Operating Instructions
LCD Television
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
The images shown in this manual are for illustrative purposes only.
Please refer to Pan European Guarantee Card if you need to contact your
local Panasonic dealer for assistance.
For more detailed instructions, refer to [eHELP]
(Built-in Operating Instructions).
How to use [eHELP]
Model No.
TX-42ASE650
TX-47ASE650
(p. 17)
English
Advertisement
Chapters
Table of Contents
Related Manuals for Panasonic TX-42ASE650
Summary of Contents for Panasonic TX-42ASE650
- Page 1 (Built-in Operating Instructions). How to use [eHELP] (p. 17) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. The images shown in this manual are for illustrative purposes only.
-
Page 2: Table Of Contents
Contents Be Sure to Read Important Notice··················································· 3 Safety Precautions ··············································· 4 Quick Start Guide Accessories ························································ 7 Connections ························································ 9 Identifying Controls ··············································12 First time Auto Setup ············································15 Using your VIERA Operations ·························································16 How to Use eHELP ··············································17 Viewing 3D images ··············································17 Others FAQs ································································18 Maintenance ······················································19... -
Page 3: Important Notice
Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. -
Page 4: Safety Precautions
This product is licensed under the AVC patent portfolio Safety Precautions license for the personal and non-commercial use of a consumer to (i) encode video in compliance with the AVC Standard (“AVC Video”) and/or (ii) decode AVC To help avoid risk of electrical shock, fire, damage or Video that was encoded by a consumer engaged in injury, please follow the warnings and cautions below: a personal and non-commercial activity and/or was... - Page 5 Radio wave Do not use an unapproved pedestal / mounting equipment. Be sure to ask your local Panasonic Warning dealer to perform the setup or installation of approved Do not use the TV and Touch Pad Controller in wall-hanging brackets.
- Page 6 Ventilation Remove the battery from the unit when not using for a prolonged period of time to prevent battery leakage, Caution corrosion and explosion. Allow sufficient space around the TV in order to help 3D Eyewear Use prevent excessive heat, which could lead to early failure of some electronic components.
-
Page 7: Accessories
LCD Television Touch Pad Controller Declaration of Conformity (DoC) (p. 13) “Hereby, Panasonic Corporation declares that this TV is N2QBYA000004 in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” If you want to get a copy of the original DoC of this TV,... - Page 8 Assembling / Removing the pedestal Assembly screw (4) M5 × 15 Assembly screw (4) M4 × 12 Bracket (2) Base Assembling the pedestal Removing the pedestal from the TV Be sure to remove the pedestal in the following way when using the wall-hanging bracket or repacking the 1 Remove the assembly screws from the TV.
-
Page 9: Connections
Connections 8 ETHERNET (p. 10) 9 Terrestrial / cable terminal (p. 9) 10 DIGITAL AUDIO External equipment and cables shown are not 11 HDMI1 - 2 (p. 10, 11) supplied with this TV. Please ensure that the unit is disconnected from the Basic connections mains socket before attaching or disconnecting any cables. - Page 10 AV devices Network To use internet service, you need a broadband network DVD Recorder / VCR environment. If you do not have any broadband network services, please consult your retailer for assistance. Prepare the internet environment for wired connection or wireless connection. Setup of the network connection will start when first using the TV.
- Page 11 Headphones Camcorder / Game equipment To adjust volume (VIDEO equipment) [Headphone Volume] in the Sound Menu To select the sound output to adjust volume [Speaker Setting] in the Sound Menu (Viewing) (Listening) (M3 stereo mini plug) Common Interface Turn the TV off with Mains Power On / Off switch Game equipment whenever inserting or removing the CI module.
-
Page 12: Identifying Controls
Identifying Controls 7 OK &RQILUPV VHOHFWLRQV DQG FKRLFHV 3UHVV DIWHU VHOHFWLQJ FKDQQHO SRVLWLRQV WR TXLFNO\ FKDQJH FKDQQHO 'LVSOD\V FKDQQHO OLVW Remote Control 8 [Option Menu] (DV\ RSWLRQDO VHWWLQJ IRU YLHZLQJ VRXQG HWF 9 Coloured buttons (red-green-yellow-blue) 8VHG IRU WKH VHOHFWLRQ QDYLJDWLRQ DQG RSHUDWLRQ RI YDULRXV IXQFWLRQV 10 Volume Up / Down 11 Numeric buttons... - Page 13 Installing / Removing batteries 3XOO RSHQ +RRN &ORVH 1RWH WKH FRUUHFW SRODULW\ RU Touch Pad Controller 7RXFK 3DG &RQWUROOHU LV GHVLJQHG IRU WKH FRQYHQLHQW RSHUDWLRQV HVSHFLDOO\ RQ +RPH 6FUHHQ RU LQWHUQHW 1 Standby On / Off switch FRQWHQWV <RX FDQ RSHUDWH WKH 79 LQWXLWLYHO\ ZLWK WKLV 2 Volume Up / Down FRQWUROOHU 3 [Main Menu]...
