Page 1 This manual will be replaced with a hyperlinked version at the end of the model year. © 2007 Honda Motor Co., Ltd. P/N 31SAA6020...
Page 2 The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd. reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation whatsoever.
Page 3 ０６／１０／２６０９：５６：１５３１ＳＡＡ６０００００２ Congratulations! Your selection of a 2007 Honda Fit was a wise investment. It will give you years of driving pleasure. One of the best ways to enhance the enjoyment of your new vehicle is to read this manual. In it, you will learn how to operate its driving controls and convenience items.
Page 4 ０５／１２／２１１６：３５：４８３１ＳＡＡ６０００００３ A Few Words About Safety Your safety, and the safety of others, is very important. And operating this vehicle safely is an important responsibility. To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual.
Page 5 ０５／１２／２１１６：３５：５８３１ＳＡＡ６０００００４ Your Vehicle at a Glance (main controls) Driver and Passenger Safety (seat belts, SRS, and child protection) (indicators, gauges, dashboard, and steering column) Instruments and Controls (heating and cooling, audio, security, and cruise control) Features (fuel, vehicle break-in, and cargo loading) Before Driving Driving (engine and transmission operation)
Page 6 ０５／１２／２１１６：３６：１５３１ＳＡＡ６０００００５ Overview of Contents Contents A convenient reference to the sections in this manual. Your Vehicle at a Glance A quick reference to the main controls in your vehicle. Driver and Passenger Safety Important information about the proper use and care of your vehicle’s seat belts, an overview of the supplemental restraint system, and valuable information on how to...
Page 7: Your Vehicle At A Glance
０５／１２／２１１６：３６：２２３１ＳＡＡ６０００００６ INSTRUMENT PANEL INDICATORS GAUGES DRIVER’S FRONT AIRBAG (P.9, 25) ＊ MIRROR CONTROLS (P.94) POWER DOOR LOCK ＊ MASTER SWITCH (P.78) POWER WINDOW SWITCH (P.93) HOOD RELEASE HANDLE (P.134) PASSENGER AIRBAG OFF INDICATOR (P.31) ACCESSORY POWER SOCKET (P.98) A/T model is shown. ＊...
Page 8 ０５／１２／２１１６：３６：２９３１ＳＡＡ６０００００７ Your Vehicle at a Glance PADDLE SHIFTER ＊ (DOWNSHIFT) (P.156) HEADLIGHTS/TURN SIGNAL/ ＊ FOG LIGHTS (P.71) ＊ MIRROR CONTROLS (P.94) HOOD RELEASE HANDLE (P.134) STEERING WHEEL ADJUSTMENT (P.74) To use the horn, press the center pad of the steering wheel. ＊...
Page 9: Table Of Contents
０５／１２／２１１６：３６：３４３１ＳＡＡ６０００００８ This section gives you important information about how to protect yourself and your passengers. It shows you how to use seat belts. It explains how your airbags work. And it tells you how to properly restrain infants and children in your vehicle. Important Safety Precautions Your Vehicle’s Safety Features Seat Belts...
Page 10: Important Safety Precautions
０５／１２／２１１６：３６：４４３１ＳＡＡ６０００００９ Important Safety Precautions You’ll find many safety recommendations throughout this section, and throughout this manual. The recommendations on this page are the ones we consider to be the most important. Always Wear Your Seat Belt A seat belt is your best protection in all types of collisions.
Page 11: Your Vehicle's Safety Features
０５／１２／２１１６：３６：５２３１ＳＡＡ６００００１０ (11) (10) (1) Safety Cage (2) Crush Zones (3) Seats and Seat-Backs (4) Head Restraints (5) Collapsible Steering Column (6) Seat Belts (7) Front Airbags (8) Side Airbags (9) Side Curtain Airbags (10) Front Seat Belt Tensioners (11) Door Locks Your Vehicle’s Safety Features Your vehicle is equipped with many features that work together to...
Page 12: Seat Belts
０５／１２／２１１６：３７：０３３１ＳＡＡ６００００１１ Your Vehicle’s Safety Features Seat Belts Your vehicle is equipped with seat belts in all seating positions. Your seat belt system also includes an indicator on the instrument panel and a beeper to remind you and your passengers to fasten your seat belts. Why Wear Seat Belts Seat belts are the single most effective safety device for adults and...
Page 13: Airbags
０５／１２／２１１６：３７：１０３１ＳＡＡ６００００１２ Airbags Your vehicle has a supplemental restraint system (SRS) with front airbags to help protect the heads and chests of the driver and a front seat passenger during a moderate to severe frontal collision (see page for more information on how your front airbags work).
Page 14 ０５／１２／２１１６：３７：１６３１ＳＡＡ６００００１３ Your Vehicle’s Safety Features The most important things you need to know about your airbags are: Airbags do not replace seat belts. They are designed to supplement the seat belts. Airbags offer no protection in rear impacts, or minor frontal or side collisions.
Page 15: Protecting Adults And Teens
０５／１２／２１１６：３７：２６３１ＳＡＡ６００００１４ Introduction The following pages provide instructions on how to properly protect the driver, adult passengers, and teenage children who are large enough and mature enough to drive or ride in the front. See pages for important − guidelines on how to properly protect infants, small children, and larger children who ride in your vehicle.
Page 16: Adjust The Seat-Backs
０５／１２／２１１６：３７：３４３１ＳＡＡ６００００１５ Protecting Adults and Teens If you sit too close to the steering wheel or dashboard, you can be seriously injured by an inflating front airbag, or by striking the steering wheel or dashboard. The National Highway Traffic Safety Administration and Transport Canada recommend that drivers allow at least 10 inches (25 cm) between the center of the steering...
Page 17: Adjust The Head Restraints
０５／１２／２１１６：３７：４３３１ＳＡＡ６００００１６ Reclining the seat-back too far can result in serious injury or death in a crash. Adjust the seat-back to an upright position, and sit well back in the seat. Reclining a seat-back so that the shoulder part of the belt no longer rests against the occupant’s chest reduces the protective capability of the belt.
Page 18: Fasten And Position The Seat Belts
０５／１２／２１１６：３７：５０３１ＳＡＡ６００００１７ Protecting Adults and Teens Fasten and Position the Seat Belts Insert the latch plate into the buckle, then tug on the belt to make sure the belt is securely latched. Check that the belt is not twisted, because a twisted belt can cause serious injuries in a crash.
Page 19: Maintain A Proper Sitting Position
０５／１２／２１１６：３７：５８３１ＳＡＡ６００００１８ RELEASE BUTTONS The front seats have adjustable seat belt anchors. To adjust the height of an anchor, squeeze the two release buttons, and slide the anchor up or down as needed (it has four positions). Protecting Adults and Teens Never place the shoulder portion of a lap/shoulder belt under your arm or This could cause...
Page 20: Advice For Pregnant Women
０５／１２／２１１６：３８：０５３１ＳＡＡ６００００１９ Protecting Adults and Teens In addition, an occupant who is out of position in the front seat can be seriously or fatally injured in a crash by striking interior parts of the vehicle or being struck by an inflating front airbag. Sitting improperly or out of position can result in serious injury or death in a crash.
Page 21: Additional Safety Precautions
０５／１２／２１１６：３８：１４３１ＳＡＡ６００００２０ Additional Safety Precautions Never let passengers ride in the cargo area or on top of a folded- If they do, they down back seat. could be very seriously injured in a crash. Never let passengers ride in the area in front of a folded-up rear seat or on top of a folded-down rear seat.
Page 22: Additional Information About Your Seat Belts
０６／０２／０２１４：０４：０７３１ＳＡＡ６００００２１ Additional Information About Your Seat Belts Seat Belt System Components Your seat belt system includes lap/ shoulder belts in all five seating positions. The front seat belts are also equipped with automatic seat belt tensioners. This system uses the same sensors as the front airbags to monitor whether the front seat belts are latched or unlatched, and how much...
Page 23: Lap/Shoulder Belt
０５／１２／２１１６：３８：３２３１ＳＡＡ６００００２２ Lap/Shoulder Belt The lap/shoulder belt goes over your shoulder, across your chest, and across your hips. To fasten the belt, insert the latch plate into the buckle, then tug on the belt to make sure the buckle is latched (see page for how to properly position the belt).
Page 24: Automatic Seat Belt Tensioners
). Any belt that is not in good condition or working properly will not provide good protection and should be replaced as soon as possible. Honda provides a limited warranty on seat belts for U.S. models. See your Honda Warranty Information booklet for details.
Page 25: Additional Information About Your Seat Belts
０５／１２／２１１６：３８：４５３１ＳＡＡ６００００２４ If a seat belt is worn during a crash, it must be replaced by your dealer. A belt that has been worn during a crash may not provide the same level of protection in a subsequent crash. The dealer should also inspect the anchors for damage and replace them if needed.
Page 26: Additional Information About Your Airbags
０５／１２／２１１６：３８：５１３１ＳＡＡ６００００２５ Additional Information About Your Airbags Airbag System Components (1) Driver’s Front Airbag (2) Passenger’s Front Airbag (3) Control Unit (4) Front Seat Belt Tensioners (5) Side Airbags (6) Driver’s Seat Position Sensor (7) Front Passenger’s Weight Sensors (8) Front Impact Sensors (9) Passenger Airbag Off Indicator (10) Occupant Position Detection System (OPDS) Sensors (11) Front Passenger’s Weight Sensors/OPDS Sensors Control Unit...
Page 27 ０５／１２／２１１６：３８：５８３１ＳＡＡ６００００２６ (15) (16) (14) Side Curtain Airbags (15) Side Impact Sensors (First) (16) Side Impact Sensors (Second) Additional Information About Your Airbags (14) (16) (15) Your airbag system includes: Two SRS (supplemental restraint system) front airbags. The driver’s airbag is stored in the center of the steering wheel;...
Page 28 ０５／１２／２１１６：３９：０７３１ＳＡＡ６００００２７ Additional Information About Your Airbags Automatic front seat belt tensioners (see page Sensors that can detect a moderate to severe front impact or side impact. Sensors that can detect whether a child is in the passenger’s side airbag path and signal the control unit to turn the airbag off (see page Sensors that can detect whether...
Page 29: How Your Front Airbags Work
０５／１２／２１１６：３９：１６３１ＳＡＡ６００００２８ How Your Front Airbags Work If you ever have a moderate to severe frontal collision, sensors will detect the vehicle’s rapid deceleration. If the rate of deceleration is high enough, the control unit will instantly inflate the driver’s and front passenger’s airbags, at the time and with the force needed.
Page 30 ０５／１２／２１１６：３９：２４３１ＳＡＡ６００００２９ Additional Information About Your Airbags After a crash, you may see what looks like smoke. This is actually powder from the airbag’s surface. Although the powder is not harmful, people with respiratory problems may experience some temporary discomfort. If this occurs, get out of the vehicle as soon as it is safe to do Dual-Stage Airbags Your front airbags are dual-stage...
Page 31 SEAT WEIGHT SENSOR The passenger’s advanced front airbag system has weight sensors under the seat. Although Honda does not encourage carrying an infant or small child in front, if the sensors detect the weight of an infant or small child (up to about 65 lbs or 29 kg), the system will automatically turn the passenger’s...
