- Page 1 NetView Service Point SmartSwitch 1800, FRX4000, FRX6000, and Frame Relay Module Supplemental Software User Guide The Com plete Network ing Solution 09-41-06-092-03...
-
Page 3: About This Manual
Related Documents These appropriate product-specific user guide(s) can be ordered from Cabletron Systems: SmartSwitch 1800 Release 4.0 User Guide, Cabletron number 09-44-06-018. 9W004 Release 4.0 User Guide, Cabletron number 09-41-06-169. Netlink FRX4000 & FRX6000 Release 4.0 User Guide, Cabletron number 09-41-06-162. - Page 4 NetView Service Point...
- Page 5 NMVTs (network management vector transports). The service point function trans- lates information from the node into NMVTs and responds to the host. The various user guides (FRX4000/6000, SmartSwitch 1800, and Frame Relay Module) describes the NetView function in the related products. The remainder of this document describes the supported operations on the NetView host.
- Page 6 Operation To invoke the program, enter to the following: Data Displayed Service Point Name Status – is the status (active or inactive) of the PU. Prod Type Software Version Config Name Last Loaded Function Key Operations Pressing one of the function keys listed below will perform the appropriate operation: [PF1] [PF3] [PF7]...
- Page 7 Moving the cursor to an entry under [PF4] Ln_Status under "Line Status Panel." Help Panel Line Status Panel Supplemental Software User Guide Service Point Name ) will display a line status screen for that service point, as described Main Statu s Pan el Line S tatus Pan el Line S tats Lin e Con fig...
- Page 8 Data Displayed Line Name Port record, or if that parameter is not configured, the Name in the NetView Param- eters part of the Network Defaults record. Actual Status Desired Status on the first screen of the SNA Port record. – is the RLP and port that defines the line. Port Interface DTR/DSR/CTS/DCD...
- Page 9 PU Status Panel Data Displayed PU Name SDLC Actual Status Desired Status screen of the SNA Port record. POLL ADDR of the SNA Port record. LLC2 Actual Status LANCON Status with Netlink's SDLC Link Server.) MAC Address of the SNA Port record. –...
-
Page 10: S Ervice Point: Bd0N Vsp Line Name: Lin E11
Moving the cursor to an entry under PU Name and pressing a supported function key gives you these additional options: [PF6] [PF7] [PF8] Line Configuration Panel Configurable Parameters ISTATUS will cause the line to be enabled (if undergoes IPL. The line will remain in that state until either an on-line port disable or enable is performed on the Cabletron device (as described in the User Guide) or a VARY INACT NRZI... - Page 11 SPEED is the line speed. Valid line speeds are: 2400 192K 336K 512K 672K 832K 1.008M 1.152M 1.288M 1.472M 1.624M 1.856M ACTIVTO is the activity timer ( RCVCLOCK is equivalent to the Cabletron device parameter the clock to be looped back from the DTE using the terminal timing signal. Valid values are PAUSE is equivalent to the Cabletron device parameter...
-
Page 12: Table Of Contents
Moving the cursor to a parameter and pressing a supported function key gives you these additional options: [PF6] [PF7] [PF8] [PF10] [PF11] PU Configuration Panel Configurable Parameters ISTATUS will cause the PU to be enabled (if is activated. The PU will remain in that state until either an on-line SDLC PU disable or enable is performed on the Cabletron device (as described in the User Guide) or a VARY INACT MAXDATA... -
Page 13: Auto Retry Tout
(Cabletron device parameter (milliseconds). LPDARESID is the LPDA Resource ID, which defines LUs on the PU. The value must match the LOCADDR defined on VTAM. Valid values are AUTOCALL causes automatic calling between SNA ports when the controller becomes active. The valid values are Auto Retry Tout is equivalent to the Cabletron device parameter... -
Page 14: Ack Timer (T2) 100
Any Unnumbered LPDUs that were not responded to the first time they were sent. If acknowledgments/responses are still outstanding after N2 tries (see that entry), the link station will declare the link inoperative. Ack Timer (T2) is used by the link station to delay sending an acknowledgment of a received Infor- mation LPDU. - Page 15 SAP address is required. If the LLC2 session will be run over a native LLC2 frame relay interface, the parameter will be ignored. Local MAC Address identifies the PU to the host. Like the local SAP address, this parameter is relevant only in a connection to a 3174 or AS/400-type setup where a specific source MAC address is required.
