CDU415
CD-ROM Drive Unit
User's Guide
Mode d'emploi
Bedienungsanleitung
©1997 by Sony Corporation
Rev. 1.0
BKC: 98000268
CDU415
CD-ROM Drive Unit
User's Guide
Mode d'emploi
Bedienungsanleitung

Advertisement

Table of Contents
loading

Related Manuals for Sony CDU415

Summary of Contents for Sony CDU415

  • Page 1 CDU415 CD-ROM Drive Unit CDU415 CD-ROM Drive Unit User’s Guide Mode d’emploi Bedienungsanleitung User’s Guide Mode d’emploi ©1997 by Sony Corporation Rev. 1.0 Bedienungsanleitung BKC: 98000268...
  • Page 2 When you use this unit as a CD player, use compact discs located on the top of the drive. LASER KLASSE 1 with the following mark. Bei diesem CD-ROM-Laufwerk CDU415 PRODUKT handelt es sich um ein Laser-Produkt der Klasse 1. Ein entsprechender Aufkleber mit...

  • Page 3: Table Of Contents

    Ejecting the Disc ..................23 Note: Specifications The CDU415 is not equipped with an ADPCM audio circuitry required to support CD-ROM XA and CD-I compatible audio modes. In addition, the unit does not support the CD-I graphic decoding function; it has to be provided by the system.

  • Page 4: Software Requirement

    Flashing: Drawer in motion ID No.7 ID No.3 CDU415 Emergency eject hole Used to open the disc drawer manually when neither the eject button nor a software command works. Insert a pointed object, such as a paper clip, into this hole and push (approx. 40 mm stroke).

  • Page 5: Rear Panel

    Precautions Installation Rear Panel Pin 1 Avoid placing the drive in a location subject to: – high humidity – high temperature – excessive dust – mechanical vibration – direct sunlight The drive can be used in either a horizontal or vertical position. Do not force the power cable.

  • Page 6: Installing The Drive In Your Computer

    Installing the Drive in Your Computer This section provides the basic instructions you need to install the drive Removing the jumper from a jumper pin pair disables its corresponding and host adapter in your computer. You should also read the manual of function, and installing the jumper enables it.

  • Page 7: Opening The Computer

    Opening the Computer Preparing a Space for the Drive If your computer has its rear side covered by a plastic panel attached Remove the screws and brackets securing the floppy disk drive and the with plastic hook pad, pull it off. lower drive bay blanking plate.

  • Page 8: Mounting The Drive

    Mounting the Drive Connecting the Drive If mounting rails are necessary, attach them to the drive in the same way as Connect the drive to the computer with the following connectors: your floppy disk drive and slide the drive into the lower drive bay. DC INPUT connector If mounting rails are not required in your system, screw the drive in place.
  • Page 9 F. GND tab INTERFACE connector Connect the F. GND tab to one of the host computer’s ground cables Firmly insert one end of the interface cable into the INTERFACE unless the drive’s frame is in direct contact with the computer’s chassis CONNECTOR.

  • Page 10: Mounting The Host Adapter

    Mounting the Host Adapter Reassembling the Computer Install the host adapter in one of the available system expansion slots of your computer. Refer to the operating instructions included with the host Reinstall the floppy disk drive in the top drive bay. adapter for complete instructions on installation and settings.

  • Page 11: Installing The Software Driver

    Installing the Software Driver Operating the Drive The MSCDEX (or equivalent) and a device driver for the CD-ROM This section describes how to start the drive and eject a disc. drive are supplied with the host adapter. Install both the MSCDEX (or equivalent) and the device driver in order to use the CD-ROM drive.

  • Page 12: Ejecting The Disc

    Note: Ejecting the Disc When the drive is set up in vertical position, use the appropriate disc locks To eject the disc, press the eject button on the front panel. The drawer to prevent your disc from falling. comes out automatically. Disc locks Press the eject button.

  • Page 13: Specifications

    Specifications General Environmental conditions Host interface SCSI-2 Operating Disc Temperature 5 °C to 50 °C (41 °F to 122 °F) Acceptable discs CD-Digital Audio discs Humidity 10 % to 90 % (Max wet bulb 29 °C) CD EXTRA discs Atmosphere Non-condensing CD-ROM mode-1 data discs Non-operating/Storage...
  • Page 14 Dimension diagram Important: The overhang of the screws should not exceed 6.0 mm from the surface of the side panels or the bottom plate. 203 (8) 42.3 47.5 79.25 Design and specifications are subject to change without notice. Specifications...
