YOGA HOME 500 All-In-One PC Hardware
Maintenance Manual
Machine Types: F0AS [YOGA Home 500-22IBU / Energy Star]

Advertisement

Table of Contents
loading

Summary of Contents for Lenovo YOGA HOME 500

  • Page 1 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual Machine Types: F0AS [YOGA Home 500-22IBU / Energy Star]...
  • Page 3 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual Machine Types: F0AS [YOGA Home 500-22IBU / Energy Star]...
  • Page 4 Third Edition (August 2015)20th © Copyright Lenovo 2015, 2015. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software are delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No.
  • Page 5: Table Of Contents

    Replacing the LED panel module ..Changing booting mode ... Exiting the Lenovo BIOS Setup Utility program . . Chapter 9. FRU lists ..45 Chapter 6.
  • Page 6 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 7: Chapter 1. About This Manual

    Chapter 1. About this manual This manual contains service and reference information for YOGA HOME 500 All-In-One computers listed on the cover. It is intended only for trained servicers who are familiar with Lenovo computer products. Before servicing a Lenovo product, be sure to read the Safety Information.
  • Page 8 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 9: Chapter 2. Safety Information

    Electrical current from power, telephone, and communication cables can be hazardous. To avoid personal injury or equipment damage, disconnect any attached power cords, telecommunication cables, network cables, and modem cables before you open the computer covers, unless instructed otherwise in the installation and configuration procedures. © Copyright Lenovo 2015, 2015...
  • Page 10 – Blowers and fans – Motor generators and similar units. (This practice ensures correct grounding of the units.) • If an electrical accident occurs: – Use caution; do not become a victim yourself. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 11: Safety Inspection Guide

    – Switch off power. – Send another person to get medical aid. Safety inspection guide The intent of this inspection guide is to assist you in identifying potential hazards posed by these products. Each computer, as it was designed and built, had required safety items installed to protect users and service personnel from injury.
  • Page 12: Grounding Requirements

    • Connect and disconnect cables as described in the following table when installing, moving, or opening covers on this product or attached devices. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 13 To Connect To Disconnect 1. Turn everything OFF. 1. Turn everything OFF. 2. First, attach all cables to devices. 2. First, remove power cords from outlets. 3. Attach signal cables to connectors. 3. Remove signal cables from connectors. 4. Attach power cords to outlet. 4.
  • Page 14 To remove all electrical current from the device, ensure that all power cords are disconnected from the power source. CAUTION: Do not place any object weighing more than 82 kg (180 lbs.) on top of rack-mounted devices. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 15: Chapter 3. General Information

    This chapter provides general information that applies to all computer models covered by this manual. Specifications This section lists the physical specifications for your computer. This section lists the physical specifications for your computer. Type YOGA HOME 500 This section lists the physical specifications. Environment Air temperature: Operating: 10°...
  • Page 16 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 17: Chapter 4. General Checkout

    • If the computer displays a POST error, go to “POST error codes”. • If the computer hangs and no error is displayed, continue at step 7. 7. If the test stops and you cannot continue, replace the last device tested. © Copyright Lenovo 2015, 2015...
  • Page 18 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 19: Chapter 5. Using The Setup Utility

    1. If your computer is already on when you start this procedure, shut down the operating system and turn off the computer. 2. Press and hold the F1 key then turn on the computer. When the Lenovo BIOS Setup Utility program is displayed, release the F1 key.
  • Page 20 Administrator Password if you are responsible for maintaining the settings of several computers. After you set an Administrator Password, a password prompt is displayed every time you access the Lenovo BIOS Setup Utility program. If both the Administrator and Power-On Password are set, you can type either password. However, you must use your Administrator Password to change any configuration settings.
  • Page 21: Enabling Or Disabling A Device

    Power-On Password When a Power-On Password is set, you cannot start the Lenovo BIOS Setup Utility program until a valid password is typed from the keyboard. Setting, changing, or deleting a Power-On Password Note: A password can be any combination of letters and numbers up to 16 characters (a-z and 0-9).
  • Page 22: Selecting A Startup Device

    Select Network Setup, press the Enter key, then select Onboard Ethernet Support or LAN Boot Agent. 4. Select Disabled or Enabled and press the Enter key. 5. Return to the Lenovo BIOS Setup Utility program menu and select the Exit option. 6. Select Save Changes and Exit from the menu. Notes: a.
  • Page 23: Changing Booting Mode

    Exiting the Lenovo BIOS Setup Utility program After you finish viewing or changing settings, press the Esc key to return to the Lenovo BIOS Setup Utility program main menu. You might have to press the Esc key several times. Do one of the following: •...
  • Page 24 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 25: Chapter 6. Symptom-To-Fru Index

