SERVICE MANUAL
MODEL
KLV-V26A10E
KLV-V32A10E
RM-EA001
All manuals and user guides at all-guides.com
COMMANDER
DEST
RM-EA001
AEP
RM-EA001
AEP
KLV-V26A10E / KLV-V32A10E
KDL-V26A12U / KDL-V32A12U
- 1 -
AT2X
MODEL
KDL-V26A12U
KDL-V32A12U
FLAT PANEL COLOR TV
AT2X
RM-EA001 / RM-ED001
CHASSIS
COMMANDER
DEST
RM-ED001
UK
RM-ED001
UK
RM-ED001

Advertisement

Table of Contents
loading

Related Manuals for Sony KLV-V26A10E

Summary of Contents for Sony KLV-V26A10E

  • Page 1 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 AT2X SERVICE MANUAL CHASSIS MODEL MODEL COMMANDER DEST COMMANDER DEST KLV-V26A10E KDL-V26A12U RM-EA001 RM-ED001 KLV-V32A10E KDL-V32A12U RM-EA001 RM-ED001 RM-EA001 KLV-V26A10E / KLV-V32A10E KDL-V26A12U / KDL-V32A12U RM-ED001 FLAT PANEL COLOR TV - 1 -...

  • Page 2: Table Of Contents

    THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE Temperature “Neutral” ........PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART 3-3-3. White Balance of Colour NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN Temperature “Warm”...

  • Page 3: Caution

    Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com - 3 -...

  • Page 4: Specifications

    All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 . s l . s l . s l e i l . s l l a i i g i i n i i n i - 4 -...
  • Page 5 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 & & y t i WARNING (UK Models only) The flexible mains lead is supplied connected to a B.S. 1363 fused plug having a fuse of 13 AMP rating. Should the fuse need to be replaced, use a 13AMP FUSE approved by ASTA to BS 1362, ie one that carries the mark.

  • Page 6: Connectors

    All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 21 pin connector Pin No Signal Signal level Audio output B Standard level : 0.5V rms (right) Output impedence : Less than 1kohm* Audio input B Standard level : 0.5V rms (right) Output impedence : More than 10kohm* Audio output A...

  • Page 7: Self Diagnosis

    All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 AT2X SELF DIAGNOSTIC SOFTWARE The identification of errors within the AT2X chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the event of one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous flashing LED) and then communicate with each device in turn to establish if a device is faulty.

  • Page 8: General

    All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 SECTION 1 GENERAL – 8 –...
  • Page 9 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 – 9 –...
  • Page 10 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 – 10 –...
  • Page 11 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 – 11 –...
  • Page 12 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 – 12 –...
  • Page 13 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 – 13 –...
  • Page 14 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 – 14 –...
  • Page 15 All manuals and user guides at all-guides.com AT2X RM-EA001 / RM-ED001 – 15 –...

  • Page 16: Rear Cover Removal

    All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 SECTION 2 DISASSEMBLY 2-1. REAR COVER REMOVAL 2-2. BRACKET REMOVAL – 16 –...

  • Page 17: Loudspeaker Removal

    All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 2-3. LOUDSPEAKER REMOVAL 2-4. A1 BOARD REMOVAL (KLV-V26A10E/KDL-V26A12U) A2 BOARD REMOVAL (KLV-V32A10E/KDL-V32A12U) – 17 –...

  • Page 18: G2 Board Removal

    All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 2-5. G2 BOARD REMOVAL 2-6. H7 BOARD REMOVAL – 18 –...

  • Page 19: H8 Board Removal

    All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 2-7. H8 BOARD REMOVAL 2-8. BL, N and NP1 BOARD REMOVAL – 19 –...

  • Page 20: H6 Board Removal

    All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 2-9. H6 BOARD REMOVAL – 20 –...

  • Page 21: Service Position

    Remove the NP1, BL and N boards (See 2-8.) Remove the A1board (KLV-V26A10E/KDL-V26A12U) or the A2 board (KLV-V32A10E/KDL-V32A12U) (See 2-4.) Re-fit the foot to the TV set and place the set back in a vertical position. Place a support of approx 35cm high as close as possible to the TV set as shown below.
  • Page 22 All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 The boards are now arranged properly in the service position. If access is required to the underside of the A1 board then an interface (IF) board is needed. IF Board Side A IF Board Side B IF Board Part Number: 9-948-020-71 Using the IF board the A1 board can the be mounted vertically as shown in the picture below.

  • Page 23: Set-Up Adjustments

    All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 SECTION 3 SET-UP ADJUSTMENTS 3-2-2. Y signal AD calibration of CCPX decode. 3-1. How to enter Service Mode (Also see 3-2-2(a)) Service adjustments to this model can be performed using the 1.

  • Page 24: Check Ad (Component Case) Calibration Registration Items

    All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 3-2-4. Check AD (Component case) calibration 8. Input red full field with burst. 9. Send “READ_PW_INPUT_CR” command from ECS. registration items.(Also see 3-2-4(a)) 10. Check that the detection value of “PW_INPUT_CR” is within 1.

  • Page 25: White Balance Of Colour Temperature "Neutral

    All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 6. Input 20 IRE SPECIAL gray full field signal into video input. 6. Input 20 IRE SPECIAL gray full field signal into video input. 7. Adjust R_BKG and B_BKG until getting low light 7.

