Panasonic SDR-S45EG Service Manual

Hide thumbs Also See for SDR-S45EG:
Table of Contents

Advertisement

Quick Links

Download this manual
SDR-S45EG
Model No.
SDR-S45EF
SDR-S45EC
SDR-S45EP
SDR-S45EB
SDR-S45EE
SDR-S45GC
SDR-S45GA
SDR-S45GN
SDR-S45PU
SDR-S45PR
VOL.2
Colour
(S)........Silver Type
© Panasonic Corporation 2010.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.VM1004028CE
SD Video Camera

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SDR-S45EG

Summary of Contents for Panasonic SDR-S45EG

  • Page 1 ORDER NO.VM1004028CE SD Video Camera SDR-S45EG Model No. SDR-S45EF SDR-S45EC SDR-S45EP SDR-S45EB SDR-S45EE SDR-S45GC SDR-S45GA SDR-S45GN SDR-S45PU SDR-S45PR VOL.2 Colour (S)..Silver Type © Panasonic Corporation 2010. Unauthorized copying and distribution is a violation of law.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 1.1. General Guidelines ----------------------------------------3 2 Warning --------------------------------------------------------------4 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices ---------------4 2.2. Service caution based on legal restrictions----------5 2.3. Caution for AC Cord (For EB/GC/GA) ----------------6 3 Specifications ------------------------------------------------------7 4 Service Mode -------------------------------------------------------8 4.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Circuit Board Layout, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent X-RADIATION, shock fire, or other hazards.

  • Page 4: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatic Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semi- conductor “chip”...

  • Page 5: Service Caution Based On Legal Restrictions

    2.2. Service caution based on legal restrictions 2.2.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb).

  • Page 6: Caution For Ac Cord (For Eb/Gc

    A replacement fuse cover can be purchased from your local Panasonic Dealer. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety.

  • Page 7: Specifications

    3 Specifications...

  • Page 8: Service Mode

    4 Service Mode 1. Indication method of the service menu Set the mode switch " Recording" mode. 2. While keep pressing the "Intelligent auto/Manual" button and "Menu" button, hold left the Zoom Lever towards to "[ W ]" posi- tion for more than 3 seconds until the top screen of the Service Menu being displayed. Service mode menu Screen Contents...

  • Page 9: Lock Search History Indication

    4.1. Lock Search History Indication 1. Select [ 4 ] Lock search history indication. Operation specifications Indication contents • Lock search history indication Display the camera system error code for three histories saved in EEPROM. • The error code contents which are displayed Error code Function Focus control is abnormal...

  • Page 10: Lock Search History Clear

    4.3. Lock Search History Clear 1. Select [ 10 ] Lock Search History Clear. Operation specifications • Lock Search History Clear An error code for three histories in EEPROM is cleared. Push the menu button to end the service mode, and then POWER OFF.

  • Page 11: Service Fixture & Tools

    5 Service Fixture & Tools 5.1. Service Tools and Equipment...

  • Page 12: Measurements And Adjustments

    6 Measurements and Adjustments 6.1. Service Positions 6.1.1. List of the extension cables Use the following extension cables when checking or adjusting individual circuit boards except module Parts (Main P.C.B.).
  • Page 13 6.1.2. Checking and repairing individual circuit boards How to use extension cables.
  • Page 14 3.The voltage being indicated on the schematic diagram is measured in "Standard-Playback" mode when there is no specify mode is mentioned. Model No. SDR-S45EG SDR-S45GC 4.Although the voltage and waveform available on here is measured with standard frame, it may be differ from actual measurement due to modification of circuit and so on.

  • Page 15: S2. Voltage Chart

    S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1.
  • Page 16 REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC IC2006 IC2006 IC2006 IC2006 IC3401 IC3401 AC11 IC3401...
  • Page 17 REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC IC3401 IC3401 IC3401 IC3401 IC3401 IC3401 IC3401 IC3401...
  • Page 18 REF No. PIN No. REC REF No. PIN No. REC REF No. PIN No. REC IC3402 Q1002 QR1003 IC3402 Q1002 QR1003 IC3402 Q1002 QR1003 IC3402 Q1002 QR1101 IC3402 Q1002 QR1101 IC3402 Q1002 QR1101 IC3402 Q1261 QR1411 IC3402 Q1261 QR1411 IC3402 Q1261 QR1411 IC3402...

  • Page 19: S3. Block Diagram

    FROM/TO ON/OFF POWER SRC SCL CHARGE E POW RST VDET OUT S CHARGE SDA S6005 POWER SRC SDA POWER LCD OPEN SW USB SW 16 LCD OPEN SW PW VBUS VCC FROM QR2301 QR2303 AUDIO/VIDEO SDR-S45EG/EF/EC/EP/EB/EE/GC/GA/GN/PU/PR SYSTEM CONTROL BLOCK DIAGRAM...

  • Page 20: S3.2. Audio/Video Block Diagram

    ECM L FP6009 ECM R E ADR (1-15) SDIN S SDA AVIO CONTROL CS X S AVIO CS AA22 SCLK AA23 S CLK AVIO LIN L AA26 AB21 AC21 EADR 15 LIN R RESET E AVIO RST SDR-S45EG/EF/EC/EP/EB/EE/GC/GA/GN/PU/PR AUDIO/VIDEO BLOCK DIAGRAM...

  • Page 21: S3.3. Camera Drive Block Diagram

    CCD SUB FT201 FP6007 CCD RESET FT201 FP6007 CCD H1 FT201 FP6007 CCD H2 OSCI CGAFE DO CGAFE SCL TIMING GENERATER CG CS CG RST FROM/TO RESET SYSTEM CTL MAIN FT201 FP6007 SENS_TEMP_VREF LENS TEMP TH201 SDR-S45EG/EF/EC/EP/EB/EE/GC/GA/GN/PU/PR CAMERA DRIVE BLOCK DIAGRAM...

  • Page 22: S3.4. Lens Drive Block Diagram

    YAW H OUT (+) Y GYIN OPEN HALL SENSOR FP6008 YAW H OUT (-) Y HO- (Y ch) YAW H IN (+) Y H IN+ FP6008 FP6008 YAW H IN (-) Y H IN- Y GYREF 104 OPEN SDR-S45EG/EF/EC/EP/EB/EE/GC/GA/GN/PU/PR LENS DRIVE BLOCK DIAGRAM...

