Summary of Contents for Sharp LC-24LE240E
-
Page 2: Table Of Contents
Contents Features ..............3 Managing Stations: Sorting Channel List ..... 20 Dear SHARP customer ........... 3 On-Screen Information ......... 20 Introduction ............. 3 Media Playback Using Media Browser ....20 Preparation ............. 3 Timeshift Recording ..........23 Instant Recording ..........23 Important safety precautions ........ - Page 3 SPECIAL NOTE FOR USERS IN THE U.K. The mains lead of this product is fi tted with a non-rewireable (moulded) plug incorporating a 5A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked and of the same rating as above, which is also indicated on the pin face of the plug, must be used.
-
Page 4: Features
Dear SHARP customer Features • Remote controlled colour LCD TV. Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years • Fully integrated Terrestrial digital-cable TV (DVB- of trouble-free operation of your product, please read T-C- MPEG2) (DVB-T-C MPEG4). -
Page 5: Important Safety Precautions
Important safety precautions • Cleaning—Unplug the AC cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. • Use a soft damp cloth to gently wipe the panel when it is dirty. To protect the panel, do not use a chemical cloth to clean it. -
Page 6: Safety Precautions
Safety Precautions Lightning In case of storm and lightning or when Read the following recommended safety going on holiday, disconnect the power precautions carefully for your safety. cord from the wall outlet. Power Source Replacement Parts The TV set should be operated only from a 220-240V When replacement parts are required, make sure that AC, 50Hz outlet. - Page 7 LCD Screen • Manufactured under license from Dolby The LCD panel is a very high technology product with Laboratories. about a million thin fi lm transistors, giving you fi ne picture details. Occasionally, a few non-active pixels • The “HD TV 1080p” Logo is a trademark of EICTA. may appear on the screen as a fi...
-
Page 8: Package Contents
Package Contents Environmental Information • This television is designed to consume less energy to save environment. You not only help to save the environment but also you can save money by reducing electricity bills thanks to the energy effi ciency feauture of this TV. To reduce energy consumption, you should take the following steps: •... -
Page 9: Remote Control Buttons
Remote Control Buttons Standby Image size / Zooms videos (in Media Browser video mode) Sleep Timer Mono / Stereo - Dual I-II / Currrent Language (*) (in DVB channels) Favourite Mode Selection (in DVB channels) Numeric buttons Electronic programme guide (in DVB channels) No function Media Browser Navigation buttons (Up/Down/Left/Right) -
Page 10: Lcd Tv And Operating Buttons
LCD TV and Operating Buttons FRONT and REAR VIEW Control buttons VIEW Control Buttons Up direction Down direction Programme/Volume / AV / Standby-On selection switch Note:You can move the switch, upward or downward to change the volume. If you want to change channels, press the middle of the switch once (Position 3) and then move upward or downward. -
Page 11: Viewing The Connections - Side Connectors
Viewing the Connections - Side Connectors CI Slot is used for inserting a CI card. A CI card allows you to view all the channels that you subscribe to. For more information, see “Conditional Access” section. USB Inputs. Note that programme recording feature is available via these USB inputs. You can connect external hard disk drives to this input. -
Page 12: Using Usb Inputs
Using USB Inputs SIDE VIEW USB MEMORY USB Connection • You can connect a USB hard disk drive or USB memory stick to your TV by using the USB inputs of the TV. This feature allows you to play fi les stored in a USB drive or record programmes. -
Page 13: Connecting To A Dvd Player Via Hdmi
• Recordings of HD programmes can occupy bigger Connecting to a DVD Player size on the USB disk depending on the broadcast’s via Component Sockets resolution. For this reason it is recommended to use USB hard disk drives for recording HD (YPbPr) or Scart Cable programmes. -
Page 14: Connecting The Lcd Tv To A Pc
Connecting the LCD TV to a PC Remote Control Handset For displaying your computer’s screen image on your Inserting Batteries LCD TV, you can connect your computer to the TV set. • Remove the battery cover located on the back of Power off both computer and display before making the handset by gently pulling backwards from the any connections. -
Page 15: Input Selection
• If the TV will not be used for a long period i.e. Basic Operations holidays, then unplug the power cord from the You can operate your TV using both the remote mains socket. control and onset buttons. Standby Notifi cations Operation with the Buttons on the TV If the TV switches off while in No Signal mode, the Volume Setting... -