  • Page 26: Panel Replacement

    When replacing the BL board please readjust the W/B (See page 24) and readjust the ADC (See page 23). 3-5-3. A1 or A2 BOARD REPLACEMENT When replacing the A1(KLV-V26A10E/KDL-V26A12U) or A2(KLV-V32A10E/KDL-V32A12U) board please readjust the ADC (See page 23). - 26 -...
  • Page 27 All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 3-2(a). ADJUSTMENT OF SIGNAL LEVEL 3-2-1(a). Check AD calibration registration items (1) Select AV1 and input PAL signal and change picture mode to 1(Custom). 3-2-3(a). C signal AD calibration of CCPX decode (2) GO TO service mode and press "...
  • Page 28 All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 3-2-4(a). Check AD calibration registration items (1) Select AV6 and input component 576i signal and change picture mode to 1(Custom). 3-2-6(a). C signal AD calibration of componet input (2) GO TO service mode and press " MENU". (1) Input 0 IRE black full field with burst.
  • Page 29 All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 3-3(a). WHITE BALANCE ADJUSTMENT (ALL AT2X except PDP W50) SService Menu SService Menu 3-3-1(a). White balance of Color temperature “Cool” White Balance Model/Version/ETI info. (1) White balance of Colour tone "Cool". Aging mode CONTRAST: ----------|----------...
  • Page 30 All manuals and user guides at all-guides.com AT2X RM-EA001/RM-ED001 7) Do "Color Save". SService Menu SService Menu SService Menu White Balance Adj. White Balance Adj. Model/Version/ETI info. Aging mode COLOR_TONE: 0(Cool) COLOR_TONE: 0(Cool) A/D Converter (Y signal) R_DRIVE: ----------|---------- R_DRIVE: ----------|---------- A/D Converter (C signal) G_DRIVE...

  • Page 31: Block Diagrams (1)

    All manuals and user guides at all-guides.com 4-1. BLOCK DIAGRAMS (1) CN4801 REGULATORS, AUDIO PROCESSOR, HEADPHONE, AUDIO OUT, MAIN PROCESSOR, TUNER, YC IN, SWITCH SCARTS, AUDIO, VIDEO, VIDEO PROCESSING Q4601 (ANALOGUE) P-TXD SWITCH Q4602 P-RXD CN4601 TO BL R-RES BOARD AV1-R-OUT R OUT B-INT...

  • Page 32: Block Diagrams (2)

    All manuals and user guides at all-guides.com 4-1. BLOCK DIAGRAMS (2) CN4801 REGULATORS, AUDIO PROCESSOR, HEADPHONE, AUDIO OUT, MAIN PROCESSOR, TUNER, YC IN, SWITCH SCARTS, AUDIO, VIDEO, VIDEO PROCESSING Q4601 (DIGITAL) P-TXD SWITCH Q4602 P-RXD CN4601 TO BL R-RES BOARD AV1-R-OUT R OUT B-INT...

  • Page 33: Block Diagrams (3)

    All manuals and user guides at all-guides.com 4-1. BLOCK DIAGRAMS (3) CN4801 REGULATORS, AUDIO PROCESSOR, HEADPHONE, AUDIO OUT, MAIN PROCESSOR, TUNER, YC IN, P-TXD SCARTS, AUDIO, VIDEO, VIDEO PROCESSING P-RXD (ANALOGUE) TO BL BOARD P-RES LINE MUTE CN1008 B-INT RGB(SW) CN4601 AV1-R-OUT R OUT...

  • Page 34: Block Diagrams (4)

    All manuals and user guides at all-guides.com 4-1. BLOCK DIAGRAMS (4) CN4801 IC4804 REGULATORS, AUDIO PROCESSOR, HEADPHONE, MULTIPLEXER/DEMULTIPLEXER AUDIO OUT, MAIN PROCESSOR, TUNER, YC IN, YS-TXT BLK3 P-TXD SCARTS, AUDIO, VIDEO, VIDEO PROCESSING P-RXD (DIGITAL) FSW-AUTO BLK2 TO BL BOARD P-RES LINE MUTE AV-FAB...

  • Page 35: Block Diagrams (5)

    All manuals and user guides at all-guides.com 4-1. BLOCK DIAGRAMS (5) T6100 D6200 DIODE CN6202 17.5V D6200 DIODE 17.5V L6502 17.5V INDUCTOR PANEL IC6502 IC6100 T6101 17.5V ACTIVE PFC SWITCHING 17.5V CONTROL CONTROL Q6502 Q6501 D6200 ZCD OUT SWITCH SWITCH DIODE Q6100 SWITCH...

  • Page 36: Block Diagrams (6)

    All manuals and user guides at all-guides.com 4-1. BLOCK DIAGRAMS (6) DIGITAL MODELS ONLY SVD_MODEM SWITCH Q3504 IC3504 IC3309 IC3306 DTE_RXD nPC-EN nPC-EN IN_TS_BCLK SMC_RXD DTE_TXD IN_TS_PSYNC MDI(7) RADD(25) SMC_TXD DTE_RTS IN_TS_PVAL MDI(6) RADD(24) MDO(7) +5VD-CI nFE_RST DTE_CTS CN3500 IC3303 IC3501 SMART IN_TSD(0)

  • Page 37: Block Diagrams (7)

    All manuals and user guides at all-guides.com 4-1. BLOCK DIAGRAMS (7) 4-2. CIRCUIT BOARD LOCATION 5-2. CIRCUIT BOARD LOCATION Reference Information A1 (26 inch) RESISTOR : METAL FILM A2 (32 inch) : SOLID DIGITAL MODELS ONLY FPRD : NON FLAMMABLE CARBON IC3805 FUSE : NON FLAMMABLE FUSIBLE...

