- Page 1 SmartSwitch 9000 9F206-02 Local Management Appendix 9031682-01...
- Page 3 This appendix contains local management information that is speciÞc to the 9F206-02 FDDI Repeater Module. The 9F206-02 FDDI Repeater Module physically attaches to the FNB-1 and the FNB-2 on the SmartSwitch 9000Õs FNB backplane. By default, the module inserts into four rings (the primary and secondary rings of the FNB-1 and the FNB-2).
- Page 4 FDDI-2 Figure 1. Front Panel Connections “Inserted” and “Bypassed” The 9F206-02 ConÞguration Screen (Figure 2), displays the current conÞguration of the moduleÕs front panel connections in relation to the FNB rings on the SmartSwitch 9000 backplane, and allows you to change the conÞguration.
- Page 5 The 9F206-02 Configuration Screen The 9F206-02 ConÞguration Screen (Figure 2), displays conÞguration and status information about the 9F206-02 Module. Module Name: Slot Number: FNB-1 Status: Port A Status: Port B Status: External Path: Configuration: FNB-2 Status: Port A Status: Port B Status:...
- Page 6 9F206-02 Module Specific Information 9F206-02 Configuration Screen Fields The following information brießy explains each 9F206-02 ConÞguration Screen Þeld. FNB-1 Status (Toggle) Allows you to control whether or not the moduleÕs FDDI-1 front panel ports will connect (insert) to the backplaneÕs FNB-1 rings (see Figure 1).
- Page 7 FDDI-2 front panel A and B ports. You can change the value in this Þeld from Primary to Secondary. A third value (Isolated) appears in this Þeld whenever the module is not inserted into the FNB-2 (i.e., when the value in the FNB-2 Status Þeld is ÒBypassedÓ). 9F206-02 Module Specific Information...
- Page 8 9F206-02 Module Specific Information (FNB-2) Configuration Indicates one of the following: ¥ FNB-2 is inserted (ÒInsertedÓ) on the backplane ring. ¥ FNB-2 is isolated (ÒBypassedÓ) from the backplane ring. DAS-2 Status Indicates the status of DAS-2: ¥ Dual Homed ¥ Isolated ¥...
- Page 9 If you exit without saving, the message ÒNOT SAVED -- PRESS SAVE TO KEEP CHANGESÓ appears. If you proceed to exit without saving, your edits will be lost. 4. Exit the screen by using the arrow keys to highlight RETURN , and then pressing the Return key. 9F206-02 Module Specific Information...
- Page 10 9F206-02 Module Specific Information...
