Page 1: Table Of Contents
WWW.MDETECTORS.COM GRIZZLY YM 203 Contents Operation and main technical parameters 1. Introduction in the metal detector operation 2. Main technical parameters 3. Seeker’s ethical code Preparation 1. Assembling of the metal detector 2. Battery charging 3. Usage of the headphones... -
Page 2: Operation And Main Technical Parameters
WWW.MDETECTORS.COM GRIZZLY YM 203 Operation and main technical of the metal detector for easier parameters: usage. 2. Main technical parameters: 1. Introduction in the metal - transmission frequency : 6.99KHz detector operation: - signal frequency: 437KHz - weight: 1.8кг. GRIZZLY... -
Page 3: Preparation
WWW.MDETECTORS.COM GRIZZLY YM 203 Do not seek in any military areas! a) Turn the locking nut of the Leave the ground and vegetation handle clockwise until it loosens. the way they were. Bury every hole you have dig! Use the metal detector only in safe... -
Page 4: Battery Charging
WWW.MDETECTORS.COM GRIZZLY YM 203 2. Charging the batteries: headphones also prolongs the life of the batteries and makes easier Your metal detector is supplied for you identifying the sound signal with built in batteries and does not you hear, for better detection. To need additional batteries. -
Page 5: Composition Of The Equipment And Introduction In The
WWW.MDETECTORS.COM GRIZZLY YM 203 COMPOSITION OF THE EQUIPMENT AND INTRODUCTION IN THE OPERATION BUTTONSS 1. Composition of the metal detector 1. Searching coil 2. Screw and nut for connecting the searching coil 3. Locking nut for adjusting the length of the handle. -
Page 6: Led Light Indicator
WWW.MDETECTORS.COM GRIZZLY YM 203 Control panel: Critical sound and on/off (TUNE) knob: The TUNE knob serves as on/off button and for adjusting the critical sound too. To turn the detector off, turn left the knob. Turn the knob left and you will hear a little click, which means that the detector is turned on. -
Page 7: Detection
WWW.MDETECTORS.COM GRIZZLY YM 203 coil to 10 – 15 cm over the ground When have level. Now pay attention to this: equipment to the ground, you can І. detector produces work with it. When you search hold sound signal as it gets closer to the... -
Page 8: Testing And Outdoor Usage
Do not near the searching coil 50 working hours with the detector to ovens or other hot objects. to get used to YM 203 GRIZZLY. Every metal detector has warranty that allows free repair until its time Log on http://www.mdetectors.com limit. -
Page 9: Specification
WWW.MDETECTORS.COM GRIZZLY YM 203 Specifications: • Transmission frequency: 6.99KHz • Signal frequency: 437KHz • Weight: 1.8кg. • Power supply – accumulating elements750мАh – 11бр.x 1.2V = 13.2V – built in the detector. • 1 charging device for the built in batteries •...