  • Page 38: A1 Board Schematic Diagram(26 Inch Only)

    All manuals and user guides at all-guides.com A1.-AT2X L4001 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL 4.7uH C4008 C4009 PS4001 C4025 R4023 6800p 1/10W R4034 R4014 CHIP 1/10W R4024 R4027 2.4k 1/10W 1/10W R4019 R7621 Q4001 2.7k IC4003 R4041 C4028...
  • Page 39 All manuals and user guides at all-guides.com A1.-AT2X COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL JL7701 R7719 JL7702 JL7704 2/7 AUDIO PROCESSOR, HEADPHONE, AUDIO OUT R7720 JL7703 C4315 R4320 R4327 R4332 1/10W R7721 1/10W 1/10W R4334 1.2k C4322 R7722 R4335...
  • Page 40 All manuals and user guides at all-guides.com A1.-AT2X PAINTER II GROUND ISOLATION STBY5V STBY3.3V FB4402 FB4401 STBY5V L7604 C4409 C4405 R4405 0 470p C4430 0.22 R7600 D4401 Q4402 MA111-TX MUN2111T1 IC4402 C4431 R7601 C4407 R4438 M24C16-WMN6T(B) 0.22 4.7k IC4401 R7602 L4401 BA33BC0FP-E2 L7605...
  • Page 41 All manuals and user guides at all-guides.com TU7650 TUNER BLOCK TO RF SPLITTER BOARD CN901 L7655 10uH C7667 D7656 CN5107 C7652 R7653 C7660 C7665 C7669 6.3V R7670 C7693 C7651 1/10W R7659 FB7652 R7669 TUNER_VID R7650 D7650 1/10W R7662 R7671 Q7652 MSB709-RT1 1/4W L7653...
  • Page 42 All manuals and user guides at all-guides.com A1.-AT2X SCART 2 (AV2) SCART 1 (AV1) RGB1 RGB2 008:7G FROM P board (HDMI) R4658 D7514 C4618 R4608 UDZS-TE17-12B 1/10W AV2_R_OUT 1/10W AV1_R_OUT C4642 C4637 C4650 CN4606 R4665 FB7509 C4601 C4608 R4617 D7516 1/10W UDZS-TE17-12B 1/10W...
  • Page 43 All manuals and user guides at all-guides.com A1.-AT2X (SCART1) AV SWITCH 6/7 AUDIO & VIDEO (FRONT) L5203 10uH (SCART2) C5215 C7618 R5239 Q5208 C7602 C5208 C7601 C7600 C5205 C5206 2SC1623-L5L6 0.47 0.47 0.47 0.47 0.47 CHIP 0.47 TUNER_VID R5238 CHIP R5245 C5224 CHIP...
  • Page 44 All manuals and user guides at all-guides.com A1.-AT2X FBLK/RGB1/RGB2 SWITCH L7611 IC4006 C7561 C7562 R7572 RGB2 BA50BC0FP-E2 C7560 1/10W RGB1 U6.5V R7571 C4040 R7570 C4046 CHIP AV_FB C4042 C7630 Q7507 2SA1226-T1E3E4 R4897 COMP 1/10W C4842 L7656 RGB_SW0 R4881 10uH CCP_Y RGB_SW1 R4878 R4898...

  • Page 45: A1 Board Printed Wiring Board

    All manuals and user guides at all-guides.com ~ A1 Printed Wiring Board Conductor Side A ~ ~ A1 Board Semiconductor Location Table Side A ~ ~ A1 Board Difference Table ~ KDL-V26A12U KLV-V26A10E C5222 0.1UF 10.00% 16V NOT FITTED C7619 2.2UF 10.00% 10V...
  • Page 46 All manuals and user guides at all-guides.com ~ A1 Printed Wiring Board Conductor Side B ~ ~ A1 Board Semiconductor Location Table Side B ~ - 46 -...

  • Page 47: A2 Board Schematic Diagram(32 Inch Only)

