INSTRUCTION MANUAL
28'' Combination LED TV/DVD
28HXJ15U
129/7355
Important - Please read these instructions fully before installing or operating and keep for future
reference.
These instructions contain important information which will help you get the best from your
television and ensure safe and correct installation and operation.
For any help concerning set up and use of your TV please call the
Customer Helpline: 0845 604 0105
Lines open: 9am - 8pm Monday to Saturday and 10am - 4pm Sunday
Advertisement
Table of Contents
Troubleshooting
Summary of Contents for Hitachi 28HXJ15U
- Page 1 INSTRUCTION MANUAL 28’’ Combination LED TV/DVD 28HXJ15U 129/7355 Important - Please read these instructions fully before installing or operating and keep for future reference. These instructions contain important information which will help you get the best from your television and ensure safe and correct installation and operation.
-
Page 2: Table Of Contents
Contents Safety Information ..........2 Quick Menu ............15 Preparation ............2 Menu Features and Functions ......16 Intended Use ............2 Menu Features and Functions ......17 Power source ............3 Menu Features and Functions ......18 Positioning the TV ..........3 Electronic Programme Guide (EPG) .... -
Page 3: Safety Information
Safety Information 7KH OLJKWQLQJ ÀDVK ZLWK DUURZKHDG V\PERO ZLWKLQ DQ HTXLODWHUDO WULDQJOH LV LQWHQGHG WR alert the user to the presence of uninsulated CAUTION “dangerous voltage” within the product’s RISK OF ELECTRIC SHOCK HQFORVXUH WKDW PD\ EH RI VXI¿FLHQW PDJQLWXGH DO NOT OPEN to constitute a risk of electric shock of persons. -
Page 4: Power Source
Safety Information DON’T SODFH KRW REMHFWV RU QDNHG ÀDPH VRXUFHV ‡ Do not block the ventilation openings. VXFK DV OLJKWHG FDQGOHV RU QLJKWOLJKWV RQ RU FORVH WR ‡ Do not SODFH WKH 79 RQ VORSLQJ RU XQVWDEOH VXUIDFHV equipment. High temperatures can melt plastic and the TV may tip over. -
Page 5: Heat Sources And Flames
Safety Information Batteries Heat sources and Flames ‡ Do not expose the TV to direct sunlight ‡ Warning: Incorrect installation of or other heat sources. batteries may cause battery leakage ‡ The TV should not be placed near to DQG FRUURVLRQ UHVXOWLQJ LQ GDPDJH WR RSHQ ÀDPHV DQG VRXUFHV RI LQWHQVH the remote control. -
Page 6: Symbols In This Instruction Book
Safety Information CAUTION Symbols in this Instruction Book 'R QRW SXW \RXU ¿QJHUV LQ WKH PLGGOH EHWZHHQ WKH 79 The following symbols are used in the Instruction DQG VWDQG HVSHFLDOO\ ZKHQ \RX FDUU\ WKH 79 DV WKH\ Book as a marker for restrictions and precautions PD\ EH LQMXUHG and safety instructions. -
Page 7: Getting Started
Getting Started Support Technical experts are available 7 days a week Simple help and advice on setting up your digital ‡ equipment (image). Guidance on connecting other devices to your ‡ television such as a DVD player, Sky, home cinema system or a games console. -
Page 8: Environmental Information
Accessories included Environmental Information This television is designed to consume less energy to ‡ Remote Control help save the environment. You can not only help to ‡ Batteries: 2 x AAA save the environment but you can also save money ‡... -
Page 9: Viewing The Tv
To change source: Press the middle of the button twice, the Viewing the TV source list will appear on screen. Scroll through the available sources by pushing the button up or down. To turn the TV off: Press the middle of the button down and hold it down for a few seconds, the TV will turn into standby mode. -
Page 10: Viewing Remote Control - Tv
Viewing remote control - TV 1. Standby 2. Numeric buttons 3. TV-AV / Channel List / DVB-T 4. Volume up/down 5. Mute 6. Navigation buttons 7. Menu on/off 8. OK / Channel List 9. Return/Back 10. Internet portal 11. Media Browser 12. -
Page 11: Viewing Remote Control - Dvd
Viewing remote control - DVD 1. Standby 2. TV Menu 3. OK / Select 4. Back 5. Angel 6. Display / DVD Menu 7. Repeat 8. Zoom 9. Language selection 10. Rapid reverse 11. Pause 12. Play 13. Stop 14. Rapid advance 15. - Page 12 Viewing the Connections Connector Type Cables Device Scart Connection (back) Connection (back) PC/YPbPr SIDE AV Audio Connection Side Audio/Video (side) Connection Cable PC Audio Cable (Supplied) (Not supplied) HDMI Connection (back) SPDIF Connection (back) Side AV SIDE AV Connection AV Connection Cable (side) (supplied) Headphone...
