CAR70V 7”CAPACITIVE TOUCH SCREEN 2 DIN MULTIMEDIA MECHLESS RECEIVER AM-FM USB Media Player Rear Camera Input INSTALLATION & OWNER’S MANUAL...
Page 2
Copyright Notes This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
CAR70V PREPARATION Table of Contents Page Warning Statement ..........
Page 4
CAR70V PREPARATION WARNING Upon installation of this monitor/media player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside the vehicle and/or...
Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your JENSEN CAR70V is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.
CAR70V PREPARATION Preparation Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
CAR70V PREPARATION Wiring Diagram - Inputs/Outputs CarPlay and Android Auto 20PIN 18PIN Note: When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage. The unit uses (1) 15 amp ATC mini style fuse located on the power connector.
CAR70V PREPARATION Control Locations The radio display features the following functions and displays: RESET Home VOL+ Power/Mute VOL- Voice Activation Button IR sensor...
CAR70V PREPARATION Remote Control Preparation Power Volume Up Tune/Track Down Enter Mute Volume Down Preset 1~6 Repeat Play/Pause Talk MODE End Call Random BAND Tune/Track Up Voice Activation Button...
CAR70V PREPARATION General Operation Power On/Off Momentarily press to turn the unit on. Press and hold to turn the unit off. Volume Press to increase or decrease the volume level. Mute Momentarily press MUTE to silence the audio. Momentarily press MUTE again to return to the previously selected volume.
Page 11
CAR70V PREPARATION General Operation From the Main Menu screen, select Setup to access the Setting menu and Setup Menu select from eight categories represented by the icons on the top of the screen: General, Audio, Display, Others. Select the category, and adjust any of the available options using the touch screen.
CAR70V PREPARATION AM/FM Tuner Operation From the main menu, touch Radio icon on the screen to select AM/ Radio Operation FM tuner mode. Main Menu Press icon to return to Main Menu screen. Current Mode Indicator Display status of various tuning functions including Auto.
CAR70V PREPARATION USB Audio Operation From the main menu, touch the USB icon on the main screen. Main Menu Press icon to return to Main Menu screen. Current Mode Indicator Displays source currently playing. List Press icon to access a list of all files and folders on the device.
CAR70V PREPARATION USB Video Operation From the main menu, touch the USB icon on the main screen. Main Menu Press icon to return to Main Menu screen. Current Mode Indicator Displays source currently playing. Press the icon to adjust Equalizer setting.
CAR70V PREPARATION Media Compatibility File Type FAT 12 File System FAT 16/FAT 32 .mp3/.MP3/.Mp3/.mP3/.flac/ogg/.MP4/.Xvid File Extension .rmp/.m4a MPEG 1 MPEG MPEG 2 Format MPEG 2.5 MPEG 1 32/44.1/48kHz Sampling MPEG 2 12/16/22.05/24kHz Frequency MPEG 2.5 8/11.025/12kHz...
Page 16
CAR70V PREPARATION Media Compatibility Media Compatibility The following types of files are not compatible: • MP3 PRO format, MP3 playlists • RMP format • AAC, protected AAC, M4A format Playback Order MP3 playback sequence begins in the root folder of the USB device. Any empty folders or folders that do not include MP3 files are skipped.
Complete the pairing sequence from your Bluetooth device. Refer to the owner's manual for your device for more details. The device name is "CAR70V". The unit can be in any mode of operation when pairing is performed. On certain phones, pairing may need to be done more than once.
Page 18
CAR70V PREPARATION Bluetooth Operation Bluetooth Music Press MUSIC to transfer audio between the unit and mobile phone. Setup Press "SETUP" to access Bluetooth settings. Call Dial a number and touch the Phone icon to call. Phone Keypad Use the keypad to dial a phone number.
CAR70V PREPARATION Apple CarPlay Operation Apple CarPlay™ is a smart interface for iPhone, allowing you to voice-control (via Siri) music, navigation, phone and messaging apps - significantly reducing driver distraction. Phone - Use Siri to make calls, return missed calls, listen to voicemail messages, and view the caller ID on the receiver’s screen.
Page 20
CAR70V PREPARATION Apple CarPlay Operation When the CarPlay menu is displayed, the home button in the lower left corner work just like the home button on your iPhone. Press and hold it to summon Siri and begin your voice commands.
CAR70V PREPARATION Android Auto™ Operation Android Auto™ brings the most useful apps to your phone screen or your compatible car display, in a format that makes it easy for you to keep your main focus on driving. You can control things like navigation and maps, calls and text messages, and music.
Page 22
CAR70V PREPARATION Android Auto™ Operation Using Android Auto™ The Android Auto™ home screen displays personalized information, like time to your destination, reminders, recent calls incoming messages, the song you're listening to, and Google Now cards. When the Android Auto™ menu is displayed, you can say "OK Google" or select the microphone in the upper right corner to talk to Google.
CAR70V PREPARATION Rear RCA Input A/V IN Connect an optional audio/video source into the RCA (rear) input. Adjust volume on the external audio source as needed (if connected to the headphone output of the device). Rear Camera Operation - (Optional) Using Rear Camera Connect an optional rear camera to the Camera Input (Black RCA connector).
The built-in SWC Interface is compatible with PAC steering wheel control modules. The PAC SWI-RC is recommended. A third-party adapter must be used in order for the CAR70V to be compatible with any steering wheel controls. The following controls are available for most vehicles.
Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your JENSEN product. Dealer Name...
4. For more information and for the location of the original retail purchaser for products purchased from nearest authorized service center please contact an authorized JENSEN dealer and used in the U.S.A. us by one of the following methods: What is covered? This warranty covers all defects •...