    All manuals and user guides at all-guides.com A2.-AT2X C4008 L4001 C4009 PS4001 4.7uH C4025 R4023 6800p R4034 R4014 CHIP 1/10W R4027 R4024 2.4k 1/10W 1/10W R4019 Q4001 2.7k R4041 IC4003 IRF7335D1-TR 1/10W SN105233DBTR C4028 CHIP D4003 PTZ-TE25-3.9B C4017 INV1 R4039 3300p D3.3V 1/10W...
  • Page 48 All manuals and user guides at all-guides.com A2.-AT2X C4330 R4332 C4315 R4320 C4310 R4327 R4306 C4306 1/10W R4334 1.2k VD4301 VD4302 VD4303 R4318 CHIP 4.7k C4322 R4335 1.5k 2/7 AUDIO PROCESSOR, HEADPHONE, AUDIO OUT R4336 1.5k Q4302 R4337 1.2k R4338 1.5k C4320 HP_R...
  • Page 49 All manuals and user guides at all-guides.com A2.-AT2X ABK15 PA12 ABK16 A17-LN STBY5V STBY3.3V L4407 STBY5V STBY3.3V C4409 10UH FB4401 C4430 C4431 0.22 D4401 MA111-TX C4405 IC4402 C4407 R4438 470p M24C16-WMN6T(B) 0.22 4.7k 1/10W L4401 C4404 22uH L4408 Q4402 R4490 10UH 6.3V MUN2111T1...
  • Page 50 All manuals and user guides at all-guides.com A2.-AT2X TU4920 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL D4922 R4920 R5130 JL5167 A2(4/7) Board Waveform TO WOOFER TO SPLITER C4933 V-Digital C4934 L4924 C4942 10uH 1000p R4936 R5131 C4927 JL5168 FB4923 CN5109...
  • Page 51 All manuals and user guides at all-guides.com A2.-AT2X RGB1 RGB2 5/7 YC IN, SCARTS RGB3 D4624 UDZSTE-179.1B C4618 C4677 R4608 C4650 R4699 D4607 D4637 R4658 Q4603 UDZSTE-179.1B 1/10W UDZSTE-179.1B 1/10W AV3_R_OUT AV2_R_OUT C4601 C4608 C4637 C4664 C4669 R4705 AV1_R_OUT C4642 R4617 R4665 Q4605...
  • Page 52 All manuals and user guides at all-guides.com A2.-AT2X (SCART1) 6/7 AUDIO & VIDEO (RCA) A2(6/7) Board Waveforms (SCART3) (10us/div) (10us/div) (10us/div) (SCART2) L5205 C5222 C5221 C5207 C5206 C5208 C5205 6.3V R5232 Q5204 CVBS_SUB 305mVp-p (H) 500mVp-p (H) 710mVp-p (H) R5214 R5229 R5222 R5215...
  • Page 53 All manuals and user guides at all-guides.com A2.-AT2X RGB1 A2(7/7) Board Waveforms BLK1 C4805 (20us/div) (20us/div) (20us/div) RGB2 C4801 7/7 VIDEO PROCESSING C4802 L4805 10uH BLK2 C4806 10 C4814 C4803 C4842 COMP L4806 10uH C4804 20mVp-p (H) 405mVp-p (H) 72.5mVp-p (H) CCP_Y C4871 C4872...

  • Page 54: A2 Board Printed Wiring Board

    All manuals and user guides at all-guides.com ~ A2 Board Semiconductor Location Table Side A ~ ~ A2 Printed Wiring Board Conductor Side A ~ ~ A2 Board Semiconductor Voltage Table Side A ~ - 54 -...
  • Page 55 All manuals and user guides at all-guides.com ~ A2 Board IC Voltage Table ~ ~ A2 Board Difference Table ~ KDL-V32A12U KLV-V32A10E C4810 10UF 20.00% 16V NOT FITTED C4812 10UF 20.00% 16V NOT FITTED C4813 10UF 20.00% 16V NOT FITTED C4847 10UF 20.00% 16V NOT FITTED...
  • Page 56 All manuals and user guides at all-guides.com ~ A2 Board Semiconductor Location Table Side B ~ ~ A2 Printed Wiring Board Conductor Side B ~ - 56 -...

  • Page 57: G2 Board Schematic Diagram

    All manuals and user guides at all-guides.com G2.-AT2X D6205 10ERB20-TB3 Mount Mecha A6007 234990011 D6000 Mount Mecha A6003 234990011 Q6500 C6216 C6203 Mount Mecha A6004 234989201 Q6100,Q6101 100V D6204 T6100 R6208 0.47 10ERB20-TB3 L6500 1/4W R6516 110uH C6011 FPRD C6501 220k R6015 1/10W...

  • Page 58: G2 Board Printed Wiring Board

    All manuals and user guides at all-guides.com ~ G2 Printed Wiring Board Conductor Side A ~ ~ G2 Board Semiconductor Location Table Side A ~ - 58 -...
  • Page 59 All manuals and user guides at all-guides.com ~ G2 Printed Wiring Board Conductor Side B ~ ~ G2 Board Semiconductor Location Table Side B ~ - 59 -...

  • Page 60: N Board Schematic Diagram(Digital Only)

