System Operating manual FUJITSU LIFEBOOK T904...
Page 2
You can find driver updates at: "http://support.ts.fujitsu.com/download" Should you have any technical questions, please contact: • our Hotline/Service Desk (see the Service Desk list or visit: "http://support.ts.fujitsu.com/contact/servicedesk") • Your sales partner • Your sales office We hope you enjoy working with your new Fujitsu system!
Page 5
FUJITSU LIFEBOOK T904 Operating manual Innovative technology Ports and controls Important notes First-time setup of your device Working with the notebook Security functions Connecting external devices Removing and installing components during servicing Settings in BIOS Setup Utility Troubleshooting and tips Technical data Manufacturer’s notes...
Page 6
Information on the product description meets the design specifications of Fujitsu and is provided for comparison purposes. Several factors may cause the actual results to differ. Technical data is subject to change without prior notification. Fujitsu rejects any responsibility with regard to technical or editorial mistakes or omissions.
The Windows drivers for your device can be found on our Internet site. The factory installation of your device does not support any other operating system. Fujitsu Technology Solutions accepts no liability whatsoever if any other operating system is used.
"Safety information" • cross-references to an external source, e.g. a web address: For more information, go to "http://www.fujitsu.com/fts/" • Names of CDs, DVDs and titles or designations for other materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety/Regulations" manual indicates a key on the keyboard, e.g:...
Page 14
Right-hand side 1 = Headphone port 5 = Power-on indicator 2 = USB port 3.0 6 = LAN connector (removable) 3 = HDMI port 7 = Attachment eye for the pen cord 4 = ON/OFF switch 8 = Pen slot Fujitsu...
Page 15
Ports and controls Bottom 1 = Loudspeakers 3 = Battery release button 2 = Battery compartment with SIM card 4 = Port for port replicator slot under the battery Fujitsu...
(e.g. petrol station, paintshops), as the transmitted radio waves can cause an explosion or a fire. For information on how to switch radio components on and off, see chapter "Switching the wireless components on and off", Page Fujitsu...
► Enquire with the corresponding government office of the country you will be travelling in as to whether you may operate the radio component integrated in your notebook there (see also "CE marking", Page 100). Fujitsu...
The surface can be cleaned with a dry cloth. If particularly dirty, use a cloth which has been moistened in mild domestic detergent and then carefully wrung out. To clean the keyboard and the clickpad, if available, you can use disinfectant wipes. Ensure that no liquid enters the device. Fujitsu...
► Unpack all the individual parts. Packaging Transport ► Check your device for any visible damage which may have occurred during transportation. You may need the packaging in the future, if you need to transport your device. Fujitsu...
► Connect the power cable (1) to the mains adapter. ► Plug the mains cable (2) into a mains outlet. ► Connect the mains adapter cable (3) to the DC jack (DC IN) of the device. Fujitsu...
To make it easier to use your device for the first time, the operating system is pre-installed on the hard disk. ► Slide the ON/OFF switch (1) to the right to switch on the notebook. The ON/OFF switch returns automatically to its original position. ► During installation, follow the instructions on screen. Fujitsu...
Page 22
If a Windows operating system is installed on your device, you will find more information on the system and drivers, help programmes, updates, manuals etc. on the device or on the Internet under "http://www.fujitsu.com/fts/support/". You can find information and help on the Windows operating system functions on the Internet at "http://windows.microsoft.com".
Please refer to the notes in "Important notes", Page Status indicators Statusindicators Symbols The status indicators provide information about the status of the power supply, the drives and the keyboard functions etc. Fujitsu...
Page 24
Drive indicator Indicator is illuminated: The hard disk drive of the notebook is being accessed. Radio components indicator • The indicator is illuminated: The radio components are switched on. • Indicator is off: The radio components are switched off. Fujitsu...
Windows 8.1 Desktop - Control Panel - Hardware and Sound - Power Options If you have assigned a password, you must enter this when requested to do so, in order to start the operating system. Detailed information can be found in the chapter "Security functions", Page Fujitsu...
You must note that the display cannot be turned completely on its own axis! Stop turning the screen when you feel resistance. No guarantee claims can be met for damage caused by wrong turning. From notebook to Tablet PC ► Raise the LCD display into a vertical position. Fujitsu...
Page 28
► Hold the screen as low as possible on both sides. Turn the screen to the left or right in the direction of the arrow. At first you will feel some slight resistance, then it will turn easily and without friction. ► Turn the display further until it has turned 180° and the hinge latches in. Fujitsu...