-
Page 13: Using A Conditional Access Module
6WDQGE\ 1RWL¿FDWLRQV Using a Conditional Access Module If the TV does not receive any input signal (e.g. From IMPORTANT: Insert or remove the CI module only when DQ DHULDO RU +'0, VRXUFH IRU PLQXWHV WKH 79 ZLOO the TV is SWITCHED OFF. JR LQWR VWDQGE\ :KHQ \RX QH[W VZLWFKRQ WKH 79 WKH ,Q RUGHU WR ZDWFK FHUWDLQ GLJLWDO FKDQQHOV D FRQGLWLRQDO following message will be displayed:... -
Page 14: Installing The Batteries To The Remote
Installing the Batteries to the Remote First Time Installation 1. Lift the cover on the back of the remote upward :KHQ WXUQHG RQ IRU WKH ¿UVW WLPH WKH ³ODQJXDJH gently. selection” menu appears. The message “Welcome please select your language!” is displayed in all 2. -
Page 15: Aerial Installation
(*) LCN is the Logical Channel Number system that You can activate Store mode option by using “ ” or “ ” organizes available broadcasts in accordance with a EXWWRQ ,I 6WRUH 0RGH LV VHOHFWHG 6WRUH PRGH RSWLRQ ZLOO EH recognizable channel sequence. -
Page 16: Using Menu Button In Media Browser Mode
Press MENU button and select Media Browser tab by Up or Down button to select the channel that will be using Left/Right and OK buttons. Main media browser processed. Press Left or Right button to select a screen will be displayed. You can display the related function on Channel List menu. -
Page 17: Menu Features And Functions
Menu Features and Functions Picture Menu Contents )RU \RXU YLHZLQJ UHTXLUHPHQWV \RX FDQ VHW WKH UHODWHG PRGH RSWLRQ 3LFWXUH PRGH FDQ EH Mode set to one of these options: CinemaGameDynamic Sport and Natural. Contrast Sets the lightness and darkness values of the screen. Brightness Sets the brightness value for the screen. -
Page 18: Menu Features And Functions
Menu Features and Functions Sound Menu Contents Volume $GMXVWV YROXPH OHYHO ,Q HTXDOL]HU PHQX WKH SUHVHW FDQ EH FKDQJHG WR Music Movie Speech Flat Classic Equalizer: and User. Press the MENU button to return to the previous menu. Equalizer menu settings can be changed manually only when the Equalizer Mode is in User. -
Page 19: Menu Features And Functions
Menu Features and Functions Settings Menu Contents Conditional Access Controls conditional access modules when available. Language &RQ¿JXUHV ODQJXDJH VHWWLQJV &RQ¿JXUHV SDUHQWDO VHWWLQJV Default PIN code can change depending on the selected country. Parental ,I \RX DUH DVNHG WR HQWHU D 3,1 FRGH IRU YLHZLQJ D PHQX RSWLRQ XVH RQH RI WKH IROORZLQJ FRGHV RU Timers Sets timers for selected programmes. -
Page 20: Electronic Programme Guide (Epg)
Electronic Programme Guide (EPG) DVD MODE 6RPH EXW QRW DOO FKDQQHOV VHQG LQIRUPDWLRQ DERXW Handling Discs the current and next programmes. Press the “ ” ‡ 7R NHHS WKH GLVF FOHDQ RQO\ KDQGOH WKH GLVF E\ LWV button to view the EPG menu. edge. -
Page 21: How To Watch A Dvd
f. When the DVD player is restarted or the disc How to watch a DVD LV FKDQJHG WKH VXEWLWOH VHOHFWLRQ LV DXWRPDWLFDOO\ changed back to the initial settings. NOTE: DVD mode cannot be accessed unless a DVD g. If a language is selected that is not supported by is inserted or a DVD control button is pressed. - Page 22 DISC MENU You can select the DVD’s disc menu language among these languages. Disc menu appears in the selected ODQJXDJH LI VXSSRUWHG E\ WKH '9' GLVF SUBTITLE You can select the default subtitle language if supported by the DVD disc. Preferences: These are the DVD mode preferences.
- Page 23 DVD Controls <RX FDQ RSHUDWH '9' PRYLH &' PXVLF RU SLFWXUH &'¶V FRQWHQW E\ XVLQJ WKH FRUUHFW EXWWRQV RQ \RXU UHPRWH control. Below are main functions of commonly used remote control buttons. Buttons DVD Playback Movie Playback Picture Playback Music Playback Play Play Play...
