Epson PowerLite 7900p Product Information

Epson PowerLite 7900p Product Information

Epson powerlite 7900p: product information
Hide thumbs Also See for PowerLite 7900p:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual, User Manual
Focus ring
Zoom ring
Air exhaust
vent
Remote
control
receiver and
Wall Shot lens
Foot
release lever
Front adjustable
foot
RJ-45 Ethernet port
RS-232
(for wired LAN)
serial port
Computer
Type B
port
USB port
Video port and
related audio
ports
Remote port
BNC ports (Comp2 or Component)
Audio-out port
S-Video port and
Monitor-out port
related audio ports

Projector Specifications

General
Type of display
Poly-silicon Thin Film Transistor
(TFT), Active Matrix
Lens
F=1.7 to 2.3, f=28 to 37 mm
Zoom ratio
1:1.35
Resolution
1024
Color reproduction 24 bit, 16.7 million colors
Temperature light
Lamp light
Control panel
Air filter
DVI port
Remote control
receiver
Kensington
security lock
Speaker
Power inlet
Audio-in port (for
Computer and DVI)
×
768 pixels (native format)
Brightness
Power
light
Contrast ratio
Image size
Projection distance 2.5 to 36.5 feet (0.8 to 11.1 meters)
Projection methods Front, rear, and ceiling mount (upside-
Internal sound
system
Optical aspect ratio 4:3 (horizontal:vertical)
Noise level
Keystone
correction angle
Projection Lamp
®
Type
Power
consumption
Lamp life
Rear
adjustable
foot
Part number
Remote Control
Range
Battery
Dimensions
Height
Width
Depth
Weight
Mouse Compatibility
Supports USB (Type B)
Electrical
Rated frequency
Power supply
Power
consumption
9/04
Epson PowerLite 7900p Projector
4000 ANSI lumens in high brightness
mode; 3000 ANSI lumens in low
brightness mode
700:1
30 to 300 inches
down front or rear)
5 W monaural
36 dB in high brightness mode;
33 dB in low brightness mode
±40° vertical, ±20° horizontal
(automatically adjusts vertical angle)
UHE (Ultra High Efficiency)
250 W
About 2000 hours (high brightness
mode); 3000 hours (low brightness
mode
V13H010L22
33 feet (10 meters)
Alkaline AA (2)
4.6 inches (117 mm), feet retracted
16.5 inches (419 mm)
12.8 inches (325 mm)
12.3 lb (5.6 kg)
50 to 60 Hz
100 to 120 VAC, 50/60 Hz
200 to 240 VAC, 50/60 Hz
1.6 to 3.6 A, 50/60 Hz
Epson PowerLite 7900p Projector
1
-
