Summary of Contents for Philips BDL4988XL

  • Page 1 BDL4988XL V1.00 www.philips.com/welcome User Manual (English)
  • Page 2 Read and follow these instructions when connecting and using your display: Operation: • Keep the display out of direct sunlight and away from stoves or any other heat sources. • Remove any object that could fall into ventilation holes or prevent proper cooling of the display’s electronics. • Do not block the ventilation holes on the cabinet. • When positioning the display, make sure the power plug and outlet are easily accessible. • When turning off the display by detaching the power cord, wait 6 seconds before re-attaching the power cord for normal operation. • Ensure the use of an approved power cord provided by Philips at all times. If your power cord is missing, please contact your local service center. • Do not subject the display to severe vibration or high impact conditions during operation. • Do not knock or drop the display during operation or transportation. Maintenance: • To protect your display from possible damage, do not put excessive pressure on the LCD panel. When moving your display, grasp the frame to lift; do not lift the display by placing your hand or fingers on the LCD panel. • Unplug the display if you are not going to use it for an extensive period of time.
  • Page 3 BDL4988XL Read and follow these instructions when connecting and using your display: • Unplug the display if you are not going to use it for an extensive period of time. • Unplug the display if you need to clean it with a slightly damp cloth. The screen many be wiped with a dry cloth when the power is off. However, never use alcohol, solvents or ammonia-based liquids. • Consult a service technician if the display does not operate normally when you have followed the instructions in this manual. • The casing cover should be opened only by qualified service personnel. • Keep the display out of direct sunlight and away from stoves or any other heat sources. • Remove any object that could fall into the vents or prevent proper cooling of the display’s electronics. • Do not block the ventilation holes on the cabinet. • Keep the display dry. To avoid electric shock, do not expose it to rain or excessive moisture.
  • Page 4 BDL4988XL Regulatory Information CE Declaration of Conformity This device complies with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (2014/30/EU), Low-voltage Directive (2014/35/EU), and RoHS directive (2011/65/EU). This product has been tested and found to comply with the harmonized standards for Information Technology Equipment, these harmonized standards published under Directives of Official Journal of the European Union. ESD Warnings When user close to the monitor may cause the equipment discharge and reboot to the display of main menu. Warning: This equipment is compliant with Class A of EN55032/CISPR 32. In a residential environment this equipment may cause radio interference. Federal Communications Commission (FCC) Notice (U.S. Only) NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 5 BDL4988XL Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source. The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value no larger than 16 amperes (A). To completely switch off the equipment, the power supply cable must be removed from the power supply socket, which should be located near the equipment and easily accessible. A protection mark “B” confirms that the equipment is in compliance with the protection usage requirements of standards PN-93/T-42107 and PN-89/ E-06251. Electric, Magnetic and Electronmagnetic Fields (“EMF”) 1. We manufacture and sell many products targeted at consumers, which, like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals.
  • Page 6 BDL4988XL Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows: 1. Remove fuse cover and fuse. 2. Fit new fuse which should be a BS 1362 5A,A.S.T.A. or BSI approved type. 3. Refit the fuse cover. If the fitted plug is not suitable for your socket outlets, it should be cut off and an appropriate 3-pin plug fitted in its place. If the mains plug contains a fuse, this should have a value of 5A. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5A.
  • Page 7 BDL4988XL 中国大陆RoHS 根据中国大陆 《电子电气产品有害物质限制使用标识要求》 ， 以下部分列出了产品中可能包含 的有害物质的名称和含量。 产品中有害物质的名称及含量 有害物质 零部件名称 六价铬 多溴联苯 多溴二苯醚 铅（Pb） 汞（Hg） 镉（Cd） (PBB) (PBDE) （Cr（VI）） 塑胶外壳 ○ ○ ○ ○ ○ ○ 后壳 ○ ○ ○ ○ ○ ○ CCFL × × ○ ○ ○ ○...
  • Page 8 BDL4988XL 《废弃电器电子产品回收处理管理条例》提示性说明 为了更好地关爱及保护地球，当用户不再需要此产品或产品寿命终止时，请遵守国家废弃电器电子产品 回收处理相关法律法规，将其交给当地具有国家认可的回收处理资质的厂商进行回收处理。 限用物質及其化學符號 單元 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) (PBB) (PBDE) 塑料外框 ○ ○ ○ ○ ○ ○ 後殼 ○ ○ ○ ○ ○ ○ 液晶面板 － ○ ○ ○ ○ ○ 電路板組件 －...
  • Page 9 BDL4988XL North Europe (Nordic Countries) Information Placering/Ventilation VARNING: FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS. Placering/Ventilation ADVARSEL: SØRG VED PLACERINGEN FOR, AT NETLEDNINGENS STIK OG STIKKONTAKT ER NEMT TILGÆNGELIGE. Paikka/Ilmankierto VAROITUS: SIJOITA LAITE SITEN, ETTÄ VERKKOJOHTO VOIDAAN TARVITTAESSA HELPOSTI IRROTTAA PISTORASIASTA. Plassering/Ventilasjon ADVARSEL: NÅR DETTE UTSTYRET PLASSERES, MÅ DU PASSE PÅ AT KONTAKTENE FOR STØMTILFØRSEL ER LETTE Å NÅ. End-of-Life Disposal Your new Public Information Display contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of. Please find out about the local regulations on how to dispose of your old display from your local Philips dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury. Dispose of in accordance to local-state and federal regulations. For additional information on recycling contact www.eia.org (Consumer Education Initiative)
  • Page 10 BDL4988XL Restriction on Hazardous Substances statement (India) This product complies with the “E-Waste (Management) Rules, 2016” CHAPTER V, rule 16, sub-rule (1) . Whereas New Electrical and Electronic Equipment and their components or consumables or parts or spares do not contain Lead, Mercury, Cadmium, Hexavalent Chromium, polybrominated biphenyls and polybrominated diphenyl ethers beyond a maximum concentration value of 0.1% by weight in homogenous materials for lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers and of 0.01% by weight in homogenous materials for cadmium. except of exemptions set in Schedule 2 of the Rule. E-Waste Declaration for India This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment . The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.

