Summary of Contents for ZippyYum WTB4010
- Page 1 THERMOMETER gt-2021-3.png USER MANUAL iOS & Works with Android Models WTB4010, WTB4010-M Updated: May 14, 2021...
-
Page 2: Table Of Contents
TABLE OF CONTENTS About Support Features Laser Safety Installing the App Pairing Mounting LED Indicator Surface & Internal Temp Troubleshooting Accuracy Check Cleaning Reset Procedure Distance to Spot Technical Specs IPRating Warranty Certifications FCC Compliance IC Warning USER MANUAL... -
Page 3: About
Aninternalbatterychargedwith a standard USB-C connector powers the thermometer. All ZippyYum thermometers are compatiblewithbothiOSand Android phones and tablets. APPROVED USES All models are food-grade, but only model WTB4010-M is rated for taking a person’s forehead temperature scan. USER MANUAL... -
Page 4: Support
Support area from the main menu of any ZippyYum app. CONTACT US To reach our support team, please use the Help & Support area from the main menu of any ZippyYum app. You can also email us at support@zippyyum.com or live chat with us on our website. -
Page 5: Features
FEATURES Infrared sensor USB-C charging port Laser indicator K-type thermocouple probe jack LED indicator &resetbutton USER MANUAL... -
Page 6: Laser Safety
Never point the laser at another person. When using model WTB4010-M to take a person’s forehead temperature the app will automaticallydisablethelaser. Always keep thermometer out of the reach of children. - Page 7 SETUP...
-
Page 8: Installing The App
INSTALLING THE APP Your ZippyYum Thermometer must be paired with the GoTemp app on an iOS or Android device before being used. To install the app, tap below or visit: www.zippyyum.com/apps TAP TO INSTALL Once the GoTemp app is installed, log into the app using your login credentials.... -
Page 9: Pairing
PAIRING PRO TIP Your thermometer’s unique identifier,alsoknownasitsMAC address, is printed on the back of the device as shown below. You may need it during pairing. MAC address USER MANUAL... - Page 10 PAIRING Your ZippyYum Thermometer arrives powered OFF. Flip it on over and use a thin toollikeapapercliptoflip the recessed switch to the ON position. PRO TIP The power switch is recessed for a reason! The thermometer is meant tobeleftintheONpositionatall times.Itwillautomaticallygointo power-saving mode when not in use.
- Page 11 Available thermometers will show as “THERM_##” with ## being the last two digits of its MAC address. The LED indicator will blink once a thermometer is selected. The ZippyYum Thermometer will pairautomaticallyorpromptyou for a pairing code. If prompted, enter code ‘123456’...
-
Page 12: Mounting
MOUNTING The ZippyYum Thermometer attachestoanyphone,case,or tabletwithaflatbackusinga univeralmountingplate. Simply clean the area thoroughly (we recommend isopropyl alcohol), peel the adhesive backing,andsticktheplateon your device. Make sure the raised bar on the mountingplateishorizontal. USER MANUAL... - Page 13 MOUNTING Next, align the raised tabs on the mountingplatewiththenotches in the back of your ZippyYum Thermometer. Place the thermometer down onto themountingplateandslideitto thesideuntilitclicks. USER MANUAL...
-
Page 14: Led Indicator
LED INDICATOR The ZippyYum Thermometer has an LED indicator to show batteryinformationandpairing connectivitystatustoitsdevice. INDICATOR OFF Poweroff,sleep mode,ordeadbattery RED LED Batterycriticallylow, should be charged ORANGE LED B atterycharging, continuecharging GREEN LED B atterycharged, ready to use IF FLASHING Connected to device... - Page 15 TAKING TEMPS...
-
Page 16: Surface & Internal Temp
SURFACE & INTERNAL TEMP The infrared thermometer measures surface temperature. Make sure to mix items prior to taking an infrared temperature to get an accurate reading. When internal temperatures aremorecriticalforitemslike meat cooking on a grill, use the thermometer’s probe jack to take an internal probe temperature. -
Page 17: Troubleshooting
If taking infrared temperatures, verify proper steps are being taken to take internal temperatures by followingtheinstructionsonthe previous page. WhencontactingZippyYum supportbepreparedtoidentify why you beleive your thermometer isnotfunctioning(likeusing another thermometer to verify the temperature, etc.) USER... - Page 18 TROUBLESHOOTING Make sure food is not covered, the ZippyYum thermometer can’t measurethroughglassorplastic. Steam, dust, smoke, and vapor can obstruct Scancase’s sensors. Avoid high humidity environments withcondensationwhenusing infrared. Avoidmeasuringreflective surfaces (like aluminum wrapping) unlessamattesurfaceisontop (like a label). When a sudden change of...
- Page 19 SERVICE & CLEANING...
