2-2. SS-TS8 (OVERALL SECTION)

SP3
#10
SP3
#10
51
Ref. No. Part No. Description
51 X-4955-907-1 FRAME ASSY, GRILLE
52 4-249-757-01 BUFFLE PANEL(FRONT)
53 4-249-754-01 SPEAKER CABINET (FR)
54 1-694-836-11 TERMINAL, SPEAKER
55 4-249-758-01 TERMINAL BASE (FR)
56 4-251-125-01 SCREW (M5X35)
57 4-250-938-01 SCREW 3X10 +PTP
8
All manuals and user guides at all-guides.com
52
#10
57
#10
#10
57
#10
#10
Remark Ref. No.
58
SP3
SP4
#8
#9
#10
#8
#9
SP4
55
57
#8
stand section
Part No. Description
4-249-768-01 COVER
1-825-592-11 SPEAKER (7cm)
1-825-591-11 SPEAKER (1.5cm)
7-685-548-19 SCREW +BTP 3X12 TYPE2 N-S
7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S
7-685-547-19 SCREW +BTP 3X10 TYPE2 N-S
53
54
58
56
Remark