Page 16: Viewing Electronic Programme Guide (Epg)
Green button (Next Time Slice): Displays the Viewing Electronic Programme programmes of the next time slice. Guide (EPG) Yellow button (Prev Day): Displays the programmes of previous day. You can view the electronic programme guide (EPG) to view information about available programmes.To Blue button (Next day): Displays the programmes view the EPG menu please press EPG button on the of the next day. -
Page 17: Programme Options
(RECORD): the TV will start to record the First Time Installation selected progamme. You can press again to stop IMPORTANT: Ensure that the aerial or cable is the recording. connected before switching on the TV for the fi rst Note: Switching to a different broadcast or source is time installation. -
Page 18: Installation
menu. If it is set to “disabled”, Store Mode will not be available after the First Time Installation. Note: If Store Mode is enabled, some features may be affected. • Press OK button on the remote control to continue and the following message will be displayed on the screen: Note: You can press “MENU”... -
Page 19: Manual Tuning
Analogue: Searches and stores analogue stations. Digital Cable Manual Search* Digital Aerial & Analogue: Searches and stores both analogue and aerial DVB stations. Digital Cable & Analogue: Searches and stores both analogue and cable DVB stations. • Whenever you select an automatic search type and press OK button, a confi... -
Page 20: Managing Stations: Channel List
Moving a Channel Managing Stations: Channel • First select the desired channel. Select Move option List in the channel list and press OK button. The TV sorts all stored stations in the Channel List. • Edit Number screen will be displayed. Enter the You can edit this channel list, set favourites or set desired channel number by using the numeric active stations to be listed by using the Channel List... -
Page 21: Managing Stations: Favourites
Managing Stations: Favourites On-Screen Information You can create a list of favourite programmes. You can press “INFO” button to display on-screen information. Details of the station and current • Press “MENU” button to view main menu. Select programme will be displayed on the information Channel List item by using “... - Page 22 You can play music, picture and video fi les from the connected USB memory stick. Use “ ” or “ ” button to select Videos, Photos, Music, Recording Library or Settings. Viewing Videos via USB Yellow: Opens subtitle time correction menu Press SWAP button to switch back to previous...
- Page 23 Previous/Next (Left/Right buttons): Jumps to Play This (OK button): Plays the selected fi le. previous or next fi le on slideshow. Previous/Next (Left/Right buttons): Jumps to Rotate (Up/Down buttons): Rotates the image using previous or next fi le to play. up/down buttons.
-
Page 24: Timeshift Recording
Media Browser Settings See the section, “Recordings” for more information on setting Max. Timeshift. Note: Switching to a different broadcast or source; and viewing main menu are not available during the timeshifting. Lip Sync delay may occur during the timeshifting. Standby button is ignored during the timeshifting. -
Page 25: Watching Recorded Programmes
Watching Recorded Changing Image Size: Picture Formats Programmes • You can change the aspect ratio (image size) of In the main menu, use “ ” or “ ” buttons to select the TV for viewing the picture in different zoom Media Browser. -
Page 26: Confi Guring Picture Settings
14:9 Cinema This zooms up the wide picture (14:9 aspect ratio) to This zooms up the wide picture (16:9 aspect ratio) to the upper and lower limits of the screen. the full screen. Confi guring Picture Settings 14:9 Zoom You can use different picture settings in detail. Press “MENU”... -
Page 27: Pc Picture Settings
Backlight (optional): This setting controls the backlight level and it can be set to Auto, Maximum, Minimum and Medium. Note: Backlight can not be activate in VGA or Media Browser mode or while picture mode is set as Game. Noise Reduction: If the broadcast signal is weak and the picture is noisy, use Noise Reduction setting to reduce the noise amount. -
Page 28: Confi Guring Your Tv's Settings
Equalizer: Press OK button to view equalizer sub- Confi guring Your TV’s Settings menu. Detailed settings can be configured to suit your personal preferences. Press “MENU” button and select Settings ikon by using “ ” or “ ” button. Press OK button to view Settings menu. -
Page 29: Using A Conditional Access Module
Using a Conditional Access Confi guring Language Module Preferences IMPORTANT: Insert or remove the CI module only You can operate the TV’s language settings using when the TV is SWITCHED OFF. this menu. • In order to watch certain digital channels, a conditional Press “MENU”... -
