  • Page 1 OWNER’S MANUAL YZF-R1T 5VY-28199-21...
  • Page 3 EAU10100 Welcome to the Yamaha world of motorcycling! As the owner of the YZF-R1, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 YZF-R1T OWNER’S MANUAL ©2004 by Yamaha Motor Co., Ltd. 1st edition, September 2004 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 PRE-OPERATION CHECKS ..... 4-1 Adjusting the rear brake light Location of important labels ....1-5 Pre-operation check list ....4-2 switch ........6-20 Checking the front and rear DESCRIPTION ........2-1 OPERATION AND IMPORTANT brake pads ........ 6-21 Left view ..........2-1 RIDING POINTS.........
  • Page 7 TABLE OF CONTENTS Supporting the motorcycle ....6-37 Front wheel ........6-38 Rear wheel ........6-40 Troubleshooting ......6-41 Troubleshooting charts ....6-42 MOTORCYCLE CARE AND STORAGE ..........7-1 Care ..........7-1 Storage ...........7-3 SPECIFICATIONS ......8-1 CONSUMER INFORMATION.....9-1 Identification numbers ....9-1 Motorcycle noise regulation (for Australia) ........9-2...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10281 AND/OR WHEN MADE NECES- • Ride where other motorists can SARY BY MECHANICAL CONDI- see you. Avoid riding in another MOTORCYCLES SINGLE TIONS. motorist’s blind spot. TRACK VEHICLES. THEIR SAFE USE Many accidents involve inexperi- AND OPERATION ARE DEPENDENT Safe riding enced operators.
  • Page 9 Modifications made to this motorcycle other motorists can see you. the single most critical factor in the pre- not approved by Yamaha, or the re- The posture of the operator and vention or reduction of head injuries. moval of original equipment, may ren- passenger is important for proper Always wear an approved helmet.
  • Page 10 Maximum load: been specifically designed for use on create instability due to improper 202 kg (445 lb) this motorcycle. Since Yamaha cannot weight distribution or aerody- test all other accessories that may be namic changes. If accessories When loading within this weight limit,...
  • Page 11 SAFETY INFORMATION tor and may limit control ability, Always turn the engine off before or clothing, immediately wash the therefore, such accessories are leaving the motorcycle unattended affected area with soap and water not recommended. and remove the key from the main and change your clothes.

  • Page 12: Location Of Important Labels

    SAFETY INFORMATION EAU10381 Location of important labels Please read the following important labels carefully before operating this vehicle.
  • Page 13 SAFETY INFORMATION Before you operate this vehicle, read the owner’s manual. Prima di usare il veicolo, leggete il manuale di istruzioni. Lire le manuel du propriétaire avant d’utiliser ce véhicule. Lesen Sie die Bedienungsanleitung bevor Sie dieses Fahrzeug fahren. Antes de conducir este vehículo, lea el Manual del Propietario. 5PA-21568-00 Use PREMIUM unleaded gasoline with min.

  • Page 14: Description

    DESCRIPTION EAU10410 Left view 1. Fuse box (page 6-30) 9. Electronic fuel injection fuse (page 6-30) 2. Front fork compression damping force adjusting screw (page 3-20) 10.Main fuse (page 6-30) 3. Front fork rebound damping force adjusting screw (page 3-20) 11.Owner’s tool kit (page 6-1) 4.

  • Page 15: Right View

    DESCRIPTION EAU10420 Right view 1. Luggage strap holder (page 3-24) 9. Shock absorber assembly rebound damping force adjusting screw (page 3-21) 2. Helmet holder (page 3-19) 10.Coolant reservoir (page 6-12) 3. Passenger seat lock (page 3-18) 4. Rear brake fluid reservoir (page 6-21) 5.

  • Page 16: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-14) 2. Left handlebar switches (page 3-13) 3. Main switch/steering lock (page 3-2) 4. Multi-function meter unit (page 3-8) 5. Right handlebar switches (page 3-13) 6. Throttle grip (page 6-16) 7. Brake lever (page 3-15)

  • Page 17: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 18: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS EAU10471 EAU10550 To lock the steering Main switch/steering lock All electrical circuits are supplied with power, the meter lighting, taillight, li- cense plate light and auxiliary lights come on, and the engine can be start- ed. The key cannot be removed. NOTE: The headlights come on automatically when the engine is started and stay on...