  • Page 23: S3.5. Monitor Block Diagram

    FP6001 FP901 FP902 STV1 LCD VST FP6001 FP901 FP902 CKV1 FP6001 FP901 FP902 LCD VCK LCD XSTBY FP6001 FP901 FP902 PW LCD3V LCD COM FP6001 FP901 FP902 COMOUT 35 LCD WIDE FP6001 FP901 FP902 WIDE SDR-S45EG/EF/EC/EP/EB/EE/GC/GA/GN/PU/PR MONITOR BLOCK DIAGRAM S-10...

  • Page 24: S3.6. Charge Block Diagram

    P ON QR1501 ADP. DETECT DC-DC CONVERTER PW RTC3R2V LOGIC DVIN & DETECT TIMER RESET H BATTERY DETECT S BAT DATA 1 S CHARGE SCL LED DRIVE S CHARGE SDA FROM/TO SYSTEM CTL LED POW CONT SDR-S45EG/EF/EC/EP/EB/EE/GC/GA/GN/PU/PR CHARGE BLOCK DIAGRAM S-11...

  • Page 25: S3.7. Power Supply Block Diagram

    (VOLTAGE REGULATOR) DRVL7 DRIVE V OUT1 PW 12V V OUT2 6 PW -7R5V CNT1 CNT2 MINE7 ERROR AMP Q1002 Q1271 Q1381 QR1481 POWER POWER PW LCD8R5V CONTROL CONTROL QR1003 Q1383, Q1384 8.6V CONTROL Q1481 SDR-S45EG/EF/EC/EP/EB/EE/GC/GA/GN/PU/PR POWER SUPPLY BLOCK DIAGRAM S-12...
  • Page 26 S-13...

  • Page 27: S4. Schematic Diagram

    S4. Schematic Diagram S4.1. Main CN Schematic Diagram SDR-S45 Main CN Section (Main P.C.B.(1/13)) Schematic Diagram PW_R3R2V_ESD C6007 C6008 C6009 C6010 C6011 TO MONITOR C6006 C6012 TO MONITOR TO VIDEO FP6001 LCD_VST E_LCD_RST K1MN27AA0094 [0.3mm] LCD_VCK LCD_RVS_SW C6013 LCD_RVS LCD_EN CLK27_LCD D_GND LCD_HST...
  • Page 28 SDR-S45 Main CN Section (Main P.C.B.(1/13)) Schematic Diagram S6001 S6002 S6003 K0H1BA000580 K0H1BA000580 K0H1BA000580 LONG REC. LIGHT/DELET POWER_OFF/ON R6040 2700 R6027 SYSCON LED_LIGHT TO LED_LIGHT TO SYSCON TO REAR_PCB LIGHT_ON_H LIGHT_ON_H HDD_TEMP TO LED_LIGHT TO HDD LED_LIGHT_K TO POWER HDD_UNLOAD_H TO CCD PW_REG5V HDD_ACC_INFO...
  • Page 29 2:SWGND J0JCC0000276 E_AVIO_RST E_AVIO_RST BUS13_MAD2 G_AUDIO_L 5:LOUT G_UNI_COUT G_UNI_COUT BUS13_MAD1 4:VOUT G_LOUT_JACK LB6003 G_UNI_YOUT G_UNI_YOUT BUS13_MAD0 G_VIDEO_OUT 3:GND SD_YLEVEL SD_YLEVEL HOST_REQ TO AV JACK J0JCC0000276 G_VOUT_JACK CAM_WAKEUP G_AUDIO_R UNI_UPDATE G_AUDIO_L TO POWER CAM_UPDATE TO HDD G_VIDEO_OUT PW_REGA3V DDR_COMP_CAL PW_SPK3V E_ATA_RESET CARD_BOOT PW_REG5V ATA_DA0...
  • Page 30 BUS13_MAD5 BUS13_MAD4 BUS13_MAD3 BUS13_MAD2 BUS13_MAD1 BUS13_MAD0 HOST_REQ CAM_WAKEUP UNI_UPDATE CAM_UPDATE DDR_COMP_CAL CARD_BOOT TO LENS TO JACK AV_PLUG FP6008 K1MN33AA0093 ZMT3 ZMT3 ZMT2 TO MAIN_CN SW ZMT2 ZMT1 TO REAR OP E_KEYIN5 ZMT1 ZMT4 E_KEYIN1 TO LENS ZMT4 FENC E_KEYIN4 LENS_LED F_ENC R6037 ZENC...

  • Page 31: S4.2. Power Schematic Diagram

    S4.2. Power Schematic Diagram SDR-S45 Power Section (Main P.C.B.(2/13)) Schematic Diagram CL1001 FROM CHARGE PW_+B CL1002 TO FRAME FRAME D_GND R1002 D1JB1R26A005 PW_RTCNOREG PW_DD5_OUT QR1002 B1GDCFLN0006 C121 1000 R1107 R121 CL1101 CL1105 TO_RTC C1212 QR1001 10u[28] P_ON_H B1GBCFGG0037 E_POW_RST QR1101 C121 B1GBCFJJ0061 CL1103...
  • Page 32 SDR-S45 Power Section (Main P.C.B.(2/13)) TO VIDEO Schematic Diagram CL1302 PW_VBUS VBUS_ON_H CL1311 PW_DD5_OUT G1311 PW_REG5V C1213 R1212 PW_REG3R2V 1000P 10K[D] PW_REGA3V R1215 R1213 3300 750[D] C1212 PW_LCD5V 10u[28] QR1411 B1GDCFGN0021 IC1413 IC1414 C0DBGFC00009 PW_FROM3V C0EBE0000237 C1214 R1214 2700[D] PW_SPK3V PW_LENS3V CL1321 3R2V...
  • Page 33 C123 C1121 C1232 C1161 10u[28] R123 C1142 R1141 C1102 16V0.1 0.01 C1101 16V0.1 C123 R1101 100K[D] C1152 R1151 TO VIDEO [64]FB6 [42]FB1 R1102 3300P 2200 BL_CONT PINE6 [65]VREF [41]MINE1 MINE2 SEL1 R1251 D1JBR046A006 MINE5 PVCC2-A R1111 C1112 R1103 C1251 6.3V 2R2[18] C1104 PVCC2-B...
  • Page 34 C1233 R1232 12K[D] C1232 10u[28] R1235 C1234 R1234 15K[D] CL1351 1R2V PW_DD2_LX2 L1251 PW_UNP1R1V G1C100MA0024 C1253 R1252 3000[D] C1252 10u[28] R1255 C1254 R1254 15K[D] CL1341 L1241 PW_DD1_LX1 PW_UNP1R2V G1C100MA0249 C1243 R1242 3000[D] C1242 R1245 R1243 10u[28] 470[D] CL1372 CL1371 C1244 R1244 15K[D] CCD_ON_H...