Page 32: How Your Side Airbags Work
０５／１２／２１１６：３９：４３３１ＳＡＡ６００００３１ Additional Information About Your Airbags When the airbag is turned off, a ‘‘passenger airbag off’’ indicator in the center of the dashboard comes on (see page If the weight sensors detect there is no passenger in the front seat, the airbag will be off.
Page 33 Your vehicle has a side airbag cutoff system designed primarily to protect a child riding in the front passenger’s seat. Although Honda does not encourage children to ride in front, if sensors in the seat detect a child has leaned into the side airbag’s deployment path, the airbag will shut off.
Page 34: How Your Side Curtain Airbags Work
０５／１２／２１１６：４０：０１３１ＳＡＡ６００００３３ Additional Information About Your Airbags How Your Side Curtain Airbags Work SIDE CURTAIN AIRBAG In a moderate to severe side impact, sensors will detect rapid acceleration and signal the control unit to instantly inflate the side curtain airbag and activate the seat belt tensioner on the driver’s or the passenger’s side of the vehicle.
Page 35: How The Side Airbag Off Indicator Works
０５／１２／２１１６：４０：１０３１ＳＡＡ６００００３４ If you see any of these indications, the airbags and seat belt tensioners may not work properly when you need them. Ignoring the SRS indicator can result in serious injury or death if the airbag systems or tensioners do not work properly. Have your vehicle checked by a dealer as soon as possible if the SRS indicator alerts you to...
Page 36: Airbag Service
０５／１２／２１１６：４０：２０３１ＳＡＡ６００００３５ Additional Information About Your Airbags Be aware that objects placed on the front seat can cause the indicator to come on. If no weight is detected on the front seat, the airbag will be automatically shut off. However, the indicator will not come on.
Page 37: Additional Safety Precautions
This could make the dealer. driver’s seat position sensor or the front passenger’s weight sensors ineffective. If it is necessary to remove or modify a front seat to accommodate a person with disabilities, first contact Honda Automobile Customer Service at (800) 999-1009.
Page 38: Protecting Children − General Guidelines
０５／１２／２１１６：４０：３４３１ＳＡＡ６００００３７ Protecting Children − General Guidelines Children depend on adults to protect them. However, despite their best intentions, many adults do not know how to properly protect child passengers. If you have children, or ever need to drive with a child in your vehicle, be sure to read this section.
Page 39: All Children Should Sit In A Back Seat
０５／１２／２１１６：４０：４３３１ＳＡＡ６００００３８ All Children Should Sit in a Back Seat According to accident statistics, children of all ages and sizes are safer when they are restrained in a back seat. The National Highway Traffic Safety Administration and Transport Canada recommend that all children aged 12 and under be properly restrained in a back seat.
Page 40: General Guidelines
０５／１２／２１１６：４０：５６３１ＳＡＡ６００００３９ Protecting Children − General Guidelines To remind you of the passenger’s front airbag hazards, and that children must be properly restrained in a back seat, your vehicle has warning labels on the dashboard (U.S. models) and on the front visors. Please read and follow the instructions on these labels.
Page 41: If You Must Drive With Several Children
０５／１２／２１１６：４１：０４３１ＳＡＡ６００００４０ If You Must Drive with Several Children Your vehicle has a back seat where children can be properly restrained. If you ever have to carry a group of children, and a child must ride in front: Place the largest child in the front seat, provided the child is large enough to wear the lap/shoulder belt properly (see page...
Page 42: Additional Safety Precautions
０５／１２／２１１６：４１：１３３１ＳＡＡ６００００４１ Protecting Children − General Guidelines Additional Safety Precautions Never hold an infant or child on If you are not wearing a your lap. seat belt in a crash, you could be thrown forward and crush the child against the dashboard or a seat-back.
Page 43: Protecting Infants And Small Children
０５／１２／２１１６：４１：２２３１ＳＡＡ６００００４２ Protecting Infants Child Seat Type An infant must be properly restrained in a rear-facing, reclining child seat until the child reaches the seat maker’s weight or height limit for the seat, and the child is at least one year old. Only a rear-facing child seat provides proper support for a baby’s head, neck, and back.
Page 44: Protecting Small Children
０５／１２／２１１６：４１：３０３１ＳＡＡ６００００４３ Protecting Infants and Small Children In any of these situations, we strongly recommend that you install the child seat directly behind the front passenger’s seat, move the seat as far forward as needed, and leave it unoccupied. Or, you may wish to get a smaller rear-facing child seat.
Page 45: Selecting A Child Seat
０５／１２／２１１６：４１：４０３１ＳＡＡ６００００４４ Even with advanced front airbags that automatically turn the passenger’s front airbag off (see page ), a back seat is the safest place for a small child. If it is necessary to put a forward- facing child seat in the front, move the vehicle seat as far to the rear as possible, and be sure the child seat is firmly secured to the vehicle and the...
Page 46: Installing A Child Seat
０５／１２／２１１６：４１：４８３１ＳＡＡ６００００４５ Selecting a Child Seat, Installing a Child Seat The child seat should fit the vehicle seating position (or positions) where it will be used. Before purchasing a conventional child seat, or using a previously purchased one, we recommend that you test the seat in the specific vehicle seating position or positions where the seat will be used.
Page 47: With Latch
０５／１２／２１１６：４１：５７３１ＳＡＡ６００００４６ Installing a Child Seat with LATCH Your vehicle is equipped with LATCH (lower anchors and tethers for children) at the outer rear seats. The lower anchors are located between the seat-back and seat bottom, and are to be used only with a child seat designed for use with LATCH.
Page 48 ０５／１２／２１１６：４２：０５３１ＳＡＡ６００００４７ Installing a Child Seat Flexible type Other LATCH-compatible seats have a flexible-type connector as shown above. Whatever type you have, follow the child seat maker’s instructions for adjusting or tightening the fit. Route the tether strap over the seat-back and through the head restraint legs.
Page 49: With A Lap/Shoulder Belt
０５／１２／２１１６：４２：１４３１ＳＡＡ６００００４８ Installing a Child Seat with a Lap/ Shoulder Belt When not using the LATCH system, all child seats must be secured to the vehicle with the lap part of a lap/ shoulder belt. In addition, the lap/shoulder belts in all seating positions except the driver’s have a locking mechanism that must be activated to secure a...
Page 50 ０５／１２／２１１６：４２：２０３１ＳＡＡ６００００４９ Installing a Child Seat After confirming that the belt is locked, grab the shoulder part of the belt near the buckle, and pull up to remove any slack from the lap part of the belt. Remember, if the lap part of the belt is not tight, the child seat will not be secure.
Page 51: With A Tether
０５／１２／２１１６：４２：２８３１ＳＡＡ６００００５０ Installing a Child Seat with a Tether A child seat with a tether can be installed in any seating position in the back seat. Each rear outside seating position has an anchorage point on the seat- back, and the center seating position has an anchorage point in the ceiling near the tailgate.
Page 52 ０５／１２／２１１６：４２：３５３１ＳＡＡ６００００５１ Installing a Child Seat Using the Center Anchor ANCHOR COVER Remove the rear center head restraint, and store it in a safe place. After properly securing the child seat (see page ), open the anchor cover. ANCHOR TETHER STRAP HOOK Route the tether strap over the seat-back, then attach the tether strap hook to the anchor, making...
Page 53: Protecting Larger Children
０５／１２／２１１６：４２：４３３１ＳＡＡ６００００５２ When a child reaches the recommended weight or height limit for a forward-facing child seat, the child should sit in a back seat on a booster seat and wear a lap/shoulder belt. The following pages give instructions on how to check proper seat belt fit, what kind of booster seat to use if one is needed, and important precautions for a child...
Page 54: Using A Booster Seat
０５／１２／２１１６：４２：５１３１ＳＡＡ６００００５３ Protecting Larger Children Does the shoulder belt cross between the child’s neck and arm? Is the lap part of the belt as low as possible, touching the child’s thighs? Will the child be able to stay seated like this for the whole trip? If you answer yes to all these questions, the child is ready to wear the lap/shoulder belt correctly.
Page 55: When Can A Larger Child Sit In Front
０５／１２／２１１６：４３：０１３１ＳＡＡ６００００５４ If a child who uses a booster seat must ride in front, move the vehicle seat as far back as possible and be sure the child is wearing the seat belt properly. A child may continue using a booster seat until the tops of their ears are even with the top of the vehicle’s or booster’s seat-back.
Page 56: Additional Safety Precautions
０５／１２／２１１６：４３：０９３１ＳＡＡ６００００５５ Protecting Larger Children If you decide that a child can safely ride up front, be sure to: Carefully read the owner’s manual, and make sure you understand all seat belt instructions and all safety information. Move the vehicle seat to the rear- most position.
Page 57: Carbon Monoxide Hazard
０５／１２／２６１３：２２：０２３１ＳＡＡ６００００５６ Your vehicle’s exhaust system contains carbon monoxide gas. Carbon monoxide should not enter the vehicle in normal driving if you maintain your vehicle properly and follow the information on this page. Have the exhaust system inspected for leaks whenever: The vehicle is raised for an oil change.
Page 58: Safety Labels
０５／１２／２１１６：４３：３１３１ＳＡＡ６００００５７ Safety Labels These labels are in the locations SUN VISORS shown. They warn you of potential U.S. models Canadian models hazards that could cause serious injury or death. Read these labels carefully. If a label comes off or becomes hard to read (except for the U.S.
Page 59 ０５／１２／２１１６：４３：４５３１ＳＡＡ６００００５８ Safety Labels HOOD RADIATOR CAP DOORJAMBS U.S. models U.S. models Canadian models Canadian models...
Page 60 ０５／１２／２１１６：４３：４７３１ＳＡＡ６００００５９ ...
Page 61: Instruments And Controls
０５／１２／２１１６：４３：５１３１ＳＡＡ６００００６０ This section gives information about the controls and displays that contribute to the daily operation of your vehicle. All the essential controls are within easy reach. Control Locations . 58 Instrument Panel . 59 Instrument Panel Indicators . 60 Gauges .
Page 62: Control Locations
０５／１２／２１１６：４３：５８３１ＳＡＡ６００００６１ Control Locations DRIVER’S FRONT AIRBAG (P.9, 25) ＊ MIRROR CONTROLS (P.94) POWER DOOR LOCK MASTER ＊ SWITCH (P.78) POWER WINDOW SWITCH (P.93) HOOD RELEASE HANDLE (P.134) PASSENGER AIRBAG OFF INDICATOR (P.31) ＊ : If equipped HAZARD WARNING INSTRUMENT PANEL INDICATORS (P.60) BUTTON GAUGES...