- Page 14 Indicator / Control panel 6OLGH \RXU ILQJHU WR PRYH WKH FXUVRU :KHQ SUHVVLQJ EXWWRQV WKH FRQWURO SDQHO RQ LQWHUQHW FRQWHQWV RU >&XUVRU JXLGH DSSHDUV RQ WKH ULJKW VLGH RI WKH VFUHHQ IRU 6HWWLQJV@ LQ >9,(5$ 7RXFK 3DG VHFRQGV WR KLJKOLJKW WKH SUHVVHG EXWWRQ &RQWUROOHU@ 6HWXS 0HQX VHOHFW WKH LWHP DGMXVW OHYHOV HWF...
-
Page 15: First Time Auto Setup
First time Auto Setup Tick the TV signal mode to tune, and then select [Start Auto Setup] WXQH VHDUFK IRU WKH DYDLODEOH FKDQQHOV VNLS WXQLQJ $XWRPDWLFDOO\ VHWV XS WKH 79 DQG VHDUFKHV IRU DYDLODEOH 79 FKDQQHOV ZKHQ WKH 79 LV WXUQHG RQ IRU WKH ILUVW WLPH $XWR 6HWXS VFUHHQ YDULHV GHSHQGLQJ RQ WKH FRXQWU\ DQG WKH VLJQDO PRGH \RX VHOHFW 7KHVH VWHSV DUH QRW QHFHVVDU\ LI WKH VHWXS KDV EHHQ... -
Page 16: Operations
Operations 7KH VHOHFWDEOH PRGHV YDU\ GHSHQGLQJ RQ WKH FKDQQHOV VWRUHG VHOHFW Turn power on DFFHVV <RX FDQ DOVR VHOHFW WKH PRGH SUHVVLQJ WKH 79 EXWWRQ 79 UHSHDWHGO\ ,I >79 6HOHFWLRQ@ LV QRW GLVSOD\HG SUHVV WKH 79 EXWWRQ WR VZLWFK WKH PRGH 5HPRWH &RQWURO Select a channel 0DLQV SRZHU 2Q 2II VZLWFK VKRXOG EH RQ S ... -
Page 17: How To Use Ehelp
3OHDVH FRQVXOW WKH VXSSOLHUV RI FRQWHQWV RU SURJUDPPHV IRU DYDLODELOLW\ RI WKLV VHUYLFH VHOHFW LWHP 3D photos and 3D videos taken by 3D-compatible Panasonic products DFFHVV $YDLODEOH LQ 0HGLD 3OD\HU DQG 1HWZRUN VHUYLFHV 6XE LWHP ILHOG 2D images converted to 3D 'HVFULSWLRQ 3UHVV WKH ' EXWWRQ DQG VHW WR >' '@ PRGH LQ >'... -
Page 18: Faqs
FAQs The display panel moves slightly and clattered sound is heard when it is pushed with a finger 7KHUH LV D OLWWOH JDS DURXQG WKH SDQHO WR SUHYHQW GDPDJH WR WKH SDQHO 7KLV LV QRW D PDOIXQFWLRQ %HIRUH UHTXHVWLQJ VHUYLFH RU DVVLVWDQFH SOHDVH IROORZ WKHVH VLPSOH JXLGHV WR VROYH WKH SUREOHP )RU PRUH LQIRUPDWLRQ UHIHU WR >H+(/3@ 6XSSRUW ! )$4V ... -
Page 19: Maintenance
Maintenance Specifications First, remove the mains plug from the socket outlet. Model No. : 7;$6( 42-inch model Display panel, Cabinet, Pedestal : 7;$6( 47-inch model Regular care: Dimensions (W × H × D) *HQWO\ ZLSH WKH VXUIDFH RI WKH GLVSOD\ SDQHO FDELQHW RU SHGHVWDO E\ XVLQJ D VRIW FORWK WR FOHDQ WKH GLUW RU 42-inch model ILQJHUSULQWV... - Page 20 HDMI 1 / 2 / 3 input PAL 525/60 7<3( $ &RQQHFWRUV 3OD\EDFN RI 176& WDSH IURP VRPH 3$/ 9LGHR UHFRUGHUV 9&5 +'0, ' &RQWHQW 7\SH +'0, ' &RQWHQW 7\SH $XGLR 5HWXUQ &KDQQHO M.NTSC 7KLV 79 VXSSRUWV ³+'$9, &RQWURO ´ IXQFWLRQ 3OD\EDFN IURP 0176&...