  • Page 35: S4.3. Charge Schematic Diagram

    S4.3. Charge Schematic Diagram TO POWER TO DC_JACK PW_ADP_IN PW_+B PW_ADP_+ ADP_-_GND TO RTC/POWER P_ON_H TO RTC BKUP_CONT PW_RTC3R2V BAT_DET ADP_DET R1517 PW_ADP_+_A CHA_CONT PW_VBUS_VCC D_GND TO SYSCON CS_FG FRAME S_FGMCOM_SCK TO USB_JACK PW_VBUS_VCC S_FGMCOM_DAT PW_VBUS S_CHARGE_SDA B1GDCFNN0031 S_CHARGE_SCL QR1506 TO POWER S_BAT_DATA_1 PW_REG5V...

  • Page 36: S4.4. Afe Schematic Diagram

    S4.4. AFE Schematic Diagram FROM POWER L102 PW_12V G1C100KA0115 TO_CCD PW_CCD_12V G_CCD_RESET_1 C108 FROM SYSCON G_CCD_RESET 16V0.1 CG_RST G_CCD_H2 G_CCD_H1 CCD_SUB D102 B0ACDJ000007 C110 16V0.1 FROM_CCD C113 0.01 G_CCD_OUT C127 6.3V 10u[28] C122 1000P TO_XP2 CH101 CH102 CLK27_CCDFCK VDRVDD(C3) BUS13_CCDVD VD(C4) 16v4.7 CH106...

  • Page 37: S4.5. Lens Drive Schematic Diagram

    S4.5. Lens Drive Schematic Diagram FROM SYSCON OIS_SENS_SW2 FROM GYRO_YAW G_GYRO_REFY TO LENS G_GYROY R701 G_YAWHO- R710 YAWHIN+ R706 R705 150K G_YAWHO+ C701 0.22 YAWHIN- G_PITHO- C719 PITHIN+ 0.01 C732 0.01 G_PITHO+ PITHIN- R716 PITDRV+ 2200 PITDRV- C733 0.01 YAWDRV- C717 0.01 C720 YAWDRV+...
  • Page 38 S-25...

  • Page 39: S4.6. Syscon Schematic Diagram

    S4.6. Syscon Schematic Diagram SDR-S45 Syscon Section (Main P.C.B.(6/13)) Schematic Diagram TO POWER PW_REG3V_SYS PW_REG1R8V D_GND CH2014 VIDEO TO VIDEO BUS13_MAD0 MAD0 IC2006 BUS13_MAD1 MAD1 POWER BUS13_MAD2 MAD2 MN103SFD0RXW BUS13_MAD3 MAD3 BUS13_MAD4 MAD4 BUS13_MAD5 MAD5 BUS13_MAD6 MAD6 BUS13_MAD7 MAD7 BUS13_MAD8 MAD8 BUS13_MAD9 MAD9...
  • Page 40 SDR-S45 Syscon Section (Main P.C.B.(6/13)) Schematic Diagram VIDEO MAD0 MAD1 MAD2 MAD3 TO RTC MAD4 S_RTC_DT RTC_DI MAD5 R2014 RTC_DO MAD6 S_RTC_SCK RTC_SCK MAD7 RTC_CS RTC_CS MAD8 MAD9 MAD10 MAD11 MAD12 MAD13 REAR_OP MAD14 MAD15 CAM_IRQ TO REAR OP UP_CS WE_L POWER_LED_B WE_H...
  • Page 41 LED_LIGHT CX2003 0.01[X4][15] CHARGE TO LED_LIGHT LIGHT_ON_H LIGHT_ON_H TO CHARG BCC_RESET_H MITSUNI_IC_RESET S_CHARGE_SDA POWER_SRC_CNT_SDA S_CHARGE_SCL POWER_SRC_CNT_SCK S_FGMCOM_DAT S_NOTICE_DI S_FGMCOM_DO S_NOTICE_DO S_FGMCOM_SCK S_NOTICE_SCK CS_FG S_NOTICE_CS FG_RESET_H S_NOTICE_RESET S_BAT_DATA_1 BATT_RXD BATT_TXD RX2003 D1H81034A024 SYSCON MAIN_CN TO MAIN_CN NTSC_L_PAL_H NTSC_PAL 1.8V RL2010 HDD_SEL1 MODELSEL_1 MODEL_SEL_1 RL2011...
  • Page 42 TO CCD 3300 LENS_TEMP LENS_TEMP ED_LIGHT LIGHT_ON_H TG/AFE TO TG/AFE S_SYS_AFE_DO CGAFE_DO S_SYS_AFE_CK CGAFE_SCK S_SYS_AFE_CS CG_CS CG_RST CG_RST R2016 LENS R2017 TO LENS LENS_LED LENS_LED R2018 ZENC ZENC R2019 MAIN_CN FENC FENC NTSC_PAL 1.8V MODEL_SEL_1 MODEL_SEL_2 USB_ROSEL CX2004 LENSDRIVE HDD_SEL0 0.01[X4][15] AV_PLUG MREF...

  • Page 43: S4.7. Rtc Schematic Diagram

    S4.7. RTC Schematic Diagram TO MONITOR PW_LI_BATT TO POWER E_POW_RST (MA2SD320GL) E_POW_RST QR2301 $[B0JCED000004] D2304 B1GDCFNN0031 PW_REG3R2V P_ON_H PW_RTCNOREG D_GND TO CHARG CHA_CONT BKUP_CONT PW_RTC3R2V SENCE ADP_DET BAT_DET TO SYSCON VDET S_RTC_DT S_RTC_DT VOUT S_RTC_SCK S_RTC_SCK RTC_CS RTC_CS IC2304 (S-78190A07-HCT1) X2301 RL2301 RL2302...
  • Page 44 S-31...

