S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Installing the Cisco MDS 9100 Series
This chapter describes how to install the Cisco MDS 9100 Series and its components, and it includes the
following information:
Preinstallation, page 2-2
•
•
•
•
•
•
•
Before you install, operate, or service the system, read the Regulatory Compliance and Safety
Note
Information for the Cisco MDS 9000 Family for important safety information.
OL-21514-01
C H A P T E R
Cisco MDS 9100 Series Hardware Installation Guide
2
2-1

Advertisement

loading

Related Manuals for Cisco MDS 9100 Series

Summary of Contents for Cisco MDS 9100 Series

  • Page 1: Table Of Contents

    S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m C H A P T E R Installing the Cisco MDS 9100 Series This chapter describes how to install the Cisco MDS 9100 Series and its components, and it includes the following information: Preinstallation, page 2-2 •...

  • Page 2: Preinstallation

    Only trained and qualified personnel should be allowed to install, replace, or service Warning this equipment. Statement 1030 Each new switch requires a license; see the Cisco MDS 9000 Family NX-OS Licensing Guide for Note instructions on installing a license.
  • Page 3 Avoid UPS types that use ferroresonant technology. These UPS types can become unstable Caution with systems such as the Cisco MDS 9000 Family, which can have substantial current draw fluctuations because of fluctuating data traffic patterns. Cisco MDS 9100 Series Hardware Installation Guide...
  • Page 4 An ESD socket is provided on the chassis. For the ESD socket to be effective, the chassis must be grounded through the power cable, the chassis ground, or the metal-to-metal contact with a grounded rack. Cisco MDS 9100 Series Hardware Installation Guide OL-21514-01...

  • Page 5: Installing The Switch In A Cabinet Or Rack

    • Installing the Switch in a Cabinet or Rack This section describes how to use the rack-mount kit provided with the switch to install the Cisco MDS 9100 Series into a cabinet or rack that meets the requirements described in Appendix A, “Cabinet and...
  • Page 6 S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m The rack-mount kit provided with the switch contains the items listed in Table 2-1. Table 2-1 Cisco MDS 9148, MDS 9134, and Cisco MDS 9124 Fabric Switch Rack-Mount Kit Description Quantity 30- to 36-inch slider rails 2 per kit...
  • Page 7 2-2. If you are using the notched slider rails for the Cisco MDS 9134 or the Cisco MDS 9124 Switch, see Figure 2-3. Depending on when you purchased your Cisco MDS 9124 Switch, you may have straight slider Note rails like those shown in Figure...
  • Page 8 S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m Use the tape measure and level to verify that the rails are horizontal and at the same height. Figure 2-2 Installing the Slider Rails Figure 2-3 Installing the Notched Slider Rails Cisco MDS 9100 Series Hardware Installation Guide OL-21514-01...
  • Page 9 Figure 2-4. If you are using the notched rails, for the Cisco MDS 9148 Switch, Cisco MDS 9134 Switch, or the Cisco MDS 9124 Switch, see Figure 2-5. Align the two C brackets on either side of the switch with the slider rails installed in the rack. Slide the C brackets onto the slider rails, and then gently slide the switch all the way into the rack.
  • Page 10 S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m Figure 2-5 Sliding the Cisco MDS 9148, Cisco MDS 9134 Switch, or the Cisco MDS 9124 Switch onto the Notched Slider Rails...

  • Page 11: Installing The Switch In A Cabinet With Insufficient Front Clearance

    Installing the Switch in a Cabinet with Insufficient Front Clearance This section describes how to use the rack-mount kit provided with the switch to install the Cisco MDS 9100 Series switch into a cabinet with insufficient front-facing clearance. The Cisco MDS 9100 Series switch is installed rear-facing to provide adequate clearance for the fibre-optic cables.
  • Page 12 This rear-facing installation is necessary to ensure that the minimum bend radius for the fiber-optic cables is maintained. In these cabinets, the Cisco MDS 9100 Series switch is mounted backwards, with the fiber-optic cables facing toward the rear of the cabinet and the power supplies facing the front of the cabinet.
  • Page 13 Installing Front Rack-Mount Brackets for Cabinets with 26 Inches or Greater of Rail Spacings The front rack-mount brackets for the Cisco MDS 9100 Series switch must be installed onto the switch prior to installing the switch into the cabinet. Follow these steps for cabinets with front-mounting rail to rear-mounting rail spacings greater or equal to 26 inches.
  • Page 14 Repeat with the other front rack-mount bracket on the other side of the switch. The front rack-mount bracket does not align with all three holes in the Cisco MDS 9100 Series switch Note in this configuration. The two screws are adequate to hold the weight of the Cisco MDS 9100 Series switch.
  • Page 15 Installing Cisco MDS 9100 Series Switch Rear-Facing into Cabinet To install a Cisco MDS 9120 or 9140 Switch rear-facing into a cabinet using the rack-mount kit provided with the switch (for cabinets with insufficient front-facing clearance), follow the steps in this section. If...
  • Page 16 180 degree position. Your front Note rack-mount brackets may look different if you kept them in the normal position. Figure 2-11 Sliding the Cisco MDS 9100 Series Switch (Rear-Facing) onto the Slider Rails Front cabinet mounting rails...
  • Page 17 Cisco MDS 9124 Switch Rear-Facing into Cabinet To install a Cisco MDS 9134 Switch, Cisco MDS 9134 Switch, or a Cisco MDS 9124 Switch rear-facing into a cabinet using the rack-mount kit provided with the switch (for cabinets with insufficient...
  • Page 18 S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m When installing the Cisco MDS 9148 Switch, Cisco MDS 9134 Switch or the Cisco MDS 9124 Note Switch rear-facing into a cabinet, do not install it higher than RU-30.
  • Page 19 Using both hands, position the switch with the back of the switch between the rear rack-mounting rails as shown in Figure 2-14. Figure 2-14 Sliding a Cisco MDS 9134, Cisco MDS 9134 Switch, or the Cisco MDS 9124 Switch (Rear-Facing) on the Notched Slider Rails Rear cabinet mounting rails...
  • Page 20 S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m Figure 2-15 Correct Position of Power Cord Routed Through Notched Slider Rail Figure 2-16 Incorrect Position of Power Cord Routed Over the Notched Slider Rail Cisco MDS 9100 Series Hardware Installation Guide 2-20 OL-21514-01...