You can choose to use either portrait or landscape orientation for the display. Windows 7 You can change these settings in the Fujitsu menu or under Start - (Settings -) Control Panel - Hardware and Sound - Display - Settings.
Switching off the notebook Notebook ► Close all applications and then shut down the operating system (please see the "Operating System Manual"). ► Slide the ON/OFF switch towards the right. The ON/OFF switch returns automatically to its original position. Fujitsu...
Portuguese, Spanish, Brazilian, Norwegian (Bokmål and Nynorsk), Swedish, Finnish, Danish, Polish, Rumanian, Serbian (Cyrillic and Latin script), Catalan, Russian, Czech and Croatian. Under Windows 8.1 you can set the required language under Control Panel – Time, Language and Region – Language. Fujitsu...
LCDscreen Notes High-quality TFT displays are installed in notebooks from Fujitsu. For technical reasons, TFT monitors are manufactured for a specific resolution. An optimal, clear picture can only be ensured with the correct resolution intended for the relevant TFT monitor. A monitor resolution which differs from the specification can result in an unclear picture.
► Touch the desired item once with your finger mouse button) tip. Keep the finger tip pressed against the touchscreen. The context menu appears. Moving the cursor ► Position one finger on the touchscreen and move the finger in the desired direction. Fujitsu...
Page 35
► Position two fingers on the touchscreen. ► Move your fingers upwards to scroll up. ► Move your fingers downwards to scroll down. Rotating ► Position the thumb on the touchscreen, then turn the picture clockwise or counter-clockwise using your index finger. Fujitsu...
2 = pen button (= right mouse button) 3= eyelet for pen cord You can use the pen on your TabletPC as an electronic writing implement to select items and to navigate through menu options and programs. Programs that support Fujitsu...
Page 37
Opening a context Click with the right-hand mouse Touch the desired element with the menu button. pen and leave the pen on the element for a moment. Moving the cursor - Place the pen tip directly on the screen. Fujitsu...
Page 38
You should attach the pen with a pen cord to prevent accidentally dropping or losing it. ► Attach the end of the pen cord with the smaller loop to your pen. ► Attach the end of the pen cord with the larger loop to your notebook. Fujitsu...
► Tap the clickpad once or press the left button once. The item is selected. Executing commands ► Move the pointer to the field you wish to select. Clickpad ► Tap the clickpad twice or press the left button twice. The command is executed. Fujitsu...
Page 40
► Press and hold the left button and drag the item to the desired position with the finger on the clickpad. The item will be moved. Switching the clickpad on and off You can switch the clickpad on and off using a key combination, "Key combinations", Page Fujitsu...
The figure below shows how to access the different characters on keys with overlaid functions. The example applies when the Caps Lock key has not been activated. The illustrations shown below may differ from your actual device. Alt Gr Fujitsu...
Page 42
The cursor keys move the cursor in the direction of the arrow, i.e. up, down, left, or right. Cursor keys Cursor control Windows key The Windows key switches between the start screen and the last used application. Windowskey Menu key The Menu key opens the menu for the active application. Fujitsu...
Further information about the status indicators can be found in chapter "Status indicators", Page Country and keyboard settings ► Change the country and keyboard settings as described in the documentation for your operating system. Fujitsu...
Increase screen brightness This key combination increases the screen brightness. Fn+F7 Screenbrightness Decrease volume This key combination reduces the volume of the internal loudspeakers. Fn+F8 Volume Increase volume This key combination increases the volume of the internal loudspeakers. Fn+F9 Volume Fujitsu...
Page 45
This key combination opens the Windows security/Task Manager Ctrl window. Strg+Alt+Entf/Ctrl+Alt+Del Back tab This key combination moves the cursor back to the previous tab stop. Shift+Tab Backtab Key combinations using the Windows keys are detailed in the manual for your operating system. Fujitsu...
If the button is pressed in combination with the ON/OFF switch, the function corresponds to the key combination Ctrl Increase volume This button increases the volume of the built-in loudspeakers. Decrease volume This button reduces the volume of the built-in loudspeakers. Fujitsu...
If you would like to perform a function test of your web cam, there is suitable test software available at "http://www.fujitsu.com/fts/support/index.html". Fujitsu...
Never store the batteries in the device. Removing and installing the battery Only use rechargeable batteries approved by Fujitsu for your notebook. Never use force when fitting or removing a battery. Make sure that no foreign bodies get into the battery connections.
Page 49
► Remove all the cables from the device. ► Turn the device over and place it on a stable, flat and clean surface. If necessary, lay an anti-slip cloth on this surface to prevent the device from being scratched. Fujitsu...