  • Page 11: Table Of Contents

    BDL4988XL Table Of Contents Operation ................. 19 4.1. Watch the Connected Video Source ......19 4.2. Change Picture Format ............19 Unpacking and Installation ............1 4.3. Play multimedia files via Local Area Network ..19 1.1. Unpacking ..................1 4.3.1. Set up the network ..........19 1.2. Package Contents ................1 4.3.2. How to use DLNA-DMP ......... 19 1.3. Installation Notes .................1 4.3.3.

  • Page 12: Unpacking And Installation

    BDL4988XL Unpacking and Installation 1.1. Unpacking • This product is packed in a carton, together with the standard accessories. • Any other optional accessories will be packed separately. • Due to the size and weight of this display it is recommended for two people to move it. • After opening the carton, ensure that the contents are complete and in good condition. 1.2. Package Contents Please verify that you received the following items with your package content: • LCD display • CD ROM • Remote control with AAA batteries • Power cord (1.8 m) • DVI cable (1.8 m) CD ROM • RS232 cable (1.8 m) Quick start guide • Daisy chain cable (1.8 m) • IR sensor cable...

  • Page 13: Mounting On A Wall

    BDL4988XL 1.4. Mounting on a Wall To mount this display to a wall, you will have to obtain a standard wall-mounting kit (commercially available). We recommend using a mounting interface that complies with TUV-GS and/or UL1678 standard in North America. Protective Sheet VESA Grid Table Tabletop stand 1. Lay a protective sheet on a table, which was wrapped around the display when it was packaged, beneath the screen surface so as not to scratch the screen face. 2. Ensure you have all accessories for mounting this display (wall mount, ceiling mount, table stand, etc). 3. Follow the instructions that come with the base mounting kit. Failure to follow correct mounting procedures could result in damage to the equipment or injury to the user or installer.