    All manuals and user guides at all-guides.com N.-AT2X NAND_ALE,NAND_CLE,NAND_RBB +3V3D_STRAPS +3V3D FB3100 THESE CAPACITORS TO BE PLACED UNDERNEATH BGA C3106 C3109 C3112 C3115 C3119 C3100 C3103 +2V5D_DDR +2V5D FB3101 THESE CAPACITORS TO BE PLACED UNDERNEATH BGA C3113 C3116 C3120 C3104 C3107 C3110 BOARD VERSION RESISTORS - MOUNT ON...
  • Page 61 All manuals and user guides at all-guides.com N.-AT2X +3V3D +2V5D_DDR PLACE CLOSE PLACE CLOSE TO PIN 1 TO PIN 33 PLACE THESE CAPACITORS CLOSE TO IC PINS. C3208 C3205 FB3202 C3206 NAND FLASH C3219 C3220 C3202 C3203 C3207 C3210 C3211 C3212 6.3V C3209...
  • Page 62 All manuals and user guides at all-guides.com TO PCMCIA CARD CN3300 N.-AT2X +3V3D_31 +5VD_CI Mount Mecha A3300 181564021 FB3301 +3V3D +3V3D_31 FB3300 C3307 C3324 R3303 IC3311 C3315 74LVT245PW-T 1/16W C3300 C3301 C3818 C3320 D[15:8] nCI_WAIT VS1B CD2B CD1B TS_BCLK, IREQB TP_SYNC, nCI_EN INPACKB...
  • Page 63 CN3402 C3450 R3442 R3461 ALL R’S R3426 +33V 0.5% +5VD +3V3D R3402 SCL_TV C3402 C3401 R3413 SDA_TV TO A1 BOARD (KDL-V26A12U/KLV-V26A10E) R3423 R3431 IC3402 CN5105 LM3526MX-H/J5000396 1/16W 1/16W TO A2 BOARD (KDL-V32A12U/KLV-V32A10E) R3410 CN5105 CI_PWR_EN +5VD_CI OUTA Q3401 2SA2029T2LQ/R R3408...
  • Page 64 All manuals and user guides at all-guides.com N.-AT2X SMARTCARD AND MODEM +3V3D_MODEM JL3500 3 MM +3V3D_MODEM +3V3D SMC/MODEM Connector M_V+ R3514 JL3529 2.2k CN3500 3 MM FB3523 CHIP M_GND PIN 1 : GND PIN 2 : nSMC_INT nMODEM_EN FB3500 PIN 3 : DTE-CTS +3V3D_MODEM C3507 PIN 4 : DTE-RTS...
  • Page 65 All manuals and user guides at all-guides.com N.-AT2X +3V3D_STRAPS +5VD +3V3D_STRAPS PINOUT DIFFERENT DUE TO MACRO CHANGE TO MACRO CODE - CNN984OR1K (EMCS) +3V3D FIT FOR R3630 FIT FOR EJTAG R3632 R3634 R3636 JTAG FWEB FWEB R3629 TESTPIN FOEB CN3603 TMODE2 FOEB TMODE0...
  • Page 66 All manuals and user guides at all-guides.com N.-AT2X +3V3D FB3801 +3V3D C3809 C3810 R3800 RESET SIGNAL GENERATION D3800 1PS184-115 1/16W C3801 R3839 R3827 nDAMON_RST IC3805 74LVC08APW R3801 IC3800 C3802 1/16W R3832 PST3629UL 1/16W nMASTER_RESET nCI_EN R3803 nPC_EN C3800 +3V3D nCIPC_EN +3V3D nSW_FE_RESET nCI_WAIT...

  • Page 67: N Board Printed Wiring Board

    All manuals and user guides at all-guides.com ~ N Printed Wiring Board Conductor Side A ~ ~ N Board Semi- ~ N Printed Wiring Board Conductor Side B ~ ~ N Board Semi- conductor Location conductor Location Table Side A ~ Table Side B ~ ~ N Board IC Voltage Table ~ - 67 -...

  • Page 68: H6 Board Schematic Diagram

    R7078 Q7040 100p D7069 D7070 R7045 R7048 R7046 CHIP 1/10W MM3Z6V8T1 MM3Z6V8T1 C7040 1/10W C7041 C7043 D7067 TO A1 BOARD (KDL-V26A12U/KLV-V26A10E) D7040 C7073 S_DET CN4605 0.47 R7047 R7077 C7042 CN7060 1/10W R7070 R7072 VD7062 R7079 R7080 TO A2 BOARD (KDL-V32A12U/KLV-V32A10E)

  • Page 69: H6 Board Printed Wiring Board

    All manuals and user guides at all-guides.com ~ H6 Printed Wiring Board Conductor Side A ~ ~ H6 Printed Wiring Board Conductor Side B ~ ~ H7 Printed Wiring Board Conductor Side A ~ ~ H7 Printed Wiring Board Conductor Side B ~ ~ H8 Printed Wiring Board Conductor Side A ~ ~ H8 Printed Wiring Board Conductor Side B ~ - 69 -...

  • Page 70: Np1 Board Schematic Diagram

    C5806 CN5801 R5605 R5694 R5695 C5603 R5739 Q5603 * R5624 CHIP R5686 CHIP D5710 R5772 R5773 Q5711 TO A1 BOARD (KDL-V26A12U/KLV-V26A10E) R5741 L5625 CN4002 CHIP R5774 TO A2 BOARD (KDL-V32A12U/KLV-V32A10E) FB5815 R5742 PS_PROT C5711 R5771 C5616 C5824 C5628 C5625 CN4002...

  • Page 71: Np1 Board Printed Wiring Board

    All manuals and user guides at all-guides.com ~ NP1 Printed Wiring Board Conductor Side A ~ ~ NP1 Board Difference Table ~ KDL-V26A12U KLV-V26A10E KDL-V26A12U KLV-V26A10E KDL-V32A12U KLV-V32A10E KDL-V32A12U KLV-V32A10E C5601 2.2UF 10% 6.3V NOT FITTED FB5810 NOT FITTED C5602 2.2UF 10% 6.3V...