- Page 21 Materials Main body / Lens section 5HVLQ 8VH 3DQDVRQLF ' (\HZHDU VXSSRUWLQJ SDVVLYH ' V\VWHP WHFKQRORJ\ Note 7RXFK 3DG &RQWUROOHU XVHV %OXHWRRWK ZLUHOHVV WHFKQRORJ\ 'HVLJQ DQG 6SHFLILFDWLRQV DUH VXEMHFW WR FKDQJH ZLWKRXW QRWLFH 0DVV DQG 'LPHQVLRQV VKRZQ DUH DSSUR[LPDWH )RU WKH LQIRUPDWLRQ RI SRZHU FRQVXPSWLRQ GLVSOD\ UHVROXWLRQ HWF SOHDVH UHIHU WR 3URGXFW ILFKH )RU WKH LQIRUPDWLRQ RI WKH RSHQ VRXUFH VRIWZDUH UHIHU WR >H+(/3@ 6XSSRUW ! /LFHQFH ...
- Page 22 Warranty Service purposes. Model Number Serial Number English TQB0E2400U Web Site: http://panasonic.net © Panasonic Corporation 2014 Printed in the Czech Republic...
- Page 23 Gebruik van de [eHELP] (p. 17) Hartelijk dank voor de aankoop van dit Panasonic-product. Lees deze instructies aandachtig voordat u het product gebruikt en bewaar ze zodat u ze later opnieuw kunt raadplegen. De afbeeldingen in deze handleiding dienen slechts als voorbeeld.
- Page 24 Inhoudsopgave Belangrijke informatie Belangrijke kennisgeving Veiligheidsmaatregelen Quick Start-handleiding Accessoires Verbindingen Bedieningsonderdelen Automatisch instellen bij het eerste gebruik Uw VIERA-tv gebruiken Bediening Gebruik eHELP 3D-beeld weergeven Overige informatie Veelgestelde vragen Onderhoud Specificaties Nederlands...
-
Page 25: Belangrijke Kennisgeving
Panasonic heeft geen bevoegdheid om u deze toestemming te geven en verleent u deze ook niet, en wijst uitdrukkelijk alle rechten, mogelijkheden of intenties af om een dergelijke toestemming in uw naam te verkrijgen. -
Page 26: Veiligheidsmaatregelen
Dit product is in licentie gegeven onder de AVC- Veiligheidsmaatregelen patentportfoliolicentie voor persoonlijk en niet- commercieel gebruik door een consument voor (i) het coderen van video in overeenstemming met de AVC- Volg onderstaande waarschuwingen en norm (“AVC Video”) en/of (ii) het decoderen van AVC- voorzorgsmaatregelen om het risico op een elektrische video die werd gecodeerd door een consument voor schok, brand, schade of letsel te helpen vermijden. - Page 27 Gebruik geen standaard of montage-uitrusting die Zorg dat kinderen niet op de standaard klimmen. niet is goedgekeurd. Vraag uw Panasonic-dealer om Gebruik minstens twee personen om de tv op de de instellingen of installatie uit te voeren van een standaard te installeren en ervan te verwijderen.
- Page 28 Bluetooth draadloze technologie Batterij voor de afstandsbediening / ® Touchpadcontroller Let op De TV en touchpadcontroller gebruiken de 2,4 Let op ® GHz radiofrequentieband ISM (Bluetooth ). Om Batterijen kunnen lekken, roesten en exploderen als een slechte werking of trage respons, veroorzaakt ze verkeerd geïnstalleerd worden.
-
Page 29: Accessoires
LCD-televisie Netsnoer (p. 9) Conformiteitsverklaring (DoC) “Panasonic Corporation verklaart hierbij dat deze tv voldoet aan de essentiële eisen en andere relevante Batterijen bepalingen van de Richtlijn 1999/5/EG.” R6 (2) Bezoek de volgende website als u een kopie wenst van... - Page 30 De standaard monteren/verwijderen Montageschroef (4) M5 × 15 Montageschroef (4) M4 × 12 Beugel (2) Steunplaat De standaard monteren De standaard van de tv verwijderen Verwijder de standaard op de volgende manier wanneer u de muurbevestigingssteun gebruikt of de tv opnieuw inpakt.