Page 63: Instrument Panel
０５／１２／２１１６：４４：０７３１ＳＡＡ６００００６２ SECURITY SYSTEM INDICATOR (P.65) HIGH BEAM INDICATOR (P.64) MALFUNCTION INDICATOR LAMP (P.219) CHARGING SYSTEM INDICATOR (P.60, 218) LOW OIL PRESSURE INDICATOR IMMOBILIZER (P.60, 218) SYSTEM INDICATOR (P.65) DOOR AND TAILGATE OPEN INDICATOR The U.S. Sport instrument panel is shown. Differences for other models are noted in the text. PARKING BRAKE AND BRAKE SYSTEM INDICATOR (P.60, 220)
Page 64: Instrument Panel Indicators
０５／１２／２１１６：４４：１７３１ＳＡＡ６００００６３ Instrument Panel Indicators The instrument panel has many indicators that give you important information about your vehicle. Malfunction Indicator Lamp See page Low Oil Pressure Indicator The engine can be severely damaged if this indicator flashes or stays on when the engine is running.
Page 65 ０５／１２／２１１６：４４：２５３１ＳＡＡ６００００６４ If your front passenger does not fasten their seat belt, the indicator comes on about 6 seconds after the ignition switch is turned to the ON (II) position. If either of you do not fasten your seat belt while driving, the beeper will sound and the indicator will flash again at regular intervals.
Page 66 ０５／１２／２１１６：４４：３４３１ＳＡＡ６００００６５ Instrument Panel Indicators Anti-lock Brake System (ABS) Indicator This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position. If it comes on at any other time, there is a problem with the ABS.
Page 67 ０５／１２／２１１６：４４：４１３１ＳＡＡ６００００６６ High Temperature Indicator This indicator monitors the temperature of the engine coolant. It normally comes on when you turn the ignition switch to the ON (II) position and goes off after a few seconds. In normal driving conditions, this indicator should not blink or stay on.
Page 68 ０５／１２／２１１６：４４：５５３１ＳＡＡ６００００６７ Instrument Panel Indicators Lights On Indicator This indicator reminds you that the exterior lights are on. It comes on when the light switch is in either the position. If you turn the ignition switch to the ACCESSORY (I) or LOCK (0) position without turning off the light switch, this indicator will stay on.
Page 69 ０５／１２／２１１６：４５：０４３１ＳＡＡ６００００６８ Maintenance Minder Indicator This indicator comes on for a few seconds when you turn the ignition switch to the ON (II) position. This indicator reminds you that it is time to take your vehicle in for scheduled maintenance. The maintenance main items and sub items will be displayed in the information display.
Page 70: Gauges
０５／１２／２１１６：４５：１１３１ＳＡＡ６００００６９ Gauges TACHOMETER SPEEDOMETER INFORMATION DISPLAY U.S. model is shown. Trip Meter This meter shows the number of miles (U.S.) or kilometers (Canada) SELECT/RESET KNOB driven since you last reset it. FUEL GAUGE There are two trip meters: Trip A and Trip B.
Page 71: Odometer
０５／１２／２１１６：４５：１９３１ＳＡＡ６００００７０ Odometer The odometer shows the total distance your vehicle has been driven. It measures miles in U.S. models and kilometers in Canadian models. It is illegal under U.S. federal law and Canadian provincial regulations to disconnect, reset, or alter the odometer with the intent to change the number of miles or kilometers indicated.
Page 72: Maintenance Minder
０５／１２／２１１６：４５：２３３１ＳＡＡ６００００７１ Gauges Maintenance Minder The information display in the instrument panel shows you the engine oil life and maintenance service items when the ignition switch is in the ON (II) position. This information helps to keep you aware of the periodic maintenance your vehicle needs for continued trouble- free driving.
Page 73: Controls Near The Steering Wheel
０５／１２／２１１６：４５：３１３１ＳＡＡ６００００７２ PADDLE SHIFTER (DOWNSHIFT) (P.156) HEADLIGHTS/TURN ＊ SIGNAL/FOG LIGHTS (P.71) ＊ MIRROR CONTROLS (P.94) HOOD RELEASE HANDLE (P.134) STEERING WHEEL ADJUSTMENT (P.74) To use the horn, press the center pad of the steering wheel. ＊ If equipped. ＊ Controls Near the Steering Wheel ＊...
Page 74: Windshield Wipers And Washers
０５／１２／２１１６：４５：４２３１ＳＡＡ６００００７３ Windshield Wipers and Washers Windshield Wiper MIST − Intermittent − Low speed − High speed Windshield washers Push the right lever up or down to select a position. MIST The wipers run at high − speed until you release the lever. The wipers are not activated.
Page 75: Turn Signals And Headlights
０５／１２／２１１６：４５：５０３１ＳＡＡ６００００７４ Hold past ON to turn the rear window wiper on and to spray the rear window washer. Rotate the switch counterclockwise to spray the window washer. The rear window washer uses the same fluid reservoir as the wind- shield washer. Windshield Wipers and Washers, Turn Signal and Headlights Turn Signal and Headlights Turn signal...
Page 76 ０５／１２／２１１６：４６：００３１ＳＡＡ６００００７５ Headlights Headlights Turning the switch to − the ‘‘ ’’ position turns on the parking lights, taillights, instrument panel lights, side-marker lights, and rear license plate lights. Turning the switch to the ‘‘ ’’ position turns on the headlights. When the light switch is in the ‘‘...
Page 77: Instrument Panel Brightness
０５／１２／２１１６：４６：０９３１ＳＡＡ６００００７６ Instrument Panel Brightness, Hazard Warning Button, Rear Window Defogger Instrument Panel Brightness INSTRUMENT PANEL BRIGHTNESS CONTROL KNOB You can change the instrument panel brightness only when the light switch is on. Turn the knob on the upper part of the instrument panel to adjust the brightness.
Page 78: Steering Wheel Adjustment
０５／１２／２１１６：４６：１７３１ＳＡＡ６００００７７ Rear Window Defogger, Steering Wheel Adjustment Make sure the rear window is clear and you have good visibility before starting to drive. The defogger wires on the inside of the rear window can be accidentally damaged. When cleaning the glass, always wipe side-to-side.
Page 79: Keys And Locks
You will need this key number if you ever have to get a lost key replaced. Use only Honda-approved key blanks. These keys contain electronic circuits that are activated by the immobilizer system. They will not work to start the engine if the circuits are damaged.
Page 80: Immobilizer System
０５／１２／２１１６：４６：３２３１ＳＡＡ６００００７９ Immobilizer System The immobilizer system protects your vehicle from theft. If an improperly-coded key (or other device) is used, the engine’s fuel system is disabled. When you turn the ignition switch to the ON (II) position, the immobilizer system indicator should come on for a few seconds, then go off.
Page 81: Ignition Switch
０５／１２／２１１６：４６：４１３１ＳＡＡ６００００８０ The ignition switch has four positions: LOCK (0), ACCESSORY (I), ON (II), and START (III). LOCK (0) − You can insert or remove the key only in this position. To turn the key, push it in slightly. If your vehicle has an automatic transmission, the shift lever must also be in park.
Page 82: Door Locks
０５／１２／２１１６：４６：５０３１ＳＡＡ６００００８１ Door Locks, Power Door Locks Door Locks Each door has a lock tab on the top of the door. Push in the tab to lock the door, and pull it out to unlock. On Canadian DX model To lock the passenger’s door when getting out of the vehicle, push in the lock tab and close the door.
Page 83: Childproof Door Locks
０５／１２／２１１６：４６：５７３１ＳＡＡ６００００８２ The lock tab on each passenger’s door locks and unlocks only that door. Pulling up the driver’s lock tab only unlocks the driver’s door. To unlock only the driver’s door from the outside, turn the key and release it. If you turn it again, the remaining doors and the tailgate unlock.
Page 84: Tailgate
０５／１２／２１１６：４７：０３３１ＳＡＡ６００００８３ Tailgate All models except Canadian DX The tailgate will lock or unlock when you lock or unlock the driver’s door by using the key, the lock tab on the driver’s door, the master door lock switch or the remote transmitter (if equipped).
Page 85 ０５／１２／２１１６：４７：１２３１ＳＡＡ６００００８４ TAILGATE HANDLE To close the tailgate, hold the tailgate handle, lower the tailgate, then press down on the back edge. Keep the tailgate closed at all times while driving to avoid damaging the tailgate and to prevent exhaust gas from getting into the interior.
Page 86: Remote Transmitter
０５／１２／２１１６：４７：１８３１ＳＡＡ６００００８５ Remote Transmitter LOCK BUTTON UNLOCK BUTTON PANIC BUTTON On Sport model LOCK − Press this button once to lock all doors and the tailgate. Some exterior lights will flash once. When you push LOCK twice within 5 seconds, the horn will sound to verify that the doors and the tailgate are locked and the security system has set.
Page 87 ０５／１２／２１１６：４７：２９３１ＳＡＡ６００００８６ Remote Transmitter Care Avoid dropping or throwing the transmitter. Protect the transmitter from extreme temperature. Do not immerse the transmitter in any liquid. If you lose a transmitter, the replacement needs to be reprogrammed by your dealer. Replacing the Transmitter Battery SCREW If it takes several pushes on the...
Page 88 ０６／１０／２６０９：５６：２１３１ＳＡＡ６００００８７ Remote Transmitter Remove the old battery, and insert a new battery into the back of the cover with the side facing down. ＋ An improperly disposed of battery can hurt the environment. Always confirm local regulations for battery disposal. Install the parts in reverse order.
Page 89: Seats
０５／１２／２１１６：４７：４２３１ＳＡＡ６００００８８ Front Seat Adjustments See pages − for important safety information and warnings about how to properly position the seats and seat- backs. Make all seat adjustments before you start driving. To adjust the seat forward and backward, pull up on the lever under the seat cushion’s front edge.
Page 90 ０５／１２／２１１６：４７：５０３１ＳＡＡ６００００８９ Seats To change the seat-back angle of the front seat, pull up the lever on the outside of the seat bottom. Once your seat is adjusted correctly, rock it back and forth to make sure it is locked in position. Rear Seat Adjustments LEVER You can adjust the angle of the rear...
Page 91 ０５／１２／２１１６：４７：５６３１ＳＡＡ６００００９０ RELEASE BUTTON FRONT The front head restraints adjust for height. You need both hands to adjust a restraint. Do not attempt to adjust it while driving. To raise it, pull upward. To lower the restraint, push the release button sideways, and push the restraint down.
Page 92 ０５／１２／２１１６：４８：０５３１ＳＡＡ６００００９１ Seats Reclining the Front Seats SEAT-BACK ANGLE ADJUSTMENT LEVER You can recline the seat-backs on the front seats so they are level with the rear seat cushions, making a large cushioned area. To do this: Recline the rear seat-backs as far backward as possible (see page SLIDE LEVER Remove the front head restraints...
Page 93 ０５／１２／２１１６：４８：１２３１ＳＡＡ６００００９２ Folding the Rear Seat Up The left and right rear seat cushions can be lifted up separately to make room for cargo. Remove any items from the seat before you fold up the seat cushion. Pull up the rear seat cushion, and fold the seat leg down.
Page 94 ０５／１２／２１１６：４８：２１３１ＳＡＡ６００００９３ Seats Folding the Rear Seat Down The rear seat-backs can be folded down for more cargo room. Each side folds down separately, so you can still carry a passenger in the rear outer seating position. Remove any items from the seat before folding down the seat-back.