  • Page 72: Semiconductors

    All manuals and user guides at all-guides.com 4-4. SEMICONDUCTORS SDA5550M-QB-T MC74LVX8053DTR2 PQ1CY1032ZP 74LVC00-PW CXA2163AQ-T6 LM3526MX-H/J5000396 PQ1CZ41H2ZPH 74LVC08APW 74LVC14APW 74LVC273PW 74LVC32A-PW 74LVC541APW MM1431ATT PST3629UL 74LVT245PW CXD9841M LM393DT (A) SN74LVC14APWR MSP4411K-QA-D5-001 PST600IMT BA09CC0WFP-E2 FA5501N-TE1 LM75CIMX-3 BA09FP-E2 BA18BC0FP-E2 BA25BC0FP-E2 SOCKET, IC RC4558PWR NJM2904M BA7046F K6F2008V2E-LF70000 M24128-BWMN6T(A)

  • Page 73: Exploded Views

    2-581-415-12 ORNAMENTAL PANEL(32)(KDL-V32A12U) *A-1090-222-A H7 BOARD, COMPLETE 2-581-415-12 ORNAMENTAL PANEL(32)(KLV-V32A10E) 2-581-349-03 GUIDE, LIGHT 2-581-411-11 ORNAMENTAL PANEL(26)(KDL-V26A12U) *A-1090-221-A H6 BOARD, COMPLETE 2-581-411-11 ORNAMENTAL PANEL(26)(KLV-V26A10E) 2-581-348-02 BUTTON, MULTI 2-581-410-01 SPEAKER GRILLE(26)(KLV-V26A10E/KDL-V26A12U) 2-581-344-13 BRACKET, MULTI BUTTON 2-581-414-02 NET, SPEAKER (32)(KLV-V32A10E/KDL-V32A12U) A-1128-520-A PANEL COMPLETE 26...

  • Page 74: Display

    All manuals and user guides at all-guides.com 5-2. DISPLAY REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK - 74 -...
  • Page 75 All manuals and user guides at all-guides.com 5-2. DISPLAY (Continued) 2-581-343-11 COVER, DIGITAL TERMINAL *A-1106-557-A A1 BOARD, COMPLETE (ANALOGUE)(KLV-V26A10E) £ 1-819-554-11 AC INLET (WITH NOISE FILTER) *A-1106-556-A A1 BOARD, COMPLETE (DIGITAL)(KDL-V26A12U) (KLV-V26A10E/KDL-V26A12U) *A-1101-816-D A2 BOARD, COMPLETE (ANALOGUE)(KLV-V32A10E) £ 1-818-098-21 AC INLET (WITH NOISE FILTER)

