Philips SPC1247AT/27 Instructions

Home power
SPC1247AT/27
Instructions
SET TIME
1. If no numbers are visible on-screen, plug timer
into an outlet and charge for 1 hour. Once
charged, press the reset ( ) button in the lower
right corner using a toothpick or pencil.
2. Use up ( ) and down ( ) arrows to set the
time - note AM or PM.
Note: After timer is charged, it can be removed
from the outlet for easy programming. Return
to outlet when finished.
PROGRAMMING OPTIONS
DEFAULT TIMER
Two ON/OFF programs feature default
settings. To activate the default times,
press ON TIME or OFF TIME button.
Indicator arrows appear on the display
to show which programs are set. To
deactivate a setting, press the desired
button again.
CUSTOMIZED TIMER
Press either ON TIME button, then use up (
) arrows to set on time. Press the ON
and down (
TIME button again or wait five seconds to store the
program and return to clock display.
Press either OFF TIME button, then use up (
and down ( ) arrows to set off time. Press the OFF
TIME button again or wait five seconds to store the
program and return to clock display.
Note: An indicator arrow ( or ) appears
on-screen to show which settings are active.
OVERRIDE OPTIONS
Override scheduled programs and manually
operate the connected device using the ON/OFF
button below the display screen or by pressing the
decorative door.
If a scheduled program is running and the device
is on, press the closed door or ON/OFF button to
turn off the device. The device remains off until
the next scheduled program begins, or the button
is pressed again.
If a scheduled program is running and the device is
off, press the closed door or ON/OFF button to turn
on the device. It remains on until the next scheduled
program ends, or the button is pressed again.
When no programs are active, press the closed
door or ON/OFF button to turn ON/OFF the
device manually.
COLOR OPTIONS
When plugged in, the LED backlight cycles through
the color options. The cycle can be stopped to select
a color or turn off the backlight. LEDs only work
when the timer is connected to an outlet.
• Press the button on top of the timer once to stop
the cycle.
• Press the button again to change the LED color.
• Repeat to manually cycle through all colors.
• Press the button for three seconds to turn OFF the LED.
• Press the button once to turn ON LED to last setting.
CLOCK SET
ON ON
TIME TIME
AM
OFF OFF
TIME TIME
R
ON/OFF
RESET
BUTTON
CLOCK SET
ON ON
TIME TIME
AM
OFF OFF
TIME TIME
R
ON/OFF
CLOCK SET
ON TIME 1 ON TIME 2
ON ON
5:00PM TIME TIME 6:00PM
AM
OFF TIME 1 OFF TIME 2
OFF OFF
12:00AM 6:00AM
TIME TIME
R
ON/OFF
)
CLOCK SET
ON ON
TIME TIME
AM
OFF OFF
TIME TIME
ON/OFF
)
CLOCK SET
ON ON
TIME TIME
AM
OFF OFF
TIME TIME
ON/OFF
CLOCK SET
ON ON
TIME TIME
AM
OFF OFF
TIME TIME
ON/OFF
CLOCK SET
ON ON
TIME TIME
AM
OFF OFF
TIME TIME
ON/OFF
CLOCK SET
ON ON
TIME TIME
AM
OFF OFF
TIME TIME
R
ON/OFF
FCC/IC - EN
Suppliers Declaration of Conformity | Model #: SPC1247AT/27 | Jasco Products Co.,
10 E. Memorial Rd., Oklahoma City, OK 73114, www.byjasco.com
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC NOTE: The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Standards. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different to which
the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3(B)/NMB-3(B)
SPECIFICATIONS
125VAC, 60Hz, 15A 1875W general/resistive
5A 625W tungsten, 1/2HP motor
Works with LED and CFL bulbs
THANK YOU FOR YOUR PURCHASE!
Product instructions
made easy
Scan to watch a step-by-step
instructional video or visit
https://byjasco.com/49791i
R
Need more
holiday timers?
For additional Philips holiday
timers visit our website!
byjasco.com/timers
R
R
R
WARNING
RISK OF ELECTRICAL SHOCK
• PLUG DIRECTLY INTO AN ELECTRICAL
OUTLET
• DO NOT USE IN WET LOCATIONS
• USE INDOORS ONLY
• UNPLUG TIMER BEFORE CLEANING
MADE IN CHINA
Philips and the Philips Shield Emblem are registered trademarks of
Koninklijke Philips N.V. and are used under license. This product has been
manufactured by and is sold under the responsibility of Jasco Products
Company, and Jasco Products Company LLC, 10 E. Memorial Rd., Oklahoma
City, OK 73114 is the warrantor in relation to this product.
This product comes with a 1-year limited warranty.
Visit www.philips.com/support for warranty details.
Questions? Contact our US-based Consumer Care
at 1-844-816-0320 between 7AM-8PM, M-F, Central Time.
Register your
Philips product
Get exclusive, web-only deals and
more! Scan here or visit
byjasco.com/deals
Like our product?
Leave us a review on Amazon.com
or your favorite retailer website!
Having issues and need
support?
Call our U.S.-based experts Monday–
Friday, from 7AM–8PM (Central)
1-844-816-0320
RISK OF FIRE
• DO NOT USE TO CONTROL APPLIANCES
THAT CONTAIN HEATING ELEMENTS
(COOKING APPLIANCES, HEATERS,
IRONS, ETC.)
• DO NOT EXCEED ELECTRICAL RATINGS
• DO NOT USE WITH EXTENSION CORD