  • Page 21: Installing Cisco Mds 9134 48-Port And 64-Port Bundles

    Installing Cisco MDS 9134 48-Port and 64-Port Bundles To install multiple Cisco MDS 9134 Switches to expand up to 48 ports and up to 64 ports, follow these steps: Ensure that the boxes that are received each consist of a Cisco MDS 9134 Switch with a 10-Gbps Step 1 transceiver plugged in and a copper cable.
  • Page 22 Installing the Cisco MDS 9100 Series Installing Cisco MDS 9134 48-Port and 64-Port Bundles S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m In both types of above-mentioned switch configurations, the distance between the 10-Gbps ports of the switches can be a maximum of 1 meter.

  • Page 23: Grounding The Switch

    A grounding pad with two threaded M4 holes is provided on the chassis for attaching a grounding lug. Figure 2-19 shows the system ground location on the Cisco MDS 9100 Series. Figure 2-19 Location of Switch Ground on the Cisco MDS 9100 Series...

  • Page 24: Starting Up The Switch

    Depending on the outlet receptacle on your power distribution unit, you may need the optional Note jumper power cord to connect the Cisco MDS 9100 Series switch to your outlet receptacle. See “Jumper Power Cord” section on page C-6.

  • Page 25: Removing And Installing Components

    Verify that the system software has booted and the switch has initialized without error messages. If any Step 9 problems occur, see the Cisco MDS 9000 Family Troubleshooting Guide or the Cisco MDS 9000 Family System Messages Guide. If you cannot resolve an issue, contact your customer service representative.
  • Page 26 During this procedure, wear grounding wrist straps to avoid ESD damage to the switch. Caution Except for the Cisco MDS 9124 switch, all the the other Cisco MDS 9100 Series switches are supported Note for operation with both power supplies and both fan modules installed, and with all fans working.
  • Page 27 S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m Figure 2-21 Rear View of the Cisco MDS 9134 Switch Power...
  • Page 28 Fixed fans For the Cisco MDS 9140 Switch and the Cisco MDS 9120 Switch, the fans should not be removed for prolonged periods of time during operation. If one fan module fails, a single healthy fan module can temporarily provide sufficient cooling to maintain switch operation under normal conditions, but the failed fan module should be replaced as soon as possible.
  • Page 29 This section provides instructions for removing and installing the AC power supplies for the Cisco MDS 9100 Series switches. Power supplies for the Cisco 9100 Series switches look similar but they differ slightly. Be sure to use Caution the correct power supply designated for your Cisco 9100 Series switch. Using an incorrect power supply will not provide redundant power in the case of a power supply failure.
  • Page 30 This section provides instructions for removing and installing the DC power supplies for the Cisco MDS 9100 Series switch. The new DC power supply is not supported on the Cisco MDS 9140 Switch, Cisco MDS 9148 Switch, Note and the Cisco MDS 9120 Switch.
  • Page 31 S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m Power supplies for the Cisco 9100 Series switches look similar but they differ slightly. Be sure to use Caution the correct power supply designated for your Cisco 9100 Series switch.
  • Page 32 Cisco MDS 9000 Family will be shut down after five minutes to prevent potentially undetectable overheating. However, the switches will shut down sooner if the higher-level temperature threshold is exceeded.
  • Page 33 Slide the seating tabs toward the center of the fan module. Step 2 Grasp the fan module handle and pull it outward. Step 3 Pull the fan module out of the switch and put it in a safe place. Step 4 Cisco MDS 9100 Series Hardware Installation Guide 2-33 OL-21514-01...
  • Page 34 Figure 2-27 Cisco MDS 9148 and MDS 9134 Fan Module Although the fan modules for the Cisco MDS 9134 and Cisco MDS 9148 switches appear to be similar, Caution there is a difference between the two with their airflow directions. The airflow for MDS 9134 is from front to back where as the airflow for the MDS 9148 is from back to front.
  • Page 35 Step 3 operate or you experience trouble with the installation. If you purchased this product through a Cisco reseller, contact the reseller directly for technical support. Note If you purchased this product directly from Cisco, contact Cisco Technical Support at this URL: http://www.cisco.com/en/US/support/tsd_cisco_worldwide_contacts.html...
  • Page 36 S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m Cisco MDS 9100 Series Hardware Installation Guide...
