- Page 1 Mi Vacuum Cleaner Light User Manual...
-
Page 2: Safety Instructions
Safety Instructions This product is for household use only. Read this manual carefully before use, and retain it for future reference. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 3 Do not rest the vacuum cleaner against a chair, table, or other unstable surfaces, as this may cause damage to the product or personal injury. If the vacuum cleaner malfunctions because of being knocked over or damaged, please contact the authorized service department.
-
Page 4: Product Overview
Product Overview Equipped with a high-speed brushless motor, the Mi Vacuum Cleaner Light boasts the features including the powerful suction and a high-efficiency filtration system. High-speed brushless motor: Run rapidly with a stable output of strong suction for quick vacuuming. - Page 5 Product Overview 1 On/Off Button 2 Suction Level Button 3 MAX Indicator 4 Battery Level Indicator 5 Dust Compartment 6 Extension Rod Release Button 7 Extension Rod 8 Electric Floor Brush Release Button 9 Floor Brush Window 10 Wheels 11 Roller Brush 12 Cleaning Soft Brush 13 Roller Brush Button 14 Dust Compartment Window...
- Page 6 1 Power Adapter 2 Dust Compartment 3 HEPA Filter 4 Filter Cotton Cyclone Separator Cyclone Separator Handle 7 Long Nozzle 8 Flat Nozzle 9 Wall Mount...
-
Page 7: How To Install
How to Install Assembling the Vacuum Cleaner Installing the Accessories 1. Connect the extension rod to the 1. The long nozzle and flat nozzle can vacuum cleaner, as illustrated, until you be connected directly to the vacuum hear a click. cleaner or the extension rod. - Page 8 Fixing the Wall Mount 1. Drill two holes with each diameter of 6 mm on the wall at the height of 99.8–101.8 cm above the ground, and ensure there is a distance of 56 mm between two holes, then insert two wall plugs into the holes. 2.
-
Page 9: How To Use
How to Use Tuning on/off: Press and hold the on/off button for 1 second, then the vacuum cleaner starts working and it runs on the standard mode by default. Press the on/off button again to stop the vacuum cleaner. Press and hold the button for 5 seconds to turn off the vacuum cleaner. - Page 10 Turning On/Off & Vacuuming Press and hold the on/off button for 1 second, then the vacuum cleaner starts working and it runs on the standard mode by default. You can switch the mode as needed. Hold the handle of the vacuum cleaner by pushing it back and forth to vacuum and clean the floor with the floor brush.
-
Page 11: Storing Accessories
When the Vacuum Cleaner is Working When the battery level is low, the battery level indicator will blink red, please recharge the vacuum cleaner soon. If the vacuum cleaner runs on the standard mode, it cannot be switched to the turbo mode. If it is not recharged in time, the battery voltage will get too low, then the vacuum cleaner will automatically turn off to protect the battery. -
Page 12: Care And Maintenance
Care & Maintenance Note: Before cleaning or doing maintenance on the vacuum cleaner, turn it off and unplug it. Clean the dust compartment regularly to avoid the buildup of dust that could cause blockage and affect the suction. To prevent dust from falling on the floor, hold the dust compartment over a trash can to remove it. - Page 13 4. Place the cyclone separator and HEPA filter back into the dust compartment when the cleaning is completed. Align the unlock symbol " " with " " then rotate the dust compartment in the direction shown in the figure until " " is lined up with the lock symbol "...
-
Page 14: Cleaning The Roller Brush
Cleaning the Roller Brush 1. Press the roller brush button as 2. Cut off the hair and fibers attached shown in the figure to pop open the to the roller brush and remove them. roller brush cover, then pull out the roller brush to clean it. -
Page 15: Troubleshooting
Troubleshooting Issue Possible Cause Solution The vacuum 1. The battery level is low. 1. Charge the vacuum cleaner. cleaner does not 2. The vacuum cleaner is running for 2. Cool the vacuum cleaner down, work. a long time so that it is overheated. then use it again. -
Page 16: Specifications
Specifications Mi Vacuum Cleaner Light Model MJWXCQ03DY Item Dimensions 240 × 148 × 1132 mm Dust Compartment Capacity Approx. 0.5 L Battery Capacity 2500 mAh Net Weight Approx. 2.3 kg Charging Time Approx. 5 hours Input Current 0.5 A Input Voltage 26.0 V... -
Page 17: Precautions For Battery Use
Precautions for Battery Use The vacuum cleaner is in standby mode and cannot be used during charging. Only use the BLJ15W260050P-VA power adapter provided with the appliance. The lithium-on battery pack contains substances that are hazardous to the environment. Before disposing of the vacuum cleaner, please first remove the battery pack, then discard, or recycle it in accordance with local laws and regulations of the country or region it is used in.