    Check that the following are properly installed: Reseat connectors • Power Cord • On/Off Switch connector • System Board Power Supply connectors • Microprocessor connections Check the power cord. Power Cord Check the power-on switch. Power-on Switch © Copyright Lenovo 2015, 2015...
  • Page 26: Post Error Codes

    3. Power-on the computer to re-test the system. 4. Repeat steps 1 through 3 until you find the failing device or component. If all devices and components have been removed and the problem continues, replace the system board. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 27: Chapter 7. Locating Connectors, Controls And Components

    Attention: Be careful not to block any air vents on the computer. Blocked air vents can cause overheating. 1. Built-in microphone 4. Ambient light sensor 2. Camera LED indicator 5. Near Field Communication (NFC) (selected models only) 3. Built-in camera © Copyright Lenovo 2015, 2015...
  • Page 28 The following illustration shows the location of connectors, controls and components on the left and right side of the computer. 1. Memory card reader 5. Power connector 2. Combo audio jack 6. Volume control button 7. Power button 3. USB 3.0 connectors (3) 4. HDMI-in connector YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 29 Rear view The following illustration shows the location of connectors and components on the rear of the computer. 1. Air vents 2. Computer stand Chapter 7 Locating connectors, controls and components...
  • Page 30 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 31: Chapter 8. Replacing Hardware

    Attention: Do not remove the computer cover or attempt any repair before reading the “Important safety information” in the Safety and Warranty Guide that was included with your computer. To obtain copies of the Safety and Warranty Guide, go to the Support Web site at: http://support.lenovo.com. Note: Use only parts provided by Lenovo.
  • Page 32: Replacing The Keyboard And Mouse

    Step 2. Locate the connector for the power cord. Refer to “Rear view”. Step 3. Disconnect the failing power adapter from the computer. Step 4. To install the new power adapter: YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 33 Connect the new power adapter to the same connector. Chapter 8 Replacing hardware...
  • Page 34: Replacing The Battery

    Disconnect all cables attached to the computer. This includes power cords, input/output (I/O) cables, and any other cables that are connected to the computer. Refer to “Left and right view” and “Rear view” for help with locating the various connectors. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 35: Removing The Rear Cover

    Step 4. Using a flat head crow bar push into the gap in-between the batter and batter cover, then prise up the cover gently as shown. Step 5. Remove the two screws that secure the battery to the rear cover, then lift up the battery pack as shown.
  • Page 36 Note: It may be helpful to place the computer face-down on a soft flat surface for this procedure. Lenovo recommends that you use a blanket, towel, or other soft cloth to protect the touch screen from scratches or other damage.
  • Page 37 Step 6. For the below procedure, it might requiring using a flat head crowbar or a boot disk Step 7. Put the head of crowbar or boot disk into the slot in between the panel and the rear cover as shown.
  • Page 38: Replacing A Memory Module

    “Rear view” for help with locating the various connectors. Step 4. Remove the rear cover. Refer to “Removing the rear cover”. Step 5. Disconnect the battery power cable from the connector on the motherboard. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 39: Replacing The Hard Disk Drive

    Step 6. Push out the latches on both sides of the memory socket to release the memory module. Gently pull the memory module upward to remove it from its socket. Step 7. To install the new memory module: Align the new memory module with the memory socket, then insert it and push down on the top edge.
  • Page 40: Replacing The Speaker System

    “Rear view” for help with locating the various connectors. Step 4. Remove the rear cover. Refer to "Removing the rear cover". Step 5. Disconnect the battery power cable from the connector on the motherboard. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 41: Replacing The Converter Board

    Step 6. Remove the four screws that secure the speaker system to the rear cover. Step 7. Disconnect the speaker cable from the connector on motherboard. Step 8. Lift up speaker system to remove it. Step 9. To install the new speaker system: Line up the new speaker system with the mounting holes on the rear cover, secure it with the screws.
  • Page 42: Replacing The Power Switch Board

    “Rear view” for help with locating the various connectors. Step 4. Remove the rear cover. Refer to "Removing the rear cover". Step 5. Disconnect the battery power cable from the connector on the motherboard. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 43: Replacing The Wi-Fi Card

    Step 6. Remove the screws that secure the power switch board to the rear cover. Step 7. Lift up the power board, and disconnect the power cable from the switch board. Step 8. To install the power switch board: Connect the power cable to the connector on the new power switch board. Line up the holes on the new power switch board with the mounting holes on the rear cover and secure the new power switch board with the screws.
  • Page 44: Replacing The System Fan