-
Page 31: Verbindingen
Verbindingen 8 ETHERNET (p. 10) 9 Aansluiting aardse ingang/kabel (p. 9) 10 DIGITAL AUDIO De afgebeelde externe apparatuur en kabels worden 11 HDMI1 - 2 (p. 10, 11) niet bij de tv meegeleverd. Zorg ervoor dat de stekker van de tv niet in het Basisaansluitingen stopcontact zit als u kabels aansluit of loskoppelt. - Page 32 AV-apparaten Netwerk Voor gebruik van de internetdienst moet u beschikken dvd-recorder / VCR over een breedbandnetwerk. Raadpleeg uw leverancier voor hulp als u geen breedbandnetwerkservices hebt. Zorg dat de internetomgeving gereed is voor het aansluiten van een bekabelde of draadloze verbinding.
- Page 33 Camcorder / Spelsysteem (VIDEO-apparatuur) (M3-stereoministekker) (Kijken) Algemene interface (CI) Zet de tv altijd met de hoofdschakelaar uit wanneer u (Luisteren) de CI-module plaatst of verwijdert. Als u een gecombineerde smartcard en CI-module hebt, plaatst u eerst de CI-module en vervolgens steekt u de smartcard in de CI-module.
-
Page 34: Bedieningsonderdelen
Bedieningsonderdelen 7 OK %HYHVWLJW VHOHFWLHV HQ NHX]HV 6FKDNHOW RYHU QDDU GH JHVHOHFWHHUGH NDQDDOSRVLWLH *HHIW GH NDQDOHQOLMVW ZHHU 8 [Menu Opties] Afstandsbediening (HQYRXGLJH RSWLRQHOH LQVWHOOLQJHQ YRRU ZHHUJDYH JHOXLG HQ] 9 Gekleurde toetsen (rood, groen, geel, blauw) 9RRU VHOHFWLH QDYLJDWLH HQ GH EHGLHQLQJ YDQ YHUVFKLOOHQGH IXQFWLHV 10 Volume omhoog/omlaag 11 Cijfertoetsen... - Page 35 De batterijen plaatsen/verwijderen 2SHQWUHNNHQ +DDNMH 6OXLWHQ 3ODDWV GH EDWWHULMHQ RS GH MXLVWH PDQLHU RI Touchpad-controller 'H]H WRXFKSDGFRQWUROOHU LV RQWZRUSHQ RP GH EHGLHQLQJ 1 Stand-bytoets YDQ GH WY WH YHUJHPDNNHOLMNHQ PHW QDPH WLMGHQV KHW 2 Volume omhoog/omlaag JHEUXLN YDQ +RPH 6FUHHQ HQ LQWHUQHW 'H FRQWUROOHU PDDNW GH EHGLHQLQJ YDQ GH WY HHQYRXGLJ HQ LQWXwWLHI 3 [Hoofdmenu] 'H WRXFKSDGFRQWUROOHU PRHW YRRU JHEUXLN YLD...
- Page 36 Indicator/Bedieningspaneel 6FKXLI PHW XZ YLQJHU RP GH $OV X RS HHQ YDQ GH WRHWVHQ GUXNW ZRUGW FXUVRU WH YHUSODDWVHQ RS LQWHUQHW JHGXUHQGH VHFRQGHQ UHFKWV RS KHW VFKHUP HHQ LQKRXG RI >&XUVRU LQVWHOOLQJHQ@ LQ KXOSDDQGXLGLQJ ZHHUJHJHYHQ YRRU GH LQJHGUXNWH >9,(5$ WRXFKSDGFRQWUROOHU@ PHQX WRHWV ,QVWHOOLQJHQ RP HHQ RQGHUGHHO WH...
