Specifications

Monitor Specifications
LCD Module
Viewable Image Size: 38.0 cm/15.0 inches
Native Resolution (Pixel Count): 1024 x 768
Input Signal
Display Colours
Synchronization Range
Viewing Angle
Resolutions Supported
Active Display Area
Power Supply
Power Consumption
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Storage Temperature: -10°C to 60°C/14°F to 140°F
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 If your display is not showing a picture of the SOG and Composite Sync. Signal, please contact our hotline for further assistance.
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD1570NX Monitor
Diagonal: 38.0 cm/15.0 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative*
Sync on Green (Video 0.7 Vp-p and Sync. 0.3 Vp-p)*
16,194,277
Horizontal: 31.5 kHz to 60.0 kHz
Vertical: 56.0 Hz to 75.0 Hz
Left/Right: 80°/80° (CR > 5)
Up/Down: 60°/80° (CR > 5)
1
720 x 400*
1
640 x 480*
1
800 x 600*
1
832 x 624*
1024 x 768 at 60 Hz to 75 Hz......................Recommended resolution is 60 Hz for
Horizontal: 304.0 mm/12.0 inches
Vertical: 228.0 mm/9.0 inches
AC 100-240V ~ 50/60Hz
20W (typ)
0.4-0.2A
336.4 mm (W) x 305.0-380.0 mm (H) x 178.0 mm (D)
13.2 inches (W) x 12.0-15.0 inches (H) x 7.0 inches (D)
3.8 kg (8.4 lbs)
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
Humidity: 10% to 85%
Feet: 0 to 40,000 Feet
2
: VGA-Text
at 60 Hz to 75 Hz
at 56 Hz to 75 Hz
at 75 Hz
English-12
Notes
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.297 mm dot
2
pitch; 250 cd/m white luminance;
450:1 contrast ratio, typical.
Digital Input: DVI
2
Depends on display card used.
Automatically
Automatically
Some systems may not support all modes
listed.
optimal display performance.