  • Page 14: Mounting In Portrait Position

    BDL4988XL 1.5. Mounting in Portrait Position This display can be installed in portrait position. 1. Remove the table stand, if attached. 2. Rotate 90 degrees anticlockwise. The “ ” logo should be bristling when facing the display at the back.

  • Page 15: Operating Instructions Of Edge Alignment Kit

    BDL4988XL 1.6. Operating Instructions of Edge Alignment Kit 1.6.1. Installing Edge Alignment Kit • Before install edge alignment kit, displays must be mounted to video wall frame correctly. • Using “Thumb Screw” for easy installing. • Using “Edge Alignment Kit-1” on adjacent four displays. • Using “Edge Alignment Kit-2” on adjacent two displays. NOTE: W hen installing the edge alignment kit, please consult a professional technician for proper installation. We accept no liability for installations not performed by a professional technician.

  • Page 16: Using Of Edge Finishing Kit (Optional)

    BDL4988XL 1.7. Using of Edge Finishing Kit (Optional) You could use the edge finishing kit to protect the display and have a better appearance. 1.7.1. Installing Edge Finishing Kit Installing Edge Finishing Kit for 1x1 Display Configuration Edge Finishiing Kit-Top (*1PC) Corner(*4PCS) Edge Finishiing Edge Finishiing Kit-Right(*1PC) Kit-Left(*1PC) Screw Edge Finishiing Kit-Bottom (QTY is different depending (*1PC) on models) Installing Edge Finishing Kit for 2x2 Display Configuration Edge Finishiing Kit-Top...

  • Page 17: Parts And Functions

    BDL4988XL Parts and Functions 2.1. Control Panel MUTE INPUT MENU [ ] button [MENU] button Use this button to turn the display on or put the display to standby. Return to previous menu while OSD menu is on, or to activate the OSD menu when OSD menu is off. [MUTE] button Remote control sensor and power status indicator Switch the audio mute ON/OFF. • Receives command signals from the remote control. [INPUT] button • Indicates the operating status of the display without OPS: Choose the input source. - Lights green when the display is turned on • Used as [ ] button in the On-Screen-Display menu.

  • Page 18: Input/Output Terminals

    BDL4988XL 2.2. Input/Output Terminals 10 11 12 15 16 18 AC IN DisplayPort IN / DisplayPort OUT AC power input from the wall outlet. DisplayPort video input / output. MAIN POWER SWITCH VGA IN (D-Sub) Switch the main power on/off. VGA video input. AC OUT COMPONENT IN (BNC) AC power supply to the AC IN jack of a media player. Component YPbPr video source input. IR IN / IR OUT Y/CVBS IR signal input / output for the loop-through function.

  • Page 19: Remote Control

    BDL4988XL 2.3. Remote Control ] HOME button Access the OSD menu. 2.3.1. General functions ] LIST button No function. [ ] [ ] [ ] [ ] NAVIGATION buttons Navigate through menus and choose items. ] button Confirm an entry or selection. [ ] ADJUST button Access currently available options, picture and sound menus. ] MUTE button Press to turn the mute function on/off.

  • Page 20: Id Remote Control

    BDL4988XL 2.3.2. ID Remote Control 4. Press [ENTER] button to confirm. The red LED blinks twice and then lights off. You can set the remote control ID when you want to use this remote control on one of several different displays. NOTE: • Press [NORMAL] button. The green LED blinks twice, indicating the display is in normal operation. • It is necessary to set up the ID number for each display before selecting its ID number. Press [ID] button. The red LED blinks twice. 1. Press [ID SET] button for more than 1 second to enter the ID Mode. The red LED lights up. Press the [ID SET] button again will exit the ID Mode. The red LED lights off. Press the digit numbers [0] ~ [9] to select the display you want to control. For example: press [0] and [1] for display No.1, press [1] and [1] for display No.11.