  • Page 19: Indicator And Warning Lights

    INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU10940 EAU11002 (Parking) Indicator and warning lights The steering is locked, and the taillight, license plate light and auxiliary lights are on. The hazard light and turn signal lights can be turned on, but all other electrical systems are off.
  • Page 20 2.5 seconds. will flash eight times, then go off for 2.5 If this occurs, have a Yamaha seconds. If this occurs, have a Yamaha dealer check the vehicle. dealer check the vehicle. EAU11250 Oil level warning light “...
  • Page 21 INSTRUMENT AND CONTROL FUNCTIONS ECA10020 CAUTION: Do not operate the engine if it is overheated.
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Coolant Display Conditions What to do temperature Under 39 °C Message “LO” is displayed. OK. Go ahead with riding. (Under 103 °F) 40–116 °C Temperature is displayed. OK. Go ahead with riding. (104–242 °F) Stop the vehicle and allow it to idle until 117–139 °C Temperature display flashes.
  • Page 23 When this occurs, flashes two times repeatedly, error EAU32990 have a Yamaha dealer check the self- Immobilizer system indicator light code 52 will be displayed. This error diagnosis system. (See page 3-8 for an “...

  • Page 24: Multi-Function Meter Unit

    INSTRUMENT AND CONTROL FUNCTIONS EAU34541 a speedometer (which shows the Tachometer Multi-function meter unit riding speed) a tachometer (which shows engine speed) an odometer (which shows the to- tal distance traveled) two tripmeters (which show the distance traveled since they were last set to zero) a fuel reserve tripmeter (which shows the distance traveled since...
  • Page 25 INSTRUMENT AND CONTROL FUNCTIONS Clock mode Odometer, tripmeter, and stopwatch “SELECT” button to switch the display modes between the various tripmeter, odome- ter, and stopwatch modes in the follow- ing order: F-TRIP → Stopwatch → TRIP A → TRIP B → ODO → F-TRIP To reset a tripmeter, select it by push- ing the “SELECT”...
  • Page 26 INSTRUMENT AND CONTROL FUNCTIONS 3. Push the “SELECT” button again When the air intake temperature NOTE: to reset the stopwatch. display is selected, “A” is displayed When the coolant temperature display before the temperature. is selected, “C” is displayed for one Split-time measurement second, and then the coolant tempera- 1.
  • Page 27 Yamaha dealer check the vehi- To adjust the brightness of the multi- should flash or stay on when acti- cle.
  • Page 28 INSTRUMENT AND CONTROL FUNCTIONS 3. Turn the key to “ON”, and then re- setting is selected when the To set the shift timing indicator light de- lease the “SELECT” button after indicator light flashes once activation function five seconds. every two seconds.) NOTE: 4.

  • Page 29: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS To adjust the shift timing indicator light EAU12343 Right Handlebar switches brightness 1. Push the “RESET” button to select Left the desired indicator light bright- ness level. 2. Push the “SELECT” button to con- firm the selected indicator light brightness level.

  • Page 30: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS position. To cancel the turn signal EAU12731 EAU12820 Hazard switch “ ” Clutch lever lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard light (simultaneous flashing of all EAU12500...

  • Page 31: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12870 EAU33850 it by aligning a groove on the adjusting Shift pedal Brake lever knob with the “ ” mark on the brake lever. 1. Shift pedal 1. Brake lever 2. Brake lever position adjusting knob The shift pedal is located on the left 3.

  • Page 32: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12941 EAU13070 Brake pedal Fuel tank cap NOTE: The fuel tank cap cannot be closed un- less the key is in the lock. In addition, the key cannot be removed if the cap is not properly closed and locked. EWA11090 WARNING Make sure that the fuel tank cap is...

  • Page 33: Fuel

    Your Yamaha engine has been de- signed to use premium unleaded gaso- line with a research octane number of 95 or higher. If knocking (or pinging) oc-...

  • Page 34: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS EAU13430 EAU33860 Catalytic converter Seats This model is equipped with a catalytic converter in the exhaust chamber. Rider seat EWA10860 WARNING To remove the rider seat Pull back the rear of the rider seat as The exhaust system is hot after op- eration.