Page 50
► Slide the release button in the direction of the arrow (1) and hold it in place. ► Slide the release button in direction of the arrow (2). ► Remove the battery compartment cover (3). ► Lift the battery out of the battery compartment (4). Fujitsu...
Page 51
► Slide the release button in the direction of the arrow (3). The battery is secured. ► Turn the notebook the right way up again and place it on a flat surface. ► Reconnect the cables that you disconnected before. Fujitsu...
If you do not intend to use your notebook for a long period of time: ► Exit power saving mode if necessary via the mouse or keyboard or by switching on the notebook. ► Close all opened programs and completely shut down the notebook. Fujitsu...
(see the documentation for your operating system). ► On devices with card locking: Press on the storage card (1). Memory card The storage card is released and can now be removed. ► Pull the storage card out of the slot (2). Fujitsu...
If you attach an external microphone, the built-in microphone is disabled. When you connect headphones or external speakers, the built-in speakers are disabled. Information on connecting headphones and a microphone can be found "Connecting external devices", Page Fujitsu...
► Press on the edge of the SIM card so that it jumps up slightly out of the slot. ► Pull the SIM card out of the slot in the direction of the arrow (1). ► Install the battery, see chapter "Inserting battery", Page Fujitsu...
Optional Wireless LAN / Bluetooth / UMTS / LTE wireless components The installation of radio components not approved by Fujitsu will invalidate the certifications issued for this device. Depending on the device configuration you ordered, your device will be equipped with Wireless LAN, Bluetooth and/or UMTS / LTE.
If you did not order a UMTS / LTE module, you can purchase the accessories for UMTS / LTE reception from your retailer or your Fujitsu Technology Solutions dealer. You will find information on establishing the connection with the UMTS / LTE network in the documentation for the hardware used.
8 = Connector on the Port Replicator for the docking port on the underside 3 = LAN port of the notebook 4 = DisplayPort 9 = Unlocking lever 5 = DVI port 10 = ON/OFF switch 6 = VGA monitor port Fujitsu...
• Never place the port replicator and the mains adapter on a heat-sensitive surface. • Do not expose the port replicator to extreme environmental conditions. Protect the port replicator from dust, humidity and heat. Fujitsu...
► Press down on the notebook’s rear corners so that it locks into position (2). ► Connect the mains adapter cable to the DC jack (DC IN) of the port replicator (3). ► Connect the power cable to the mains adapter (4). ► Plug the power cable into the mains socket (5). Fujitsu...
If the notebook cannot be shut down properly, press the ON/OFF button on the Port Replicator for approx. four seconds. The notebook will switch off. Any unsaved data may however be lost. Fujitsu...
Working with the notebook Disconnecting the notebook from the port replicator ► Pull the unlocking lever in the direction of the arrow (1), until you hear the notebook unlatch. ► Lift off the notebook (2). Fujitsu...
If you forget your passwords you will need to contact the our Service Desk. Deletion or resetting of passwords is not covered by your warranty and a charge will be made for assistance. Fujitsu...
Brief overview of security functions Detailed information about the security equipment of your device can be found in the "Professional Notebook" manual, on the "Drivers & Utilities" CD/DVD or on the Internet at "http://www.fujitsu.com/fts/support/index.html". Security functions Type of protection Preparation...
Kensington Lock Cable, a sturdy steel cable, to help protect your notebook from theft. The Kensington Lock Cable is available as an accessory. Fujitsu recommends the use of a combination lock. ► Fit the Kensington Lock Cable on the device on your notebook.
The notebook will be rebooted and the new password will come into effect. It will now be necessary to first enter your supervisor or user password in order to open the BIOS Setup Utility. Please note that the user password only provides access to a few of the BIOS settings. Fujitsu...
► Select the Disabled option and press the Enter key. If you do not want to change any other settings, you can exit BIOS Setup Utility. ► Select the Save Changes & Exit option under Exit. The notebook will reboot. The system is no longer password-protected. Fujitsu...
► To cancel the password for the second hard disk (Drive1), go to the Drive1 area and select the field Set Master Password, then proceed in exactly the same way as for cancelling the password for the first hard disk (Drive0). Fujitsu...
In order to be able to take advantage of all the security features of your notebook, you will need a CardOS SmartCard from Fujitsu Technology Solutions. The SmartCard can only be used with a PIN, offering maximum protection even if you lose the SmartCard.
With SystemLock enabled, the device can only be started using an initialised SmartCard (SICRYPT, CardOS or Fujitsu) and a personal identification number (PIN). The SmartCard and PIN are checked during system booting in the BIOS, i.e. before the operating system is started.