-
Page 24: Connectivity Functions
Connectivity Functions Connecting to a Wired Network For connecting to a wired LAN network, you should perform the following steps: ‡ Connect broadband ISP connection ethernet cable to the ETHERNET INPUT of your modem. ‡ Ensure that Nero Media Home software is installed to your PC.(for DLNA function). -
Page 25: Rq¿Jxulqj 1Hwzrun 6Hwwlqjv
‡ 8VH /$1 FRQQHFWLRQ IRU TXLFNHU ¿OH VKDULQJ EHWZHHQ other devices like computers. ‡ The frequency and channel differ depending on the area. ‡ The transmission speed differs depending on the distance and number of obstructions between the WUDQVPLVVLRQ SURGXFWV WKH FRQ¿JXUDWLRQ RI WKHVH SURGXFWV WKH UDGLR ZDYH FRQGLWLRQV WKH OLQH WUDI¿F and the products that you use. -
Page 26: Information
You can navigate between menu tabs by pressing left/ right buttons. The help bar on the bottom of the dialog shows features that you may use. Press BLUE button to check your internet connection speed. You can check the signal strenght by using the network settings menu for the wireless device mode. -
Page 27: Connectivity Troubleshooting
OK ,Q WKH VHWWLQJV RSWLRQV KLJKOLJKW View Style and Connectivity Troubleshooting change to Folder using Left or Right button. Wireless Network Not Available Please select desired media type and press OK. Ensure that the firewalls of your network allows the TV wireless connection. The dedicated XVE ZL¿ dongle(sold separately) should be plugged properly (if available). -
Page 28: Internet Portal
Select Videos from this screen to list all the available ‡ Press BACK to go to the previous screen. YLGHR ¿OHV IURP WKH VHOHFWHG QHWZRUN ‡ Press EXIT to quit internet portal mode. 7R SOD\ RWKHU PHGLD W\SHV IURP WKLV VFUHHQ \RX Note: Possible application dependent problems may must go back to main Media Browser screen and be caused by the content service provider. -
Page 29: Troubleshooting & Tips
2) 3.AM search and upgrade mode 4. Is the aerial cable damaged? 5. Are suitable plugs used to connect the aerial? ‡ ,I Automatic scanning in Upgrade Options menu LV HQDEOHG 79 ZDNHV XS DW DQG VHDUFKHV 6. ,I \RX DUH LQ GRXEW FRQVXOW \RXU GHDOHU broadcast channels for new software upgrade. -
Page 30: Dvb-T Functionality Information
DVB-T functionality information 640x480 72Hz 640x480 75Hz This DVB receiver is only suitable for use in the country which it was designed to be used in. 640x480 85Hz 800x600 56Hz Although this DVB receiver conforms to the latest DVB VSHFL¿FDWLRQV DW WKH WLPH RI PDQXIDFWXUH ZH FDQQRW 800x600 60Hz guarantee compatibility with future DVB transmissions... -
Page 31: Disposal Information
POWER CONSUMPTION (W) 50 W (max) 6SHFL¿FDWLRQV PANEL 16:9 TV BROADCASTING TV Dimensions PAL/SECAM B/G D/K K’ I/I’ L/L’ DxLxH (with foot): 185 x 648 x 433 DIGITAL RECEPTION DxLxH (without foot): 60 x 648 x 397 DVB-T MPEG2 DVB-T MPEG4 HD DVB-T MHEG-5 Engine (for UK only) Weight NJ ZLWK IRRW NJ ZLWKRXW IRRW ... -
Page 32: Supported File Formats For Usb Media Browser
Supported File Formats for USB Media Browser Media Extension Format Notes Video Audio Movie GDW PSJ 0SHJ 03(* /D\HU $$&+($$& 1080P@ 30fps 50Mbit/ mpeg $&($& /3&0$'3&0 GDW PSJ 03(* + 9& $96 03(* /D\HU $$&+($$& H.264:1080Px2@25fps mpeg $&($& /3&0$'3&0 1080P@ 50fps MVC: 1080P@ 24fps Other: 1080P@ 30fps”... -
Page 33: Supported Dvi Resolutions
Supported DVI Resolutions :KHQ FRQQHFWLQJ GHYLFHV WR \RXU 79¶V FRQQHFWRUV E\ XVLQJ '9, FRQYHUWHU FDEOHV QRW VXSSOLHG \RX FDQ UHIHU to the following resolution information. 56Hz 60Hz 66Hz 70Hz 72Hz 75Hz 640x400 640x480 800x600 832x624 1024x768 1152x864 1152x870 1280x768 1360x768 1280x960 1280x1024 1400x1050... -