  • Page 35: Helmet Holders

    INSTRUMENT AND CONTROL FUNCTIONS 2. While holding the key in that posi- EAU33870 To release a helmet from a helmet Helmet holders tion, lift the front of the passenger holder seat and pull it forward. Remove the passenger seat, remove the helmet from the helmet holder, and To install the passenger seat then install the seat.

  • Page 36: Adjusting The Front Fork

    INSTRUMENT AND CONTROL FUNCTIONS EAU14741 load thereby soften Rebound damping force Adjusting the front fork suspension, turn the adjusting bolt on This front fork is equipped with spring each fork leg in direction (b). preload adjusting bolts, rebound damp- NOTE: ing force adjusting screws and com- Align the appropriate groove on the ad- pression...

  • Page 37: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS Compression damping force ECA10100 EAU33970 Adjusting the shock absorber CAUTION: assembly Never attempt to turn an adjusting This shock absorber assembly is mechanism beyond the maximum or equipped with a spring preload adjust- minimum settings. ing ring and rebound and compression damping force adjusting screws.
  • Page 38 INSTRUMENT AND CONTROL FUNCTIONS To increase the spring preload and thereby harden the suspension, turn the adjusting ring in direction (a). To de- crease the spring preload and thereby soften the suspension, turn the adjust- ing ring in direction (b). NOTE: Align the appropriate notch in the adjusting ring with the position in-...
  • Page 39 To obtain a precise adjust- formance. ment, it would be advisable to check Always have a Yamaha dealer the number of clicks of each damping service the shock absorber. 1. Compression damping force adjusting screw force adjusting mechanism and to mod- ify the specifications as necessary.

  • Page 40: Luggage Strap Holders

    EAU15281 EAU15300 Luggage strap holders EXUP system Sidestand This model is equipped with Yamaha’s The sidestand is located on the left side EXUP (EXhaust Ultimate Power valve) of the frame. Raise the sidestand or system. This system boosts engine lower it with your foot while holding the power by means of a valve that regu- vehicle upright.

  • Page 41: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS below and have a Yamaha dealer re- EAU15311 Ignition circuit cut-off system pair it if it does not function proper- The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 42 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 43: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15591 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 44: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. 6-12 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 45 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-16, 6-25 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-25 •...

  • Page 46: Operation And Important Riding Points

    3-25. should be on, otherwise have a short time. Always make sure Never ride with the sidestand Yamaha dealer check the electrical cir- that there is adequate ventila- down. cuit. tion. 1. Turn the key to “ON” and make 3.

  • Page 47: Shifting

    OPERATION AND IMPORTANT RIDING POINTS serve the battery. Do not crank the en- EAU16671 ECA10260 Shifting CAUTION: gine more than 10 seconds on any one attempt. Even with the transmission in the neutral position, do not ECA11130 coast for long periods of time CAUTION: with the engine off, and do not For maximum engine life, always...

  • Page 48: Tips For Reducing Fuel Consumption

    If any engine trouble should oc- result in engine overheating must be lights or at railroad crossings). cur during the engine break-in avoided. period, immediately have a Yamaha dealer check the vehi- EAU17091 cle. 0–1000 km (0–600 mi) Avoid prolonged operation above 6900 r/min.

  • Page 49: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17212 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10310 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them.

  • Page 50: Owner's Tool Kit

    Yamaha dealer do it for you. NOTE: If you do not have the tools or experi- 1. Muffler bracket cover ence required for a particular job, have 2. Muffler bracket a Yamaha dealer perform it for you.

  • Page 51: Periodic Maintenance And Lubrication Chart

    The annual checks must be performed every year, except if a kilometer-based maintenance is performed in- stead. From 50000 km, repeat the maintenance intervals starting from 10000 km. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. ODOMETER READING (× 1000 km)
  • Page 52 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Check tread depth and for damage. • Replace if necessary. √ √ √ √ √ 10 * Tires • Check air pressure. •...
  • Page 53 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Change. √ √ √ √ √ √ Engine oil • Check oil level and vehicle for oil leakage. Engine oil filter car- √...
  • Page 54 PERIODIC MAINTENANCE AND MINOR REPAIR EAU18680 NOTE: Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. Hydraulic brake service •...

