RT10.
This technology transfers digital audio signals with
no compression using the 2.4 GHz band range of ISM
band (Industrial, Scientific, and Medical band), such
as wireless LANs and Bluetooth applications.
S-AIR main unit 
Wall socket
EZW-RT10/Wireless transceiver
After pairing
The connection is established between the paired unit
and S-AIR main unit.
Your system
This unit
ID A
Pairing
ID A
S-AIR main unit 
1
Place the S-AIR main unit to be paired near this
unit.
2
Check that the power of the unit and the S-AIR
main unit to be connected are turned on.
3
Check that the S-AIR ID of the unit is the same as
the S-AIR ID of the S-AIR main unit.
4
Operate the S-AIR main unit to turn on the pairing
function.
For details on turning on the pairing function, refer
to the Operating Instructions supplied with the S-
AIR main unit.

.
5
Press the PAIRING button on the rear panel of the
unit using a pointed object.
When pairing is performed, the S-AIR indicator
on the unit flashes and the display changes as follows:
"PAIRING"  "COMPLETE"
To cancel pairing
Change the S-AIR IDs of the unit and the S-AIR main
unit to different S-AIR IDs.
To stop the pairing operation midway
Press the PAIRING button again.
 on the unit lights up and "LINKED"
Inserting the batteries to the
remote
Slide and remove the battery compartment lid
insert the two supplied R03 (size AAA) batteries,  side
first, matching the polarities shown below.
Notes on using the remote
Neighboring system
 W ith normal use, the batteries should last for about six months.
 D o not mix an old battery with a new one or mix different types of
batteries.
This unit
 I f you do not use the remote for a long period of time, remove the
batteries to avoid damage from battery leakage and corrosion.
ID A
ID A ID A
S-AIR main unit 
Neighboring system
ID A
S-AIR main unit 

 , and
