Panasonic TY-FB8TA Service Manual

Specifications
Receiving System
Receiving Channels Regular TV
VHF BAND
2-12 (PAL/SECAM B, K1)
0-12 (PAL B AUST.)
1-9 (PAL B N.Z)
1-12 (PAL/SECAM D)
1-12 (NTSC M Japan)
2-13 (NTSC M U.S.A.)
OUTPUT
AUDIO OUT AUDIO L-R (RCA Pin Type × 2)
VIDEO OUT VIDEO (BNC Type)
Others Ir System terminal × 1
INPUT
AUDIO IN AUDIO L-R (RCA Pin Type × 2)
VIDEO IN VIDEO (BNC Type)
S-VIDEO (MINI DIN 4-pin)
ANT-IN UHF / VHF
Mass (Weight) 0.55 kg
All manuals and user guides at all-guides.com
U/V Tuner Board with Hospitality Port
UHF BAND
21-69 (PAL G, H, I/SECAM G, K, K1)
28-69 (PAL B AUST.)
13-57 (PAL D, K)
13-62 (NTSC M Japan)
14-69 (NTSC M U.S.A.)
0.5 Vrms
1.0 Vp-p (75 W)
0.5 Vrms
1.0 Vp-p (75 W)
Y:1.0 Vp-p (75 W) C:0.286 Vp-p (75 W)
TY-FB8TA
© 2004 Matsushita Electric Industrial Co., Ltd. All
rights reserved.
distribution is a violation of law.
ORDER NO. ITD0604015CE
CATV
S1-S20 (OSCAR)
1-125 (U.S.A. CATV)
C13-C49 (JAPAN)
S21-S41 (HYPER)
Z1-Z37 (CHINA)
5A, 9A (AUST.)
Unauthorized copying and
