Talkaphone AOR-8 Installation Manual

THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE
APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE
HAZARDS INVOLVED
CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE CODE D'INSTALLATION
PERTINENT, PAR UNE PERSONNE QUI CONNAÎT BIEN LES PRODUIT
ET SON FONCTIONNEMENT AINSI QUE LES RISQUES INHÉRENTS
I. Introduction
This installation guide provides instructions for installation, programming, and operation of Model
AOR-8 or Model AOR-16. For instructions on installation or programming of Talkaphone Area of
Rescue Call Stations, please refer to the manual for the AOR-CSE Analog Call Station.
It is recommended that this instruction set be read completely prior to the start of any installation.
II. Contents
Please ensure receipt of each of the included AOR-8 / AOR-16 components:
QTY Part Number
1 AOR-8 or AOR-16
2 68684
1 68430
Optional components (sold separately) include:
QTY Part Number
1 AOR-TR16
8 42970
Page 1 of 26
Copyright 2014-2021 Talk-A-Phone, LLC • 7530 North Natchez Avenue • Niles, Illinois 60714 • Phone 773.539.1100 • info@talkaphone.com • www.talkaphone.com.
All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of
Talk-A-Phone, LLC. All rights reserved. All other trademarks mentioned in this document or website are the property of their respective owners and does not imply or indicate
any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.
Area of Rescue Command Unit
Model AOR-8 / Model AOR-16
Description
8- or 16-Station Area of Rescue Command Unit
12VDC, 4.5Ah Backup Battery
Strobe/Siren
Description
Trim Ring for Flush Mounting Model AOR-8 or Model
AOR-16
6-18 Phillips Screw for Flush Mount Trim Ring
Installation Guide
Product Revision 2.0
Rev. 7/1/2021