Page 30: Language Settings
Language Settings Note: If the Country option is set to France, you can use 4725 as the default code. After coding the correct PIN number, parental settings menu will be displayed: Parental Settings Menu Operation • Select an item by using “ ”... -
Page 31: Timers
Deleting a Timer Timers • Select the timer you want to delete by pressing “ To view Timers menu, press “MENU” button and ” or “ ” button. select Channel List icon by using “ ” or “ ” button. •... -
Page 32: Confi Guring Date/Time Settings
Note: If the Country option is set to France, you can Confi guring Source Settings use 4725 as the default code. You can enables or disable selected source options. The After you enter the pin, a pop-up menu appears on TV will not switch to the disabled source options when the screen to ensure that the hard disk should be “SOURCE”... -
Page 33: Other Features
Menu Timeout: Changes timeout duration for menu Standby Search (optional): Use “ ” or “ ” button to screens. select Standby Search and then press “ ” or “ ” button to set this setting as On or Off. If you change Standby Scan Encrypted Channels: When this setting is on, Search to Off, this function will be unavailable.To use search process will locate the encrypted channels as... -
Page 34: Teletext
Poor Picture: Have you selected the correct TV Teletext system? Is your TV set or house aerial located too close The teletext system transmits information such as to a non-earthed audio equipment or neon lights, etc.? news, sports and weather on your TV. Note that if the Mountains or high buildings can cause double pictures signal degrades, for example in poor/adverse weather or ghost images. -
Page 35: Appendix A: Pc Input Typical Display Modes
Appendix A: PC Input Typical Appendix B: AV and HDMI Signal Display Modes Compatibility (Input Signal Types) The display has a maximum resolution of 1920 x 1080. Source Supported Signals Available The following table is an illustration of some of the typical video display modes. -
Page 36: Appendix C: Supported Dvi Resolutions
Appendix C: Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI to HDMI cables (not supplied), you can refer to the following resolution information. Index Resolution Frequency 640x400 70Hz 60Hz-66Hz-72Hz 640x480 -75Hz 56Hz-60Hz-70Hz- 800x600 72Hz -75Hz 75 Hz 832x624 60Hz-66Hz-70Hz-... -
Page 37: Appendix D: Supported File Formats For Usb Mode
Appendix D: Supported File Formats for USB Mode File Format Remarks Media Extension Video Audio (Maximum resolution/Bit rate etc.) .mpg, .mpeg MPEG1, 2 MPEG Layer 1/2/3 .dat MPEG1, 2 MPEG2 .vob MPEG2 .mkv H.264, MPEG1,2,4 EAC3 / AC3 MAX 1920x1080 @ 30P 20Mbit/sec MPEG4, Xvid 1.00, Xvid 1.01, Xvid 1.02, .mp4... -
Page 38: Appendix E: Software Upgrade
Appendix E: Software Upgrade • Your TV is capable of fi nding and updating new software upgrades over broadcast channels. • For broadcast channels search, TV looks the available channels stored in your settings. So before software upgrade search, it is advised to auto search and update all available channels. 1) Software upgrade search via user interface •... -
Page 39: Specifi Cations
Digital Reception (DVB-C) Specifi cations TV BROADCASTING Transmission Standards: PAL/SECAM B/G D/K K’ I/I’ L/L’ DVB-C, MPEG2, DVB-C, MPEG4 RECEIVING CHANNELS i. DEMODULATION VHF (BAND I/III) -Symbolrate: 4.0 Msymbols/s to 7.2 Msymbols/s UHF (BAND U) - Modulation: 16-QAM , 32-QAM ,64-QAM, 128-QAM and 256-QAM HYPERBAND ii. -
Page 40: Dimensional Drawings
Dimensional Drawings English - 39 - A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 39 A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 39 15.03.2012 16:27:33 15.03.2012 16:27:33... -
Page 41: End Of Life Disposal
End of life disposal English - 40 - A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 40 A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 40 15.03.2012 16:27:39 15.03.2012 16:27:39... -
Page 42: Installing The Stand
Installing the Stand English - 41 - A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 41 A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 41 15.03.2012 16:27:40 15.03.2012 16:27:40... -
Page 43: Uninstalling The Stand
Uninstalling the Stand English - 42 - A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 42 A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 42 15.03.2012 16:27:40 15.03.2012 16:27:40... -
Page 44: Screw Dimensions
Screw Dimensions Model Item Number VESA Installation of the Screw Ø4 To the wall LC-24LE240E 75 x 75 (W x H) To the product English - 43 - A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 43 A01_MB62_[GB]_1910UK_IDTV_TC_PVR_BRONZE19_24942LED_ROCKER_ZIGGO_10077476_50211339.indd 43 15.03.2012 16:27:51 15.03.2012 16:27:51...