  • Page 55: Removing And Installing Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18771 Removing and installing panels The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1.

  • Page 56: Checking The Spark Plugs

    Do not attempt to diagnose such problems To install the panel yourself. Instead, have a Yamaha deal- 1. Place the panel in its original posi- er check the vehicle. tion, and then install the screw.

  • Page 57: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND MINOR REPAIR Before installing a spark plug, the spark EAU34003 NOTE: Engine oil and oil filter plug gap should be measured with a If a torque wrench is not available when cartridge wire thickness gauge and, if necessary, installing a spark plug, a good estimate The engine oil level should be checked adjusted to specification.
  • Page 58 PERIODIC MAINTENANCE AND MINOR REPAIR b. Remove the engine oil filler cap NOTE: with the special wrench as The engine oil should be between the shown. minimum and maximum level marks. 1. Cowling 1. Engine oil filler cap 2. Special wrench 1.
  • Page 59 PERIODIC MAINTENANCE AND MINOR REPAIR NOTE: An oil filter wrench is available at a Yamaha dealer. 8. Apply a thin coat of engine oil to the O-ring of the new oil filter car- tridge. 1. Cowling 1. Engine oil drain bolt 2.
  • Page 60 ECA11620 17 Nm (1.7 m·kgf, 12 ft·lbf) or remains on, immediately turn the CAUTION: engine off and have a Yamaha dealer In order to prevent clutch slip- 10. Install the engine oil drain bolt, and check the vehicle. page (since the engine oil also...

  • Page 61: Coolant

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU20070 Coolant The coolant level should be checked before each ride. In addition, the cool- ant must be changed at the intervals specified in the periodic maintenance and lubrication chart. EAU34011 To check the coolant level 1.
  • Page 62 PERIODIC MAINTENANCE AND MINOR REPAIR If water has been added to the The coolant must be changed at the in- coolant, have a Yamaha dealer tervals specified in the periodic mainte- check the antifreeze content of nance and lubrication chart. Have a the coolant as soon as possible, Yamaha dealer change the coolant.

  • Page 63: Replacing The Air Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU34020 Replacing the air filter element The air filter element should be re- placed at the intervals specified in the periodic maintenance and lubrication chart. Replace the air filter element more frequently if you are riding in un- usually wet or dusty areas.
  • Page 64 Before installing the fuel tank, make sure that the fuel hoses are not damaged. If any fuel hose is damaged, do not start the engine. Have a Yamaha dealer replace the hose, other- wise fuel may leak. 1. Air filter element Make sure that the fuel hoses 7.

  • Page 65: Adjusting The Engine Idling Speed

    Yamaha dealer make the adjustment. sary, have a Yamaha dealer adjust it. screw in direction (a). To decrease the engine idling speed, turn the screw in direction (b).

  • Page 66: Valve Clearance

    250 kPa (36 psi) (2.50 kgf/cm²) Rear: from occurring, the valve clearance regarding the specified tires. 290 kPa (42 psi) (2.90 kgf/cm²) must be adjusted by a Yamaha dealer 90–202 kg (198–445 lb): at the intervals specified in the periodic Tire air pressure Front: maintenance and lubrication chart.
  • Page 67 LOAD YOUR VEHICLE. Make sure in it, or if the sidewall is cracked, con- that the total weight of the cargo, rid- tact a Yamaha dealer immediately and er, passenger, and accessories have the tire replaced. Tire information (cowling, saddlebags, etc.

  • Page 68: Cast Wheels

    Other tires may run fore each ride. If any damage is valve cores listed below to the danger of bursting at super found, have a Yamaha dealer re- avoid tire deflation during a high speeds. place the wheel. Do not attempt high-speed ride.

  • Page 69: Adjusting The Clutch Lever Free Play

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU33890 EAU22270 Adjusting the clutch lever free NOTE: Adjusting the rear brake light If the specified clutch lever free play play switch cannot be obtained as described above, proceed as follows. 1. Fully turn the adjusting bolt at the clutch lever in direction (a) to loos- en the clutch cable.

  • Page 70: Checking The Front And Rear Brake Pads

    EAU22580 Checking the front and rear Checking the brake fluid level touches the brake disc, have a Yamaha brake pads dealer replace the brake pads as a set. Front brake The front and rear brake pads must be...