  • Page 45: S4.8. Video Schematic Diagram

    S4.8. Video Schematic Diagram SDR-S45 Video Section (Main P.C.B.(8/13)) Schematic Diagram TO POWER PW_FROM3V PW_UNP1R1V PW_UNP1R2V PW_REG1R8V PW_REG3V PW_REG3R2V R3404 $[18] POWER CAMERA I/F D_GND TO CAMERA BUS13_ADIN0 BUS13_ADIN1 BUS13_ADIN2 BUS13_ADIN3 BUS13_ADIN4 BUS13_ADIN5 BUS13_ADIN6 BUS13_ADIN7 BUS13_ADIN8 BUS13_ADIN9 TO LENSDRIVE BUS13_ADIN10 CLK27_LENS BUS13_ADIN11 BUS13_TVVD...
  • Page 46 SDR-S45 Video Section (Main P.C.B.(8/13)) Schematic Diagram C3479 C3480 $[18] 16V0.1 58 57 53 52 Ext. BUS CLK40_ECLK CH3411 BUS20_ECS0 BUS20_EDAT9 BUS20_EADR1 BUS20_EDAT3 BUS20_EADR2 BUS20_EDAT5 AF20 BUS20_EADR3 AC21 BUS20_EADR4 BUS20_EDK IC3402 BUS20_EADR12 AD21 AA26 BUS20_EWE BUS20_EADR5 FROM_INT C3FBSY000017 BUS20_EADR11 AE19 AB21 BUS20_EADR6 BUS20_EADR4...
  • Page 47 AB22 AC23 TO EVR CN AD24 S_BE_RXD TO EVR CN S_BE_TXD TO POWER VBUS_ON_H CHARGE AD23 AD25 TO AVIO S_SDA_AVIO AD26 S_CLK_AVIO TO AVIO AE23 S_AVIO_CS TO AVIO AC25 AC26 TO LCD E_LCD_RST AF21 VIDEO I/F TO AVIO G_UNI_YOUT TO SYSCON G_UNI_COUT INT_FRP G_YCCOMP...
  • Page 48 16V0.1 INT/IO/ADC TO EVR CN TO SYSCON S_BE_RXD AD16 /RXD0 P63/ HOST_REQ TO EVR CN S_BE_TXD AE17 /TXD0 P64/ TO POWER VBUS_ON_H AF17 /P50 P65/ HDD_UNLOAD_H TO SYSCON/HDD CHARGE CH3401 /SRRM2 P66/ TO MAIN_CN P67/ E_AVIO_RST TO AVIO CH3402 /P72 P73/ NTSC_L_PAL_H 1.8V...

  • Page 49: S4.9. Avio Schematic Diagram

    S4.9. AVIO Schematic Diagram TO POWER L3701 G1C100KA0115 PW_REG5V_AV1 PW_REG5V C3701 10u[28] L3702 G1C100KA0115 PW_REG3V_AV1 PW_REG3V C3702 10u[28] PW_REGA3V L3704 G1C470MA0031 PW_SPK3V_AV1 PW_SPK3V C3704 F3F0J226A032 R3713 $[22] PW_REG1R8V C3709 R3711 TO JACK D_GND G_AUIO_R_AV1 6.3V G_AUDIO_R G_AUIO_L_AV1 6.3V G_AUDIO_L R3712 C3710 TO SIDE_R SPOUT1...

  • Page 50: S4.10. Mic Schematic Diagram

    S4.10. MIC Schematic Diagram Q4801 TO POWER DSC300100L PW_REG5V_FR1 PW_REG5V D_GND C4806 TO ECM C4804 C4801 R4806 0.047 0.047 G_ECM_L_OUT1 G_ECM_L G_ECM_L_IN1 G_ECM_R R4805 C4802 TO AVIO 0.047 PW_REG5V_FR2 G_INT_MIC_R1 G_INT_MIC_L1 R4808 C4810 C4809 0.047 R4809 G_ECM_R_OUT1 G_ECM_R_IN1 SDR-S45 MIC Section (Main P.C.B.(10/13)) Schematic Diagram S-37...

  • Page 51: S4.11. Lcd Schematic Diagram

    S4.11. LCD Schematic Diagram TO POWER TO MONITOR PW_LCD5V PW_LCD3V LCD_VST D_GND LCD_VCK LCD_EN LCD_HST CLK3_LCDHCK1 CLK3_LCDHCK2 LCD_PCG PW_LCD3V LCD_RL LCD_UD LCD_COM LCD_PSIG CKV1 G_LCD_B STV2 G_LCD_R STV1 [64]CKV2 [48]CKH3 G_LCD_G [47]CKH4 VDD1(2.85V) BLCONT1 SDATA BLCONT2 SCLK TEST1 LCD_WIDE IC601 TO VIDEO VDD1(2.85V) TEST0...

  • Page 52: S4.12. G_Sensor Schematic Diagram

    S4.12. G_Sensor Schematic Diagram / S4.13. LED Schematic Diagram TO POWER PW_REG3V C3301 D_GND LED_LIGHT PW_REG5V LED_LIGHT_K TO SYSCON R3301 R3302 LIGHT_ON_H LIGHT_ON_H 2200 2200 CL3301 TO SYSCON R6405 R6406 $(4300) $(68K[D]) S_HDD_G_SCL (2SC584600L) S_HDD_G_SDA (2SA207800L) Q6402 Q6403 $[DSC300100L] $[DSA300100L] C6402 R6403 R6407...