Page 95 ０５／１２／２１１６：４８：２８３１ＳＡＡ６００００９４ Move the front seat backward to the desired position. Make sure the seat is locked in place. Do not put any heavy items on the seat-back when it is folded. Make sure that the folded down rear seat does not interfere with the front passenger’s seat-back.
Page 96 ０５／１２／２１１６：４８：３６３１ＳＡＡ６００００９５ Seats Detachable Anchor The seat belt in the rear center seat is equipped with a detachable anchor. This allows the center seat belt to be unlatched when the driver’s side rear seat is folded. Using a seat belt with the detachable anchor unlatched increases the chance of serious injury or death in a crash.
Page 97 ０５／１２／２１１６：４８：４４３１ＳＡＡ６００００９６ ANCHOR BUCKLE LATCH PLATE To unlatch the detachable anchor, insert the latch plate into the slot on the side of the anchor buckle. Store the detachable anchor and seat belt latch plates in the retractor housing. Power Windows DRIVER’S WINDOW SWITCH MAIN SWITCH Turn the ignition switch to the ON (II) position to raise or lower any...
Page 98 ０５／１２／２１１６：４８：５１３１ＳＡＡ６００００９７ Power Windows, Mirrors When you push the MAIN switch in, the switch is off, and the passenger windows cannot be raised or lowered. To cancel this feature, push on the switch again to get it to pop out. Keep the MAIN switch off when you have children in the vehicle so they do not injure themselves by operating the windows...
Page 99: Mirrors, Parking Brake
０５／１２／２１１６：４８：５７３１ＳＡＡ６００００９８ Push the appropriate edge of the adjustment switch to move the mirror right, left, up, or down. When you finish, move the selector switch to the center (off) position. This turns the adjustment switch off to keep your settings. Parking Brake PARKING BRAKE LEVER To apply the parking brake, pull the...
Page 100 ０５／１２／２１１６：４９：０３３１ＳＡＡ６００００９９ Interior Convenience Items COAT HOOK SEAT-BACK POCKET REAR SIDE POCKET (RIGHT SIDE) FRONT DOOR VANITY MIRROR POCKET ACCESSORY BEVERAGE HOLDERS POWER SOCKET SUN VISOR COIN TRAY CENTER POCKET PASSENGER’S TRAY GLOVE BOX...
Page 101 ０５／１２／２１１６：４９：０９３１ＳＡＡ６０００１００ Beverage Holders Be careful when you are using the beverage holders. A spilled liquid that is very hot can scald you or your passengers. Liquid can also spill from the door pocket beverage holders when you open or close the doors.
Page 102: Socket P
０５／１２／２１１６：４９：１９３１ＳＡＡ６０００１０１ Interior Convenience Items, Interior Lights Accessory Power Socket This socket is intended to supply power for 12 volt DC accessories that are rated 120 watts or less (10 amps). To use the accessory power socket, pull up the cover. The ignition switch must be in the ACCESSORY (I) or ON (II) position.
Page 103 ０５／１２／２１１６：４９：２４３１ＳＡＡ６０００１０２ The heating and air conditioning system in your vehicle provides a comfortable driving environment in all weather conditions. The standard audio system has many features. This section describes those features and how to use them. Your vehicle has an anti-theft audio system that requires a code number to enable it.
Page 104: Vents, Heating, And A/C
０５／１２／２１１６：４９：２８３１ＳＡＡ６０００１０３ Vents, Heating, and A/C TEMPERATURE CONTROL DIAL ＊ If equipped AIR CONDITIONING BUTTON FRESH AIR/RECIRCULATION LEVER FAN CONTROL DIAL MODE CONTROL DIAL ＊ REAR WINDOW DEFOGGER BUTTON U.S. model is shown.
Page 105 ０５／１２／２１１６：４９：４６３１ＳＡＡ６０００１０４ Airflow Controls Fan Control Dial Turn this dial to increase or decrease the fan speed and airflow. Temperature Control Dial Turning this dial clockwise increases the temperature of the airflow. Air Conditioning (A/C) Button If equipped This button turns the air conditioning on and off.
Page 106 ０５／１２／２１１６：４９：５６３１ＳＡＡ６０００１０５ Vents, Heating, and A/C Ventilation The flow-through ventilation system draws in outside air, circulates it through the interior, then discharges it through vents near the tailgate. Set the temperature to the lower limit. Make sure the A/C is off. Select Set the fan to the desired speed.
Page 107 ０５／１２／２１１６：５０：０５３１ＳＡＡ６０００１０６ Dehumidify the Interior Air conditioning, as it cools, removes moisture from the air. When used in combination with the heater, it makes the interior warm and dry and can prevent the windows from fogging up. Turn the fan on. If the A/C is off, turn it on (if equipped).
Page 108 ０５／１２／２１１６：５０：１３３１ＳＡＡ６０００１０７ Vents, Heating, and A/C To Remove Exterior Frost or Ice From the Windows Set the fan and temperature controls to maximum level. Select . The system automatically turns on the A/C (if equipped). The A/C indicator does not come on if it was previously off. Select To clear the windows faster, you can close the dashboard corner vents by...
Page 109: Playing The Am/Fm Radio
０５／１２／２１１６：５０：２０３１ＳＡＡ６０００１０８ All models except Sport PRESET BUTTONS AM BUTTON SCAN BUTTON PWR/VOL KNOB SOUND BUTTON SEEK BAR FM BUTTON Sport model PRESET BUTTONS AUTO SELECT BUTTON PWR/VOL KNOB SOUND BUTTON TUNE BAR AM/FM BUTTON Playing the AM/FM Radio AUTO SELECT BUTTON SCAN BUTTON SEEK BAR...
Page 110 ０５／１２／２１１６：５０：３０３１ＳＡＡ６０００１０９ Playing the AM/FM Radio To Play the AM/FM Radio The ignition switch must be in the ACCESSORY (I) or ON (II) position. Turn the system on by pushing the PWR/VOL knob or the AM/FM button (AM or FM button except Sport model).
Page 111 ０５／１２／２１１６：５０：４０３１ＳＡＡ６０００１１０ AUTO SELECT If you are − traveling far from home and can no longer receive your preset stations, you can use the auto select feature to find stations in the local area. Press the A. SEL button. ‘‘A. SEL’’ flashes in the display, and the system goes into scan mode for several seconds.
Page 112 ０５／１２／２１１６：５０：５０３１ＳＡＡ６０００１１１ Playing the AM/FM Radio Adjusts the volume level − based on the vehicle speed. On Sport model Selects the sound equalizer − settings. The system will return to the audio display about 5 seconds after you stop adjusting a mode. Speed-sensitive Volume Compensation (SVC) The SVC mode controls the volume...
Page 113 ０５／１２／２１１６：５０：５４３１ＳＡＡ６０００１１２ Playing the AM/FM Radio Audio System Lighting You can use the instrument panel brightness control knob to adjust the illumination of the audio system (see page ). The audio system illuminates when the parking lights are on, even if the radio is off.
Page 114: Am/Fm Radio Reception
０５／１２／２１１６：５１：０２３１ＳＡＡ６０００１１３ AM/FM Radio Reception Radio Frequencies The radio can receive the complete AM and FM bands. Those bands cover these frequen- cies: AM band: 530 to 1,710 kHz FM band: 87.7 to 107.9 MHz Radio stations on the AM band are assigned frequencies at least 10 kHz apart (530, 540, 550).
Page 115 ０５／１２／２１１６：５１：０８３１ＳＡＡ６０００１１４ Radio signals, especially on the FM band, are deflected by large objects such as buildings and hills. Your radio then receives both the direct signal from the station’s transmitter, and the deflected signal. This causes the sound to distort or flutter. This is a main cause of poor radio reception in city driving.
Page 116: Playing A Disc
０５／１２／２１１６：５１：１５３１ＳＡＡ６０００１１５ Playing a Disc All models except Sport CD SLOT REPEAT BUTTON CD EJECT BUTTON RANDOM BUTTON CD BUTTON SEEK/SKIP BAR PWR/VOL KNOB Sport model DISC SLOT SCAN BUTTON DISC EJECT BUTTON CD BUTTON DISP BUTTON PWR/VOL KNOB REPEAT SCAN BUTTON BUTTON RANDOM BUTTON...
Page 117 ０５／１２／２１１６：５１：２５３１ＳＡＡ６０００１１６ To Play a CD All models except Sport To load or play CDs, the ignition switch must be in the ACCESSORY (I) or the ON(II) position. You operate the CD player with the same controls used for the radio. To select the CD player, press the CD button.
Page 118 ０５／１２／２１１６：５１：３０３１ＳＡＡ６０００１１７ Playing a Disc REPEAT To continuously replay − a track, press and release the RPT button. You will see RPT in the display. Press it again to turn it off. This feature plays the RANDOM − tracks in random order. To activate random play, press and release the RDM button.
Page 119 ０５／１２／２１１６：５１：３８３１ＳＡＡ６０００１１８ To Play a Disc On Sport model To load or play discs, the ignition switch must be in the ACCESSORY (I) or ON (II) position. You operate the disc player with the same controls used for the radio. To select the disc player, press the CD button.
Page 120 ０５／１２／２１１６：５１：４６３１ＳＡＡ６０００１１９ Playing a Disc Insert the disc about halfway into the disc slot. The drive will pull the disc in the rest of the way and begin to play it. When the system reaches the end of the disc, it will return to the beginning and play the disc again.
Page 121 ０６／０３／２３１５：４５：０６３１ＳＡＡ６０００１２１ Playing a Disc REPEAT (TRACK/FILE REPEAT) To continuously replay − a track (file in MP3/WMA mode), press and release the RPT button. You will see RPT in the display. Press and hold the RPT button to turn it off. In MP3/WMA mode FOLDER-REPEAT This feature,...
Page 122 ０６／０３／２３１５：４５：０６３１ＳＡＡ６０００１２１ Playing a Disc REPEAT (TRACK/FILE REPEAT) To continuously replay − a track (file in MP3/WMA mode), press and release the RPT button. You will see RPT in the display. Press and hold the RPT button to turn it off. In MP3/WMA mode FOLDER-REPEAT This feature,...
Page 123 ０５／１２／２１１６：５２：０４３１ＳＡＡ６０００１２２ In MP3/WMA mode FOLDER-RANDOM This − feature, when activated, plays the files in the current folder in random order, rather than in the order they are compressed in MP3/WMA. To activate folder random play, press the RDM button. You will see F-RDM in the display.
Page 124 ０５／１２／２１１６：５２：０９３１ＳＡＡ６０００１２３ Playing a Disc To Stop Playing a Disc Press the eject button ( ) to remove the disc. If you eject the disc, but do not remove it from the slot, the system will automatically reload it after 10 seconds and put it in pause mode.
Page 125: Disc Player Error Messages
０５／１２／２１１６：５２：１５３１ＳＡＡ６０００１２４ If you see an error message in the display while playing a disc, find the cause in the chart to the right. If you cannot clear the error message, take your vehicle to your dealer. Disc Player Error Messages Indication Cause Press the EJECT button, and pull out the disc.
Page 126: Protecting Your Discs
０５／１２／２１１６：５２：２５３１ＳＡＡ６０００１２５ Protecting Your Discs General Information When using CD-R or CD-RW discs, use only high quality discs labeled for audio use. When recording a CD-R or CD-RW, the recording must be closed for it to be used by the system. Play only standard round discs.