  • Page 21: Inserting The Batteries In The Remote Control

    BDL4988XL 2.3.3. Inserting the batteries in the remote control The remote control is powered by two 1.5V AAA batteries. To install or replace batteries: 1. Press and then slide the cover to open it. 2. Align the batteries according to the (+) and (–) indications inside the battery compartment. 3. Replace the cover. Caution: The incorrect use of batteries can result in leaks or bursting. Be sure to follow these instructions: • Place “AAA” batteries matching the (+) and (–) signs on each battery to the (+) and (–) signs of the battery compartment. • Do not mix battery types. • Do not combine new batteries with used ones. It causes shorter life or leakage of batteries. • Remove the dead batteries immediately to prevent them from liquid leaking in the battery compartment. Don’t touch exposed battery acid, as it can damage your skin.

  • Page 22: Connecting External Equipment

    BDL4988XL Connecting External Equipment 3.1. Connecting External Equipment (DVD/VCR/VCD) 3.1.1. Using COMPONENT video input Audio Out COMPONENT Out (YPbPr) DVD / VCR / VCD [AUDIO IN] [COMPONENT IN] (YPbPr) 3.1.2. Using Video Source input Y/CVBS Out DVD / VCR / VCD...

  • Page 23: Using Hdmi Video Input

    BDL4988XL 3.1.3. Using HDMI video input DVD / VCR / VCD HDMI Out [HDMI IN] 3.2. Connecting a PC 3.2.1. Using VGA input VGA Out D-Sub 15 pin Audio Out [VGA IN] [VGA AUDIO IN] 3.2.2. Using DVI input DVI Out...

  • Page 24: Using Hdmi Input

    BDL4988XL 3.2.3. Using HDMI input HDMI Out [HDMI IN] 3.2.4. Using DisplayPort input DisplayPort Out [DisplayPort IN] 3.3. Connecting Audio Equipment 3.3.1. Connecting external speakers External speakers...

  • Page 25: Connecting An External Audio Device

    BDL4988XL 3.3.2. Connecting an external audio device Audio In Stereo Amplifier [AUDIO OUT] 3.4. Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a video wall. 3.4.1. Display control connection Connect the [RS232C OUT] connector of DISPLAY 1 to the [RS232C IN] connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [RS-232C] [RS-232C IN] [RS-232C OUT] [RS-232C IN] DISPLAY 1...

  • Page 26: Digital Video Connection

    BDL4988XL 3.4.2. Digital video connection Connect the [DVI OUT / VGA OUT] connector of DISPLAY 1 to the [DVI IN] connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [DVI] [DVI IN] [DVI/VGA OUT] [DVI IN] Connect the [DP OUT] connector of DISPLAY 1 to the [DP IN] connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [DP] [DP IN] [DP OUT] [DP IN] Connect the [DVI OUT ] connector of DISPLAY 1 to the [DVI IN] connector of DISPLAY 2. DVD / VCR / VCD DISPLAY 1 DISPLAY 2 [HDMI]...

  • Page 27: Ir Connection

    BDL4988XL 3.5. IR connection External IR Receiver [IR IN] NOTE: T his display’s remote control sensor will stop working if the [IR IN] is connected. 3.6. IR Pass-through Connection [IR OUT] DVD / VCR / VCD [IR IN] (DVD / VCR / VCD) Remote Control...

  • Page 28: Wire-Connecting To Network

    BDL4988XL 3.7. Wire-connecting to Network If you connect this display to a home network, you can play photos, music and videos from your computer. See Play multimedia files via Local Area Network (Page 18) for more detail. INTERNET ROUTER [RJ-45] [RJ-45] To setup the network: 1. Switch on the router and switch on its DHCP setting. 2. Connect the router to this display with an Ethernet cable. Setup 3. Press [ ] HOME button on the remote control, then select Connect to network ] button.