    “Rear view” for help with locating the various connectors. Step 4. Remove the rear cover. Refer to "Removing the rear cover". Step 5. Disconnect the battery power cable from the connector on the motherboard. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 45: Replacing The Heat-Sink

    Step 6. Disconnect the power cable from the connector on the motherboard. Step 7. Remove the three screws that secure the system fan to the rear cover. Step 8. Lift up the system fan to remove it. Step 9. To install the new system fan: Line up the new system fan with the mounting holes on the rear cover and place it into position.
  • Page 46: Replacing The Motherboard

    Remove the rear cover. Refer to “Removing the rear cover”. Step 5. Disconnect the battery power cable from the connector on the motherboard. Step 6. Remove the memory modules. Refer to “Replacing a memory module”. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 47: Replacing The Camera

    Step 7. Replacing the system fan. Refer to “Replacing the system fan”. Step 8. Remove the heat-sink. Refer to “Replacing the heat-sink”. Step 9. Remove the Wi-Fi card. Refer to “Replacing the Wi-Fi card”. Step 10. Remove all the cables connected to the motherboard. Step 11.
  • Page 48: Replacing The Led Panel Module

    Step 7. Press the pins to unlock the LVDS cable from the connector on the LED panel , then pull it out. Step 8. Remove the touch control-motherboard cable and converter-LED cable. YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 49 Step 9. The LED panel module including: LED panelGlassLED bracketsTouch control boardNFC board Step 10. To install the new the LED panel module: Connect the LVDS cable to the connector and touch control board. Reattach the camera to the front bezel. Connect the converter cables to the connectors on both LED panel.
  • Page 50 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 51: Chapter 9. Fru Lists

    Chapter 9. FRU lists This chapter lists the information on the field replaceable units (FRUs) for Lenovo YOGA HOME 500 All-In-One desktop computer. Attention: Be sure to read and understand all the safety information before replacing any FRUs. Fru P/N...
  • Page 52 Power Board T horizon2e CARDPOP 5CB0G59974 Battery Cover T horizon2e COVER 5CB0G60002 RearCover T horizon2e W/TV_HDMI COVER 5D10K36368 LCD Module YOGA 500 TS BLK DISPLAY 00PC218 SK-8861(MY) 2.4G KB-improved8 DT_KYB DT_KYB 00PC217 SK-8861(CH) 2.4G KB-improved8 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 53 01AH600 2.4G SK-8861 improved8 KB HBW DT_KYB 5F10G59979 FAN T horizon2e DIS&UMA Delta 16200420 SGT KahunaV 500G ST500LM000 HDD_ASM SSHD-LH 16200385 ST1000LM024 6G 9.5mm 5.4K 1T HDD_ASM 16200067 HGST HTS545050A7E380 HDD_ASM 5400PRM7mm 500G HDD 16200387 ST500LM012 6G 9.5mm 5.4K 500G HDD_ASM 16200375 HTS541010A9E680 6G 9 5.4K 1T...
  • Page 54 M471B5173DB0-YK0 4GB 1600 MEMORY Sodimm 1100967 Mic_R D9QBJ 4GB D3L-1600S MEMORY MEMORY 1100943 M471B1G73DB0-YK0 8GB 1600 MEMORY Sodimm 1100986 HMT41GS6BFR8A-PB 8GB DDR3L MEMORY 1600 Sodimm 1101012 Mic_R D9QBJ ?8GB D3L-1600 MEMORY Sodimm YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 55 1100959 Mic_S D9QBJ? 4GB D3L-1600 MEMORY Sodimm 03T7118 SODIMM,8G,DDR3L,1600 MEMORY 03T7117 SODIMM,4G,DDR3L,1600 MEMORY 1100985 HMT451S6BFR8A-PB 4GB DDR3L MEMORY 1600 Sodimm 1100957 MT8KTF51264HZ-1G6E1 4GB 1600 MEMORY Sodimm 00PC220 ZTM600 2.4G MC BID(No BTY) SLV MOUSE 00PC219 ZTM600 2.4G MC BID(WW) Silver MOUSE 00PC221 ZTM600 2.4G Mouse BID(MY) SLV...
  • Page 56 YOGA HOME 500 All-In-One PC Hardware Maintenance Manual...
  • Page 57: Chapter 10. Additional Service Information

    • Wake Up on Alarm: You can specify a date and time at which the computer will be turned on automatically. This can be either a single event , a daily event or a weekly event. • Wake Up on LAN: This feature allows LAN adapter card to wake the System. © Copyright Lenovo 2015, 2015...