  • Page 53: S5. Print Circuit Board

    S5. Print Circuit Board S5.1. Main P.C.B. S5.1.1. Main P.C.B. SDR-S45 Main P.C.B. (Component Side) C6021 D1481 C1381 Q1481 S6005 CX2004 QR1481 CL1423 R1384 C2009 Q1384 Q1383 RX2001 R2013 R2021 CL1104 C2001 LB3402 R2008 C6013 IC2001 L1231 L1261 L1281 C6012 FP6005 R6011 C6006...
  • Page 54 SDR-S45 Main P.C.B. (Component Side) CL6005 R6002 C6003 QR6005 JK6002 LB3402 JK6001 C3709 R3711 C6012 QR6001 QR6002 QR6006 QR6004 FP6005 C3710 R6011 C1520 R3712 R6004 R6005 R6001 C6006 FL6001 VA6001 VA6005 R1544 C3480 CL3301 R1520 C6007 Q1503 C1510 VA6003 9 8 7 6 R1524 IC1505 D1502...
  • Page 55 (Component Side) RX6001 CL2006 RX3405 S6002 S6001 CL2005 R1412 R3414 IC1412 X3401 R3417 CL1302 R3415 IC1414 R6003 C3434 C3485 C3401 C3452 R1533 R1534 C1312 IC3401 D1501 AA26 AB26 AC26 AD26 AE26 AF26 AA25 AB25 AC25 AD25 AE25 AF25 AA24 AB24 AC24 AD24 AE24...
  • Page 56 R6019 R6017 RX6001 FP6001 R6034 CL2006 CL2004 CL2003 R6016 R6036 RX3405 S6002 QR1411 S6003 R6018 R6032 CL2005 CL2007 CL2002 C602 C1213 R1215 C1233 R1235 L1211 X3401 R3417 R1213 C1231 R1214 IC2002 C3401 C1214 C1171 C1131 C1211 C1111 C609 CL6008 IC3401 C1212 R601 AA26...

  • Page 57: S5.1.2. Main P.c.b. Address Information

    S5.1.2. Main P.C.B. Address Information Main P.C.B. Integrated Circuit QR3401 D-12 Diode C113 C1103 D-16 C1415 C3439 K-11 C6003 M-13 R1151 C-14 R1522 J-16 R3435 C-12 R6037 B-16 IC101 QR3402 D-12 D101 I-13 C114 I-13 C1104 D-16 C1416 C3441 D-12 C6004 L-14 R1161...

  • Page 58: S6. Abbreviation

    S6. Abbreviation INITIAL/LOGO ABBREVIATIONS A GND Analogue GND A MUTE Audio Mute A0-8, 0-17 Memory Address A3V2 AD Converter Reference Voltage AB0- Address BUS ABSF Focus Encoder Input ACLK Audio Clock AD Converter Analogue Digital Converter Auto Date AD CLK AD Clock AD0-, ADR0- Address Data Line...
  • Page 59 INITIAL/LOGO ABBREVIATIONS Auto Power Save AREQ Audio Pes Packet Request Audio RF Servo AMP Inverted Input Servo AMP Output ASYNC Audio Word Distinction Sync Auto Lock Select Absolute Track Number Advanced TV AUDIO (N) Audio (Normal) Auxiliary AVDD Analogue VDD AVSS Analogue Ground AWTB...
  • Page 60 INITIAL/LOGO ABBREVIATIONS Bypath BYTCK Byte Clock C A In/Out Pre-Aperture In/Out C CNT Colour Control C SYNC Composite Sync Signal Carrier/Noise C0-7, C00-07 Chrominance Signal CAGAIN Aperture Gain Control Camera CAM CLK Camera Clock CAM RST Camera Reset CAM SIOC Camera Serial In/Out Contol CAM T Camera Test...
  • Page 61 INITIAL/LOGO ABBREVIATIONS CHR BACK Character Back-up CHR MIX Character Mix CI, CO Buffer In/Out Control Signal Forward Input CIF, CIR Positive Control Pulse, Negative Control Pulse Control Signal Reverse Input Clock CKSL System Clock Select Clock Clock CLASS Classeffication Signal for Compress (DCT/VLC) CLASS 0.1 Class Control Signal Durring DCT/VLC CLK135...
  • Page 62 INITIAL/LOGO ABBREVIATIONS CPDT CPU Data Component Signal CPOB Clamp Pulse for Optical Blanking CPRD CPU Read Enable Composite Signal CPUADR CPU Address Latch CPUADT CPU Address Data Bus CPUIRQ CPU Interrupt Request Gate Scan Clock CPWR CPU Write Enable CR OUT Pre Apature Out CR POW SW Camera Remote Power ON Switch...
  • Page 63 INITIAL/LOGO ABBREVIATIONS DIBDCK bit Clock DICLK Digital Clock DIDAT Serial Data Durring Digital Audio In Digital Interface DIG0- FL Digit Output DILRCK Serial Clock Durring Digital Audio In DIMCK Master Clock Durring Digital Audio In Data Input DIO 1-8 Data In/Out DIOS Data In/Out Select Control Signal DIOS...
  • Page 64 INITIAL/LOGO ABBREVIATIONS Digital Video Cassette Digital Video Disc DVDD Digital VDD DVIO Digital Video Input Output DVSS Digital Ground Shift Data for X Direction (for LCD) Shift Data for Y Direction (for LCD) TFT Y-axis Shift Data Digital Zoom E Snap Electric Snap Shot E ZM Electric Zoom...
  • Page 65 INITIAL/LOGO ABBREVIATIONS Focus Error FENC Focus Encoder FEND Frame End Pulse Focus Error AMP Output Focus Error AMP Inverted Input Frequency Generator FLICK Flicker Output Field Memory FMCO0-3 Field Memory Chrominance Out FMDIR Focus Motor Direction FMOEM Field Memory Enable FMOEO Field Memory Enable FMT1-4...
  • Page 66 INITIAL/LOGO ABBREVIATIONS High Pass Filter HRXW Host Read/Write Modulated Data Output Horizontal Sync Signal HS-WT High Speed Zoom High Speed Zoom Interface I-2 C Inter Integrated Circuit Wide Television IECOUT IEC958 Format Data Output Inter Microprocessor Protocol CCD Input Signal 1 Input Frame Signal CCD Input SIgnal 2 INTER...
  • Page 67 INITIAL/LOGO ABBREVIATIONS MCLK Memory Serial Command Clock Modulation MD0-7 Microprocessor Data MDATA Memory Serial Command Data MDQ0- Memory Data Input/Output MDQM Memory Data I/O Mask MDT0-7 Microprocessor Data MENB Focus Motor Enable Manual Focus Far Manual Focus Near MHSYNC Monitor Horizontal Sync Signal MIX N.R.D.
  • Page 68 INITIAL/LOGO ABBREVIATIONS Overlap Pulse Optical Zoom P SW Power Switch PORT PBCTL Play Back Control PBCTL Pre-Branking Control PBLK Pre-Blanking (Pulse) PCBM Carrier Balance CD Tracking Phase Difference Phase Compensator (Hall AMP) Phase Compensator (Current) PLL Clock Phase Compensator Out Switching Power Control Phase Compensator (Voltage) PDVD...
  • Page 69 INITIAL/LOGO ABBREVIATIONS Read Address Enable Read Busy R Bias R Carrier Balance Read Enable R Bias RENCF Lens Control (Forward) RENCR Lens Control (Reverse) RFENV RF Envelope RF Phase Difference Output RGO R/G OFF Offset Voltage for AWT R (CD-ROM) Register Select RSEL RF Polarity Select Reset...
  • Page 70 INITIAL/LOGO ABBREVIATIONS Shift In Clock Input SIN1, 2 Serial Data In SIOC Serial In/Out Control SNAP Snap Shot SNS LED Sensor LED Serial Data Output SOUT1, 2 Serial Data Out ATF Smapling Pulse SPDI Serial Port Data Input SPDO Serial Port Data Output SPEN Serial Port R/W Enable Speaker...
  • Page 71 INITIAL/LOGO ABBREVIATIONS Sub Code Sub Code Data TPSN OP AMP Input TPSO OP AMP Output TPSP OP AMP Inverted Input TRCRS Track Cross Signal TRON Tracking ON TRSON Traverse Servo ON U/V SEL R-Y/B-Y Select Signal UNRE Microprocessor Read Enable UNWE Microprocessor Write Enable R-Y/B-Y...
  • Page 72 INITIAL/LOGO ABBREVIATIONS VREF Voltage Reference VREFH Refference Voltage High Side VREFL Refference Voltage Low Side Refference Voltage Input Refference Voltage Output Voltage Refference Top VRTS Voltage Refference Top Output Switching Comparator Source Power Supply Voltage Vertical Sync Signal VSSX X Driver Power for Colour LCD VSSXY X-Y Driver Power for Colour LCD Mode Select for Window Mode...
  • Page 73 INITIAL/LOGO ABBREVIATIONS XSRMOE X SRAM Output Enable XSRMWE X SRAM Write Enable XVCS X V-Dec Chip Select XVDS X V-Dec Control Bus Strobe XVSYNCO X Vertical Sync Output Y FM0-7 Y Field Memory Y Gain Control YMO 0-7 Y Field Memory YNCST Noize Canceller Luminance Noise Reduction...

