9 RELAY COMMISSIONING

9.10 RELAY METERING

Set the relay to the same frequency than the AC source used and apply the following current and voltage values, checking
that the unit measures the values within an accuracy of 5%. The table shows the minimum and maximum values expected
for each applied value, in MIWII1000 models:
MAGNITUDE
Ia
VI
VII
VIII
The table shows the minimum and maximum values expected for each applied value, in MIWII2000 models:
MAGNITUDE
Ia
VI
Apply the rated current and a voltage value of apprx. 63 Vca with an arbitrary angle difference and check that the angle
measure is within an accuracy of 5%.
GEK-113308
MIN. VALUE MAX. MIN.
0.47 0.5 0.53 0.95
9.5 10 10.5 38
9.5 10 10.5 38
9.5 10 10.5 38
MIN. VALUE MAX. MIN.
0.47 0.5 0.53 0.95
9.5 10 10.5 38
MIWII Directional Power Protection System
9.10 RELAY METERING
9.10.1

CURRENT AND VOLTAGE METERING

VALUE MAX. MIN. VALUE
1 1.05 1.9 2
40 42 76 80
40 42 76 80
40 42 76 80
VALUE MAX. MIN. VALUE
1 1.05 1.9 2
40 42 76 80
MAX.
2.1
84
84
84
MAX.
2.1
84
9
9-11
