Summary of Contents for Cabletron Systems TRFOT-3
Page 1
TRFOT-3 TOKEN RING SINGLE MODE FIBER OPTIC TRANSCEIVER LOBE CABLE CONVERTER USER’S GUIDE The Complete Networking Solution™ CABLETRON SYSTEMS, P. O. Box 5005, Rochester, NH 03867-0505...
Page 2
P.O. Box 5005, Rochester, NH 03867-0505 All Rights Reserved Printed in the United States of America Order Number: 9030942 October 93 TRFOT-3, TRRMIM-A, TRRMIM-2A, TRRMIM-4A, TRMM, TRFMIM-32, TRFMIM-36, and TRFMIM-38 are trademarks of Cabletron Systems, Inc. LANVIEW is a registered trademark of Cabletron Systems, Inc.
NOTICE FCC NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.
TRFOT-3. Chapter 3, Installing the TRFOT-3, contains instructions for mounting the TRFOT-3 and attaching the cables to your network. It also describes the front panel LANVIEW ® LEDs. 1.2 TRFOT-3 OVERVIEW The TRFOT-3, Token Ring Single Mode Fiber Optic Transceiver, converts single mode fiber lobes to copper and/or copper lobes to single...
10 km over single mode fiber optic cable. You can attach the TRFOT-3 at either end of a fiber link. Ring Speed Compatibility The TRFOT-3 supports both 4 and 16 mb/sec ring speeds and senses the ring speed automatically. 1.4 RECOMMENDED READING We recommend the following publications for more information on implementing a token ring network.
INSTALLATION REQUIREMENTS/SPECIFICATIONS REQUIREMENTS/SPECIFICATIONS This chapter describes cabling requirements, network guidelines, and operating specifications for the TRFOT-3. Ensure that you read this chapter before you install the TRFOT-3. Failure to follow these guidelines could result in unsatisfactory network performance. 2.1 FIBER OPTIC CABLE SPECIFICATIONS Single mode fiber optic link segments must meet the requirements...
Media Filters To connect an Unshielded Twisted Pair (UTP) segment from a token ring concentrator to the TRFOT-3, you need to install a Type 3 media filter such as the Cabletron Systems TRMF-2. Use the TRMF-2 at the concentrator end of the connection as shown in Figure 2-1.
INSTALLATION REQUIREMENTS/SPECIFICATIONS 2.3 OPERATING SPECIFICATIONS This section lists power supply requirements, safety and environmental guidelines, and physical specifications for the TRFOT-3. Cabletron Systems reserves the right to change these specifications at any time without notice. POWER REQUIREMENTS Input Voltage: 9-12 VDC...
1. Carefully remove the TRFOT-3 from the shipping box. 2. Remove the TRFOT-3 from its protective plastic bag. 3. Visually inspect the TRFOT-3. If there are any signs of damage, contact Cabletron Systems Technical Support immediately. 3.2 SETTING THE CONFIGURATION SWITCHES Figure 3-1 shows the location of the TRFOT-3’s four configuration...
Page 11
Switch D This switch selects modes on the TRFOT-3’s fiber optic connector. Select ON to attach the TRFOT-3’s fiber optic connector to a Cabletron fiber RI/RO port, for example the TRRMIM-A/2A/4A. Select OFF to attach the fiber optic connector to an IEEE 802.5J compatible RI/RO Page 3-2 Table 3-1.
To attach the TRFOT-3 to a token ring concentrator that supports Shielded Twisted Pair (STP), use the DB9 to DB9 cable supplied with the unit. If you want to attach the TRFOT-3 to a concentrator that does not have a DB9 connector, you need an adapter cable. Cabletron offers cables that adapt to RJ45 and MIC style connectors.
Page 13
Note: Perform the following steps only if the device attached to the TRFOT-3 is a Cabletron device, for example the TRFMIM-32/36/38. If you attach a non-Cabletron device to the TRFOT-3, the FO Link LED may not light, even though a good link may exist.
TRFOT-3, then the RX cable. 3.5 CONNECTING POWER The TRFOT-3 is equipped with an external power supply. Plug the power supply connector into the Power Input port on the TRFOT-3, then plug the power supply into a standard wall outlet.
TRFOT-3 to wall-mount the unit. 1. Remove the tape from the adhesive backing on the Velcro strips. 2. Place one Velcro half on the TRFOT-3 and the other half on the mounting surface. 3. Press firmly on each Velcro strip, then press the TRFOT-3 onto the mounting surface.
2. Check the FO LED. If it is not lit, check the fiber optic connections as detailed in Section 3.4. 3. Check the copper cable connecting the TRFOT-3 to the device. Verify that it is installed correctly, see Section 3.3.