  • Page 74: S7. Check Point Of The Ic

    S7. Check Point of The IC S7.1. Check Point of the IC101 CSP IC Check Point Remarks Name 1(A1) C116 (UPPER) MAIN P.C.B. (F) 2(A2) DVDD5 3(A3) DVSS5 4(A4) DLLC C113 (LOWER) MAIN P.C.B. (F) 5(A5) DVSS3 6(A6) DVDD3 7(A7) OSCO 8(A8) OSCI...
  • Page 75 Check Point of the IC101 CSP IC Check Point Remarks Name 53(G8) V6 54(G9) D1 55(G10) DVSS12 56(H1) VRM C111 (LEFT) MAIN P.C.B. (F) 57(H2) OSC_ON 58(H3) AVSS12 59(H4) AVSS12 60(H5) DVDD1 61(H6) DVDD1 62(H7) MON CH103 MAIN P.C.B. (F) 63(H8) VL 64(H9) NC 65(H10) SUB...
  • Page 76 S7.2. Check Point of The IC701 CSP IC Check Point Remarks Name TEST1 NSCS CH705 MAIN P.C.B. (C) CK37 CH703 MAIN P.C.B. (C) CH704 MAIN P.C.B. (C) DGND_1 VDD18 LIN_SIG MGND_1 CH708 MAIN P.C.B. (C) VD60 CH709 MAIN P.C.B. (C) VD30 CH709 MAIN P.C.B.
  • Page 77 Check Point of The IC701 CSP IC Check Point Remarks Name IR_HR R729 (LEFT) MAIN P.C.B. (C) IR_HIN+ C729 (RIGHT) MAIN P.C.B. (C) IR_IN- C728 (RIGHT) MAIN P.C.B. (C) IR_IN+ C734 (UPPER) MAIN P.C.B. (C) IR_FNO CH702 MAIN P.C.B. (C) ND_ER+ ND_CNTO R710 (RIGHT)
  • Page 78 Check Point of The IC701 CSP IC Check Point Remarks Name P_GYOUT R714 (LEFT) MAIN P.C.B. (C) MIXO Y_GYOUT R715 (LOWER) MAIN P.C.B. (C) MGND_4 AF1- VM_4 POIS_PWM AF1+ LAF- YOIS_PWM LAF+ AF2- LIN_PWM MGND_5 AF2+ CH707 MAIN P.C.B. (C) (C): COMPONENT SIDE (F): FOIL SIDE S-65...
  • Page 79 S7.3. Check Point of The IC1001 CSP IC Check Point Remarks Name TEST PGND5 LX5-2 L1211 (LEFT) MAIN P.C.B. (F) LX5-1 L1211 (RIGHT) MAIN P.C.B. (F) SEL2 PVCC5 C1211 (RIGHT) MAIN P.C.B. (F) PVCC3-B C1231 (RIGHT) MAIN P.C.B. (F) PVCC3-A C1231 (RIGHT) MAIN P.C.B.
  • Page 80 Check Point of The IC1001 CSP IC Check Point Remarks Name VO4-B CL1321 MAIN P.C.B. (C) VO4-A CL1321 MAIN P.C.B. (C) CTL6 CL1411 MAIN P.C.B. (F) C1103 (UPPER) MAIN P.C.B. (F) NSWO C1163 (LOWER) MAIN P.C.B. (F) PGND6 NSWI D905-K MONITOR P.C.B.
  • Page 81 S7.4. Check Point of The IC2006 CSP IC Check Point Remarks Name VDD33 VDD33 P32/AN26 KEYIN5 CX2002-1 MAIN P.C.B. (C) KEYIN2 CX2002-3 MAIN P.C.B. (C) P16/AN14 HDD_TEMP P07/AN7 P03/AN3 P00/AN0 PS4/TM14IO PR2/SBOA EEPROM_DO CL2006 MAIN P.C.B. (F) RTC_DO R2014 (LOWER) MAIN P.C.B.
  • Page 82 Check Point of The IC2006 CSP IC Check Point Remarks Name EEPROM_PROTECT CL2007 MAIN P.C.B. (F) PR1/SBIA EEPROM_DI CL2004 MAIN P.C.B. (F) LENS_DEBAG_DO R6034 (LEFT) MAIN P.C.B. (F) CARD_BOOT CH3410 MAIN P.C.B. (F) VDDL AV_PLUG RX2001-1 MAIN P.C.B. (C) LCD_RVS_SW RX2001-3 MAIN P.C.B.
  • Page 83 Check Point of The IC2006 CSP IC Check Point Remarks Name G_SENSOR_SCL R3302 (UPPER) MAIN P.C.B. (C) CTL6_ON_H CL1411 MAIN P.C.B. (F) POWER_SRC_CNT_SCK CH1503 MAIN P.C.B. (C) CCD_ON_H IC1371-1 MAIN P.C.B. (C) VDD18 HDD_SEL2 HOST_RQ2 CH2013 MAIN P.C.B. (C) G_SENSOR_SCA R3301 (LEFT) MAIN P.C.B.
  • Page 84 Check Point of The IC2006 CSP IC Check Point Remarks Name EXTRG0 MAD0 MAD1 MAD8 MAD9 RX2001-7 MAIN P.C.B. (C) TRCCLK TRCD0 PH6/RWSEL RL2005 MAIN P.C.B. (F) PH3/SYSCLK TRCST TRCD1 TRCD3 TRCD2 PG4/NCS4 WE_H RL2003 MAIN P.C.B. (F) XWAIT RL2004 MAIN P.C.B.
  • Page 85 Check Point of The IC2006 CSP IC Check Point Remarks Name LENS_DRV_DI CH707 MAIN P.C.B. (C) LENS_DRV_SCK CH704 MAIN P.C.B. (C) PE1/TM11IO PF3/IRQ9 PF5/TM0IO VDDB NTSC_PAL R6042 (RIGHT) MAIN P.C.B. (C) PG0/NCS0 VDD33 VDD33 CGAFE_SCK CH108 MAIN P.C.B. (F) CGAFE_DO CH107 MAIN P.C.B.
  • Page 86 S7.5. Check Point of The IC2304 CSP IC Check Point Remarks Name 1 /RMIN 2 XOUT X2301-1 MAIN P.C.B. (F) 3 XIN X2301-4 MAIN P.C.B. (F) 4 VSS 5 CS RL2301 MAIN P.C.B. (F) 6 SCK RL2302 MAIN P.C.B. (F) 7 SIO R2014 (LOWER) MAIN P.C.B.
  • Page 87 S7.6. Check Point of The IC3401 CSP IC Check Point Remarks Name DDR_VDD2 DDR_VDD1 YOUT R3409 (RIGHT) MAIN P.C.B. (F) YCCOMP C3403 (RIGHT) MAIN P.C.B. (F) SDHDSEL FPEN AIDAT IC3701-1 MAIN P.C.B. (C) AODAT1 XO_CAM R3425 (LEFT) MAIN P.C.B. (C) XI_CAM C3461 (LEFT) MAIN P.C.B.
