Baumatic BTI975GL-SA Instruction Manual

90 cm glass island

Advertisement

Quick Links

BTI975GL-SA 90 cm
Glass island cooker hood
1

Advertisement

Table of Contents
loading

Summary of Contents for Baumatic BTI975GL-SA

  • Page 1 BTI975GL-SA 90 cm Glass island cooker hood...
  • Page 2 User Manual for your Baumatic BTI975GL-SA Cooker Hood 90 cm Glass island cooker hood in stainless steel NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
  • Page 3: Table Of Contents

    Contents Page Environmental note IMPORTANT SAFETY INFORMATION 5 – 7 Specifications of your cooker hood Using your Baumatic cooker hood Cleaning your Baumatic cooker hood The grease filters Maintenance 11 - 14 Removing and cleaning the grease filters Changing a light bulb...
  • Page 4: Environmental Note

    ENVIRONMENTAL NOTE Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person.
  • Page 5: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Advice Line.
  • Page 6 o The edges of the cooker hood are sharp – be mindful of this as you handle your appliance, especially during installation and cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTERS! o If the room where the cooker hood is to be used contains a fuel burning appliance such as a central heating boiler then its flue must be of the sealed or balanced flue type.
  • Page 7 o Remember that when in extraction mode, your cooker hood is removing air from your room. Ensure that proper ventilation measures are being observed. o Note that it removes odours from your room, not steam. o Warning - Always ensure that the cooker hood been disconnected...
  • Page 8: Specifications Of Your Cooker Hood

    Specifications of your cooker hood Congratulations on purchasing a Baumatic cooker hood! PRODUCT DIMENSIONS Height: 660 mm * – 1160 mm Width: 900 mm Depth: 600 mm DIMENSIONS OF CHIMNEY SECTION 282 mm x 295 mm o High extraction tangential motor...
  • Page 9: Using Your Baumatic Cooker Hood

    Make sure that it has been installed by a suitably qualified person, information contained Baumatic’s installation instructions. o Find the control panel, which is located on the right hand side of the canopy. o There are several buttons on the control panel, which perform separate functions.
  • Page 10: Cleaning Your Baumatic Cooker Hood

    Cleaning your Baumatic cooker hood IMPORTANT: BEFORE CLEANING, ALWAYS ENSURE THAT HAVE SWITCHED YOUR COOKER HOOD OMNI-POLAR SWITCH, SET AT THE WALL FROM THE CABLE. Cleaning o Clean the external parts of your cooker hood with mild liquid detergent and a new damp cloth.
  • Page 11: Maintenance

    Maintenance Removing and cleaning the grease filters o First remove the grease filters by pulling down on the handle and pulling them away from cooker hood. o Soak the grease filters in hot water and washing up liquid for about an hour. o Rinse it off thoroughly with hot water.
  • Page 12: Changing A Light Bulb

    Changing a light bulb IMPORTANT: BEFORE ATTEMPTING TO CHANGE A LIGHT BULB, YOU MUST ENSURE THAT YOU HAVE DISCONNECTED THE COOKER HOOD FROM YOUR MAINS SUPPLY. o Prior to touching the light bulbs ensure that they have cooled down. o Find the bulb that requires replacement, you will find it located in the light fixture which is inside the exposed section of the canopy.
  • Page 13: Fitting The Carbon Filter

    o Use a screwdriver to remove the glass cover that sits over the bulb. Unplug the light bulb that needs to be replaced and insert a new G4 20W (max) bulb. Then replace the glass cover. o IMPORTANT: Defective bulbs should be replaced immediately. o If the lights still do not work, make sure that the bulbs are fitted properly into their housings before you call for technical assistance.
  • Page 14 3) Insert the carbon filter in the rectangular hole, fitting it over the motor. IMPORTANT: cutaway (indicated by the arrow) must be located at the front right of the rectangular hole. 4) After inserting the front edge of the carbon filter into the slot on the cooker hood.
  • Page 15: Installation

    Installation IMPORTANT: Before installation and usage read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found behind the grease filter.
  • Page 16: Before Beginning Installation

    o As the colours of the wires in the appliance’s mains lead may not correspond with the coloured markings identifying the terminals in your spur box, please proceed as follows: o The blue wire must be connected to the terminal marked “N” (neutral), or coloured black.
  • Page 17: Positioning

    o Do not tile, grout or silicone this appliance to the ceiling. This appliance is designed to be surface mounted only. o Remove any protective wrapping that has been put on the cooker hood or chimney sections, to protect them during transit. Positioning Height of the appliance Total height of the kitchen...
  • Page 18: Installing Your Cooker Hood

    IMPORTANT: Your ceiling should have a minimum height of 2.7 metres; otherwise you may encounter difficulties when installing the appliance. IMPORTANT: Although the minimum height of the appliance can be set at 660 mm. During the installation process you will need to move the lower chimney section upwards, to allow you to attach the main body of the hood to the framework.
  • Page 19: Supplied Installation Components

    Supplied installation components 1) Position the hanging plate on the ceiling and then mark the position of the screw holes. o The hanging plate should securely fixed to the ceiling, using the 12 x ST6 (40 mm) screws. o Depending on the surface of the ceiling that you are fixing the hanging plate to, you may need to use 8 x expansion bolts (for concrete).
  • Page 20 2) Fix the angle bars to the hanging plate, using the 8 x M4 nuts and bolts with metal washers. 3) Extend the angle bars to the required height and then fix them in position using the 16 x M4 nuts and bolts with metal washers.
  • Page 21 5) Fix the upper chimney section to the hanging plate, using the 4 x self tapping screws. o Slide the lower chimney section onto the angle bars and raise it until it sits just below the upper chimney section. o Use the hanging hook to temporarily keep the lower chimney section in this position, to make sure that it does not drop down whilst fixing the main body of the hood to the...
  • Page 22: Completing The Installation

    8) If you are going to be using the hood in extraction mode, you should fix the ducting hose to the spigot. o The electrical connection must correspond electrical requirement noted rating plate, which is placed inside the cooker hood. The appliance should connected...
  • Page 23: Extraction Mode Or Recirculation Mode

    o Refit the grease filters and then switch on the mains supply to the appliance. Check that the appliance is operating correctly by selecting each speed and switching the light bulbs on and off. Extraction mode or recirculation mode? What is the difference between extraction and recirculation modes? To get optimum performance from your cooker, the air will be taken out of the room via external ducting.
  • Page 24: Troubleshooting

    Troubleshooting IMPORTANT: If your cooker hood appears not to be operating properly, before contacting the Advice Line, please refer to the checklist below. My cooker hood will not start. o Check that the hood is connected to the electricity supply o Check that the fan speed control is set correctly.
  • Page 25 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance.
  • Page 26: Contact Details

    United Kingdom Baumatic Ltd., Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom E-mail: sales@baumatic.co.uk customercare@baumatic.co.uk spares@baumatic.co.uk technical@baumatic.co.uk Website: www.baumatic.co.uk Saudi Arabia Awad Badi Nahas P.O. Box 11529 21463 Jeddah Saudi Arabia Telephone: +96622560888 E-mail: info@awadnahas.com...