  • Page 29: Operation

    BDL4988XL Operation DISPLAY 1 DISPLAY 2 NOTE: T he control button described in this section is mainly on the remote control unless specified otherwise. ROUTER [RJ-45] [RJ-45] [RJ-45] 4.1. Watch the Connected Video Source See page 11 for external equipments connection. NOTE: I f the apparatus does not return to DLNA mode due to 1. Press [ ] SOURCE button. external electrical disturbances (e.g. electrostatic discharge), user 2. Press [ ] or [ ] button to choose a device, then press [ intervention is required.

  • Page 30: How To Use Dlna-Dmr From Pc

    BDL4988XL 4.3.3. How to use DLNA-DMR from PC Advanced sharing settings Turn on 7. Go to , and check network discovery 1. Press [ ] HOME button, choose Network and press [ 8. Now, go to the directory of your media files. Choose the media button. Play To file by right click. On the submenu from , You can find all displays connected to your network.

  • Page 31: Play Options

    BDL4988XL 4.5. Play options 4.5.3. Playing photo files Photo 1. Choose in the top bar. 4.5.1. Playing music files Photo Music 1. Choose in the top bar. ] button. 2. Choose a photo thumbnail, then press Music Start a slideshow ] button. 2. Choose one music track, and press [ If there are multiple photos in a folder, choose a photo. Then, press • To play all the tracks in a folder, choose one music file.
  • Page 32 BDL4988XL Internet Web Address： http:// History www.google.com Bookmark . , @ ‘ Done w x y z Hide p q r s ? ! - < 123 www Backspace 3. Move the cursor to “  ” icon and press [ ] button. Internet Web Address： http://www.google.com History www.google.com...

  • Page 33: Change Your Settings

    BDL4988XL Change your settings 5.1.1. Picture Using the remote control: Picture style Picture Sound Backlight Tiling Colour Network Sharpness MENU General settings Noise reduction m e n u MPEG artifact reducti... Picture enhancement Advanced Scan mode Format and edges EXIT Picture reset 1.

  • Page 34: Sound

    BDL4988XL Sync. Volume • {V Zoom}: Expands the vertical size of the image only. Choose to {On} or {Off} the Sync. Volume function. Set {On} to Note: Zoom, H Zoom and V Zoom are functional only when the synchronize the volume of internal speaker and line-out. Set {Off} to Picture format setting is set to Custom Zoom. adjust the volume of internal speaker and line-out, respectively. Picture format See page 18 for the descriptions about Sound reset Picture reset Reset to default setting. Reset all your picture settings to the factory defaults. Card OPS audio Choose to set OPS audio output format. 5.1.2. Sound The options are: {Auto}, {Analog}, {Digital}...

  • Page 35: Network

    BDL4988XL Example: 5 x 5 screen matrix (25 displays) H monitors = 5 displays V monitors = 5 displays H monitors Position Note: To use this function, serial connect all machines with RS-232 cable and set their Network control port to RS-232 too. Frame comp. Note: To use this function for DP 1.2 connectivity, the maximum resolution only support to 1920x1080/60Hz @ 4sets. For 4Kx2K/30Hz Choose to turn the frame compensation function on or off. If selected resolution only support to 2 sets connectivity. {On}, the display will adjust the image to compensate for the width of the display bezels in order to accurately display the image.

