Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read the “Safety Information” (page 2). • Instructions about “Installing the TV to the Wall” are included within this TV’s instruction manual.
Page 3
Installation/Set-up Topple prevention Install and use the TV set in accordance with the instructions KD-65S8500D / 55S8500D only below in order to avoid any risk of fire, electric shock or damage and/or injuries. Installation • The TV set should be installed near an easily accessible AC power outlet (mains socket).
Page 4
Use only Sony supplied AC power cords (mains lead), not those of other brands. Insert the plug fully into the AC power outlet (mains socket).
Page 5
Ask your dealer or Sony service centre to have it checked by near flammable objects (candles, etc). The TV set shall not be qualified service personnel.
Caution about handling the remote control Precautions • Observe the correct polarity when inserting batteries. • Do not use different types of batteries together or mix old and Viewing the TV new batteries. • View the TV in moderate light, as viewing the TV in poor light or •...
Parts and Controls Controls and Indicators KD-65S8500D / 55S8500D only Except KD-65S8500D / 55S8500D Remote Control sensor* / Light sensor* (Input select) / Illumination LED Display and select the input source. The illumination LED lights up or blinks according to the status of the TV.
Using Remote Control Remote Control Parts Description The remote control shape, location, availability and function of remote control button may vary depending on your region/country/TV model. KD-65S8500D / 55S8500D only Except KD-65S8500D / 55S8500D / (Input select/Text hold) DIGITAL/ANALOG In TV mode: Display and select the input Switch between digital and analogue mode.
Page 9
AUDIO (Info/Text reveal) Display information. Change the language for the programme currently being viewed. Google Play ////// Access the “Google Play” online service. Operate media contents on TV and NETFLIX (Only on limited region/ connected BRAVIA Sync-compatible device. country/TV model) (Subtitle setting) Access the “NETFLIX”...
Connection Diagram For more information on connections, refer to the Help Guide (page 2). KD-65S8500D / 55S8500D only DVD player with HDMI Device component output Digital still camera/ Camcorder/ USB storage media Headphone/ Home Audio System/ Subwoofer HDMI Device DVI-HDMI...
Page 11
USB 1/2, USB3 • Connecting a large USB device may interfere with other connected devices beside it. • When connecting a large USB device, connect to the USB 1 port. AUDIO OUT* / • To listen to the TV's sound through the connected equipment, press HOME.
Page 12
Except KD-65S8500D / 55S8500D Digital still camera/ Camcorder/USB storage media Headphone/Home Audio System/ Subwoofer HDMI Device DVD player with HDMI component output Device Home Audio System with ARC/ HDMI Device HDMI Device VCR/Video game equipment/DVD player/Camcorder Router Cable/Antenna VCR/Video game...
Page 13
USB 1/2, USB3 < 12 mm • Connecting a large USB device may interfere with other connected devices < 21 mm beside it. • When connecting a large USB device, connect to the USB 1 port. AUDIO OUT* /...
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.
Page 15
Remove the stand cover. KD-65S8500D / 55S8500D only Remove the screws from the rear of the TV. KD-65S8500D / 55S8500D only Except KD-65S8500D / 55S8500D...
SU-WL450 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 22-23 (Specifications) for the TV’s weight.
Page 17
• If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference. Standard mounting KD-65S8500D / 55S8500D only Pulley Screw (+PSW 6 x 20) ...
Page 18
Slim mounting Note • You cannot use some of the terminals on the rear of the TV when using this mounting style. KD-65S8500D / 55S8500D only Except KD-65S8500D / 55S8500D KD-65S8500D / 55S8500D only Pulley Spacer (20 mm) ...
Page 19
• You cannot access to any terminal after installing the TV to the wall. Detach the Table-Top Stand from the TV. KD-65S8500D / 55S8500D only Except KD-65S8500D / 55S8500D Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the Wall”...
TV. If the problem persists, contact your dealer or Sony service centre with the number of times the illumination LED flashes red (interval time is three seconds). Disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre.
Page 21
Select [[Manual entry]] and press to enter on the TV. network name. Rear of TV KD-65S8500D / 55S8500D only Except KD-65S8500D / 55S8500D The illumination LED is turned on. If you do not wish to light up the illumination LED, you can turn it off.
Specifications Digital and DTS ARC (Audio Return Channel) (HDMI IN 4 only) System (Two channel linear PCM, Dolby Digital, DTS) Except KD-65S8500D / 55S8500D Panel system Video: LCD (Liquid Crystal Display) Panel, LED Backlight 4096 × 2160p (50, 60 Hz)* , 4096 ×...
Page 23
Dimensions (Approx.) (w × h × d) other countries. with Table-Top Stand • Opera® Devices SDK from Opera Software KD-65S8500D: 1,456 x 895 x 287 mm ASA. Copyright 1995-2015 Opera Software KD-55S8500D: 1,238 x 772 x 262 mm ASA. All rights reserved.
Page 28
AC 電源線 為了避免火災、觸電或損壞及 / 或受傷等危險,請遵照下列指示來處 • 將電視機放置在潮濕或多塵的空間,或有 理 AC 電源線和插座 : 油煙或蒸氣的場所 (靠近灶台或加濕 僅使用 Sony 隨附的 AC 電源線,不能使用其他品牌的電源線。 器) 。這可能導致火災、觸電或本機彎曲。 將插頭完全插入 AC 電源插座。 僅在 220 V - 240 V AC 電源範圍內操作本電視機。 • 將電視機安裝在會遭受極端溫度的位置, 連接纜線時,為了安全起見請務必拔下 AC 電源線,以免被纜線絆...
統啟動需要時間。等待大約一分鐘,然後再次操 請參閲下圖有關電視機上按鈕的位置。 作。在按遙控器或電視機上的電源按鈕開啟時,需 要一定時間打開照明 LED 以及使遙控器工作。 電視機背面 當照明 LED 閃紅燈時,計算閃爍次數 (間隔時間 僅限 KD-65S8500D / 55S8500D 為三秒) 。 若 照明 LED 閃爍紅色 ,斷開 AC 電源線兩分鐘, 然後再開啟電視機,以此來重設電視機。 如果問題仍然存在,請聯繫您的經銷商或 Sony 服 務中心並告知照明 LED 閃紅燈的次數 (間隔時間 為三秒) 。拔掉 AC 電源線,然後告訴您的經銷商 或 Sony 服務中心。...