-
Page 37: Automatisch Instellen Bij Het Eerste Gebruik
Automatisch instellen Vink het tv-signaal aan waarop u wilt afstellen en selecteer [Start auto set-up] DIVWHPPHQ EHVFKLNEDUH NDQDOHQ ]RHNHQ bij het eerste gebruik DIVWHPPHQ RYHUVODDQ +HW LQVWHOVFKHUP YHUVFKLOW DIKDQNHOLMN YDQ KHW JHVHOHFWHHUGH ODQG HQ WYVLJQDDO 'H]H IXQFWLH KHOSW X ELM KHW DXWRPDWLVFK LQVWHOOHQ HQ >'9%&... -
Page 38: Bediening
Bediening 'H VHOHFWHHUEDUH VWDQGHQ ]LMQ DIKDQNHOLMN YDQ GH RSJHVODJHQ NDQDOHQ VHOHFWHUHQ Schakel de tv in RSHQHQ 8 NXQW GH VWDQG RRN VHOHFWHUHQ PHW GH 79WRHWV GRRU GH]H ]R YDDN DOV QRGLJ LQ WH GUXNNHQ 79 $OV KHW PHQX >79 NHX]H@ QLHW YHUVFKLMQW VHOHFWHHUW X GH PRGXV PHW GH WYWRHWV $IVWDQGVEHGLHQLQJ Selecteer een kanaal... -
Page 39: Gebruik Ehelp
5DDGSOHHJ GH OHYHUDQFLHUV YDQ GH LQKRXG RI GH SURJUDPPD¶V RPWUHQW GH EHVFKLNEDDUKHLG YDQ GH]H GLHQVW 3D-foto’s en 3D-video die zijn opgenomen RQGHUGHHO op 3D-compatibele producten van VHOHFWHUHQ Panasonic RSHQHQ %HVFKLNEDDU YRRU 0HGLDVSHOHU HQ QHWZHUNGLHQVWHQ 6XERQGHUGHHO %HVFKULMYLQJ Naar 3D geconverteerd 2D-beeld VXERQGHUGHHO 'UXN RS GH 'NQRS HQ VWHO LQ RS GH VWDQG >' '@... -
Page 40: Veelgestelde Vragen
Veelgestelde vragen Het weergavekanaal beweegt lichtjes en er komt een kletterend geluid wanneer er met een vinger op wordt gedrukt. (U LV HHQ EHHWMH UXLPWH URQG KHW SDQHHO RP VFKDGH 3UREHHU HHUVW KHW SUREOHHP RS WH ORVVHQ DDQ GH KDQG HUDDQ WH YRRUNRPHQ 'LW LV QRUPDDO YDQ GH YROJHQGH HHQYRXGLJH ULFKWOLMQHQ YRRUGDW X KXOS LQURHSW... -
Page 41: Onderhoud
Onderhoud Specificaties Verwijder eerst de stekker van het netsnoer uit het stopcontact. Modelnr. : 7;$6( 42 inch-model Beeldscherm, Behuizing, Standaard : 7;$6( 47 inch-model Regelmatig onderhoud: Afmetingen (B × H × D) 9HHJ GH EXLWHQNDQW YDQ KHW EHHOGVFKHUP GH EHKXL]LQJ RI GH VWDQGDDUG YRRU]LFKWLJ DI PHW HHQ ]DFKWH GRHN RP 42 inch-model YXLO RI YLQJHUDIGUXNNHQ WH YHUZLMGHUHQ... - Page 42 HDMI 1 / 2 / 3-ingang PAL 525/60 7<3( $DDQVOXLWLQJHQ 176&WDSHV DIVSHOHQ YLD VRPPLJH 3$/ YLGHRUHFRUGHUV 9&5 +'0, ' &RQWHQWW\SH +'0, ' &RQWHQWW\SH $XGLR 5HWXUQ &KDQQHO M.NTSC 'H WY RQGHUVWHXQW ³+'$9, &RQWURO ´IXQFWLRQDOLWHLW $IVSHOHQ YLD 0176&YLGHRUHFRUGHUV 9&5 Kaartsleuf NTSC (alleen AV-ingang) 6'NDDUWVOHXI î...
- Page 43 Materialen Hoofdeenheid / Lenzen +DUV *HEUXLN HHQ 'EULO YDQ 3DQDVRQLF GLH SDVVLHYH 'V\VWHHPWHFKQRORJLH RQGHUVWHXQW Opmerking 7RXFKSDGFRQWUROOHU JHEUXLNW GUDDGOR]H %OXHWRRWK WHFKQRORJLH 2QWZHUS HQ VSHFLILFDWLHV NXQQHQ ]RQGHU YRRUDIJDDQGH NHQQLVJHYLQJ ZRUGHQ JHZLM]LJG *HZLFKW HQ DIPHWLQJHQ ELM EHQDGHULQJ 5DDGSOHHJ GH SURGXFWILFKH YRRU LQIRUPDWLH RYHU KHW HQHUJLHYHUEUXLN GH VFKHUPUHVROXWLH HQ] 5DDGSOHHJ GH >H+(/3@ YRRU LQIRUPDWLH RYHU GH RSHQEURQVRIWZDUH 2QGHUVWHXQLQJ ! /LFHQWLH ...
- Page 44 Modelnummer Serienummer Nederlands TQB0E2400B Web Site: http://panasonic.net © Panasonic Corporation 2014 Gedrukt in de Tsjechische Republiek...