  • Page 71: Changing The Brake Fluid

    Changing the brake fluid is above the minimum level mark and ter the brake fluid reservoir when Have a Yamaha dealer change the replenish if necessary. A low brake fluid refilling. Water will significantly brake fluid at the intervals specified in...

  • Page 72: Drive Chain Slack

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU22760 Drive chain slack NOTE: Using the alignment marks on each The drive chain slack should be side of the swingarm, make sure that checked before each ride and adjusted both chain pullers are in the same posi- if necessary.

  • Page 73: Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND MINOR REPAIR 3. Tighten the locknuts, then the axle EAU23021 ECA11110 Lubricating the drive chain CAUTION: nut to their specified torques. The drive chain must be cleaned and Do not use engine oil or any other lu- lubricated at the intervals specified in Tightening torques: bricants for the drive chain, as they...

  • Page 74: Checking And Lubricating The Cables

    If a cable is damaged periodic maintenance chart. or does not move smoothly, have a Yamaha dealer check or replace it. Recommended lubricant: Engine oil EWA10720 Clutch lever...

  • Page 75: Checking And Lubricating The Sidestand

    EWA10730 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-26...

  • Page 76: Checking The Front Fork

    Securely support the vehicle so that fork does not operate smoothly, damage and excessive oil leakage. there is no danger of it falling over. have a Yamaha dealer check or re- pair it. To check the operation 2. Hold the lower ends of the front 1.

  • Page 77: Checking The Wheel Bearings

    To charge the battery Have a Yamaha dealer charge the bat- tery as soon as possible if it seems to have discharged. Keep in mind that the battery tends to discharge more quickly if the vehicle is equipped with optional electrical accessories.
  • Page 78 IES OUT OF THE REACH OF If you do not have access to a Electrolyte is poisonous and CHILDREN. sealed-type (MF) battery charg- have a Yamaha dealer dangerous since it contains sul- charge your battery. furic acid, which causes severe To store the battery burns.

  • Page 79: Replacing The Fuses

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU34052 Replacing the fuses The main fuse and the electronic fuel injection fuse are located under the rid- er seat. (See page 3-18.) 1. Cowling 1. Quick fastener If a fuse is blown, replace it as follows. 3.
  • Page 80 6. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates. 7. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 6-31...

  • Page 81: Replacing A Headlight Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR 8. Place the cowling in its original po- EAU33900 Replacing a headlight bulb sition, and then install and tighten the quick fastener screws. 1. Headlight bulb cover 2. Headlight coupler 1. High beam headlight bulb 2.
  • Page 82 4. Install the headlight bulb cover, from oil, otherwise the transpar- and then connect the coupler. ency of the glass, the luminosity 5. Have a Yamaha dealer adjust the of the bulb, and the bulb life will headlight beam if necessary. be adversely affected. Thor- 1.
  • Page 83 7. Have a Yamaha dealer adjust the ency of the glass, the luminosity headlight beam if necessary. of the bulb, and the bulb life will be adversely affected.

  • Page 84: Tail/Brake Light

    1. Remove the license plate light unit If the tail/brake light does not come on, by removing the screw. by removing the screws. have a Yamaha dealer check it. 1. Screw 1. Screw 2. License plate light unit 2. Remove the defective bulb by 2.

  • Page 85: Replacing An Auxiliary Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR 3. Remove the defective bulb by pull- EAU33910 3. Remove the socket (together with Replacing an auxiliary light ing it out. the bulb) by pulling it out. bulb 4. Insert a new bulb into the socket. This model is equipped with two auxil- 5.

  • Page 86: Supporting The Motorcycle

    PERIODIC MAINTENANCE AND MINOR REPAIR 7. Install the auxiliary light bulb cover EAU24350 a jack either under each side of the Supporting the motorcycle by installing the quick fastener. frame in front of the rear wheel or under Since this model is not equipped with a each side of the swingarm.