  • Page 88 Check Point of The IC3401 CSP IC Check Point Remarks Name AB17 VDDIO_AM1 AB18 VDDIO_AM1 AB19 XNFCE AB20 NANDRYBY AB21 AB22 AB23 AB24 ED10 AB25 AB26 DDR_VDD1 DDR_VDD2 DDR_VDD2 DDR_VSSDQ P74/INT6 CAMIFIRQ RX2005-7 MAIN P.C.B. (C) MODE0 ADM9 RL2001 MAIN P.C.B. (F) AC10 RL2003 MAIN P.C.B.
  • Page 89 Check Point of The IC3401 CSP IC Check Point Remarks Name AD17 NFCLE AD18 AD19 AD20 AD21 XECS4 AD22 AD23 DDR_VDD2 AD24 AD25 DDR_VDD2 AD26 DDR_VDD2 DDR_VDDDQ DDR_VSSDQ ADM15 ADM7 ADM8 TESTCK0 ADM2 AE10 SCK4/PA1 AE11 P00/ADC0 AE12 AVSS_AM AE13 AVDD_AM AE14 AE14...
  • Page 90 Check Point of The IC3401 CSP IC Check Point Remarks Name AF17 SCK2/P50 IC1301-1 MAIN P.C.B. (F) AF18 P53/SY RX2006-7 MAIN P.C.B. (C) AF19 XERE AF20 XECS2 AF21 DDR_VDDDQ AF22 AF23 DDR_VDD1 AF24 DDR_VSSDQ AF25 AF26 DDR_VDD2 DDR_VSSDQ C2OUT VREF C3409 (RIGHT) MAIN P.C.B.
  • Page 91 Check Point of The IC3401 CSP IC Check Point Remarks Name YI2_CAM2 YI2_CAM4 CI1_CAM1 YI1_CAM1 YI1_CAM6 DDR_VSSDQ AVSS_PLL13 DDR_VDDDQ DDR_VDD2 VDDIO_HDMI VDDIO_HDMI CO_HDMI0 TCPOUT0 AVDD_PLL9_10 AVDD_DAC AVSS_DAC ABCK0 AODAT0 IC3701-2 MAIN P.C.B. (C) ALRCK0 VDDIO_CAM3 REFYC3 REFYC1 S_DATA0 CH703 MAIN P.C.B. (C) S_DATA1 CH709 MAIN P.C.B.
  • Page 92 Check Point of The IC3401 CSP IC Check Point Remarks Name YI2_CAM1 YI2_CAM0 CI1_CAM5 CH105 MAIN P.C.B. (F) DDR_VSSDQ DDR_VDDDQ VDD_USB VDD_USB VDD_USB YO_HDMI3 YO_HDMI4 CO_HDMI3 CO_HDMI4 DOBCK_HDMI AVSS_USB AVSS_USB FL6001-4 MAIN P.C.B. (C) YO_HDMI0 CO_HDMI6 YO_HDMI7 YO_HDMI6 DOLRCK_HDMI AVSS_PLL9_10 AVSS_PLL7_8 DDR_VDDDQ DDR1_VREFDQ...
  • Page 93 Check Point of The IC3401 CSP IC Check Point Remarks Name DDR_VDDDQ DDR_VDDDQ DDR1_DIOZQD DDR_VSSDQ DDR_VDDDQ SDDATA_3 RX3404-7 MAIN P.C.B. (F) SDDATA_2 RX3404-5 MAIN P.C.B. (F) AVDD_USB AVDD_USB AVDD_USB VCLKO_HDMI HSYNC_HDMI YCO_EVF7 YCO_EVF6 YO_HDMI2 SPDO_HDMI DODAT_HDMI DDR_VSSDQ DDR_VDDDQ SBD6 VDDIO_UHS1A SDCLK R3414 (RIGHT) MAIN P.C.B.
  • Page 94 Check Point of The IC3401 CSP IC Check Point Remarks Name XSOF SBD7 SDDATA1_3 RX3405-1 MAIN P.C.B. (F) SDDATA1_2 RX3405-3 MAIN P.C.B. (F) SDDATA1_1 RX3405-5 MAIN P.C.B. (F) SDDATA1_0 RX3405-7 MAIN P.C.B. (F) SDCMD1 R3417 (LEFT) MAIN P.C.B. (F) SDCLK1 R3416 (LOWER) MAIN P.C.B.
  • Page 95 Check Point of The IC3401 CSP IC Check Point Remarks Name CARD_DET RX3402-4 MAIN P.C.B. (C) PROTECT RX3402-2 MAIN P.C.B. (C) CARD_DET2 SDDATA2_2 VDDIO_UHS1C SBD0 SDDATA2_0 VDDIO_UHS1C SDCLK2 CLKN_LCD AVDD_LVDS D1N_LCD DDR_VSSDQ AVSS_PLL1_2 AVDD_PLL3_5 DDR_VSSDQ CARD_DET1 RX3402-8 MAIN P.C.B. (C) PROTECT1 RX3402-6 MAIN P.C.B.
  • Page 96 Check Point of The IC3401 CSP IC Check Point Remarks Name VDDIO_ATA VDDIO_ATA USBCLK ATADD0 RX3413-8 MAIN P.C.B. (F) OSCO R3421 (LOWER) MAIN P.C.B. (F) D2P_LCD DDR_VSSDQ DDR_VDDDQ DDR_VDDDQ DDR_VDDDQ DDR_VDDDQ DDR0_ZQ R3467 (UPPER) MAIN P.C.B. (C) P64/INT1 RX3417-6 MAIN P.C.B. (F) P65/INT2 ATADMARQ R3439 (LEFT)
  • Page 97 Check Point of The IC3401 CSP IC Check Point Remarks Name ATAIORDY R3440 (UPPER) MAIN P.C.B. (F) RST_LCD V_LCD H_LCD YCO_LCD4 IC601-18 MAIN P.C.B. (F) BL_PWM_LCD R1102 (RIGHT) MAIN P.C.B. (F) SCK1/P70 IC3701-4 MAIN P.C.B. (C) XWAIT RL2004 MAIN P.C.B. (F) TESTSEL XRSTOUT KINT5/KP5...
  • Page 98 Check Point of The IC3401 CSP IC Check Point Remarks Name MODE1 KINT1/KP1 KINT6/KP6 CH2013 MAIN P.C.B. (C) KINT7/KP7 XEDK XNFWP SDBOOT CH3410 MAIN P.C.B. (F) SI3/P93 XECS0 P66/INT3 QR3402-C MAIN P.C.B. (F) EA11 EA24 ECLK EA25 YCO_LCD2 IC601-20 MAIN P.C.B. (F) YCO_LCD3 IC601-19 MAIN P.C.B.
  • Page 99 S7.7. Check Point of The IC3402 CSP IC Check Point Remarks Name RX3417-6 MAIN P.C.B. (F) DQ15 DQ12 C3428 (LOWER) MAIN P.C.B. (C) AVDB DQ11 DQ14 DQ10 S-86...
  • Page 100 Check Point of The IC3402 CSP IC Check Point Remarks Name DQ13 VCCCORE VCCIO (C): COMPONENT SIDE (F): FOIL SIDE S-87...

