9. TECHNICAL INFORMATION ..........15 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler –...
ENGLISH 1. SAFETY INFORMATION Before the installation and use of the appliance, careful- ly read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use cau- ses injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.
• Never try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket. • Do not store items on the cooking surfaces. • Do not use a steam cleaner to clean the appliance.
Page 5
ENGLISH • Make sure not to cause damage to the appliance from the power supply. This mains plug (if applicable) or to the to prevent an electrical shock. mains cable. Contact the Service or an WARNING! electrician to change a damaged Risk of fire or explosion.
• Make sure pots are centrally posi- • Clean the appliance with a moist soft tioned on the rings and do not stick cloth. Only use neutral detergents. Do out over edges of the cooking surface. not use abrasive products, abrasive cleaning pads, solvents or metal ob- •...
Page 7
ENGLISH 4.1 Ignition of the burner WARNING! Be very careful when you use open fire in kitchen environment. Manufacturer decline any re- sponsibility in case misuse of the flame Always light the burner before you put cookware. To light the burner: Burner cap Turn the control knob counterclock- Burner crown...
4.3 Using the wok stand When you install the grate of the Triple Crown burner afterwards, A wok stand lets you use a round-bot- align the hollow part of the grate tomed wok on the hob. You must only...
ENGLISH Do not put unstable or damaged pots WARNING! on the rings to prevent from spill and in- Liquids spilt during cooking can jury. cause the glass to break WARNING! Do not use a flame diffuser. 6. CARE AND CLEANING WARNING! Refer to the Safety chapters.
10 www.aeg.com 6.1 Cleaning of the spark plug 6.2 Periodic maintenance This feature is obtained through a ce- Periodically speak your local Service ramic ignition candle with a metal elec- Force Centre to check the conditions of trode. Keep these components well...
ENGLISH MOD. MOD. MOD. TYPE PROD.NO. 230V-50Hz PROD.NO. PROD.NO. 0049 SER.NO. IP20 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY MODEL MODEL Stick it on Guarantee Card and send Stick it on instruction booklet this part Stick it on Guarantee Card and keep this part 8.
Page 12
12 www.aeg.com Location The connection should be suitable for connecting to R 1/2 (1/2 BSP male The hob may be located in a kitchen, a thread). kitchen/diner or bed sitting room (with a When the final connection has been volume greater than 20 m³), but not in a made, it is essential that a thorough leak bathroom or shower room.
Page 13
ENGLISH 8.4 Adjustment of minimum Electrical Requirements level Permanent electrical installation must agree with the latest I.E.E. Regulations To adjust the minimum level of the burn- and local Electricity Board regulations. ers: For your own safety the installation must Light the burner. be done by a qualified electrician (e.g.
Page 14
14 www.aeg.com To replace the connection cable use only H05V2V2-F T90 or equivalent type. Make sure that the cable section is applicable to the voltage load and the working temperature. The yellow/green earth wire (B) must be approxi- mately 2 cm longer than the live and neutral wire (A).
ENGLISH cess in case a technical assistance inter- vention is necessary. 40 mm min 20 mm (max 150 mm) 60 mm Removable panel Space for connections Kitchen unit with oven The hob recess dimensions must obey the indication and the kitchen unit must be equipped with vents to let a continu- supplied seal ous supply of air.
Page 16
16 www.aeg.com TOTAL POWER: G20 (2H) 20 mbar = 10.5 kW G30 (3+) 28-30 mbar = 763 g/h G31 (3+) 37 mbar = 750 g/h Electric supply: 230 V ~ 50 Hz 3 core flexible cable with non rewireable plug fitted...