Page 34: 9' 0Rgh 6Xssruwhg ¿Oh Irupdwv
'9' 0RGH 6XSSRUWHG ¿OH IRUPDWV Media File Format Supported Extension (Maximum resolution/Bit rate etc.) Video Audio MPEG1 MPEG Layer .mpg/.dat/.vob 1/2/3 MPEG2 MPEG2 ;YL'LY[ PCM/MP3 ;YL' 9HUVLRQ XS WR Movie MPEG4 PCM/MP3 .avi MS ISO PCM/MP3 Support SP and ASP MPEG4 Sample Rate: 8K ~ 48KHz Music... -
Page 35: Appendix: Nero Mediahome Installation
Appendix: Nero MediaHome Installation To install Nero MediaHome, please proceed as follows: Note: To use DLNA function, this software should be installed to your PC. 1. Insert the Nero MediaHome installation disc in your optical disc drive. ‡ The Nero MultiInstaller screen with a button to start the installation process will open automatically. - Page 36 7. Use Typical installation and click the Next 10. ,QVWDOODWLRQ ¿QLVKHV button. The Help us to Enhance Nero Software screen is ‡ The Prerequisites screen is displayed. GLVSOD\HG ,Q RUGHU WR RIIHU D EHWWHU VHUYLFH 1HUR is collecting anonymous data to determine which The Nero MediaHome installation wizard checks the IHDWXUHV DUH XVHG DQG ZKDW SUREOHPV LI DQ\ RFFXU availability of required third-party software on your PC.
- Page 37 14. Run Nero MediaHome by pressing shortcut icon. ‡ Click ADD icon from LOCAL FOLDERS to add the folder you want to share with the network. Select the folder that you want to share and click START SERVER. 15. You can display all media types from the library. Click Refresh icon to refresh.
-
Page 38: Getting Started With Skype
Getting Started with Skype Make voice calls and video calls with Skype on your TV. Select the Skype app from the portal section to start a conversation. Follow the on screen instructions to see how to operate related features. NOTE ‡... - Page 39 Sign In & Sign Up Now 7R XVH WKH 6N\SH DSSOLFDWLRQ \RX QHHG D 6N\SH DFFRXQW <RX FDQ FUHDWH D 6N\SH DFFRXQW XVLQJ WKLV DSS LQ WKH µ6LJQ ,Q 6LJQ 8S 1RZ¶ PHQX LI \RX GRQ¶W DOUHDG\ KDYH RQH ,I \RX DOUHDG\ KDYH D 6N\SH DFFRXQW enter your name and password correctly.
- Page 40 Adding a contact By pressing the EXWWRQ VHOHFW WKH ³6HDUFK &RQWDFWV´ RSWLRQ (QWHU WKH IXOO QDPH VN\SH QDPH RU HPDLO DGGUHVV RI WKH FRQWDFW \RX ZDQW WR ¿QG DQG DGG Use the remote control or virtual keyboard to enter a keyword. Recent history Incoming call Outgoing call...
- Page 41 Actions $ F F R X Q W 1 D P H O n l i n e Select a Menu by pressing the button. mood message and status SUR¿OH SLFWXUH Your contact list (Press Ok to use video&voice call) Help bar Select a person from the contact list screen and press OK.
- Page 42 Incoming call The incoming call dialog is shown when you are logged into Skype and when other users initiate a Skype call. A small dialog box will appear in the lower right corner of the TV screen whether the user watches TV or is browsing through Skype. Use the remote control button and choose your action.
-
Page 43: Guarantee
Guarantee Product Guarantee This product is guaranteed against manufacturing defects for a period of Year This product is guaranteed for twelve months from the date of original purchase. $Q\ GHIHFW WKDW DULVHV GXH WR IDXOW\ PDWHULDOV RU ZRUNPDQVKLS ZLOO HLWKHU EH UHSODFHG refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit. - Page 44 ,/d ,/ 10084787 Product No. 28HXJ15U 28 inches / 71 cm 0,5W 1366 x 768 English - 43 - For any help concerning set up and use of your TV please call the Customer Helpline: 0845 604 0105...
- Page 45 Manufacturer: Hitachi Europe Ltd., Whitebrook Park, Lower Cookham Road, Maidenhead, Berkshire SL6 8YA U.K. Importer: Argos Ltd., 489 - 499 Avebury Boulevard, Central Milton Keynes, Buckinghamshire MK9 2NW U.K. www.hitachidigitalmedia.com...