  • Page 87: Front Wheel

    4. Remove the brake caliper on each To remove the front wheel side by removing the bolts. EWA10820 WARNING It is advisable to have a Yamaha dealer service the wheel. Securely support the motor- cycle so that there is no danger 1. Wheel axle of it falling over.
  • Page 88 PERIODIC MAINTENANCE AND MINOR REPAIR 8. Retighten pinch bolt B to the spec- NOTE: ified torque. Make sure that there is enough space between the brake pads before install- Tightening torque: ing the brake calipers onto the brake Wheel axle pinch bolt: discs.

  • Page 89: Rear Wheel

    4. Loosen the locknut on each side of EWA10820 WARNING the swingarm. 5. Turn the drive chain slack adjust- It is advisable to have a Yamaha ing bolts fully in direction (a) and dealer service the wheel. push the wheel forward. Securely support the motor- 6.

  • Page 90: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha 1. Retainer dealer, whose skilled technicians have 2. Slot the necessary tools, experience, and 2.

  • Page 91: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 92 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. NOTE: If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 93: Motorcycle Care And Storage

    MOTORCYCLE CARE AND STORAGE EAU26020 ucts onto seals, gaskets, sprock- Do not use any harsh chemical Care ets, the drive chain and wheel products on plastic parts or the While the open design of a motorcycle axles. Always rinse the dirt and de- muffler.
  • Page 94 MOTORCYCLE CARE AND STORAGE den part of the windshield to thoroughly cleaned with mild de- NOTE: make sure that it does not leave tergent, alkaline products and a Salt sprayed on roads in the winter may any marks. If the windshield is soft brush may be used.

  • Page 95: Storage

    WARNING NOTE: To prevent corrosion, avoid Make sure that there is no oil or Consult a Yamaha dealer for advice on damp cellars, stables (because what products to use. wax on the brakes or tires. of the presence of ammonia)
  • Page 96 MOTORCYCLE CARE AND STORAGE 3. Perform the following steps to pro- 4. Lubricate all control cables and the tect the cylinders, piston rings, etc. pivoting points of all levers and from corrosion. pedals as well as of the side- a. Remove the spark plug caps stand/centerstand.

  • Page 97: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Type: Recommended fuel: 2065 mm (81.3 in) SAE10W30 or SAE10W40 or SAE15W40 Premium unleaded gasoline only Overall width: or SAE20W40 or SAE20W50 Fuel tank capacity: 720 mm (28.3 in) 18.0 L (4.76 US gal) (3.96 Imp.gal) Overall height: Fuel reserve amount: -20 -10...
  • Page 98 SPECIFICATIONS Gear ratio: Loading: Front brake: 1st: Maximum load: Type: 38/15 (2.533) 202 kg (445 lb) Dual disc brake 2nd: (Total weight of rider, passenger, cargo and Operation: 33/16 (2.063) accessories) Right hand operation 3rd: Tire air pressure (measured on cold Recommended fluid: 37/21 (1.762) DOT 4...
  • Page 99 SPECIFICATIONS Battery: Coolant temperature warning light: Model: Engine trouble warning light: YTZ10S Voltage, capacity: Immobilizer system indicator light: 12 V, 8.6 Ah Headlight: Shift timing indicator light: Bulb type: Halogen bulb Fuses: Bulb voltage, wattage x quantity: Main fuse: Headlight: 12 V, 55.0 W ×...

  • Page 100: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.

  • Page 101: Motorcycle Noise Regulation (For Australia)

    This informa- b. The use of the vehicle after such tion will be needed when ordering device or element of design has spare parts from a Yamaha dealer. been removed or rendered inoper- EWA12371 ative by any person.
  • Page 102 INDEX Fuel............3-17 Fuel consumption, tips for reducing..5-3 Air filter element, replacing ....6-14 Panels, removing and installing ....6-6 Fuel level warning light ......3-4 Auxiliary light bulb, replacing ....6-36 Parking ............5-4 Fuel tank cap ........3-16 Part locations .......... 2-1 Fuses, replacing ........
  • Page 103 INDEX Troubleshooting........6-41 Troubleshooting charts ......6-42 Turn signal indicator lights ...... 3-3 Turn signal light bulb, replacing.... 6-35 Turn signal switch......... 3-13 Valve clearance ........6-17 Vehicle identification number....9-1 Wheel bearings, checking ....6-28 Wheel (front) ......... 6-38 Wheel (rear)..........
  • Page 106 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2004.09-0.3×1 CR...