-
Page 20: Accuracy Check
The thermometer should read about 32.0°F or 0°C. If the temperature is more than 4°F or 2°C out-of-range, please contact ZippyYum support. USER MANUAL... - Page 21 COMPLETE ACCURACY CHECK For a more detailed accuracy check procedure for both hot and cold temperatures, please visit the ZippyYum knowledge base. You can access the knowledge base in the Help & Support area from the main menu of any ZippyYum app.
-
Page 22: Cleaning
CLEANING The ZippyYum Thermometer’s sensors should always be kept free of dirt, dust, moisture, smoke, and debris. WARNING! Do not submerge the thermometer or wash in a dishwasher. To clean the body of the thermometer, moisten a cloth with a water-based mild detergent and wipe the device. - Page 23 CLEANING A dirty infrared lens is the most common cause of inaccurate infrared temperatures. To clean the infrared lens, lightly moistenacottonswabwithwater and insert and swirl it in the lens opening to clean any debris. Repeatwithacleancottonswab untilitcomesoutclean.Finishwith adrycottonswabtodrythelens. USER MANUAL...
-
Page 24: Reset Procedure
RESET PROCEDURE To reset the thermometer, simply useyourfingertopressthereset buttonlocatedonthebottomarea of the front of the thermometer. The LED indicator is also the reset button. The thermometer will blink orange 5timestoconfirmthereset. LED indicator &resetbutton USER MANUAL... -
Page 25: Distance To Spot
DISTANCE TO SPOT Thefieldofview(distance- to-spot) is the area of where temperature is being measured via infrared. The distance you hold the thermometer away from the product determines the dimensions of this area. The further away from the product, the larger the area being measured. The laser helps indicate where the thermometer is measuring. - Page 26 TECHNICAL SPECS...
-
Page 27: Technical Specs
TECHNICAL SPECS Storage Temp 14°F to 113°F -10°C to 45°C OperatingTemp 50°F to 104°F 10°C to 40°C Humidity 10% to 90% Charging Current ≤100mA Charging Voltage Bluetooth Power 0 dBM Capacity 400 mAH Voltage 3.7V Standby Time 360 hours Measuring Time 16 hours Peak Wavelength 650 nm... - Page 28 TECHNICAL SPECS Temperature Unit °F and °C IR Measurement -94°F to 716°F Range -70°C to 380°C Probe -454°F to 2500°F Measurement -270°C to 1372°C Range Actual probe measurement may be limited by the range of the probe. Please refer to your probe’s documentation prior to use.
- Page 29 TECHNICAL SPECS IR Accuracy ±2°F or ±1°C at Room Temp when object is (77°F or 25°C) 32°F to 140°F ±4°F or ±2°C when object is <32°F or >140°F IR Emissivity 0.95 (preset, but adjustable) IR Measurement 1” to 12” Distance 2.5 cm to 30cm Distance-to-Spot 12:1...
-
Page 30: IpRating
IP RATING The ZippyYum thermometer is rated IP67 (maximum depth of 1 meter up to 30 minutes) under IEC standard 60529. Thisratingisforthethermometer only. Please refer to the owner’s manual for your iOS or Android device for itswaterproofrating. Completeprotectionisnot guaranteedunderallconditions. Read this guide for proper use of Scancase.Malfunctionsdueto... - Page 31 WARRANTY & LEGAL...
- Page 32 WARRANTY ZippyYum warrants the ZippyYum Thermometer,atthetimeofitssale by ZippyYum, is free of defects in material, workmanship, and component failures under normal and proper use for a period of one (1) year from date of delivery. This warranty applies worldwide. ZippyYum’sonlyobligationisto correct such defects by repair...
-
Page 33: Warranty
WARRANTY ... or failure to perform this warrantyobligation. ZippyYum’s liability on any claim fordamagesarisinginconnection with the manufacture, sale, installation,delivery,oruseof the ZippyYum Thermometer shall never exceed the purchase price of the product. The remedies provided herein are the exclusive remedies under this warranty, whether based on contract, tort, or otherwise. -
Page 34: Certifications
CERTIFICATIONS The ZippyYum thermometer conforms to the following standards: UL LISTED FOR UL2333 Infrared Thermometers - E1481655 UL EPH CLASSIFIED FOR ANSI/NSF 2 Food Service Equipment - SA44549 FCC CFR47 PART 15 SECTION 15.247:2014 FCC ID: GU6WTB4010 INDUSTRY CANADA RSS-247... -
Page 35: Fcc Compliance
FCC COMPLIANCE This device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS standard(s).Operationissubjecttothefollowingtwo conditions:(1)thisdevicemaynotcauseharmful interference, and (2) this device must accept any interference received, including interference that may causeundesiredoperation. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modificationsorchangetothisequipment.Such modificationsorchangecouldvoidtheuser’s... -
Page 36: Ic Warning
IC WARNING This device complies with Industry Canada license- exemptRSSstandard(s).Operationissubjecttothe followingtwoconditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operationofthedevice. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts delicence.L’exploitationestautoriséeauxdeux conditionssuivantes:...