  • Page 76: Electrical Parts List

    NP1 BOARD COMMON Parts List : Parts common to all models listed in this manual ....Model Parts that belong only to the model specified KLV-V26A10E & KLV-V32A10E ....................99 KDL-V26A12U & KDL-V32A12U ....................100 A2 BOARD COMMON Parts List : Parts common to all V32 models listed in this manual ....
  • Page 77 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK *A-1101-788-B N Board, Complete C3204 1-164-846-11 CERAMIC CHIP 6PF 0.50PF 50V KDL-V26A12U/KDL-V32A12U only C3205 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3206 1-165-908-11 CERAMIC CHIP 1UF 2-580-625-01 SCREW, +B M2X8 C3207...
  • Page 78 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C3411 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3521 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3412 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3522 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3413 1-126-206-11...
  • Page 79 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C3806 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V FB3404 1-469-869-21 FERRITE C3807 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V FB3405 1-469-869-21 FERRITE C3808 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V FB3406 1-469-869-21...
  • Page 80 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK IC3309 8-759-644-48 IC 74LVC541APW Q3801 8-729-027-43 TRANSISTOR DTC114EKA-T146 IC3310 8-759-644-48 IC 74LVC541APW Q3804 8-729-027-43 TRANSISTOR DTC114EKA-T146 IC3311 8-759-298-90 IC 74LVT245PW Q3805 8-729-027-43 TRANSISTOR DTC114EKA-T146 IC3312 8-759-644-48 IC 74LVC541APW Q3806...
  • Page 81 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R3152 1-218-937-11 RES-CHIP 1/16W R3406 1-218-990-81 SHORT CHIP R3156 1-218-937-11 RES-CHIP 1/16W R3408 1-218-966-11 RES-CHIP 1/16W R3157 1-218-965-11 RES-CHIP 1/16W R3409 1-218-967-11 RES-CHIP 1/16W R3160 1-218-937-11 RES-CHIP 1/16W...
  • Page 82 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R3457 1-208-675-11 METAL CHIP 0.5% 1/16W R3564 1-218-941-81 RES-CHIP 1/16W R3458 1-208-885-11 METAL CHIP 0.5% 1/16W R3565 1-218-941-81 RES-CHIP 1/16W R3459 1-218-949-11 RES-CHIP 1/16W R3566 1-218-989-11 RES-CHIP 1/16W...
  • Page 83 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R3827 1-218-953-11 RES-CHIP 1/16W RB3203 1-234-702-11 RES, NETWORK 68 (1005X4) R3828 1-218-941-81 RES-CHIP 1/16W RB3204 1-234-702-11 RES, NETWORK 68 (1005X4) R3830 1-218-941-81 RES-CHIP 1/16W RB3206 1-234-372-21 RES, NETWORK 100 (1005X4)
  • Page 84 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C6213 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V D6104 6-501-043-01 DIODE UMZ16NT106 C6216 1-107-928-11 ELECT 4.7UF 100V D6105 6-501-043-01 DIODE UMZ16NT106 C6217 1-135-362-31 ELECT 1500UF D6106 8-719-081-67 DIODE M1FM3 D6107...
  • Page 85 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < COIL > R6111 1-218-873-11 METAL CHIP 0.5% 1/10W R6114 1-211-969-11 METAL CHIP 0.5% 1/10W L6000 1-456-678-11 LINE FILTER COIL R6116 1-216-009-91 RES-CHIP 1/10W L6001 £...
  • Page 86 All manuals and user guides at all-guides.com G2 H6 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R6458 1-216-839-11 METAL CHIP 1/10W < VARISTOR > R6459 1-218-831-11 METAL CHIP 0.5% 1/10W R6502 1-215-882-00 METAL OXIDE VD6000 £ 1-804-996-21 VARISTOR R6503 1-215-882-00 METAL OXIDE VD6001 £...
  • Page 87 C4050 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V *A-1106-556-A A1 Board Complete KDL-V26A12U only C4052 1-127-573-11 CERAMIC CHIP 1UF *A-1106-557-A A1 Board Complete KLV-V26A10E only C4053 1-127-573-11 CERAMIC CHIP 1UF 4-382-854-11 SCREW (M3X10), P, SW (+) C4107 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V...
  • Page 88 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4132 1-127-715-91 CERAMIC CHIP 0.22UF C4417 1-126-392-11 ELECT CHIP 100UF 20.00% 6.3V C4133 1-127-715-91 CERAMIC CHIP 0.22UF C4418 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V C4134 1-127-715-91 CERAMIC CHIP 0.22UF C4419...
  • Page 89 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4826 1-100-742-91 CERAMIC CHIP 2.2UF C7558 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C4827 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V C7559 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C4828 1-125-891-11 CERAMIC CHIP 0.47UF...
  • Page 90 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C7687 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V D7513 8-719-081-98 DIODE MM3Z6V8T1 C7703 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V D7514 8-719-083-82 DIODE UDZS-TE17-12B C7704 1-165-870-21 ELECT CHIP 100UF 20.00% 6.3V D7515...
  • Page 91 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK FB5103 1-469-775-21 FERRITE < COIL > FB5104 1-469-775-21 FERRITE FB5105 1-469-775-21 FERRITE L4001 1-406-657-11 INDUCTOR 4.7UH FB5106 1-469-775-21 FERRITE L4003 1-400-323-21 INDUCTOR 47UH FB5107 1-469-775-21 FERRITE L4004 1-424-758-21...
  • Page 92 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK Q4402 8-729-424-08 TRANSISTOR UN2111 R4017 1-216-841-11 METAL CHIP 1/10W Q4403 8-729-421-22 TRANSISTOR UN2211 R4018 1-216-841-11 METAL CHIP 1/10W Q4404 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R R4019 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W Q4802 8-729-120-28...
  • Page 93 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4124 1-216-809-11 METAL CHIP 1/10W R4323 1-216-853-11 METAL CHIP 470K 5% 1/10W R4125 1-216-815-11 METAL CHIP 1/10W R4324 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R4128 1-216-805-11 METAL CHIP 1/10W...
  • Page 94 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4441 1-216-809-11 METAL CHIP 1/10W R4635 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R4444 1-216-809-11 METAL CHIP 1/10W R4636 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R4449 1-218-725-11 METAL CHIP 0.5% 1/10W...
  • Page 95 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4860 1-216-809-11 METAL CHIP 1/10W R5237 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R4861 1-216-817-11 METAL CHIP 1/10W R5238 1-216-864-11 SHORT CHIP R4862 1-218-285-11 METAL CHIP 1/10W R5239 1-216-864-11...