Page 127: Auxiliary Input Jack
０６／０７／１９１５：１８：５９３１ＳＡＡ６０００１２６ Auxiliary Input Jack U.S. Sport and all Canadian models The auxiliary input jack is underneath the accessory power socket in the center pocket. The system will accept auxiliary input from standard audio accessories. When a compatible audio unit is connected to the jack, press the AUX button to select it.
Page 128: Radio Theft Protection
０５／１２／２１１６：５２：３５３１ＳＡＡ６０００１２７ Radio Theft Protection Your vehicle’s audio system will disable itself if it is disconnected from electrical power for any reason. To make it work again, you must enter a specific five-digit code in the preset buttons. Because there are hundreds of number combinations possible from five digits, making the system work without knowing the...
Page 129: Setting The Clock
０５／１２／２１１６：５２：４３３１ＳＡＡ６０００１２８ Press and hold the CLOCK button until you hear a beep. The displayed time begins to blink. Change the hours by pressing the H (preset 4) button until the numbers advance to the desired time. Change the minutes by pressing the M (preset 5) button until the numbers advance to the desired time.
Page 130: Security System
０５／１２／２１１６：５２：５１３１ＳＡＡ６０００１２９ Security System On Sport model The security system helps to protect your vehicle and valuables from theft. The horn sounds and a combination of headlights, parking lights, side marker lights, and taillights flash if someone attempts to break into your vehicle or remove the radio.
Page 131: Cruise Control
０６／１０／２６０９：５６：３０３１ＳＡＡ６０００１３０ On Sport model and Canadian LX model Cruise control allows you to maintain a set speed above 25 mph (40 km/h) without keeping your foot on the accelerator pedal. It should be used for cruising on straight, open highways. It is not recommended for city driving, winding roads, slippery roads, heavy rain, or bad weather.
Page 132 ０５／１２／２１１６：５３：０７３１ＳＡＡ６０００１３１ Cruise Control Changing the Set Speed You can increase the set cruising speed in any of these ways: Press and hold the RES/ACCEL button. When you reach the desired cruising speed, release the button. To increase your speed in very small amounts, tap the RES/ ACCEL button.
Page 133 ０５／１２／２１１６：５３：１６３１ＳＡＡ６０００１３２ Canceling Cruise Control CRUISE BUTTON CANCEL BUTTON You can cancel cruise control in any of these ways: Tap the brake or clutch pedal. Push the CANCEL button on the steering wheel. Push the CRUISE button on the steering wheel. Tapping either of the paddle shifters shifts the gear up or down, but does not cancel the cruise control.
Page 134 ０５／１２／２１１６：５３：１８３１ＳＡＡ６０００１３３ ...
Page 135: Before Driving
０５／１２／２１１６：５３：２２３１ＳＡＡ６０００１３４ Before you begin driving your vehicle, you should know what gasoline to use and how to check the levels of important fluids. You also need to know how to properly store luggage or packages. The information in this section will help you.
Page 136: Break-In Period
０５／１２／２１１６：５３：３２３１ＳＡＡ６０００１３５ Break-in Period, Fuel Recommendation Break-in Period Help assure your vehicle’s future reliability and performance by paying extra attention to how you drive during the first 600 miles (1,000 km). During this period: Avoid full-throttle starts and rapid acceleration. Avoid hard braking for the first 200 miles (300 km).
Page 137: Service Station Procedures
０５／１２／２１１６：５３：４１３１ＳＡＡ６０００１３６ Refueling ATTACHMENT FUEL FILL CAP TETHER Park with the driver’s side closest to the service station pump. Outside of the vehicle, open the fuel fill door by pulling its notched edge. Service Station Procedures Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel.
Page 138: Opening And Closing The Hood
０５／１２／２１１６：５３：４８３１ＳＡＡ６０００１３７ Service Station Procedures Screw the fuel fill cap back on until it clicks at least once. If you do not properly tighten the cap, the malfunction indicator lamp may come on (see page ). You will also see a ‘‘CHECK FUEL CAP’’...
Page 139: Oil Check
０５／１２／２１１６：５３：５８３１ＳＡＡ６０００１３８ GRIP CLIP SUPPORT ROD Holding the grip, pull the support rod out of its clip. Insert the end into the designated hole in the hood. To close the hood, lift it up slightly to remove the support rod from the hole.
Page 140: Engine Coolant Check
０５／１２／２１１６：５４：０３３１ＳＡＡ６０００１３９ Service Station Procedures Engine Coolant Check RESERVE TANK Look at the coolant level in the radiator reserve tank. Make sure it is between the MAX and MIN lines. If it is below the MIN line, see Adding Engine Coolant on page information on adding the proper coolant.
Page 141: Fuel Economy
０５／１２／２１１６：５４：１０３１ＳＡＡ６０００１４０ Improving Fuel Economy Always maintain your vehicle according to the maintenance messages displayed in the information display. See Owner’s on page Maintenance Checks an underinflated tire For example, causes more ‘‘rolling resistance,’’ which uses more fuel. The build-up of snow or mud on your vehicle’s underside adds weight and rolling resistance.
Page 142: Accessories And Modifications
Accessories Your dealer has Honda accessories that allow you to personalize your vehicle. These accessories have been designed and approved for your vehicle, and are covered by warranty.
Page 143 Here are some examples: Lowering the vehicle with a non- Honda suspension kit that significantly reduces ground clearance can allow the undercarriage to hit speed bumps or other raised objects, which could cause the airbags to deploy.
Page 144: Carrying Cargo
０５／１２／２１１６：５４：３４３１ＳＡＡ６０００１４３ Carrying Cargo FRONT DOOR POCKETS CARGO AREA REAR SIDE POCKET (RIGHT SIDE) CENTER POCKET SEAT-BACK POCKET GLOVE BOX Your vehicle has several convenient storage areas: Glove box Front door pockets Seat-back pocket Center pocket Cargo area side pocket Cargo area, including the rear seats when folded up or down.
Page 145 ０５／１２／２１１６：５４：４２３１ＳＡＡ６０００１４４ Load Limits The maximum load for your vehicle is 850 lbs (385 kg) for U.S. models and 395 kg for Canadian models. This figure includes the total weight of all occupants, cargo, and accessories. Overloading or improper loading can affect handling and stability and cause a crash in which you can be hurt or killed.
Page 146 ０５／１２／２１１６：５４：４９３１ＳＡＡ６０００１４５ Carrying Cargo Carrying Cargo in the Passenger Compartment Store or secure all items that could be thrown around and hurt someone during a crash. Be sure items placed on the floor behind the front seats cannot roll under the seats and interfere with the driver’s ability to operate the pedals, the proper operation of the seats, or proper operation of the...
Page 147 ０５／１２／２１１６：５４：５３３１ＳＡＡ６０００１４６ Optional Separation Net The separation net can be used to hold back soft, lightweight items stored in the cargo area. Heavy items should be properly secured on the floor of the cargo area. The net may not prevent heavy items from being thrown forward in a crash or a sudden stop.
Page 148 ０５／１２／２１１６：５４：５５３１ＳＡＡ６０００１４７ ...
Page 149 ０５／１２／２１１６：５４：５９３１ＳＡＡ６０００１４８ This section gives you tips on starting the engine under various conditions, and how to operate the manual and automatic transmissions. It also includes important information on parking your vehicle and the braking system. Driving Driving Guidelines . 146 Preparing to Drive .
Page 150: Driving Guidelines
０５／１２／２１１６：５５：０３３１ＳＡＡ６０００１４９ Driving Guidelines On Sport model Your vehicle is designed to give you optimum handling and performance on well-maintained roads. As part of this design, your vehicle has a minimum of ground clearance. Use caution if you ever drive your vehicle on very rough or rutted roads.
Page 151: Preparing To Drive
０５／１２／２１１６：５５：１３３１ＳＡＡ６０００１５０ Preparing to Drive You should do the following checks and adjustments before you drive your vehicle. Make sure all windows, mirrors, and outside lights are clean and unobstructed. Remove frost, snow, or ice. Check that the hood is fully closed. Visually check the tires.
Page 152: Starting The Engine
０５／１２／２１１６：５５：２２３１ＳＡＡ６０００１５１ Starting the Engine Apply the parking brake. In cold weather, turn off all electrical accessories to reduce the drain on the battery. Manual transmission: Press the clutch pedal down all the way. The START (III) position does not function unless the clutch pedal is pressed.
Page 153: Manual Transmission
０５／１２／２１１６：５５：２８３１ＳＡＡ６０００１５２ The manual transmission is synchronized in all forward gears for smooth operation. It has a lockout so you cannot shift directly from fifth to reverse. When shifting up or down, make sure you push the clutch pedal down all the way, shift to the next gear, and let the pedal up gradually.
Page 154 ０６／０３／２３１５：４５：１３３１ＳＡＡ６０００１５３ Manual Transmission Recommended Shift Points Drive in the highest gear that lets the engine run and accelerate smoothly. This will give you good fuel economy and effective emissions control. The following shift points are recommended: Shift up Normal acceleration 1st to 2nd 15 mph (24 km/h) 2nd to 3rd...
Page 155: Automatic Transmission
０５／１２／２１１６：５５：４２３１ＳＡＡ６０００１５４ Shift Lever Position Indicators Sport model These indicators on the instrument panel show which position the shift lever is in. The ‘‘D’’ indicator comes on for a few seconds when you turn the ignition switch to the ON (II) position.
Page 156 ０５／１２／２１１６：５５：４９３１ＳＡＡ６０００１５５ Automatic Transmission All models except Sport To shift from: Do this: Press the brake pedal, and P to R press the shift lever release button. R to P N to R Press the shift lever release D to 2 button.
Page 157 ０５／１２／２１１６：５５：５８３１ＳＡＡ６０００１５６ Reverse (R) Press the brake − pedal and press the release button on the front of the shift lever to shift from Park to reverse. To shift from reverse to neutral, come to a complete stop, and then shift. Press the release button before shifting into reverse from neutral.
Page 158 ０５／１２／２１１６：５６：０４３１ＳＡＡ６０００１５７ Automatic Transmission All models except Sport First (1) To shift from second to − first, press the release button on the front of the shift lever. This position locks the transmission in first gear. By upshifting and downshifting through 1, 2, D , and D, you can operate the transmission much like a manual transmission without a clutch pedal.
Page 159 ０５／１２／２１１６：５６：１３３１ＳＡＡ６０００１５８ Shift Lock Release This allows you to move the shift lever out of Park if the normal method of pushing on the brake pedal and pressing the release button does not work. Set the parking brake. Remove the key from the ignition switch.
Page 160: Driving With The Paddle Shifters (Sport Only)
０５／１２／２１１６：５６：２１３１ＳＡＡ６０００１５９ Driving with the Paddle Shifters (Sport only) Using the Paddle Shifters in D position (D-Paddle Shift Mode) When you are driving in D position, you can shift the transmission up or down manually with the paddle shifters. To shift up or down, use the ＋...