Unblocking all blocked SmartCards Generating user cards Uninstall SystemLock * BIOS Setup setting (Unblock own SmartCard) Usually there is always one Admin SmartCard and at least one User or SuperUser SmartCard that will allow a system to be operated. Fujitsu...
User SmartCards or SuperUser SmartCards must still be generated using SystemLock so that users can access the systems within the user group. Using a User SmartCard or SuperUser SmartCard a user can log on to each system within the user group. Fujitsu...
SystemLock Admin Install Group PC [Enter] SmartCard into this PC without modifying any data on the SmartCard. A correct SmartCard is Enter PIN: required for a permanent installation. ► Insert a new SmartCard in the reader and press Enter. Fujitsu...
Page 74
Please wait a few seconds after confirming the new PIN: SystemLock is being installed. The following message will be displayed if installation is successful: Setup Notice Changes have been saved [Continue] ► Now press the Enter key. The SystemLock administration menu will be displayed: Fujitsu...
Page 75
PIN/PUK do not match = You have confirmed the PUK incorrectly. You will then be requested to re-enter and reconfirm the new PUK. F5,function key F6,function key F7,function key F8,function key F9,function key F10,functionkey Instructions on how to initialise additional SmartCards can be found in Section "Carrying out administrator functions", Page Fujitsu...
ACCESS DENIED = You have confirmed the PIN incorrectly. You are then requested to enter and confirm the new PIN again. After three failed attempts, the SmartCard will be blocked and can then only be activated again by entering the PUK. Enter the PUK: Fujitsu...
Page 77
F5,function key F6,function key F8,function key F9,function key Generate a user card for the device as described in Section "Carrying out administrator functions", Page ► If you do not want to initialise any further SmartCards, press remove the Admin SmartCard. Fujitsu...
► Press the desired function key. The following message will be displayed: Remove the SmartCard. ► Remove the Admin SmartCard. Insert a SmartCard. Keep the Admin SmartCard in a safe place and protect it from unauthorised access. Fujitsu...
Page 79
Always change the PIN and PUK for all further SmartCards. The PUK is used to re-activate a blocked SmartCard. ► Remove the User SmartCard and label it, e.g. with the name of the user. But NEVER write the PIN on the SmartCard under any circumstances! Fujitsu...
The activation code can only be used once to start the device; it immediately becomes invalid when the device boots. If you wish to switch off the device and start it again without your SmartCard, the procedure described above must be repeated each time. Fujitsu...
► Confirm the new PIN. Uninstall SystemLock ► Start the device. Uninstalling ► Follow the instructions given in section "Carrying out administrator functions", Page 74. Select "Uninstall" to uninstall SystemLock. You can now use the device again without the need for a SmartCard. Fujitsu...
Setting the Supervisor password ► Select Start - Run. ► Enter the following at the command line: C:\Program Files\Fujitsu\Security Panel Application\Supervisor\FJSECS.EXE. ► Confirm with Enter ►...
► Mark the TPM Security Chip Setting field and press the Enter key. ► Select Disabled to deactivate the TPM. ► From the Exit menu, choose the option Exit Saving Changes. ► Press the Enter key and select Yes. Your notebook will now restart and TPM will be disabled. Fujitsu...
Peripheraldevices Disconnecting devices from the notebook 1. Turn off your notebook and all external devices. 2. Unplug your notebook and all devices from the mains sockets. 3. Disconnect the cables for your external devices following the instructions. Devices Peripheraldevices Fujitsu...
The HDMI port on your notebook can be used to connect an external amplifier, LCD TV or a plasma TV with an HDMI connection. ► Connect the data cable to the external device. ► Connect the data cable to the HDMI port of the notebook. Fujitsu...
► First switch on the external monitor and then the notebook. You can also switch between the external monitor and the LCD monitor of the notebook, see chapter "Key combinations", Page You can display the same picture on the external monitor and the notebook LCD monitor simultaneously. Fujitsu...
Additional information can be found in the documentation for the USB devices. ► Connect the data cable to the external device. ► Connect the data cable to a USB port of the notebook. Device drivers USB devices will be automatically recognised and installed by your operating system. Fujitsu...
► Left click on the icon to safely remove hardware, located in the taskbar. ► Select the device which you want to shut down and remove. ► Press the Enter key. Wait for the dialogue box which tells you that it is now safe to remove the device. Fujitsu...
If you purchase a cable from a retailer, please note the following information: The headphone port on your notebook is a "3.5 mm jack socket". If you want to connect headphones or a speaker you will need a "3.5 mm jack plug". Fujitsu...
