Dell™ Latitude™ C400

Replacing the Display

w w w . d e l l . c o m | s u p p o r t . d e l l . c o m

Advertisement

loading

Summary of Contents for Dell Latitude C400

  • Page 1: Replacing The Display

    Dell™ Latitude™ C400 Replacing the Display w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
  • Page 2: Notes, Notices, And Cautions

    Dell Computer Corporation disclaims any proprietary interest in trademarks and trade names other than its own.
  • Page 3: Removing The Display

    Replacing the Display This document describes how to replace the display in your Dell Latitude C400 computer. The display and the top cover of the computer are designed to be removed and replaced as one unit. CAUTION: Before performing the following procedures, read "Safety and EMC Instructions: Portable Computers"...
  • Page 4 Re plac ing the Display Turn the computer right-side up and open it. display center cover computer base...
  • Page 5 Remove the center cover. center cover Open the display all the way (180 degrees) so that it lies flat against your work surface. Press down the slot on the front edge of the center cover. Press down the keys to locate the right release slot. To protect the keyboard, place a flexible straightedge (such as the ruler in the illustration) across the rows of keys directly in front of the center cover, touching the front edge of the center cover.
  • Page 6 D i s p l a y S c r e w s Re plac ing the Display Close the display. Turn the computer over and remove the two 6-mm screws at the back corners of the computer. Put the screws aside in a safe place. Turn the computer right-side up and open the display all the way.
  • Page 7 Disconnect the display cable assembly from the computer base. 12-mm securing board screws (2) securing board pull tab display cable assembly Remove the two 12-mm screws from the securing board. Use the pull tab to pull the securing board up out of its connector. Replacing the Display...
  • Page 8 Pivot the display upright and lift it out of the computer. Re plac ing the Display...
  • Page 9 Installing the New Display Position the replacement display upright and align its hinges with the slots at the back corners of the computer. Ensure that the display cable assembly is positioned well in front of the display to avoid trapping or pinching the cable when you insert the display.
  • Page 10 Press the display-cable securing board firmly into its connector in the computer base, and replace the two 12-mm screws you removed in step 8 of the previous procedure (or use the new screws provided with the display kit). Re plac ing the Display...
  • Page 11 Close the display, turn the computer over, and replace the two 6-mm screws at the back corners of the computer. Turn the computer right-side up, open it all the way, and replace the center cover: Carefully position the cover, and then press down first on the center and then on the back ridge of the cover to snap those areas into place.
  • Page 12 Re plac ing the Display...
  • Page 14 Printed in the U.S.A. 08M232A00 P/N 8M232 Rev. A00 w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