Page 161 ０５／１２／２１１６：５６：２７３１ＳＡＡ６０００１６０ The transmission control system monitors the accelerator pedal use and your driving conditions. When you press the accelerator pedal as in the normal driving, the system judges that you are driving at a constant cruising speed without using the paddle shifters. Under these conditions, D-paddle shift mode is cancelled, and the transmission automatically returns to...
Page 162 ０５／１２／２１１６：５６：３６３１ＳＡＡ６０００１６１ Driving with the Paddle Shifters (Sport only) Using the Paddle Shift in S position (Sequential Shift Mode) With the shift lever in S position, you can manually shift up or down with the paddle shifters. The transmission goes into the sequential shift mode and holds the selected gear.
Page 163 ０６／０２／０２１４：０３：１３３１ＳＡＡ６０００１６２ Downshifting gives you more power when climbing, and provides engine braking when going down a steep hill. The transmission also shifts automatically as the vehicle comes to a complete stop. It downshifts to first gear when the vehicle speed reaches 6 mph (10 km/h) or less.
Page 164: Parking
０５／１２／２１１６：５６：５２３１ＳＡＡ６０００１６３ Parking Always use the parking brake when you park your vehicle. Make sure the parking brake is set firmly, or your vehicle may roll if it is parked on an incline. If your vehicle has an automatic transmission, set the parking brake before you put the transmission in Park.
Page 165: Braking System
０５／１２／２１１６：５６：５９３１ＳＡＡ６０００１６４ Your vehicle is equipped with front disc brakes. The brakes on the rear wheels are drum. A power assist helps reduce the effort needed on the brake pedal. The anti-lock brake system (ABS) helps you retain steering control when braking very hard.
Page 166: Anti-Lock Brakes (Abs)
０５／１２／２１１６：５７：０５３１ＳＡＡ６０００１６５ Anti-lock Brakes (ABS) The anti-lock brake system (ABS) helps prevent the brakes from locking up, and helps you retain steering control by pumping the brakes rapidly, much faster than a person can do it. The ABS also balances the front-to- rear braking distribution according to vehicle loading.
Page 167 ０５／１２／２１１６：５７：１２３１ＳＡＡ６０００１６６ If the ABS indicator and the brake system indicator come on together, and the parking brake is fully released, the front-to-rear braking distribution system may also be shut down. Test your brakes as instructed on page . If the brakes feel normal, drive slowly and have your vehicle repaired by your dealer as soon as possible.
Page 168: Towing A Trailer
０５／１２／２１１６：５７：１５３１ＳＡＡ６０００１６７ Towing a Trailer Your vehicle is not designed to tow a trailer; Attempting to do so can void your warranties.
Page 169 ０５／１２／２１１６：５７：２０３１ＳＡＡ６０００１６８ This section explains why it is important to keep your vehicle well maintained and how to follow basic maintenance safety precautions. This section also includes instructions on how to read the maintenance minder messages on the information display, a maintenance record, and instructions for simple maintenance tasks you may want to take care of yourself.
Page 170: Maintenance Safety
０５／１２／２１１６：５７：３０３１ＳＡＡ６０００１６９ Maintenance Safety All service items not detailed in this section should be performed by a certified technician or other qualified mechanic. Important Safety Precautions To eliminate potential hazards, read the instructions before you begin, and make sure you have the tools and skills required.
Page 171: Maintenance Minder
０５／１２／２１１６：５７：３７３１ＳＡＡ６０００１７０ Your vehicle displays engine oil life and maintenance service items on the information display to show you when you should have your dealer do engine oil replacement and indicated maintenance service. Based on the engine operating conditions and accumulated engine revolutions, the onboard computer in your vehicle calculates the remaining engine oil life and displays it as a...
Page 172 ０５／１２／２１１６：５７：４３３１ＳＡＡ６０００１７１ Maintenance Minder MAINTENANCE MINDER INDICATOR ENGINE OIL LIFE MAINTENANCE ITEM CODE(S) INDICATOR If the remaining engine oil life is 15 to 6 percent, you will see the engine oil life indicator every time you turn the ignition switch to the ON (II) position.
Page 173 ０６／０２／０２１４：０３：２５３１ＳＡＡ６０００１７２ The maintenance item code or codes indicate the main and sub items required at the time of the oil change (see page You can switch the information display from the engine oil life display to the odometer or the trip meter.
Page 174 ０５／１２／２１１６：５８：０２３１ＳＡＡ６０００１７３ Maintenance Minder To change the information display from the engine oil life display to the odometer or the trip meter, press and release the Select/Reset knob. When the engine oil life is 0 percent or negative mileage, the maintenance minder indicator ) remains on even if you change the information display.
Page 175 This can lead to serious mechanical problems because you will no longer have an accurate record of when maintenance is needed. Your authorized Honda dealer knows your vehicle best and can provide competent, efficient service. CONTINUED...
Page 176 Check your warranty booklet for more information. We recommend using Honda parts and fluids whenever you have maintenance done. These are manufactured to the same high- quality standards as the original components, so you can be confident of their performance and durability.
Page 177 ０５／１２／２１１６：５８：２７３１ＳＡＡ６０００１７６ Symbol Maintenance Main Items ＊ Replace engine oil ＊ Replace engine oil and oil filter Inspect front and rear brakes Check parking brake adjustment Inspect these items: Tie rod ends, steering gear box, and boots Suspension components Driveshaft boots Brake hoses and lines (including ABS) All fluid levels and condition of fluids ＃...
Page 178: Maintenance Record
You or the servicing dealer can record all completed maintenance here. When maintenance is performed, record the mileage, circle the coded item(s) completed, and write in any other non-coded items (such as brake fluid replacement) below the codes. Keep the receipts for all work done on your vehicle. Maintenance can also be recorded in your Honda service history booklet. Mileage...
Page 179 ０５／１２／２１１６：５８：３９３１ＳＡＡ６０００１７８ Mileage Maintenance Performed Signature Mileage Maintenance Performed Date Maintenance Record Signature Date...
Page 180: Fluid Locations
０５／１２／２１１６：５８：４３３１ＳＡＡ６０００１７９ Fluid Locations ENGINE OIL FILL CAP ENGINE OIL DIPSTICK (Orange loop) WASHER FLUID (Blue cap) BRAKE FLUID (Black cap) CLUTCH FLUID (Manual Transmission only) (Gray cap) RADIATOR CAP ENGINE COOLANT RESERVOIR AUTOMATIC TRANSMISSION FLUID DIPSTICK (Yellow loop)
Page 181: Adding Engine Oil
Adding Engine Oil Honda Motor Oil is the preferred 5W-20 lubricant for your vehicle. It is highly recommended that you use Honda Motor Oil in your vehicle for optimum engine protection. Make sure the API Certification Seal says ‘‘For Gasoline Engines.’’...
Page 182: Changing The Engine Oil And Filter
０５／１２／２１１６：５８：５９３１ＳＡＡ６０００１８１ Adding Engine Oil, Changing the Engine Oil and Filter Synthetic Oil You may use a synthetic motor oil if it meets the same requirements given for a conventional motor oil, it displays the API Certification Seal, and it is the proper weight. You must follow the oil and filter change intervals given in the maintenance schedule.
Page 183 ０５／１２／２１１６：５９：０９３１ＳＡＡ６０００１８２ OIL FILTER Remove the oil filter, and let the remaining oil drain. A special wrench (available from your dealer) is required. Make sure the oil filter gasket is not stuck to the engine block. If it is, remove it before installing a new oil filter.
Page 184: Engine Coolant
MIN line, add coolant to bring it up to the MAX line. Inspect the cooling system for leaks. Always use Honda Long-life Anti- freeze/Coolant Type 2. This coolant is pre-mixed with 50 percent antifreeze and 50 percent water.
Page 185 ０５／１２／２１１６：５９：２４３１ＳＡＡ６０００１８４ RADIATOR CAP Make sure the engine and radiator are cool. Relieve any pressure in the cooling system by turning the radiator cap counterclockwise, without pressing down. Remove the radiator cap by pushing down and turning counterclockwise. RESERVE TANK The coolant level should be up to the base of the filler neck.
Page 186: Windshield Washers
０５／１２／２１１６：５９：３０３１ＳＡＡ６０００１８５ Windshield Washers Check the fluid level in the windshield washer reservoir at least monthly during normal use. LEVEL GAUGE Check the fluid level by removing the cap and looking at the level gauge. The low washer On Canadian models: level indicator comes on when the level is low (see page Fill the reservoir with a good-quality...
Page 187: Transmission Fluid
DEXRON III automatic transmission fluid as a temporary replacement. However, continued use can affect the shift quality. Have the transmission flushed and refilled with Honda ATF-Z1 by your dealer as soon as it is convenient. CONTINUED...
Page 188: Manual Transmission
Put a new washer on the filler bolt, then reinstall the filler bolt and tighten it securely. If Honda MTF is not available, you may use an SAE 10W-30 or 10W-40 viscosity motor oil with the API Certification seal that says ‘‘FOR GASOLINE ENGINES’’...
Page 189: Brake And Clutch Fluid
DOT 3 or DOT 4 fluid, from a sealed container, as a temporary replacement. Using any non-Honda brake fluid can cause corrosion and decrease the life of the system. Have the brake system flushed and refilled with Honda Heavy Duty Brake Fluid DOT 3 as soon as possible.
Page 190: Lights
０５／１２／２１１７：００：０５３１ＳＡＡ６０００１８９ Lights Headlight Aiming The headlights were properly aimed when your vehicle was new. If you regularly carry heavy items in the cargo area, readjustment may be required. Adjustments should be done by your dealer or other qualified mechanic. Replacing a Headlight Bulb Your vehicle has halogen headlight bulbs.
Page 191 ０５／１２／２１１７：００：１５３１ＳＡＡ６０００１９０ HOLD-DOWN ELECTRICAL WIRE BULB CONNECTOR RUBBER WEATHER SEAL Remove the electrical connector from the bulb by pulling the connector straight back. Remove the rubber weather seal by pulling on the tab. Unclip the end of the hold-down wire from its slot. Pivot the wire out of the way, then remove the bulb.
Page 192 ０５／１２／２１１７：００：２４３１ＳＡＡ６０００１９１ Lights Replacing a Parking Light/Front Side Marker Bulb and a Turn Signal Light Bulb HOLDING CLIP To change the bulb on the driver’s side, start the engine, turn the steering wheel all the way to the right, then turn off the engine. To change the bulb on the passenger’s side, turn the steering wheel to the left.
Page 193 ０５／１２／２１１７：００：３４３１ＳＡＡ６０００１９２ Replacing a Fog Light Bulb On Sport model SCREW The fog lights use halogen bulbs. When replacing a bulb, handle it carefully. See page for more information. Use a Phillips-head screwdriver to remove the screw. To remove the fog light assembly, slide it inward, then carefully pull it out of the bumper.
Page 194 ０５／１２／２１１７：００：４４３１ＳＡＡ６０００１９３ Lights Replacing Rear Bulbs LIGHT ASSEMBLY COVER Open the tailgate. Place a cloth on the edge of the light assembly cover. Remove the cover by carefully prying in the notch on its middle edge with a flat-tip screwdriver. Determine which of the four bulbs is burned out: stop/taillight, back- up light, turn signal light, or taillight.