  • Page 36: General Settings

    BDL4988XL 5.1.5. General settings Picture Menu language Sound Monitor Group Picture Menu language Tiling Monitor ID Sound Monitor Group Network Tiling Eco mode Monitor ID General settings Auto search Network Eco mode Clock General settings Auto search Scheduling Clock Scheduling...
  • Page 37 BDL4988XL On time Playlist setting 3. Set 6. If {Source}  {USB} is chosen. Go to 0001/0002 Photo Schedule 1 Status Schedule 2 Source Photo On time Schedule 3 Video Schedule 4 Off time Schedule 5 Repeat modes On time Schedule 6...
  • Page 38 BDL4988XL Local KB lock Light sensor Choose to enable or disable the keyboard (control buttons) function of Choose {On} and the display will automatically adjust backlight. the display. Human sensor • {Unlock}: Enable the keyboard function. Set the display to turn on backlight if it does sensor human and turn off • {Lock all}: Lock all keyboard function. backlight after an amount of the specified. • {Lock but volume}: Disable all the keyboard function except the The options are :{Off, 10 ~ 60} minutes. Only available when you plug in ] and [ ] button. CRD41. • {Lock but power}: Disable all the keyboard function except the Power LED Light [ ] button.
  • Page 39 BDL4988XL 5.1.6. Advanced Picture Jitter clean Sound EQ boost Picture Jitter clean Tiling USB copying Sound EQ boost Network Tiling USB copying General settings Network General settings Advanced Advanced Jitter clean Turn on/off Jitter cleaning function for HDMI and DVI signal quality enhancement. The default setting is on. Picture Jitter clean Sound EQ boost...

  • Page 40: Usb Device Compatibility

    BDL4988XL USB device compatibility USB Video Subtitle Formats (for language subtitles, etc.) File Max.Bit Rate Container Video codec Maximum resolution Max.Frame Rate (fps) Audio codec Extensions (Mbps) MPEG-1 1920x1080 25p,30p,50i,60i MPEG-1(L1&L2), .mpg MPEG-2 1920x1080 25p,30p,50i,60i MPEG-1,2,2.5 L3, mpeg AAC/HE-AAC(v1&v2), MPEG-4 ASP 1920x1080 25p,30p,50i,60i .vob DVD-PCM,AC3 H.264 1920x1080 25p,30p,50p,60p,60i...
  • Page 41 BDL4988XL .wma .asf (V2 up to V9.2) .wma WMA Pro WMA,WMA Pro .wav(PC) LPCM LPCM .aif(mac) LPCM LPCM .aiff(mac) .aac .mp4 1024 AAC,HE-AAC(v1&v2) .m4a .pls Playlists .m3u .m4a 1024 AAC,HE-AAC(v1&v2) NOTES: • Sound or video may not work if the contents have a standard bit rate/frame rate above the compatible Frame/sec listed in the table above. • Video content with a Bit rate or Frame rate larger than the rate specified in the table above can cause choppy video during playback.

  • Page 42: Input Mode

    BDL4988XL Input Mode VGA Resolution: Active Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Stand for Mode Resolution H Pixels V Lines 60 Hz 25.175 MHz 480 72 Hz 31.5 MHz Video Graphic Array 75 Hz 31.5 MHz WVGA 400 70 Hz 33.75 MHz 16:9 Wide Video Graphic Array 60 Hz 40 MHz SVGA 600 Super VGA 75 Hz 49.5 MHz 60 Hz 65 MHz 1024 768 Extended Graphic Array 75 Hz 78.75 MHz...

  • Page 43: Pixel Defect Policy

    We strive to deliver the highest quality products and use some of the industry’s most advanced manufacturing processes whilst practicing stringent quality control. However, pixel or sub-pixel defects on the PDP / TFT panels used in Plasma- & LCD- displays are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but Philips guarantees that any Plasma- & LCD- displays with an unacceptable number of defects will be repaired during the warranty period in line with your local guarantee conditions. This notice explains the different types of pixel defects and defines the acceptable defect level for the LCD screen. In order to qualify for repair under warranty, the number of pixel defects must exceed a certain level as shown in the reference table. If the LCD screen is within specification a warranty exchange / claim back will be refused. Additionally, because some types or combinations of pixel defects are more noticeable than others, Philips sets even higher quality standards for those. 8.1. Pixels and Sub-Pixels A pixel, or picture element, is composed of three sub-pixels in the primary colors of red, green and subpixel blue.