  • Page 101: S8. Replacement Parts List

    S8. Replacement Parts List Note: 1.* Be sure to make your orders of replacement parts according to this list. 2. IMPORTANT SAFETY NOTICE Components identified with the mark have the special characteristics for safety. When replacing any of these components, use only the same type. 3.
  • Page 102 SDR-S45EG-S vol.2 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C1261 ECJ1VB0J225K C.CAPACITOR CH 6.3V 2.2U VEP03H83DP MAIN P.C.B. EG,EF,EC,EP,EB (RTL) E.S.D. C1262 F1H1E105A116 C.CAPACITOR CH 25V VEP03H83DQ MAIN P.C.B. GC,GA,EE,GN (RTL) E.S.D.
  • Page 103 SDR-S45EG-S vol.2 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C3460 ECJ0EC1H150J C.CAPACITOR CH 50V 15P IC1503 VUEALLPT034 1 E.S.D. C3461 ECJ0EC1H150J C.CAPACITOR CH 50V 15P IC1504 C0JBAR000432 IC 1 E.S.D. C3478 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U...
  • Page 104 SDR-S45EG-S vol.2 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R106 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 R1519 ERJ2GEJ103 M.RESISTOR CH 1/10W 10K R129 ERJ2GEJ3R3X M.RESISTOR 3.3K R1521 D0GA472JA021 RESISTOR R603 ERJ2RHD511 M.RESISTOR CH 1/16W 510...
  • Page 105 SDR-S45EG-S vol.2 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R6001 ERJ2GEJ331 M.RESISTOR CH 1/16W 330 R6002 ERJ2GEJ821 M.RESISTOR CH 1/10W 820 R6003 D1JBR046A006 RESISTOR R6005 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 R6006 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K...