Page 195 ０５／１２／２１１７：００：５２３１ＳＡＡ６０００１９４ Replacing a High-mount Brake Light Bulb Open the tailgate. Remove the light assembly cover by pushing in the tabs on both sides and pulling the cover off. Remove the socket from the light assembly by turning it one-quarter turn counterclockwise. Pull the bulb straight out of its socket.
Page 196: Cleaning The Seat Belts
Floor Mats (Optional) FRONT If your vehicle is equipped with genuine Honda floor mats, the mats hook over floor mat anchors. This keeps the floor mats from sliding forward and possibly interfering with the pedals or making the front passenger’s weight sensors...
Page 197: Audio Antenna
If you remove a floor mat, make sure to re-anchor it when you put it back in your vehicle. A non-Honda floor mat may not fit your vehicle properly. This could prevent the proper operation of the folding rear seats and the passenger’s seat weight sensors.
Page 198: Dust And Pollen Filter
０５／１２／２１１７：０１：１３３１ＳＡＡ６０００１９７ Dust and Pollen Filter, Wiper Blades Dust and Pollen Filter On models with A/C This filter removes the dust and pollen that is brought in from the outside through the heating and cooling system. Have your dealer replace the filter when this service is indicated by a maintenance message on the information display.
Page 199 ０５／１２／２１１７：０１：２２３１ＳＡＡ６０００１９８ Disconnect the blade assembly from the wiper arm: Press and hold the lock tab. Slide the blade assembly toward the lock tab until it releases from the wiper arm. When replacing a wiper blade, make sure not to drop the wiper blade or wiper arm down on the windshield.
Page 200 ０５／１２／２１１７：０１：３２３１ＳＡＡ６０００１９９ Wiper Blades Install the new blade onto the blade assembly: Pull back either end of the blade assembly. Place the side of the blade not labeled ‘‘LOCK’’ on the end of the blade assembly, and slide the blade onto the assembly until it is fully installed.
Page 201: Wheels
０５／１２／２１１７：０１：４２３１ＳＡＡ６０００２００ Wheels Clean the wheels as you would the rest of the exterior. Wash them with the same solution, and rinse them thoroughly. If equipped Aluminum alloy wheels have a protective clear-coat that keeps the aluminum from corroding and tarnishing. Cleaning the wheels with harsh chemicals (including some commercial wheel cleaners) or a stiff brush can damage the...
Page 202 ０５／１２／２１１７：０１：５４３１ＳＡＡ６０００２０１ Tires Use a gauge to measure the air pressure in each tire at least once a month. Even tires that are in good condition may lose 1 to 2 psi (10 to 20 kPa, 0.1 to 0.2 kgf/cm ) per month.
Page 203 This increases riding comfort and tire life. For best results, have the installer perform a dynamic balance. On vehicles with aluminum wheels, improper wheel weights can damage your vehicle’s wheels. Use only Honda wheel weights f or balancing.
Page 204 ０５／１２／２１１７：０２：１２３１ＳＡＡ６０００２０３ Tires Tire Rotation Front Front (For Non-directional (For Directional Tires and Wheels) Tires and Wheels) To help increase tire life and distribute wear more evenly, rotate the tires according to the maintenance messages displayed on the information display. Move the tires to the positions shown in the chart each time they are rotated.
Page 205 ０５／１２／２１１７：０２：２２３１ＳＡＡ６０００２０４ Installing improper tires on your vehicle can affect handling and stability. This can cause a crash in which you can be seriously hurt or killed. Always use the size and type of tires recommended in this owner’s manual. Wheel and Tire Specifications Wheels: All models except Sport 14 x 5 1/2JJ...
Page 206 ０５／１２／２１１７：０２：２７３１ＳＡＡ６０００２０５ Tires Tire Chains Because your vehicle has limited tire clearance, mount only SAE Class ‘‘S’’ cable-type traction devices, with rubber chain tensioners, on the front tires. Use traction devices only when required by driving conditions or local laws. Make sure they are the correct size for your tires.
Page 207: Checking The Battery
０５／１２／２１１７：０２：３５３１ＳＡＡ６０００２０６ TEST INDICATOR WINDOW Check the condition of the battery monthly by looking at the test indicator window. The label on the battery explains the test indicator’s colors. The test indicator window’s location differs according to the battery manufacturer. Check the terminals for corrosion (a white or yellowish powder).
Page 208: Vehicle Storage
０５／１２／２１１７：０２：４５３１ＳＡＡ６０００２０７ Vehicle Storage If you need to park your vehicle for an extended period (more than 1 month), there are several things you should do to prepare it for storage. Proper preparation helps prevent deterioration and makes it easier to get your vehicle back on the road.
Page 209: Taking Care Of The Unexpected
０５／１２／２１１７：０２：４８３１ＳＡＡ６０００２０８ Taking Care of the Unexpected This section covers the more common problems that motorists experience with their vehicles. It gives you information about how to safely evaluate the problem and what to do to correct it. If the problem has stranded you on the side of the road, you may be able to get going again.
Page 210: Compact Spare Tire
０５／１２／２１１７：０２：５６３１ＳＡＡ６０００２０９ Compact Spare Tire Use the compact spare tire as a temporary replacement only. Get your regular tire repaired or replaced, and put it back on your vehicle as soon as you can. Check the inflation pressure of the compact spare tire every time you check the other tires.
Page 211: Changing A Flat Tire
０５／１２／２１１７：０３：０４３１ＳＡＡ６０００２１０ If you have a flat tire while driving, stop in a safe place to change it. Drive slowly along the shoulder until you get to an exit or an area to stop that is far away from the traffic lanes. The vehicle can easily roll off the jack, seriously injuring anyone underneath.
Page 212 ０５／１２／２１１７：０３：１２３１ＳＡＡ６０００２１１ Changing a Flat Tire Take the jack out of the cargo area. Turn the jack’s end bracket counterclockwise to loosen it, then remove the jack by lifting it straight Unscrew the wing bolt and take the spare tire out of its well. EXTENSION WHEEL NUT WHEEL COVER...
Page 213 ０５／１２／２１１７：０３：２０３１ＳＡＡ６０００２１２ JACKING POINT Place the jack under the jacking point nearest the tire you need to change. It is pointed to by a △ mark molded into the underside of the body (Sport model). Turn the end bracket clockwise until the top of the jack contacts the jacking point.
Page 214 ０５／１２／２１１７：０３：２８３１ＳＡＡ６０００２１３ Changing a Flat Tire Put on the spare tire. Put the wheel nuts back on finger-tight, then tighten them in a crisscross pattern with the wheel nut wrench until the wheel is firmly against the hub. Do not try to tighten the wheel nuts fully.
Page 215 ０６／０２／０２１４：０３：３５３１ＳＡＡ６０００２１４ Store the jack. Place the tool kit in the center of the flat tire. Loose items can fly around the interior in a crash and could seriously injure the occupants. Store the wheel, jack, and tools securely before driving. Store the wheel cover or center cap in the cargo area.
Page 216: If The Engine Won't Start
０５／１２／２１１７：０３：４６３１ＳＡＡ６０００２１５ Changing a Flat Tire, If the Engine Won’t Start WIRE SUPPORT RING Make sure the wire support ring is on the outer side of the tire valve as shown. If the Engine Won’t Start Diagnosing why the engine won’t start falls into two areas, depending on what you hear when you turn the ignition switch to the START (III)
Page 217 ０５／１２／２１１７：０３：５４３１ＳＡＡ６０００２１６ Turn the ignition switch to the START (III) position. If the headlights do not dim, check the condition of the fuses. If the fuses are OK, there is probably something wrong with the electrical circuit for the ignition switch or starter motor. You will need a qualified technician to determine the problem.
Page 218: Jump Starting
０５／１２／２１１７：０４：０２３１ＳＡＡ６０００２１７ Jump Starting Although this seems like a simple procedure, you should take several precautions. A battery can explode if you do not follow the correct procedure, seriously injuring anyone nearby. Keep all sparks, open flames, and smoking materials away from the battery.
Page 219 ０５／１２／２１１７：０４：０９３１ＳＡＡ６０００２１８ Connect one jumper cable to the positive ( ) terminal on your ＋ battery. Connect the other end to the positive ( ) terminal on the ＋ booster battery. Connect the second jumper cable to the negative ( ) terminal on −...
Page 220: If The Engine Overheats
０５／１２／２１１７：０４：１７３１ＳＡＡ６０００２１９ If the Engine Overheats The high temperature indicator should be off under most conditions. If the engine coolant temperature gets higher than normal, the indicator will blink. If it stays on, you should determine the reason (hot day, driving up a steep hill, etc.). If the vehicle overheats, you should take immediate action.
Page 221 ０５／１２／２１１７：０４：２５３１ＳＡＡ６０００２２０ Look for any obvious coolant leaks, such as a split radiator hose. Everything is still extremely hot, so use caution. If you find a leak, it must be repaired before you continue driving (see Emergency on page Towing If you don’t find an obvious leak, check the coolant level in the radiator reserve tank.
Page 222: Low Oil Pressure Indicator
０５／１２／２１１７：０４：３４３１ＳＡＡ６０００２２１ Low Oil Pressure Indicator, Charging System Indicator Low Oil Pressure Indicator This indicator should never come on when the engine is running. If it starts flashing or stays on, the oil pressure has dropped very low or lost pressure. Serious engine damage is possible, and you should take immediate action.
Page 223: Malfunction Indicator Lamp
０５／１２／２１１７：０４：４１３１ＳＡＡ６０００２２２ If this indicator comes on while driving, it means one of the engine’s emissions control systems may have a problem. Even though you may feel no difference in your vehicle’s performance, it can reduce your fuel economy and cause increased emissions.
Page 224: Brake System Indicator
０５／１２／２１１７：０４：４８３１ＳＡＡ６０００２２３ Brake System Indicator U.S. Canada The brake system indicator normally comes on when you turn the ignition switch to the ON (II) position, and as a reminder to check the parking brake. It will stay on if you do not fully release the parking brake.
Page 225: Fuses
０５／１２／２１１７：０４：５５３１ＳＡＡ６０００２２４ INTERIOR DIAL DRIVER’S COIN TRAY The vehicle’s fuses are contained in three fuse boxes. The interior fuse box is behind the driver’s coin tray. To access it, remove the tray by turning the dial counterclockwise then pulling it toward you. To install the coin tray, line up the tabs on the bottom, pivot the tray up to engage its side clips, then turn the dial clockwise.
Page 226 ０５／１２／２１１７：０５：０３３１ＳＡＡ６０００２２５ Fuses Checking and Replacing Fuses If something electrical in your vehicle stops working, check for a blown fuse first. Determine from the chart on pages , or the diagram on the fuse box lid, which fuse or fuses control that device. Check those fuses first, but check all the fuses before deciding that a blown fuse is the cause.
Page 227 ０５／１２／２１１７：０５：０９３１ＳＡＡ６０００２２６ BLOWN Look for a blown wire inside the fuse. If it is blown, replace it with one of the spare fuses of the same rating or lower. If you cannot drive the vehicle without fixing the problem, and you do not have a spare fuse, take a fuse of the same rating or a lower rating from one of the other circuits.
