- Page 1 Operating Instructions Memory Card Drive AJ-PCD35P Model No. AJ-PCD35E Model No. AJ-PCD35EJ Model No. Before operating this product, please read the instructions carefully and save this manual for future use. ENGLISH FJ1108AT6033 -FJ Printed in Japan VQT1X46-5...
-
Page 2: Read This First
Notice (U.S.A. only): Disposal may be regulated in your community due to Environmental considerations. For disposal or recycling information, please visit Panasonic website: http://www.panasonic.com/environmental or call 1-888-769-0149. Manufactured by: Panasonic Corporation, Osaka, Japan Importer’s name and address of pursuant to EU rules:... - Page 3 Declaration of Conformity Model Number: AJ-PCD35P Trade Name: Panasonic Responsible Party: Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094 Support contact: 1-800-524-1448 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two...
- Page 4 Fuse If you lose the fuse cover the plug must not be used until a replacement cover is obtained. replacement fuse cover purchased from your local Panasonic Dealer. indicates safety information. EEE Yönetmeliğine Uygundur. EEE Complies with Directive of Turkey.
-
Page 5: Table Of Contents
Power Switch Box (AJ-PCD35EJ only)........9... -
Page 6: Before Use
However, the transfer speed varies depending on the files transferred, system, application software, P2 card version, and other factors. A memory card adapter (AJ-P2AD1) can be used. This feature is supported with firmware version 2.00 or later of the unit. For the latest information on firmware, visit the following Web site. http://pro-av.panasonic.net/... -
Page 7: Supplied Accessories (Aj-Pcd35P/Aj-Pcd35E/Ej)
For AJ-PCD35E/EJ For AJ-PCD35E/EJ (U.K.) (continental Europe,etc) Power switch box (AJ-PCD35EJ only) CD-ROM Operating Environment Required for Installation To operate the P2 drive, the following environment is required on the host computer. Empty slot(s) (full height) for the PCI Express : 1 or more To mount the each P2 drive in a personal computer, 1 empty slot is required. -
Page 8: Parts And Their Functions
Do not remove the P2 card during access of AC adapter to this socket. the card, otherwise files may be corrupted, or For the AJ-PCD35EJ only: For external use of the P2 card may fail. the P2 drive, connect the power switch box to this socket. -
Page 9: Power Switch Box (Aj-Pcd35Ej Only)
Parts and their Functions (continue) Power Switch Box (AJ-PCD35EJ only) （2） （3） （1） During external use of the P2 drive, connect the power switch box between the drive and the AC adapter. When the power switch box is connected, you can use the switch to turn off the P2 drive instead of unplugging the power cord. -
Page 10: Inserting A P2 Card
Inserting a P2 Card When inserting a P2 card into the slot in the P2 drive, make sure you keep the card horizontal as you ease it in. Forcing the card in on an angle may cause a problem. Write-protection of P2 Card A P2 card has a write-protect switch. -
Page 11: To Connect The P2 Drive To A Personal Computer For External Use
Installation (continue) To Connect the P2 drive to a Personal Computer for External Use After switching the personal computer off, Connect the included PCI Express cable remove the power cable from the personal to the PCI Express connector of the P2 computer. - Page 12 If the personal computer is on with the unit off, before turning the unit on, turn the personal computer off. For the AJ-PCD35EJ only: Plug the power switch box supplied with Pay attention to the items below if you are the P2 drive into the DC IN 16V socket on using Mac Pro (1st Generation).
-
Page 13: To Mount The P2 Drive In A Personal Computer 5-Type Bay
Installation (continue) To Mount the P2 drive in a Personal Computer 5-type Bay After switching the personal computer off, If you are unable to pass the PCI remove the power cable from the personal Express cable through the slot on your computer. - Page 14 Installation (continue) Mount the P2 drive in a 5-type bay on the Connect the P2 drive to the internal power personal computer. Use the screws (page cable (4 pins) of the personal computer. 7) supplied with the P2 drive for mounting. Please refer to your computer’s instruction manual for guidance in mounting to 5-type bay drives.
-
Page 15: Pci Express Driver For Windows
When checking that the PCI Express driver is following website. properly installed, be sure to connect the appropriate device to the personal computer. http://pro-av.panasonic.net/ Devices not connected to the personal computer cannot be checked using the following method: 1) Installation of the PCI Express... - Page 16 PCI Express Driver for Windows (continue) Check the following items with Device Manager. “Panasonic AJ-PCD35” is displayed below “IDE ATA/ATAPI controllers”. “MATSHITA AJ-PCD35 #1 SCSI Disk Device” to “MATSHITA AJ-PCD35 #5 SCSI Disk Device” are displayed below “Disk drives”. PCI Express...
-
Page 17: Pci Express Driver For Macintosh
Macintosh using PCI Express to transfer data at a higher rate. The latest driver information can be viewed at the following website. http://pro-av.panasonic.net/ Installation of the PCI Express driver For the driver installation procedure, refer to “2. Installation of the P2 Software” in the installation manual in the Manuals folder on the CD-ROM. -
Page 18: Specifications