- Page 16 Alerts The Cabletron device will issue alerts (events) based upon NMVT protocols. The node transparently passes all Alerts (Basic, Generic, RECFMS, etc.) received from down- stream SNA/SDLC devices. Host Alert ID Number Each Alert generated by the Cabletron node appears in the event log identified by a Netlink event number.
- Page 17 Alerts Event Log Message Host Console Message Alert Condition Alert ID Number Alert Type Alert Description Probable Causes User Causes Actions Install Causes Failure Causes Actions Additional SVs Supplemental Software User Guide puname/linename – SDLC Link Stn Not Responding LINK ERROR:SDLC COMMUNICATIONS/REMOTE NODE An SDLC logical link has been lost.
- Page 18 Event Log Message Host Console Message Alert Condition Alert ID Number Alert Type Alert Description Probable Causes User Causes Install Causes Failure Causes Actions Additional SVs puname/linename – SDLC Link Stn Sent DM LINK ERROR:SDLC COMMUNICATIONS An SDLC logical link has been lost. The secondar y link station sent a Disconnect Mode response to the primar y station.
- Page 19 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The primary link station sent an invalid or unsup- ported command to the secondary link station. The secondar y link station responded with a Frame r eject. Alert ID Number X'B776CA94’...
- Page 20 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The prim ary link station sent an i-field when not per- mitted to the secondary link station. The secondary link station responded with a Frame reject.
- Page 21 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The primar y link station sent a frame with an invalid N(r). The secondary link station responded with a Frame r eject. Alert ID Number X'BEF4F1FA’...
- Page 22 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The primary link station sent a fr ame with an i-field that was too long. The secondary link station responded with a Frame reject. Alert ID Number X'BA35EC4D’...
- Page 23 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The secondary link station sent an invalid or unsup- ported command to the pr imar y link station. Alert ID Number X'15C2CCE5’ Alert Type X'01’ Alert Description X'2100’...
- Page 24 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The secondary link station sent an I-field when not perm itted to the primar y link station. Alert ID Number X'15C2CCE5’ Alert Type X'01’ Alert Descr iption X'2100’...
- Page 25 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The secondary link station sent a frame with an invalid N(r). Alert ID Number X'1C40F78B’ Alert Type X'01’ Alert Description X'2100’ X'2004' Probable Causes X'1023' User Causes (none) Install Causes...
- Page 26 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The number of I-frames transmitted by the remote link station has exceeded the local link station's r eceive window size. Alert ID Number X'EABB6A14’ Alert Type X'01’...
- Page 27 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The secondary link station's inactivity timer has expired. Alert ID Number X'0E2DDF11’ Alert Type X'01’ Alert Description X'3300’ Probable Causes X'2104' X'2031' User Causes X'0209’ Actions X'0200’...
- Page 28 Event Log Message Host Console Message Alert Condition Link establishment has failed. The local link station's retry limit for XID has been exceeded. Alert ID Number X'0AECC2A6’ Alert Type X'01’ Alert Descr iption X'3300’ Probable Causes X'2104' X'2031' User Causes X'0209’...
- Page 29 Event Log Message Host Console Message Alert Condition An SDLC logical link has been lost. The secondary link station sent a Fram e Reject with no reason for the rejection. Alert ID Number X'A472BC48’ Alert Type X'01’ Alert Description X'2100’ Probable Causes X'2004' X'1000'...
- Page 30 Event Log Message Host Console Message Alert Condition Secondar y transmit frame exceeds MAXDATA. Alert ID Number X'6E0781DD’ Alert Type X'01’ Alert Descr iption X'2100’ Probable Causes X'2004' X'1000' User Causes (none) Install Causes (none) Failure Causes X'1000' X'F023’ Actions Additional SVs X'8C'SV X’01'SF...