Page 228: Fuse Locations
０５／１２／２１１７：０５：１６３１ＳＡＡ６０００２２７ Fuse Locations INTERIOR FUSE BOX Amps. Circuits Protected 10 A Back Up Light Not Used − 10 A IG METER 10 A Turn Light Not Used − 30 A Front Wipers 10 A (7.5 A) Daytime Running Light ＊ 20 A Rear Defogger Amps.
Page 229 ０５／１２／２１１７：０５：２４３１ＳＡＡ６０００２２８ UNDER-HOOD FUSE BOXES PRIMARY Primary Fuse Box Amps. Circuits Protected 80 A Battery 60 A 50 A Ignition 30 A 40 A Blower Relay 40 A Power Window (30 A) (HAC Option) 10 A Back Up Secondary Fuse Box (On the battery) Amps.
Page 230: Emergency Towing
０５／１２／２１１７：０５：３５３１ＳＡＡ６０００２２９ Emergency Towing If your vehicle needs to be towed, call a professional towing service or organization. Never tow your vehicle with just a rope or chain. It is very dangerous. There are two ways to tow your vehicle: The operator Flat-bed Equipment −...
Page 231: If Your Vehicle Gets Stuck
０５／１２／２１１７：０５：４３３１ＳＡＡ６０００２３０ Trying to lif t or tow your vehicle by the bumpers will cause serious damage. The bumpers are not designed to support the vehicle’s weight. The steering system can be damaged if the steering wheel is locked. Leave the ignition switch in the ACCESSORY (I) position, and make sure the steering wheel turns f reely bef ore you begin...
Page 232 ０５／１２／２１１７：０５：４８３１ＳＡＡ６０００２３１ If Your Vehicle Gets Stuck Screw the towing hook into the bolt hole behind the bumper, then tighten the hook securely with the extension. To avoid damage to your vehicle, use the towing hook f or straight, f lat ground towing only.
Page 233: Technical Information
０５／１２／２１１７：０５：５１３１ＳＡＡ６０００２３２ The diagrams in this section give you the dimensions and capacities of your vehicle and the locations of the identification numbers. It also includes information you should know about your vehicle’s tires and emissions control systems. Identification Numbers . 230 Specifications .
Page 234: Identification Numbers
０５／１２／２１１７：０５：５６３１ＳＡＡ６０００２３３ Identification Numbers Your vehicle has several identifying VEHICLE IDENTIFICATION NUMBER numbers in various places. The vehicle identification number (VIN) is the 17-digit number your dealer uses to register your vehicle for warranty purposes. It is also necessary for licensing and insuring your vehicle.
Page 235 ０５／１２／２１１７：０６：０１３１ＳＡＡ６０００２３４ The engine number is stamped into the front of the engine block. The transmission number is on a label on top of the transmission. Identification Numbers ENGINE NUMBER TRANSMISSION NUMBER...
Page 236 ０６／０２／０２１４：０３：５３３１ＳＡＡ６０００２３５ Specifications Dimensions Length Width Height Wheelbase Track Front Rear Weights Gross vehicle weight rating See the certification label attached to the driver’s doorjamb. Engine Type Water cooled 4-stroke SOHC VTEC 4-cylinder gasoline engine Bore x Stroke 2.87 x 3.52 in (73.0 x 89.4 mm) Displacement Compression ratio Spark plugs...
Page 237: Specifications
０６／０３／２３１５：４５：３７３１ＳＡＡ６０００２３６ Air Conditioning Refrigerant type Charge quantity 14.1 15.9 oz (400 450 g) Lubricant type Lights Headlights High/Low 12 V Front turn signal lights 12 V Parking lights/side marker 12 V lights Fog lights 12 V Rear turn signal lights 12 V Stop/Taillights 12 V...
Page 238: Dot Tire Quality Grading (U.s. Vehicles)
０５／１２／２１１７：０６：４９３１ＳＡＡ６０００２３７ DOT Tire Quality Grading (U.S. Vehicles) The tires on your vehicle meet all U.S. Federal Safety Requirements. All tires are also graded for treadwear, traction, and temperature performance according to Department of Transportation (DOT) standards. The following explains these gradings. Uniform Tire Quality Grading Quality grades can be found where applicable on the tire sidewall...
Page 239: Temperature
０５／１２／２１１７：０６：５４３１ＳＡＡ６０００２３８ Temperature A, B, C − The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat, and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 240: Tire Labeling
０５／１２／２１１７：０７：０９３１ＳＡＡ６０００２３９ Tire Labeling The tires that came on your vehicle have a number of markings. Those you should be aware of are described below. Tire Size Whenever tires are replaced, they should be replaced with tires of the same size. Below is an example of tire size with an explanation of what each component means.
Page 241: Emissions Controls
This section summarizes how the emissions controls work. ＊ In Canada, Honda vehicles comply with the Canadian emission requirements, as specified in an agreement with Environment Canada, at the time they are manufactured.
Page 242: Exhaust Emissions Controls
Clean Air Act. To make sure the emissions remain low, you should use only new Honda replacement parts or their equivalent for repairs. Using lower quality parts may increase the emissions from your vehicle.
Page 243: Three Way Catalytic Converter
The catalytic converter is referred to as a three-way catalyst, since it acts on HC, CO, and NOx. A replacement unit must be an original Honda part or its equivalent. The three way catalytic converter must operate at a high temperature for the chemical reactions to take place.
Page 244: State Emissions Testing
０５／１２／２１１７：０７：４２３１ＳＡＡ６０００２４３ State Emissions Testing Testing of Readiness Codes If you take your vehicle for a state emissions test shortly after the battery has been disconnected or gone dead, it may not pass the test. This is because of certain ‘‘readiness codes’’...
Page 245: Warranty And Customer Relations
０５／１２／２１１７：０７：４５３１ＳＡＡ６０００２４４ Warranty and Customer Relations Customer Service Information Warranty Coverages Reporting Safety Defects (U.S. Vehicles) Authorized Manuals . 242 . 243 . 244 . 245...
Page 246: Customer Service Information
If you are dissatisfied with the decision made by the dealership’s management, contact your Honda Customer Service Office. U.S. Owners: American Honda Motor Co., Inc. Automobile Customer Service Mail Stop 500-2N-7A 1919 Torrance Boulevard Torrance, California 90501-2746 Tel: (800) 999-1009...
Page 247: Warranty Coverages
Accessory Limited Warranty − Honda accessories are covered under this warranty. Time and mileage limits depend on the type of accessory and other factors. Please read your warranty booklet for details.
Page 248: Reporting Safety Defects (U.s. Vehicles)
National Highway Traffic Safety Administration (NHTSA) in addition to notifying American Honda Motor Co., Inc. If NHTSA receives similar com- plaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 249: Authorized Manuals
＊ Prices are subject to change without notice and without incurring obligation. Valid only for sales within the United States. Canadian owners should contact their authorized Honda dealer. ORDER TOLL FREE: 1-800-782-4356 (NOTE: For Credit Card Holder Orders Only) Monday-Friday 8:00 A.M.
Page 250 ０５／１２／２１１７：０８：２６３１ＳＡＡ６０００２４９ Authorized Manuals NOTE: Dealers and companies, please provide dealer or company name, and the name of the person to whose attention the shipment should be sent. For purchases outside U.S.A. please write to the address shown below for a quotation. Ｓ...
Page 251 National Highway Traffic Safety Administration (NHTSA) in addition to notifying American Honda Motor Co., Inc. If NHTSA receives similar com- plaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 252 ０５／１２／２１１７：０８：３５３１ＳＡＡ６０００２５１ Index Cargo, How to Carry . 140 CAUTION, Explanation of CD Care . 122 CD Error Messages . 121 CD Player . 112 Certification Label . 230 Chains, Tires . 202 Changing a Flat Tire . 207 Changing Oil .
Page 253 ０５／１２／２１１７：０８：４０３１ＳＡＡ６０００２５２ DOT Tire Quality Grading ＊ . 234 Downshifting, Manual Transmission . 149 Driver and Passenger Safety Driving . 145 Economy . 137 Driving Guidelines . 146 Driving with the Paddle Shifters . 156 Dust and Pollen Filter . 194 Economy, Fuel .
Page 254 ０５／１２／２１１７：０８：４５３１ＳＡＡ６０００２５３ Index Fuel . 132 Check Fuel Cap Indicator Fill Door and Cap . 133 Low Fuel Indicator Gauge Octane Requirement . 132 Oxygenated . 132 Tank, Refueling . 133 Fuel Economy . 137 Fuses, Checking the . 222 Gas Mileage, Improving .
Page 255 ０５／１２／２１１７：０８：５１３１ＳＡＡ６０００２５４ Malfunction . 219 Passenger Airbag Off Seat Belt Reminder . 18, 60 Security System Side Airbag Off . 31, 61 . 30, 61 Turn Signal and Hazard Warning . 71, 73 Washer Level Indicators, Instrument Panel Infant Restraint Infant Seats Tether Anchorage Point Inflation, Proper Tire .
Page 256 ０５／１２／２１１７：０８：５７３１ＳＡＡ６０００２５５ Index Meters, Gauges . 59, 66 Methanol in Gasoline . 132 Mirrors, Adjusting Modifying Your Vehicle . 138 Neutral Gear Position . 153 New Vehicle Break-in . 132 Normal Shift Speeds . 150 NOTICE, Explanation of Numbers, Identification . 230 Octane Requirement, Gasoline .
Page 257 ０５／１２／２１１７：０９：０２３１ＳＡＡ６０００２５６ Remote Transmitter Replacement Information Dust and Pollen Filter . 194 Engine Oil and Filter . 178 Fuses . 221 Light Bulbs . 186 Tires . 200 Wiper Blades . 195 Replacing Seat Belts After a Crash ＊ Reporting Safety Defects .
Page 258 ０５／１２／２１１７：０９：０６３１ＳＡＡ６０００２５７ Index How Your Side Curtain Airbags Work SRS Indicator . 30, 61 START (Ignition Key Position) Starting the Engine . 148 In Cold Weather at High Altitude . 148 With a Dead Battery . 214 State Emissions Testing . 240 Steam Coming from Engine .
Page 259 ０５／１２／２１１７：０９：１１３１ＳＡＡ６０００２５８ Unexpected, Taking Care of the . 205 Uniform Tire Quality Grading ＊ . 234 Unleaded Gasoline . 132 Used Oil, How to Dispose of . 179 Vehicle Capacity Load . 141 Vehicle Dimensions . 232 Vehicle Identification Number . 230 Vehicle Storage .
Page 260 ０５／１２／２１１７：０９：１３３１ＳＡＡ６０００２５９ ...
Page 261 ０５／１２／２１１７：０９：１５３１ＳＡＡ６０００２６０ ...
Page 262: Service Information Summary
(see page Capacity (including differential): 1.6 US qt (1.5 ) Brake Fluid: Honda Heavy Duty Brake Fluid DOT 3 preferred, or a DOT 3 or DOT 4 brake fluid as a temporary replacement (see page Tire Pressure (measured cold): Front/Rear: 32 psi (220 kPa , 2.2 kgf/cm )