Removing and installing components during servicing Removing and installing components during servicing Only qualified technicians should repair your notebook. Unauthorized opening or incorrect repair may greatly endanger the user (electric shock, fire risk) and will invalidate your warranty. Servicing Components Fujitsu...
► Select the option you want to change with the cursor keys ↑ ↓ ► Press the Enter key. ► Press the key to exit the selected menu. ► For future reference, make a note of the changes you have made (for example, in this manual). Fujitsu...
► If you want to exit BIOS Setup Utility with these settings, choose Exit Saving Changes and Yes. Save Changes and Power Off ► To save the changes and switch off your device, select Save Changes and Power Off and Yes. The changes are saved. Your device is shut down. Fujitsu...
PC if you are running processor-intensive gaming software, e.g. games with intensive 3D graphics. Updating your hardware with drivers which have not been approved by Fujitsu Technology Solutions may result in performance losses, data losses or malfunction of the equipment. A list of approved drivers and current BIOS versions can be downloaded from: "http://support.ts.fujitsu.com/Download/Index.asp"...
The notebook’s LCD screen remains blank LCDscreen LCDscreenistoodark Cause Troubleshooting Monitor is switched off. ► Press a key or touch the clickpad. External monitor or television set connected. ► Press the key combination to switch the screen output, see "Key combinations", Page Fujitsu...
Change the following setting: ► Set the screen resolution: Set the screen resolution as described in the documentation for your operating system. ► Select monitor: Select monitor 1 or 2 as described in the documentation for your operating system. Fujitsu...
► Charge the battery. ► Insert a charged battery. ► Connect the mains adapter to the notebook. The power adapter is not connected correctly. ► Check whether the mains adapter is connected correctly to the notebook. ► Switch the notebook on. Fujitsu...
The wireless component is enabled. Despite ► Check whether the radio connection is this, the wireless connection to a network does switched on via the software. not work. ► Further information on using the radio component can be found in the help files. Fujitsu...
Supervisor PIN. SmartCard lost Troubleshooting Cause SmartCard lost ► If you are working in a network, contact your system administrator, who can boot up your notebook with a Supervisor SmartCard. Fujitsu...
The system configuration information is ► Press the function key to access the incorrect. BIOS Setup. ► In the BIOS Setup, select the Exit menu. ► Select the entry Load Setup Defaults. ► Select OK and press the Enter key. Fujitsu...
Page 100
► Contact your sales outlet or our customer service centre. System cache error - Cache disabled ► Contact your sales outlet or our customer service centre. System timer error ► Contact your sales outlet or our customer service centre. Fujitsu...
4 x USB 3.0 Audio Headphone port Docking port 100-pin Security Lock Ambient conditions Environment class DIN IEC 721 Mechanism class DIN IEC 721 Operating temperature 5℃ ..35℃ / 41°F ..95°F Transport temperature –15°C ..60°C / 5°F ..140°F Fujitsu...
Technical data Rechargeable battery You will find information on the batteries used in your device on the Internet at "http://www.fujitsu.com/fts/support/". Rated voltage 14.4 V Rated capacity 45 Wh Nominal power 3150 mAh The operating time depends on the device configuration, the active applications and the energy-saving settings.
Declarationofconformity The "Declarations of Conformity" for the device can be found on the Internet at: "http://globalsp.ts.fujitsu.com/sites/certificates/default.aspx". Fujitsu Technology Solutions hereby declares that your device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. CE marking...
F5, function key 71, 73 cleaning 14 F6, function key 71, 73 Deactivating 40 F7, function key 71 Dragging items 36 F8, function key 71, 73 Executing commands 35 F9, function key 71, 73 Moving the pointer 35 Selecting an item 35 Fujitsu...
Page 106
14 difficult to read 91 notes 29 reflected glare 91 Operating system remains blank 90 activating system protection 63 LCD screen is too dark 90 cancel system protection 63 Life, battery 44 protecting with password 63 Line feed 38 Fujitsu...
Page 107
Trusted Platform Module 79 Security functions, SmartCard 65 Security Lock 61 Selecting a location 16 Uninstalling Self-discharge, battery 44 SystemLock 77 Servicing 86 USB charging function 84 Setup USB ports 83 see BIOS Setup Utility 87 User groups Shift 38 installing 69 Fujitsu...
Page 108
Webcam 43 Using the Kensington Lock Cable 61 Windows key 38 Wireless LAN switching module off 52 VGA connection socket 82 switching module on 52 Virtual numeric keypad 39 Wireless LAN: Volume safety notes 12 decrease 40 increase 40 Fujitsu...