  • Page 96 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R7618 1-216-821-11 METAL CHIP 1/10W R7692 1-216-809-11 METAL CHIP 1/10W R7619 1-216-821-11 METAL CHIP 1/10W R7699 1-216-817-11 METAL CHIP 1/10W R7621 1-216-295-91 SHORT CHIP R7700 1-218-839-11 METAL CHIP 0.5% 1/10W...
  • Page 97 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK A1 Board Variant parts KLV-V26A10E < RESISTOR > < CAPACITOR > R5113 1-216-864-11 SHORT CHIP R5114 1-216-864-11 SHORT CHIP C5222 NOT FITTED R5115 1-216-864-11 SHORT CHIP...
  • Page 98 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C5828 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V R5653 1-216-864-11 SHORT CHIP C5829 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V R5654 1-216-864-11 SHORT CHIP C5830 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V R5655 1-216-864-11...
  • Page 99 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK NP1 Board Variant parts KDL-V26A10E/KDL-V32A10E < DIODE > < CAPACITOR > D5601 NOT FITTED D5602 NOT FITTED C5601 NOT FITTED D5631 NOT FITTED C5602 NOT FITTED D5697 NOT FITTED C5603...
  • Page 100 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R5615 NOT FITTED C5628 1-128-401-11 ELECT CHIP 100UF R5616 NOT FITTED C5631 1-100-421-21 ELECT CHIP 220UF 6.3V R5617 NOT FITTED C5632 1-162-969-11 CERAMIC CHIP 0.0068UF 10.00% 25V R5618 NOT FITTED...
  • Page 101 All manuals and user guides at all-guides.com NP1 A2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < TRANSISTOR > C4004 1-126-396-11 ELECT CHIP 47UF 20.00% 16V C4005 1-126-396-11 ELECT CHIP 47UF 20.00% 16V Q5601 6-550-828-01 TRANSISTOR RSQ035P03TR C4006 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V Q5602...
  • Page 102 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4101 1-137-765-21 ELECT CHIP 47UF C4310 1-125-889-91 CERAMIC CHIP 2.2UF C4103 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V C4312 1-125-889-91 CERAMIC CHIP 2.2UF C4104 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V C4313 1-164-230-11...
  • Page 103 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4606 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V C4675 1-164-505-11 CERAMIC CHIP 2.2UF C4607 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V C4676 1-164-505-11 CERAMIC CHIP 2.2UF C4608 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V...
  • Page 104 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4858 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V C5205 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C4859 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V C5206 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C4860 1-125-891-11...
  • Page 105 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK D4401 8-719-404-50 DIODE MA111-TX FB4602 1-400-333-21 FERRITE D4407 8-719-069-55 DIODE UDZSTE-175.6B FB4603 1-400-333-21 FERRITE D4408 8-719-069-55 DIODE UDZSTE-175.6B FB4901 1-414-445-11 FERRITE D4409 8-719-069-55 DIODE UDZSTE-175.6B FB4920 1-469-775-21 FERRITE...
  • Page 106 All manuals and user guides at all-guides.com B1 A2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK IC4807 8-752-106-86 IC CXA2181Q-T6 Q4101 8-729-422-33 TRANSISTOR 2SD601A-Q-TX IC4810 8-759-598-44 IC TC7WH08FK(TE85R) Q4301 8-729-422-29 TRANSISTOR 2SD601A-S IC4901 8-759-514-57 IC BA7046F Q4304 8-729-422-29 TRANSISTOR 2SD601A-S IC5201 8-752-080-04 IC CXA2069Q...
  • Page 107 All manuals and user guides at all-guides.com B1 A2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4022 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W R4146 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R4023 1-218-835-11 METAL CHIP 0.5% 1/10W R4148 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R4024...
  • Page 108 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4328 1-216-833-11 METAL CHIP 1/10W R4425 1-216-809-11 METAL CHIP 1/10W R4329 1-216-841-11 METAL CHIP 1/10W R4426 1-216-809-11 METAL CHIP 1/10W R4330 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R4427 1-216-809-11...
  • Page 109 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4476 1-216-810-11 METAL CHIP 1/10W R4628 1-216-834-11 METAL CHIP 1/10W R4477 1-216-833-11 METAL CHIP 1/10W R4629 1-216-809-11 METAL CHIP 1/10W R4478 1-216-809-11 METAL CHIP 1/10W R4630 1-216-853-11 METAL CHIP...
  • Page 110 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4686 1-216-809-11 METAL CHIP 1/10W R4739 1-216-813-11 METAL CHIP 1/10W R4687 1-216-809-11 METAL CHIP 1/10W R4740 1-216-813-11 METAL CHIP 1/10W R4688 1-216-864-11 SHORT CHIP R4741 1-216-813-11 METAL CHIP 1/10W...
  • Page 111 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4821 1-216-817-11 METAL CHIP 1/10W R4929 1-216-809-11 METAL CHIP 1/10W R4822 1-218-847-11 METAL CHIP 0.5% 1/10W R4930 1-216-809-11 METAL CHIP 1/10W R4824 1-216-864-11 SHORT CHIP R4931 1-216-853-11 METAL CHIP...
  • Page 112 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R5219 1-216-825-11 METAL CHIP 2.2K 5% 1/10W X4401 1-767-654-21 VIBRATOR, CRYSTAL R5221 1-216-809-11 METAL CHIP 1/10W X4801 1-813-124-21 VIBRATOR, CERAMIC R5223 1-216-841-11 METAL CHIP 1/10W X4802 1-813-604-21 VIBRATOR,CERAMIC...
  • Page 113 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R5124 NOT FITTED R4826 NOT FITTED R5130 NOT FITTED R4827 NOT FITTED R5131 1-216-864-11 SHORT CHIP R5002 1-216-864-11 SHORT CHIP R5134 NOT FITTED R5113 1-216-864-11 SHORT CHIP R5135 1-216-864-11...
  • Page 114 All manuals and user guides at all-guides.com REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK D7066 8-719-062-19 DIODE MA3200WA-TX D7068 8-719-062-19 DIODE MA3200WA-TX D7069 8-719-081-98 DIODE MM3Z6V8T1 D7070 8-719-081-98 DIODE MM3Z6V8T1 D7071 8-719-081-98 DIODE MM3Z6V8T1 < FERRITE BEAD > FB7060 1-414-760-21 FERRITE FB7061...
  • Page 115 1-826-239-21 LOUDSPEAKER(R) (KDL-V26A12U/KDL-V32A12U) 1-805-870-51 PANEL, LCD(KLV-V32A10E/KDL-V32A12U) 1-479-394-11 REMOTE COMMANDER (RM-EA001) 1-805-871-11 PANEL, LCD(KLV-V26A10E/KDL-V26A12U) (KLV-V26A10E/KLV-V32A10E) 8-597-997-00 TUNER, FSS BTP-DC412Z(KDL-V26A12U/V32A12U) £ 1-819-554-11 AC INLET(WITH NOISE FILTER)(KLV-V26A10E/ KDL-V26A12U) £ 1-818-098-21 AC INLET(WITH NOISE FILTER)(KLV-V32A10E/ KDL-V32A12U) 1-787-333-11 D.C. FAN(KLV-V32A10E/KDL-V32A12U) 8-597-993-00 TUNER, FSS BTF-EF412Z £...