- Page 31 Event Log Message Host Console Message Alert Condition Secondary sent UA while in NRM. Alert ID Number X'0396D7BA’ Alert Type X'01’ Alert Description X'2100’ Probable Causes X'1000' X'1023' User Causes (none) Install Causes (none) Failure Causes X'1023’ Actions X'32A0’ Additional SVs X'8C'SV X’01'SF X'02'SF...
- Page 32 Event Log Message Host Console Message Alert Condition No DSR on link. Alert ID Number X'34FFCB87’ Alert Type X'01’ Alert Descr iption X'3617’ Probable Causes X'2031' X'32D1' User Causes X’0201’ Actions X'0200’ Install Causes (none) Failure Causes X'3601’ X’F035’ Additional SVs X'05'SV X'10'SF Event Log Message...
- Page 33 Event Log Message Host Console Message Alert Condition No external clock. Alert ID Number X'1D1B6697’ Alert Type X'01’ Alert Description X'3612’ Probable Causes X'2031' X'32D1' User Causes (none) Install Causes (none) Failure Causes X'3601’ X’3511’ Additional SVs X'05'SV X'10'SF Supplemental Software User Guide linename –...
- Page 34 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost. The remote link station does not respond. The inactiv- ity tim er or acknowledgment timer has expired. Alert ID Number X'5B8F5BA7’ Alert Type X'01’ Alert Descr iption X'3300’...
- Page 35 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost. The remote link station sent a Disconnect Mode response to the local link station. Alert ID Number X'B1D9A4C5’ Alert Type X'01’ Alert Description X'3300’ Probable Causes X'2007' User Causes (none)
- Page 36 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost.The remote link station sent a SABME to the local link station, which was alr eady initialized with a SABME-UA exchange. Alert ID Number X'E65B0B7F’ Alert Type X'01’...
- Page 37 Event Log Message Host Console Message A LAN logical link has been lost. The local link station sent an invalid or unsupported Alert Condition command or response to the remote link station. The remote link station returned a Frame Reject response. Alert ID Number X'8A5B2D2C’...
- Page 38 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost. The local station send an I-field when not perm itted to the remote link station. The remote link station returned a Frame Reject response. Alert ID Number X'8E9A309B’...
- Page 39 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost. The local link station sent a fr ame with an invalid N(r). The remote link station returned a Frame Reject response. Alert ID Number X'83D91642’ Alert Type X'01’...
- Page 40 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost. The local link station sent a frame with an i-field that was too long. The remote link station returned a Frame Reject response. Alert ID Number X'87180BF5’...
- Page 41 Event Log Message Host Console Message A LAN logical link has been lost. The remote link station sent an invalid or unsuppor ted Alert Condition command or response to the local link station. The local link station returned a Frame Reject response.
- Page 42 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost. The remote link station sent an I-field to the local link station when not permitted. The local link station returned a Frame Reject response. Alert ID Number X'2C2E36EA’...
- Page 43 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost. The remote station sent a fram e with an invalid N(r ). The local link station returned a Fram e Reject r esponse. Alert ID Number X'216D1033’...
- Page 44 Event Log Message Host Console Message Alert Condition A LAN logical link has been lost. The r emote station sent a fram e with an i-field that was too long. The local link station retur ned a Frame Reject response. Alert ID Number X'25AC0D84’...
- Page 45 Event Log Message Host Console Message Alert Condition Excessive CRC errors received. Line is shut down and is retried once each minute. Alert ID Number X'C08037D8’ Alert Type X'01’ Alert Description X'3300’ Probable Causes X'2031' X'2104’ User Causes (none) Install Causes (none) Failure Causes X'3511'...
- Page 46 Event Log Message Host Console Message Alert Condition A fatal transmit error detected. The line is shutdown and is retried later. Alert ID Number X'32E516A1’ Alert Type X'01’ Alert Descr iption X'3300’ Probable Causes X'2031' X'2004’ User Causes (none) Install Causes (none) Failure Causes X'3511'...
- Page 47 Event Log Message Host Console Message An SDLC logical link has been lost. The primary link station sent an S or U frame with an Alert Condition unexpected I-field attached. Alert ID Number X'480F6C65’ Alert Type X'01’ Alert Description X'2100’ Probable Causes X'2004' X'1000’...