  • Page 44: Dark Dot Defects

    Dark Dot Defects Black dot defects appear as pixels or sub-pixels that are always dark or “off ”. These are the examples of black dot defects: One dark dot Two adjacent dark dots = 1 pair of dark dots Two dark dots, specifications defines the minimum distance between dark dots 8.5. Proximity of Pixel Defects Because pixel and sub-pixels defects of the same type that are nearby one another may be more noticeable, Philips also specifies tolerances for the proximity of pixel defects. In the table below you can find specifications about: • Allowed amount of adjacent dark dots = (adjacent dark dots =1 pair of dark dots) • Minimum distance between dark dots • Total no. of all defective dots 8.6. Pixel Defect Tolerances In order to qualify for repair due to pixel defects during the warranty period, a PDP / TFT panel in a Philips Plasma / LCD- display must have pixel or sub- pixel defects exceeding the tolerances listed in the following table.

  • Page 45: Cleaning And Troubleshooting

    BDL4988XL Cleaning and Troubleshooting 9.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes. Burns or personal injuries may occur if any body parts are brought too close. Placing any object near the top of the display could also result in heat related damage to the object as well as the display itself. • Be sure to disconnect all cables before moving the display. Moving the display with its cables attached may damage the cables and thus cause fire or electric shock. • Disconnect the power plug from the wall outlet as a safety precaution before carrying out any type of cleaning or maintenance procedure. Front Panel Cleaning Instructions • The front of the display has been specially treated. Wipe the surface gently using only a cleaning cloth or a soft, lint-free cloth.

  • Page 46: Troubleshooting

    BDL4988XL 9.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is disconnected. 1. Plug in the power cord. 2. The main power switch on the back of the 2. Make sure the power switch is switched on. display is not switched on. 3. Connect a signal connection to the display. 3. The selected input has no connection. 4. The display is in standby mode. Interference displayed on the display or audible...
  • Page 47 BDL4988XL How to setup the settings in the menu to Daisy chained by RS232 and no IR cable 1. The first display sets as “Primary” on OSD control all the monitors at the same time and (Advanced option/IR control item), others set as individually via RC? “Secondary”. 2. The setup OSD will show on Top-Left of display. (Toggle MENU will show again if it disappear) 3. Default setting: ID NO: 0, GP NO: 0, this setting can control all displays by IR.

  • Page 48: Technical Specifications

    BDL4988XL Technical Specifications Display: Item Specifications Screen Size (Active Area) 48.5” (123.2 cm) LCD Aspect Ratio 16:9 Number of pixels 1920 (H) x 1080 (V) Pixel pitch 0.559 (H) x 0.559 (V) [mm] Displayable colors 1.07B colors Brightness (typical) 450 cd/m Contrast ratio (typical) 1300:1 Viewing angle 178 degrees In/Out Terminals: Item Specifications Speaker Output Internal Speakers 10W (L) + 10W (R) [RMS]/8Ω External Speakers 1 Way 1 Speaker System 82 dB/W/M/160 Hz ~ 13 KHz Audio Output 3.5mm phone jack x 1 0.5V [rms] (Normal) / 2 Channel (L+R) Audio Input RCA Jack x 2 0.5V [rms] (Normal) / 2 Channel (L+R) 3.5mm phone jack x 1 RS232C 2.5mm Phone jack x 2...
  • Page 49 BDL4988XL General: Item Specifications Power Input 100 - 240V~, 50 - 60Hz, 6.0A Power Output 100 - 240V~, 50 - 60Hz, 2.5A Power Consumption (Max) 235 W Power Consumption (typ.) 110 W Power Consumption (Standby & Off) <0.5 W (RS232 in active) Dimensions (Without Stand) [W x H x D] 1077.7 x 607.9 x 93.5 (@Wall mount) / 103.8 (@Handle) Weight (Without Stand) 21.6 Kg Gross Weight (Without Stand) 33.5 Kg Environmental Condition: Item Specifications Temperature Operational 0 ~ 40°C Storage -20 ~ 60°C Humidity Operational 20 ~ 80% RH (No condensation)
  • Page 50 2015 © Koninklijke Philips N.V. All rights reserved. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. Specifications are subject to change without notice.
